Emerson Rosemount 248 User manual

Quick Start Guide
00825-0200-4248, Rev EC
April 2019
Rosemount™248 Wireless Temperature
Transmitter
00825-0200-4248_RevEC.fm Page 1 Wednesday, April 17, 2019 9:03 AM

April 2019
2
Quick Start Guide
Rosemount 248 Wireless Temperature
Transmitter
Rosemount 248 Wireless Hardware Revision
HART®Device Revision
Device Install Kit/Device Driver (DD) Revision
Device Type
1
1
Device Revision 01, DD Revision 01 or greater
2676
NOTICE
This guide provides basic guidelines for the Rosemount 248 Wireless. It does not provide instructions for
detailed configuration, diagnostics, maintenance, service, troubleshooting, or installations. Refer to the
Rosemount 248 Wireless Reference Manual for more instruction. The manual and this guide are also
available electronically on Emerson.com/Rosemount.
Failure to follow these installation guidelines could result in death or serious injury.
Make sure only qualified personnel perform the installation.
Explosions could result in death or serious injury.
Before connecting a Field Communicator in an explosive atmosphere, make sure the instruments are
installed in accordance with intrinsically safe or non-incendive field wiring practices.
Verify the operating atmosphere of the transmitter is consistent with the appropriate hazardous
locations certifications.
Process leaks could result in death or serious injury.
Do not remove the thermowell while in operation.
Install and tighten thermowells and sensors before applying pressure.
Electrical shock could cause death or serious injury.
Avoid contact with the leads and terminals. High voltage that may be present on leads can cause
electrical shock.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired
operations.
This device must be installed to ensure a minimum antenna separation distance of 20 cm from all
person.
The power module may be replaced in a hazardous area. The power module has surface resistivity
greater than one giga-ohm and must be properly installed in the wireless device enclosure. Care must be
taken during transportation to and from the point of installation to prevent electrostatic charge
build-up.
Contents
Wireless considerations. . . . . . . . . . . . . . . . . . . . 4
Physical installation . . . . . . . . . . . . . . . . . . . . . . . 5
Verify operation . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Reference Information. . . . . . . . . . . . . . . . . . . . 11
Power module replacement . . . . . . . . . . . . . . . 14
Product Certifications . . . . . . . . . . . . . . . . . . . . 16
00825-0200-4248_RevEC.fm Page 2 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
3
April 2019
NOTICE
Shipping considerations for wireless products (Lithium Batteries: Green Power Module, model
number 701PGNKF):
The unit was shipped to you without the Power Module installed. Remove the power module prior to
shipping the unit.
Each green power module contains one “D” size primary lithium-thionyl chloride battery. Primary lithium
batteries are regulated in transportation by the U. S. Department of Transportation, and are also covered by
IATA (International Air Transport Association), ICAO (International Civil Aviation Organization), and ARD
(European Ground Transportation of Dangerous Goods). It is the responsibility of the shipper to ensure
compliance with these or any other local requirements. Consult current regulations and requirements
before shipping.
Power module considerations (Green Power Module, model number 701PGNKF):
The green power module with the wireless unit contains one “D” size primary lithium-thionyl chloride
battery (model number 701PGNKF). Each battery contains approximately 5.0 grams of lithium. Under
normal conditions, the battery materials are self-contained and are not reactive as long as the batteries and
the pack integrity are maintained. Care should be taken to prevent thermal, electrical or mechanical
damage. Contacts should be protected to prevent premature discharge.
Battery hazards remain when cells are discharged.
Power modules should be stored in a clean and dry area. For maximum power module life, storage
temperature should not exceed 30 °C.
00825-0200-4248_RevEC.fm Page 3 Wednesday, April 17, 2019 9:03 AM

April 2019
4
Quick Start Guide
1.0 Wireless considerations
1.1 Power up sequence
The power module should not be installed on any wireless device until the
Gateway is installed and functioning properly. Wireless devices should also be
powered up in order of proximity from the Gateway, beginning with the closest.
This will result in a simpler and faster network installation. Enable Active
Advertising on the Gateway to ensure new devices join the network faster. For
more information, see the Gateway Reference Manual.
1.2 Antenna position
The internal antenna is designed for multiple mounting orientations. The
transmitter should be mounted according to best practices for your temperature
measurement application. The transmitter should be approximately 3 ft. (1 m)
from any large structure or building to allow clear communication to other
devices.
1.3 Field Communicator connections
The power module must be installed in the device for the Field Communicator to
interface with the Rosemount 248 Wireless. The Field Communicator
connections are located on the green power module. To communicate to the
transmitter, begin by removing the power module cover. This will expose the
HART communication terminals located on the green power module. Next,
connect the Field Communicator leads to the COMM port connections on the
green power module.
This transmitter uses the green power module; order model number 701PGNKF.
The power module is keyed and can only be inserted in one orientation. Field
communication with this device requires a HART-based Field Communicator.
Refer to Figure 1 for instructions on connecting the Field Communicator to the
Rosemount 248 Wireless.
Figure 1. Field Communicator Connection
00825-0200-4248_RevEC.fm Page 4 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
5
April 2019
2.0 Physical installation
The Rosemount 248 Wireless can be installed in one of two configurations: Direct
Mount, where the sensor is connected directly to the Rosemount 248 Wireless
conduit entry, or remote mount, where the sensor is mounted separately from
the 248 Wireless housing, then connected to the Rosemount 248 Wireless via
wiring or conduit. Select the installation sequence that corresponds to the
mounting configuration.
2.1 Direct mount
The direct mount installation should not be used when installing with a
Swagelok®fitting.
1. Remove the transmitter enclosure cover.
2. Remove the LCD display (if applicable).
3. Loosen the captive screws and Remove LCD display adapter plate (if
applicable).
Figure 2. Exploded View of LCD Display and Power Module Assembly
4. Attach the sensor to the Rosemount 248 Wireless housing using the threaded
conduit entry. Be sure to use an approved thread sealant on all connections.
5. Attach the sensor wiring to the terminals as indicated on Figure 7.
6. Reattach and secure LCD display adapter plate to 5 in-lb of torque (if
applicable).
7. Reattach the LCD display (if applicable).
8. Reattach and tighten the transmitter enclosure cover.
9. Remove the power module cover.
10. Connect the green power module.
Note
Wireless devices should be powered up in order of proximity from the Gateway, beginning
with the closest device to the Gateway. This will result in a simpler and faster network
installation.
11. Reattach and tighten the power module cover.
00825-0200-4248_RevEC.fm Page 5 Wednesday, April 17, 2019 9:03 AM

April 2019
6
Quick Start Guide
12. Always ensure a proper seal by installing the electronics housing cover(s) so
that polymer contacts polymer (i.e. no o-ring visible). Use Rosemount O-rings.
13. Provide 1.75-in. (45 mm) of clearance for units without an LCD display.
Provide 3-in. (76 mm) of clearance for units with an LCD display for cover
removal.
Figure 3. Direct Mount
Note
Wireless devices should be powered up in order of proximity from the Gateway, beginning
with the closest device to the Gateway. This will result in a simpler and faster network
installation.
2.2 Remote mount
1. Remove the transmitter enclosure cover.
2. Remove the LCD display (if applicable).
3. Loosen the captive screws and remove LCD display adapter plate (if
applicable). Refer to Figure 2.
4. Run wiring (and conduit, if necessary) from the sensor to the Rosemount 248
Wireless. Use an 1/2-in. NPT when mating conduit to the Rosemount 248
Wireless.
5. Pull the wiring through the threaded conduit entry of the Rosemount 248
Wireless.
6. Attach the sensor wiring to the terminals as indicated on Figure 7.
7. Reattach and secure LCD display adapter plate to 5 in-lb of torque (if
applicable).
8. Reattach the LCD display (if applicable).
9. Reattach and tighten the transmitter enclosure cover.
10. Remove the power module cover.
11. Connect the green power module.
00825-0200-4248_RevEC.fm Page 6 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
7
April 2019
12. Reattach and tighten the power module cover.
Note
Wireless devices should be powered up in order of proximity from the Gateway, beginning
with the closest device to the Gateway. This will result in a simpler and faster network
installation.
13. Always ensure a proper seal by installing the electronics housing cover(s) so
that polymer contacts polymer (i.e. no o-ring visible). Use Rosemount O-rings.
14. Provide 1.75-in. (45 mm) of clearance for units without an LCD display.
Provide 3-in. (76 mm) of clearance for units with an LCD display for cover
removal.
Figure 4. Remote Mount
Note
Wireless devices should be powered up in order of proximity from the Gateway, beginning
with the closest device to the Gateway. This will result in a simpler and faster network
installation.
00825-0200-4248_RevEC.fm Page 7 Wednesday, April 17, 2019 9:03 AM

April 2019
8
Quick Start Guide
3.0 Verify operation
Operations can be verified in four locations: at the device via the local display,
using the Field Communicator, at the Gateway's integrated web interface, or
using AMS™Suite Wireless Configurator or AMS Device Manager.
3.1 Local display
During normal operation, the LCD display will display the PV value at the
configured update rate.
For Device Status screens, see LCD screen messages on Rosemount 248 Wireless
Reference Manual.
3.2 Field Communicator
For HART Wireless transmitter communication, a Rosemount 248 Wireless DD is
required. To obtain the latest DD, visit the Emerson™Easy Upgrade site at:
Emerson.com/Rosemount/Device-Install-Kits
The communication status may be verified in the wireless device using the
following Fast Key sequence.
3.3 Gateway
In the integrated web interface from the Gateway, navigate to the Explorer>Status
page. This page shows whether the device has joined the network and if it is
communicating properly.
Note
It may take several minutes for the device to join the network.
Note
If the device joins the network and immediately has an alarm present, it is likely due to
sensor configuration. Check the sensor wiring (see Figure 7 on page 11) and the sensor
configuration (see Table 3 on page 12).
Table 1. Fast Key Sequence
Function Fast Key sequence Menu items
Communications 3, 4 Comm Status, Join Mode, Available Neighbors,
Advertisement, Join Attempts
00825-0200-4248_RevEC.fm Page 8 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
9
April 2019
Figure 5. Gateway Network Settings
3.4 AMS Wireless Configurator
When the device has joined the network, it will appear in the Wireless
Configurator window as illustrated in figure below. For HART Wireless transmitter
communication, a Rosemount 248 Wireless DD is required. To obtain the latest
DD, visit the Emerson Easy Upgrade site at:
Emerson.com/Rosemount/Device-Install-Kit
00825-0200-4248_RevEC.fm Page 9 Wednesday, April 17, 2019 9:03 AM

April 2019
10
Quick Start Guide
Figure 6. Rosemount 248 Wireless shown on AMS Wireless Configurator
3.5 Troubleshooting
If the device is not joining to the network, check to make sure that you have a
power supply in your device. If the device is not joined to the network after power
up, verify the correct configuration of the Network ID and Join Key, and verify that
Active Advertising has been enabled on the Gateway. The Network ID and Join
Key in the device must match the Network ID and Join Key of the Gateway.
The Network ID and Join Key may be obtained from the Gateway on the
Setup>Network>Settings page on the web server (see Figure 5 on page 9). The
Network ID and Join Key may be changed in the wireless device by using the
following Fast Key sequence.
Table 2. Fast Key Sequence
Function Fast Key sequence
Join to Network 2, 1, 1
00825-0200-4248_RevEC.fm Page 10 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
11
April 2019
4.0 Reference Information
Figure 7. Rosemount 248 Wireless Sensor Wiring Diagram
Note
Emerson provides 4-wire sensors for all single element RTDs. Use these RTDs in 3- or 2-wire
configurations by leaving the unneeded leads disconnected and insulated with electrical
tape.
Thermocouple and mV 4-Wire RTD and Ω
3-Wire RTD and Ω2-Wire RTD and Ω
Sensor connections diagram
1234123412341234
2-wire RTD and Ω3-wire RTD and Ω4-wire RTD and ΩT/C and mV
00825-0200-4248_RevEC.fm Page 11 Wednesday, April 17, 2019 9:03 AM

April 2019
12
Quick Start Guide
Note
Emerson provides 4-wire sensors for all single element RTDs. Use these RTDs in 3- or 2-wire
configurations by leaving the unneeded leads disconnected and insulated with electrical
tape.
Note
In order to communicate with a Field Communicator, the wireless device must be powered
by connecting the power module.
Figure 8. Rosemount 214C RTD Lead Wire Configuration per IEC 60751
Note
To configure a single element, 4-wire RTD as a 3-wire system, connect only one white lead.
Insulate or terminate the unused white lead in a manner that prevents shorting to the
ground.
To configure a single element, 4-wire RTD as a 2-wire system, connect matching colored
wires first and then connect the paired wires to the terminal.
Table 3. Rosemount 248 WirelessHART®Fast Key Sequences
Function Fast Key sequence Menu items
Device Information 1, 7 Identification, Revisions, Radio, Security
Guided Setup 2, 1 Join Device to Network, Configure Update Rate,
Configure Sensor, Calibrate Sensor
Manual Setup 2, 2 Wireless, Process Sensor, Percent of Range, Device
Temperatures, Device Information, Other
Wireless
Configuration 2, 2, 1 Network ID, Join to Network, Broadcast Info
Sensor Calibration 3, 5, 2
Sensor Value, Sensor Status, Current Lower Trim,
Current Upper Trim, Lower Sensor Trim, Upper Sensor
Trim, Recall Factory Trim
Single element, 3-wire Single element, 4-wire Dual element, 3-wire
Red
Red
White
White
Red
Red
White
Red
Red
White
Black
Black
Yellow
00825-0200-4248_RevEC.fm Page 12 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
13
April 2019
Figure 9. Rosemount 214C Thermocouple Lead Wire Configurations
Note
Dual thermocouple sensors are shipped with one pair of the wires shrink wrapped together.
Single thermocouple, 2-wire Dual thermocouple, 4-wire
IEC 60584 thermocouple colors ASTM E- 230 thermocouple colors
Type POS (+) NEG (-) POS (+) NEG (-)
JBlack White White Red
KGreen White Yellow Red
TBrown White Blue Red
( – )
( + ) ( + )
( + )
( – )
( – )
00825-0200-4248_RevEC.fm Page 13 Wednesday, April 17, 2019 9:03 AM

April 2019
14
Quick Start Guide
5.0 Power module replacement
Expected power module life is 10 years at reference conditions.(1)
When power module replacement is required, remove the cover and remove the
green power module. Replace the green power module (part number 701PGNKF)
and replace the cover. Tighten to specification and verify operation.
Figure 10. Exploded Power Module View
5.1 Handling considerations
The green power module with the wireless unit contains one “D” size primary
lithium-thionyl chloride battery (green power module, model number
701PGNKF). Each battery contains approximately 5.0 grams of lithium. Under
normal conditions, the battery materials are self-contained and are not reactive
as long as the batteries and the pack integrity are maintained. Care should be
taken to prevent thermal, electrical or mechanical damage.
Contacts should be protected to prevent premature discharge.
Power modules should be stored in a clean and dry area. For maximum power
module life, storage temperature should not exceed 30 °C.
Note
Continuous exposure to ambient temperature limits of –40 °F or 185 °F (–40 °C or 85 °C)
may reduce specified life by less than 20 percent.
Use caution when handling the power module, it may be damaged if dropped
from heights in excess of 20 feet.
Battery hazards remain when cells are discharged.
1. Reference conditions are 70 °F (21 °C), transmit rate of once per minute, and routing data for three additional
network devices.
00825-0200-4248_RevEC.fm Page 14 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
15
April 2019
5.2 Environmental considerations
As with any battery, local environmental rules and regulations should be
consulted for proper management of spent batteries. If no specific requirements
exist, recycling through a qualified recycler is encouraged. Consult the material’s
safety data sheet for battery specific information.
5.3 Shipping considerations
The unit was shipped to you without the power module installed. Remove the
power module prior to shipping the unit.
00825-0200-4248_RevEC.fm Page 15 Wednesday, April 17, 2019 9:03 AM

April 2019
16
Quick Start Guide
6.0 Product Certifications
Rev 1.6
6.1 European Directive Information
A copy of the EU Declaration of Conformity can be found at the end of the Quick Start Guide.
The most recent revision of the EU Declaration of Conformity can be found at
Emerson.com/Rosemount.
6.2 Ordinary Location Certification
As standard, the transmitter has been examined and tested to determine that the design
meets the basic electrical, mechanical, and fire protection requirements by a nationally
recognized test laboratory (NRTL) as accredited by the Federal Occupational Safety and
Health Administration (OSHA).
6.3 Telecommunication compliance
All wireless devices require certification to ensure that they adhere to regulations regarding
the use of the RF spectrum. Nearly every country requires this type of product certification.
Emerson is working with governmental agencies around the world to supply fully compliant
products and remove the risk of violating country directives or laws governing wireless
device usage.
6.4 FCC and IC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions: This device may not cause harmful interference. This device must accept any
interference received, including interference that may cause undesired operation. This
device must be installed to ensure a minimum antenna separation distance of 20 cm from all
persons.
6.5 Installing Equipment in North America
The US National Electrical Code®(NEC) and the Canadian Electrical Code (CEC) permit the
use of Division marked equipment in Zones and Zone marked equipment in Divisions. The
markings must be suitable for the area classification, gas, and temperature class. This
information is clearly defined in the respective codes.
USA
I5 USA Intrinsically Safe
Certificate: 70008071
Standards: FM 3600: 2011; FM 3610: 2010; FM 3611: 2004; UL 61010-1: 2012;
UL 50E: 2012; ANSI/IEC 60529:2004
Markings: Intrinsically Safe: CL I, DIV 1, GP A, B, C, D; CL I, DIV 2, GP A, B, C, D; Class I,
Zone 0, AEx ia IIC T4/T5 Ga; T4 (-50 °C ≤Ta≤+70 °C); T5 (-50 °C ≤Ta≤+40 °C);
when installed per Rosemount drawing 00249-2020; Type 4x, IP66/67
See Table 4 for entity parameters.
Special Condition for Safe Use (X):
1. Battery exchange: The battery module can be changed inside hazardous gas-explosive
locations. During battery change it must be assured that the connections are free from
dust or dirt.
00825-0200-4248_RevEC.fm Page 16 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
17
April 2019
Canada
I6 Canada Intrinsically Safe
Certificate: 70008071
Standards: CSA C22.2 No. 0-10; CSA C22.2 No. 94.2-07 (R2012); CSA C22.2 No.
213-M1987 (R2013); CAN/CSA-60079-0-11; CAN/CSA-60079-11-14;
CAN/CSA C22.2 No. 60529-05; CAN/CSA-C22.2 No. 61010-1-12
Markings: Intrinsically Safe: CL I, DIV 1, GP A, B, C, D; CL I, DIV 2, GP A, B, C, D; Ex ia IIC
T4/T5 Ga; T4 (-50 °C £ Ta £ +70 °C); T5 (-50 °C £ Ta £ +40 °C); when installed
per Rosemount drawing 00249-2020; Type 4X, IP66/67
See Table 4 for entity parameters.
Special Condition for Safe Use (X):
1. Battery exchange: The battery module can be changed inside hazardous gas-explosive
locations. During battery change it must be assured that the connections are free from
dust or dirt.
Europe
I1 ATEX Intrinsic Safety
Certificate: Baseefa14ATEX0359X
Standards: EN 60079-0: 2012; EN 60079-11: 2012
Markings: II 1 G Ex ia IIC T4/T5 Ga; T4 (-60 °C ≤Ta ≤+70 °C); T5 (-60 °C ≤Ta ≤+40 °C)
See Table 4 for entity parameters.
Special Condition for Safe Use (X):
1. The plastic enclosure may present a potential electrostatic ignition hazard and must not
be rubbed or cleaned with a dry cloth.
International
I7 IECEx Intrinsic Safety
Certificate: IECEx BAS 14.0158X
Standards: IEC 60079-0: 2011; IEC 60079-11: 2011
Markings: Ex ia IIC T4/T5 Ga; T4 (-60 °C ≤Ta ≤+70 °C); T5 (-60 °C ≤Ta ≤+40 °C)
See Table 4 for entity parameters.
Special Conditions for Safe Use (X):
1. The plastic enclosure may present a potential electrostatic ignition hazard and must not
be rubbed or cleaned with a dry cloth.
Brazil
I2 INMETRO Intrinsic Safety
Certificate: UL-BR 15.0222X
Standards: ABNT NBR IEC 60079-0: 2008 + Corrigendum 1:2011;
ABNT NBR IEC 60079-11: 2009
Markings: Ex ia IIC T4/T5 Ga; T4 (-60 °C ≤Ta ≤+70 °C); T5 (-60 °C ≤Ta ≤+40 °C)
See Table 4 for entity parameters.
Special Condition for Safe Use (X):
1. The plastic enclosure may present a potential electrostatic ignition hazard and must not
be rubbed or cleaned with a dry cloth.
00825-0200-4248_RevEC.fm Page 17 Wednesday, April 17, 2019 9:03 AM

April 2019
18
Quick Start Guide
China
I3 NEPSI Intrinsic Safety
Certificate: GYJ15.1143X
Standards: GB3836.1-2010, GB3836.4-2010, GB3836.20-2010
Markings: Ex ia IIC T4/T5 Ga; T4 (-60 °C ≤Ta≤+70 °C); T5 (-60 °C ≤Ta≤+40 °C)
See Table 4 for entity parameters.
Special Conditions for Safe Use (X):
1. Non-metallic parts incorporated in the enclosure of the product shall only be cleaned
with a damp cloth to avoid electrostatic charge.
2. Must use Rosemount Model 701PGNKF SmartPower Green Power Module provided by
the manufacture.
Japan
I4 TIIS Intrinsic Safety
Certificate: TC21031
Markings: Ex ia IIC T4 X (-20 °C ~+60 °C)
See Table 4 for entity parameters.
EAC
IM Technical Regulation Customs Union (EAC) Intrinsic Safety
Certificate: TC RU C-US.AA87.B.00057
Markings: 0Ex ia IIC T4,T5 Ga X, T5(-60 °C ≤Ta≤ +40 °C), T4(-60 °C ≤Ta≤ +70 °C);
IP66/IP67
Special Condition for Safe Use (X):
1. See certificate for special conditions.
Table 4. Entity Parameters
Voltage UO6.6 V
Current IO26.2 mA
Power PO42.6 mW
Capacitance CO11 μF
Inductance LO25 mH
00825-0200-4248_RevEC.fm Page 18 Wednesday, April 17, 2019 9:03 AM

Quick Start Guide
19
April 2019
Figure 11. Rosemount 248 Wireless Declaration of Conformity
EU Declaration of Conformity
No: RMD 1082 Rev. K
Page 1 of 3
We,
Rosemount, Inc.
8200 Market Boulevard
Chanhassen, MN 55317-9685
USA
declare under our sole responsibility that the product,
Rosemount™ 248 Wireless Temperature Transmitter
manufactured by,
Rosemount, Inc.
8200 Market Boulevard
Chanhassen, MN 55317-9685
USA
to which this declaration relates, is in conformity with the provisions of the European Union
Directives, including the latest amendments, as shown in the attached schedule.
Assumption of conformity is based on the application of the harmonized standards and, when
applicable or required, a European Union notified body certification, as shown in the attached
schedule.
(signature)
Vice President of Global Quality
(function)
Chris LaPoint
(name)
1-Feb-19
(date of issue)
00825-0200-4248_RevEC.fm Page 19 Wednesday, April 17, 2019 9:03 AM

April 2019
20
Quick Start Guide
EU Declaration of Conformity
No: RMD 1082 Rev. K
Page 2 of 3
EMC Directive (2014/30/EU)
Harmonized Standards:
EN 61326-1: 2013
EN 61326-2-3: 2013
Radio Equipment Directive (RED) (2014/53/EU)
Harmonized Standards:
EN 300 328 V2.1.1
EN 301 489-1 V2.2.0
EN 301 489-17 V3.2.0
EN 61010-1: 2010
EN 62479: 2010
ATEX Directive (2014/34/EU)
Rosemount 248 Wireless Temperature Transmitter (Polymer housing)
Baseefa14ATEX0359X – Intrinsic Safety Certificate
Equipment Group II, Category 1 G
Ex ia IIC T4/T5 Ga
Harmonized Standards:
EN60079-0: 2012+A11: 2013, EN60079-11: 2012
00825-0200-4248_RevEC.fm Page 20 Wednesday, April 17, 2019 9:03 AM
