EMPORIA SIMPLICITY LTE User manual

English
SIMPLICITY
LTE
Eveline Pupeter, emporia Telecom
www.emporia.eu
Thank you for purchasing an emporia product!
Please read this user guide before attempting to use your phone.

2
1
9
14
13
4 7
5 8
3 6
10
12
11
15
16 17
16
20
18 19
21
1Loudspeaker
2 Display (screen)
3 On/O key
4 Handset volume controls &
5 Keypad lock
Press this button for 2seconds to lock or unlock the keypad.
6 Torch button
7 Menu key
8 Alarm key
9 Green key
• Start or accept a call
• In the menu: Conrm selection
• On standby: Access Call history
10 Arrow keys
• Use these to ick through your Contacts and the Menu.
• When the phone is on standby, press to access Favourites.
• When the phone is on standby, press to access Contacts.
11 Red key
• When in a call: End
• When in the menu: One step back
• When entering digits or letters: Delete
12 Speed-dial keys
13 key (voicemail)
› YOUR MOBILE PHONE AT A GLANCE

14 key: Indicates the
charge status of the battery
byashing:
• Flashing red light:
Battery is out of charge
• Flashing green light:
Battery is loading
• On constantly:
Battery is fullycharged
15 key
• Flashes when there is
amissed call
• Stops ashing as soon as
your Call history has been
viewed
16 Port for USB charging
cable
17 Headset port (Attention:
This is not a charger port!)
18 Opening for removing
thebattery cover
19 Torch (LED)
20 Emergency button
(optional)
21 Battery cover
›Symbols on the screen
Network signal
strength
Roaming (abroad)
Battery indicator
Missed call
Call forwarding
New text message
(SMS)
Prole: Silent/Sleep
mode
Prole: Maximum
Prole: Meeting/
Theatre mode
Alarm on
Bluetooth activated
Bluetooth connected

ENGLISH-04
1. Setting up your phone 06
1.1 Inserting a SIM card .....06
1.2 Inserting the battery ....06
1.3 Charging the battery ....06
1.4 Turning on the phone . . . 08
1.5 Entering a PIN code .....08
1.6 Setting the language,
timeand date ...........08
1.7 Saving battery power ...08
2. Using the phone ......09
2.1 Home screen............09
2.2 Menu ...................09
2.3 Dual-function keys ......10
2.4 Writing text .............10
3. Calls ................. 12
3.1 Accepting, declining or
ending a call ............12
3.2 Calling someone . . . . . . . . 12
4. Messages (SMS)....... 13
4.1 Writing and sending a
message ................ 13
4.2 Reading a message...... 13
5. FM radio.............. 14
5.1 Searching for a station ..14
5.2 Adjusting the volume ...14
5.3 Station list ..............14
5.4 Manual input ...........14
5.5 Auto search .............14
6. Tools . . . . . . . . . . . . . . . . . 15
6.1 Alarm Clock ............. 15
6.2 Bluetooth ...............15
› CONTENTS

ENGLISH-05
7. Contac ts.............. 16
7.1 Searching for a contact in
the phone book.........16
7.2 Adding a contact........16
7.3 Editing contact..........16
7.4 Deleting a contact ......17
7.5 Sending contact via SMS 17
7.6 Copy contacts........... 17
7.7 My number .............17
7.8 Speed-dial keys ,
and .................. 17
7.9 Contact settings ........18
7.10 SMS's in Contacts .......18
7.11 Blocked numbers .......18
8. Call history ........... 19
9. Settings ..............20
9.1 Mobile network .........20
9.2 Silent/Sleep mode ......21
9.3 Sound and alerts ........21
9.4 Display and lights .......21
9.5 Keypad lock.............22
9.6 Favourite key............23
9.7 Voicemail number.......23
9.8 Security settings ........23
9.9 0000 to enter settings ...23
9.10 System updates .........24
9.11 Master reset.............24
10. Emporia emergency
callfunction .......... 25
11. Guarantee and service 28
12. Declaration of
conformity(DOC) ..... 31

ENGLISH-06
1. SETTING UP YOUR PHONE
1.1 Inserting a SIM card
1. Remove the battery cover (opening in the top left-hand
corner).
2. Insert the SIM card into the SIM card holder with
the gold contacts facing down.
1.2 Inserting the battery
1. Insert the battery, making sure that the battery contacts touch
the phone's gold contacts.
2. Place the battery cover over the battery and click it into place.
1.3 Charging the battery
Before you use the phone for the rst time, charge the battery for
at least four hours. If you don't charge the phone for this period of
time, the battery life could be reduced.

ENGLISH-07
Never connect the phone to the charger or a PC if a battery has
not been inserted. Do not attempt to operate the phone without a
battery inserted. Doing this can damage the phone.
›Charging with the charging cable
To avoid contact faults with the USB connector, only use
thecharging cable supplied with the phone for charging.
• Connect the USB cable to the mains plug.
• Plug the charging cable into the USB port on the phone.
• Then plug the mains plug into a wall socket.
›Using the charging cradle
• Connect the USB cable to the mains plug.
• Plug the charging cable into the USB port on the back of
thecharging cradle and then
• Place the phone in the charging cradle.
If you intend to use this method to charge your phone every time,
you can leave the charging cable plugged into the charging cradle
permanently.
›Using a computer
Plug the phone into a USB port on your computer.
If necessary, disconnect the USB cable from the mains plug
todo this.

ENGLISH-08
1.4 Turning on the phone
• Press and hold the key for at least 2 seconds until
theemporia logo appears. It will take a few seconds for
thehome screen to be displayed.
1.5 Entering a PIN code
Enter the four-digit PIN code for your SIM card when asked to
do so and conrm the entry.
You have a maximum of three attempts to enter the correct
number. If you enter the wrong number three times in a row, you
will only be able to unblock the SIM card with the PUK code. You
will nd your original PIN code and PUK code in the documents
supplied with your SIM card by your network operator.
1.6 Setting the language, timeand date
1. Use to select a Language and then conrm your selection by
pressing OK.
2. Set the Time and Date and then save these settings.
1.7 Saving battery power
After a few seconds of inactivity, the screen will turn o to
save battery power. In the event of an incoming call or you
pressing any key, the screen will light up again. If the keypad
is set to lock automatically, the phone will only respond if the
green button or the button (on the side of the phone) is
pressed.

ENGLISH-09
2. USING THE PHONE
2.1 Home screen
If your phone is on but not using a
function, it will display the home screen.
You can return to the home screen any
time by pressing the redkey several
times.
2.2 Menu
The keywill display the menu.
The menu is a list that enables you to
manage the phone's various functions
and adapt the phone to your needs.
• Use the arrow keys to scroll through the
menu.
• The items available in the menu list are Messages, FM Radio,
Tools, Contacts, Call history and Settings
• Use the green key and red key beneath the screen to
conrm your selection or to return to the home screen.
Call history
12:30
Su, 21.04
LT E
Messages
OK Back

ENGLISH-10
2.3 Dual-function keys
Pressing and holding the key:
Allows you to listen to your voicemail
Pressing the key twice: + for a country code,
such as +49 for Germany
Pressing and holding the key: Show Missed calls
Pressing and holding the Torch key:
Torch on continuously when the phone is on
2.4 Writing text
You enter text using the keypad in Manual mode or T9 mode
(software-supported suggested words).
›Use the key to switch between the input methods.
• abc: All letters in lower case
• ABC: All letters in upper case
• Abc: The rst letter is in upper case and all the letters
thatfollow are in lower case.
• 123: Digits
• sEn: T9 english for Abc
• sen: T9 english for abc
• sEN: T9 english for ABC

ENGLISH-11
›Inputting text in T9 mode
• Find the key bearing the letter you require and press it once
only. After a few entries, the software will start to detect word
patterns and suggest appropriate words, (e.g. 4 2 5 5 6 for
Hallo).
• Use the arrow keys and to move between
the suggested words.
• Press the green button to select your required word and
itwill be added to the message you're writing.
›Inputting text in manual mode
Press a number key multiple times
(e.g. 4 4 2 5 5 5 5 5 5 6 6 6 for Hallo).
• Special characters and symbols have been assigned to
thevarious keys, but can dier in some languages:
. , - ? ! 1 '@ : ; ( ) *  abc2äàåāâæçáć
 def3đéē€èêë  ghi4îïíìğι
j k l 5 £ m n o 6 ö ñ ô œ ó ò
 pqrs7ß$ş t u v 8 ü ù û ú
 wxyz9ŵýÿ Space 0
 ., ? ! ' " ()@ \ / : _;+- * = % &<>£ $ ¥ § €¤[ ] { } ~ #

ENGLISH-12
3. CALLS
3.1 Accepting, declining or ending a call
• To answer: Press the green key for Answer.
• To reject a call or to end a call: Press the red key.
• To mute the ringtone temporarily, press the volume
controlbutton.
If the screen has gone dark during the call,
press the red key twice.
3.2 Calling someone
›Dialling a number
1. Enter the phone number you want to dial (incl. the area code)
using the keypad.
2. Start the call by pressing the green key .
›Using the redial function
1. When on the home screen, press the green key .
Your Call history will be displayed.
2. Use the arrow keys and to select a number.
3. Start the call by pressing the green key .
To go hands-free during a call, open Options and turn on
thespeaker.

ENGLISH-13
4. MESSAGES SMS
›Menu items: Write message, Chats, SMS settings
4.1 Writing and sending a message
1. Open Menu _Messages.
2. Select Write message.
3. Enter the text using the keypad.
4. To specify a recipient for the SMS,
open Options and select Send.
5. You can now select a Contact from the phone book or
type in a Phone number using the keypad.
4.2 Reading a message
1. When you receive a new message,
a symbol will appear on the home screen.
2. Press the green key for View and
to read the message immediately.
3. You can nd the text message again later on
in Menu _Messages _Chats.
4. To read a message, tap on it.

ENGLISH-14
5. FM RADIO
›Menu items in Options: Channel list, Manual input, Auto
search, Loudspeaker and Exit
5.1 Searching for a station
You can set the station with the or key.
5.2 Adjusting the volume
You can adjust the volume of the radio with and
on the side of the phone.
You cannot change the volume if you are in an Options menu
item. In this case, close the Options menu rst.
5.3 Station list
This list will display all the radio stations that have already
been saved.
5.4 Manual input
If you know the frequency of the station you want,
you can enter it here directly.
Use this key for the decimal point.
5.5 Auto search
This function searches for all detectable stations and saves
them in the station list together with their frequencies.

ENGLISH-15
6. TOOLS
›Menu items: Alarm Clock, Birthday reminder, Calendar,
Calculator and Bluetooth
6.1 Alarm Clock
1. Open Set time.
2. Enter your desired Alarm time and then Save it.
3. The alarm clock is activated and will now go o at the time you
have set every day.
4. When the alarm is ringing, you can press the red key to turn
it o or the green key to activate the snooze function.
5. Select Off to deactivate the alarm permanently.
If the phone is turned o, the alarm is turned o as well.
The alarm will therefore not sound when the phone is o.
6.2 Bluetooth
1. Turn the Bluetooth function On.
2. Tap on Connect and on Search for new devices.
A list of available devices will be displayed.
3. Select the device you want to pair the phone with from the list.
4. Follow the instructions to pair the devices.
Devices that have been connected before will be recognised and
connected automatically.

ENGLISH-16
7. CONTACTS
›Menu items: Search for name, Add contact, Edit contact,
Delete, Send contact via SMS, Copy contacts, My number,
Speed-dial keys, Emergency contacts, Contact settings,
SMS's in Contacts and Blocked numbers
7.1 Searching for a contact in the phone book
1. When on the home screen, press the Phonebook key or
open Menu _Contacts _Search for name.
2. Use the arrow keys and to scroll through the entries or
use the keypad to type the rst letter of the contact you are
looking for.
3. Start the call by pressing the green key .
7.2 Adding a contact
1. Open Menu _Contacts _Add contact.
2. Enter the person's name and the phone number and
then Save them.
Always save names and numbers with the international dialling
code, e.g. +41 for Switzerland, +43 for Austria and +49 for Germany.
7.3 Editing contact
Edit the previously saved entries and save your changes.

ENGLISH-17
7.4 Deleting a contact
• Single: Select a contact you want todelete.
• Delete all: Specify whether you want to delete all the contacts
from the SIM card or from the phone.
7.5 Sending contact via SMS
1. Select the contact you want to send.
2. Enter the recipient's Number or Search
for their name in your contacts.
3. You'll then send an SMS that the contact receives as text in
theformat #Name#Number#.
7.6 Copy contacts
You can save one or all the contacts on your SIM card in
thephone's memory or vice versa.
7.7 My number
Save your own phone number so that you never forget it again.
7.8 Speed-dial keys , and
›Saving a speed-dial key
You can assign quick dial keys to numbers you call often.
1. Press one of the speed-dial keys , and .
2. Enter a Name and Number or Search for a contact in
thephone book.

ENGLISH-18
›Changing or deleting a speed-dial key
1. Open Menü _Contacts _Speed-dial keys.
2. Select a speed-dial key from the list.
3. Change or delete its link to a particular contact.
7.9 Contact settings
• Save entries on SIM or Phone
• Memory in use: SIM, Phone or both
• Automatically save in Contacts: On or Off
• Memory status: Up to 300 contacts can be saved on
theSIMcard and up to 500 contacts can be saved
on the phone.
7.10 SMS's in Contacts
If you receive a message that contains text in the format
#Name#Number#, the text will be saved in your contacts
automatically. Specify whether this function should be
switched on or o and whether only entries from saved
numbers are permitted in contacts.
7.11 Blocked numbers
Enter selected numbers you don't want to receive calls or
messages from. A maximum of 10 numbers can be blocked.

ENGLISH-19
8. CALL HISTORY
›Menu items: Missed calls, Dialled calls, Received calls,
Call duration and Delete
Each list is sorted chronologically and shows the date and
timeof each call beneath the contact's name or number.
Options: Call, Save in Contacts, Edit number before call,
Write message, and Delete
When on the home screen, you can access your Call history
containing all your calls by pressing the green key .
The symbols indicate the following:
• Missed calls 
• Dialled calls 
• Received calls 
• Call duration
Duration of the last call
Total duration of all outgoing calls
Total duration of all received calls
Total duration of all calls

ENGLISH-20
9. SETTINGS
›Menu items: Mobile network, Silent/Sleep mode,
Sound & alerts, Handset volume, Hands-free volume,
Display & light, Time & date, Language, Call waiting,
Call forwarding, Suppress number, Auto. Keylock,
Favourite key, Mailbox number, Emergency numbers,
Emergency button, Security settings, Contact settings,
0000 to enter settings, System updates, Reset
9.1 Mobile network
• Mobile data: on/o (preset to be on)
• Data roaming: on/o (preset to be o)
