Ems Firecellwdc User manual

Installation

Guide

Contents

Ordering information

Pre installation

Components

Equipment familiarisation

Insert batteries

Add to system - unprogrammed systems only

Assign device

Position template against door

Drill xing positions

Fix unit to door

Position oor plate

Mark oor plate xing positions

Drill oor plate xing positions

Fix oor plate to oor

Open re door & depress plunger

Post installation conguration

Test device

Troubleshooting

Device tone & ash indication

Specication

Regulatory information

8. Mark xing positions

10. Fix oorplate to oor

=6mm

9. Drill xing Positions

CHECK FOR

WATER

PIPES

ELECTRIC

CABLES

GAS

PIPES

1. Introduction

The following steps

are a quick reference

overviewonly.

Refer to the FireCell WDC

Installation Guide (MK241) for

fullinstallation details.

RESET LOGON

BACK

HEALTHY

FAULT

SYSFAULT

LOOP1

INOUTIN OUT

LOOP2

INOUTIN OUT

LOOP3

INOUTIN OUT

LOOP4

INOUTIN OUT

RF1 RF2

AddNew Device

3. Add to system

2. Insert batteries

OBSERVE

POLARITY!

Ensure ESD

protection label is

fitted when

installing WDC on

metal kick plates

or uneven surfaces

(inside cut out)

4. Positiontemplate

FITESD PROTECTION LABEL

IFFITTING TO A METALLIC SURFACE

5. Drill xing positions

=2.5mm

6. Fix unit to door

7. Position oor plate

11. Open door

12.Test device

Ordering information

Pre installation

Part no Product description

FC-60-2000 FireCell Wireless Door Control (Black)

FC-60-2010 FireCell Wireless Door Control (White)

Installation must conform to applicable local installation codes and

should only be installed by a fully trained competent person.

Ensure that the device is installed as per the site survey.

Ensure that the device is tted to the side of the door that shuts against the

door frame.

The supplied ESD protection label must be tted when installing the

Wireless Door Control (WDC) on metal kick plates or uneven surfaces.

DO NOT press the log on button on a pre-programmed device, as this will

cause communication with the control panel to be lost. Should this happen,

delete the device from the system and add it back on.

Before installing the device, ensure that the re door is suitable e.g. self

closing, has a at surface to x to and has appropriate clearance under the

door to accommodate the oor plate.

Any door closing devices used in conjunction with the WDC must conform to

EN 1154.

Components

FireCell

WDC

Small & large

oor plates

1 2 Fixing template

(MK255)

Fixings

ESD protection

label

Equipment familiarisation

Ferrule

Plunger

Battery

compartment

Log on button

Fixing position

Insert batteries

When tting / replacing batteries;

observe correct polarity, using only

specied batteries.

Indication LED

Note; upon rst power

up the device will

initiate a startup sequence,

denoted by a series of low

pitched beeps and motor

operations. This sequence will

take approximately 15 seconds

and concludes with three low

pitched beeps.

Should the sequence close with a

mix of high and low pitched

beeps, refer to page 13.

Free to download from

www.emsgroup.co.uk

Add to system - unprogrammed systems only

The device’s loop address is congured within the menu structure of the radio

hub. It is recommended to congure the device to the system prior to

installation.

Note; devices can alternatively be added to the system after installation. If this

method is to be taken, it is recommended to note the devices ident number at

this stage. Skip this section and refer to the ‘Post Installation Conguration’

section on page 10 for details on the device’s ident location.

Note; if programming the FireCell WDC to a Fusion Loop Module, refer to the

Fusion Loop Module Engineers Guide (TSD062) for programming details.

Skip this step If the device has been supplied as part of a

pre-programmed system, as this will cause communication with the

control panel to be lost. Should this happen, delete the device from

the system and add it back on.

To add devices by log on (pre installation);

From Front Display Add New Device Select Desired RCC 01 Set Loop 1

.Addr 003 Add By Log On Press Dev Log On ‘press the devices

log on button, followed by Add Dev 03456 Y? New Addr L1 A003.

To Exit

The device has now been added to the Radio Hub and should be installed in its

location. For further details, refer to the

programming manual (MK98) for full

programming information.

BACK

Note: the device can also be programmed utilising the control panel’s cause and

eects, as part of the buildings evacuation plan.

Assign device

RESET LOGON

BACK

HEALTHY

FA U LT

SYS FAULT

LOOP 1

IN OUT IN OUT

LOOP 2

IN OUT IN OUT

LOOP 3

IN OUT IN OUT

LOOP 4

IN OUT IN OUT

RF1 RF2

Assign Device

Newly added devices must now be assigned to the system.

From Unassigned Dev Assign Device Assign All Dev 000 of 001

changing to Done 001 of 001 (once complete)

To Exit

BACK

Position template against door

If the device is to be tted to a metal surface, e.g. a

metal kick plate, the ESD protection label must be

tted. Simply ax the label inside the xing template’s cut

out, on to the metal surface.

Note: the device must now also be added and

congured on the control panel. Refer to the FireCell

Programming Guide (MK98) for details.

Use all four xing positions.

Use supplied xing screws.

Fix unit to door

= 2.5mm

Drill xing positions

Drill all four xing positions.

Mark oor plate xing positions

Use small oor plate, if bumpstop

creates a trip hazard

Mark all four xing positions.

Position oor plate

Door

Bump

stop

Side view

Ferrule

Floor plate

Fix oor plate to oor

Use all four xing holes.

Use supplied xing screws.

Drill oor plate xing positions

Before drilling, check

locations of water pipes,

gas pipes & electrical cables

= 6 mm

Open re door & depress plunger

Open door against bump

stop and depress plunger -

check ferrule ts neatly into

recess

Post installation conguration

Skip this step if the device has already been congured to the

system

To add devices by ident (post installation);

From Front Display Add New Device Select Desired RCC 01 Set Loop 1

.Addr 003 Add By Ident Add Dev 01ABC Y? ’Enter the Device’s ident

.’Enter the device type Input Output Device New Addr L1 A003 .

To Exit

BACK

The device must now be assigned to the system. Refer to the ‘ Assign Devices’

section on page 6 for details.

Ensure the device’s ident number has

been noted. The device’s ident is located

at the top of the device as shown:

01ABC

Device top view

Test device

Troubleshooting

In the rare event of an issue with the device’s operation, refer to the points below:

Device not releasing upon a re alarm condition?

Check that the device is added correctly to the system and that it is fault free at

the FireCell radio hub.

Check that the door closes freely when closed manually.

Check that the plunger has a minimum of 10mm clearance between the ferrule

and the oor / oor plate.

Check that the WDC’s output properties are set correctly within the control panel

programming.

Why does the re door not close freely?

Check that the ferrule is not worn or damaged. Replace as necessary.

Check that the plunger has a minimum of 10mm clearance between the ferrule

and the oor / oor plate.

Device not holding the door in an open position

Check that the plunger is depressed fully.

Check that the device is added correctly to the system and fault free at the

FireCell radio hub.

Check that the device is positioned low enough for a good connection between

the ferrule and the oor plate. The optimum plunger movement is 10 - 15 mm.

Device in tamper fault?

Check that the device is xed correctly to the door.

Check that the surface is at and that the tamper switch is engaging correctly,

when the device is xed to the door.

Battery fault / device not powered?

Check the polarity and the voltage of the batteries.

Check that the battery cover is tted correctly.

Do NOT Press the log on button on a pre-programmed device, as this will cause

communication with the control panel to be lost. Should this happen, delete the

device from the system and add it back on.

Device tone and ash indication

In addition to fault reporting at the control panel, the FireCell WDC has various beep

and ash sequences to indicate a number of conditions.

Beep sequence

Low-Low-Low

High-High-Low

(repeated until

resolved)

High-High-High-

High-Low-Low-

Low-Low

None

Flash sequence

None

Red-Red (on rst

two beeps only)

Red-Red-Red-Red

(on rst four beeps

only)

Red-Green

Indicative meaning

Startup complete

Motor operation fail*

Battery pack 2 fail

(non-serviceable part)

Battery pack 1 low /

incorrectly inserted

(2x C batteries)

Action required

None

Remove and re-insert

batteries

Remove and re-insert

batteries (If fault persists,

return to manufacturer)

Replace / remove and

re-insert batteries

(as appropriate)

During device startup sequence / motor operation

Beep sequence

Low-Low-High

(repeated until the

plunger releases)

High-Low-Low-Low

(repeated until

resolved)

High-Low

(seven times, then

door releases)

Flash sequence

Red (on low beeps

only)

Red (on rst

sequence only)

Red (on rst beep

in sequence only)

Indicative meaning

Plunger fail

Battery pack 2 fail

(non-serviceable part)

Door is about to

close†

Action required

Check for obstructions to

the plunger

Remove and re-insert

batteries (If fault persists,

return to manufacturer)

Move away from the

doorway

During standard operation

* Additional notication will be reported at the control panel as an analogue value 4

fault - Tamper/ Input Fault (short or open circuit).

† Door closing can be as a result of many factors such as a fire condition, a loss of

communication or a battery critical condition. Refer to the control panel for details.

Operating temperature -10 °C to 55 °C

Storage temperature 5 °C to 30 °C

Humidity Up to 95% non-condensing

Supply 2x C Alkaline (Panasonic LR14AD Powerline /

Varta 4014 Industrial)

CAUTION!

Fitting of an incorrect battery type invalidates the product certication and may

result in poor performance.

Supply voltage 2.22 to 3.3 VDC

Current consumption 60 μA

Operating frequency 868 MHz

Output transmitter power Auto adjusting 0 - 14 dBm (0 - 25 mW)

Signalling protocol X2

Dimensions (W x H x D) 195 mm x 205 mm x 45 mm

Weight 0.5 kg

Location Type A: For indoor use

Max. hold open power size 7

Max. door leaf width 1600 mm

Max. test door mass 160 kg

Max. overload test drop weight 36 kg

Max. test door friction 0.8 Nm

Min. angle between door open 66 °

and closed positions

Note: FireCell WDC is not for use on metal doors.

Specication

Regulatory information

Manufacturer

Year of manufacture See devices serial number label

European Union directives

Approved to BS EN1155:1997. Incorporating Amendment No. 1 and

Corrigendum Nos. 1, 2 and 3.

BS 7273-4:2007. Code of practice for the operation of re

protection measures – Part 4: Actuation of release

mechanisms for doors. (Category B)

EN54-25:2008. Incorporating corrigenda September 2010

and March 2012. Fire detection and re alarm systems. Part

25: Components using radio links.

Certication

Certication body

CPR certicate DOP 0359-CPR-00648

EMS Ltd. Technology House, Herne Bay, Kent, CT6 8JZ,

United Kingdom

0359

EMS declares that the radio equipment type FireCell WDC is

in compliance with Directive 2014/53/EU. The full text of

the EU declaration of conformity is available at the

following internet address: www.emsgroup.co.uk

2012/19/EU (WEEE directive):

Products marked with this symbol cannot be disposed of

as unsorted municipal waste in the European Union. For

proper recycling, return this product to your local supplier

upon purchase of equivalent new equipment, or dispose of

it at designated collection points. For more information see

www.recyclethis.info

Dispose of your batteries in an environmentally friendly

manner according to your local regulations.

The information contained within this literature is correct at time of publishing. EMS reserves the right to change any information regarding products as part of its continual development

enhancing new technology and reliability. EMS advises that any product literature issue numbers are checked with its head oce prior to any formal specication being written.

enquiries@emsgroup.co.uk

www.emsgroup.co.uk

+44 (0) 1227 369570

Table of contents
