Two messages!
Two messages!Two messages!
Two messages!
Our Wearable Talker is so versatile; you can wear it on any part of your
body–your wrist, forearm, or leg – or place it on a wheelchair arm.
Features:
•20 seconds of recording time
•10 seconds per message
•2 messages
• Adjustable volume
• Two clear covers for switches
• Extra add-on strap
Size: 5½"L x 2¼"W x 1½"H. Requires 3 AAA Batteries. Weight: ¼ lb.
Operation:
Operation:Operation:
Operation:
1. The Wearable Talker requires 3 AAA batteries to operate (Not
included .There are two Phillips head screws one on each side of the
talker. Remove each screw to open the unit and reveal the battery
compartment. Lift the bottom cover off with the help of the wrist strap.
Observing polarity, install 3 AAA size batteries into the holder. Alkaline
batteries must be used (e.g. Duracell or Energizer brand . Do not use
rechargeable or heavy duty batteries or any other type of batteries
because they supply lower voltage and the unit will not perform
properly. Close the unit back up and replace screws.
2. The Wearable Talker can record two messages up to 10 seconds for
each. There is a separate Microphone and Record button for each
message button. To record your message, turn the Talker’s
ON/Off/Volume knob about midway. Next press and hold the Record
button for the corresponding message button then while holding the
record button press the message button and speak your message into
the Microphone. Speak between 6 to 8 inches away from the
Microphone for optimal recording. Repeat step for second message
button.
3. To play back your message, simply press the button you just recorded.
It is not necessary to continue holding the button when listening to the
message.
4. The unit will retain recorded information indefinitely, even if the
batteries are disconnected. Previously stored information will be
erased only when a new recording is performed.
5. Talker advances each time the two colored buttons are pressed. When
you come back around like a continuous loop you will hear the changed
message.
The Wearable Talker comes with an extra extension strap so you are able
to use it on your upper arms, legs etc.
Please Note:
Please Note:Please Note:
Please Note: If the Wearable Talker is not going to be used for a long
period of time, e.g. one month or longer, we recommend removing the
batteries during storage to prevent battery drain or leakage, which can
cause damage to the unit.
Troubleshooting:
Troubleshooting:Troubleshooting:
Troubleshooting:
Problem:
Problem:Problem:
Problem: The unit fails to operate, or operates incorrectly.
Action #1:
Action #1:Action #1:
Action #1: Disconnect the power by removing one of the batteries for 20
seconds in order to reset the unit. Re-install the batteries. If the unit does
not work correctly, replace all the batteries paying careful attention to
proper polarity.
Action #2
Action #2Action #2
Action #2:
::
: Make sure that you are holding both the record switch and the
message button simultaneously while you are recording.
Action #4:
Action #4:Action #4:
Action #4: Make sure that there is nothing covering the Microphone.
Problem:
Problem:Problem:
Problem: The unit is playing old messages fine, but will not record new
messages.
Action #1:
Action #1:Action #1:
Action #1: Check your batteries – There is a 99% chance that batteries
are weak or are non-Alkaline.
Care of the Unit:
Care of the Unit:Care of the Unit:
Care of the Unit:
The Wearable Talker can be wiped clean with any mild household multi-
purpose, non-abrasive cleaner and disinfectant. We recommend Simple
Green, which is a non toxic biodegradable all-purpose cleaner.
Do not use
Do not useDo not use
Do not use abrasive cleaners, as they will scratch the surface of the unit.
Do not submerge
Do not submergeDo not submerge
Do not submerge the unit, as it will damage the electrical components.
Rev
Rev Rev
Rev 5
55
5/26
/26/26
/26/17
/17/17
/17
