Endress+Hauser Fieldgate FXA720 User manual

BA 030S/04/en/02.04
Software Version1.x
Hardware Version 1.x
Firmware Version 1.x
Fieldgate
FXA 720
Operating Instructions
.
Hauser+Endress
The Power of Know How

.

Fieldgate FXA 720 Table of Contents
Endress+Hauser 1
Table of Contents
Revision Index . . . . . . . . . . . . . . . . . . 3
Trademarks . . . . . . . . . . . . . . . . . . . . 3
1Safety
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Installation, commissioning and operation . . . 5
1.3 Operational safety . . . . . . . . . . . . . . . . . . . . . . 5
1.4 Technical improvement . . . . . . . . . . . . . . . . . . 5
1.5 Declaration of conformity . . . . . . . . . . . . . . . . . 6
1.6 Writing conventions . . . . . . . . . . . . . . . . . . . . . 7
1.7 Drawing conventions . . . . . . . . . . . . . . . . . . . . 8
2 Identification . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Device designation . . . . . . . . . . . . . . . . . . . . . 9
2.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Licensing agreement . . . . . . . . . . . . . . . . . . . . 9
3 Function and System Design . . . . . . 10
3.1 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2.1 Connectors . . . . . . . . . . . . . . . . . . . . . 11
3.2.2 Display elements (LEDs) . . . . . . . . . . 11
3.3 System architecture . . . . . . . . . . . . . . . . . . . . 12
3.4 System requirements . . . . . . . . . . . . . . . . . . . 14
4 Hardware Installation . . . . . . . . . . . . 15
4.1 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2.1 Power supply . . . . . . . . . . . . . . . . . . . 16
4.2.2 Communication ports . . . . . . . . . . . . . .17
5 Getting Started . . . . . . . . . . . . . . . . . . . 18
5.1 Installing Fieldgate tool . . . . . . . . . . . . . . . . . 18
5.2 Making initial contact . . . . . . . . . . . . . . . . . . . 21
5.3 Changing the Fieldgate address . . . . . . . . . . 23
5.4 Configuring the Fieldgate communication driver
24
5.5 Configuring the Fieldgate Web server . . . . . . 27
5.6 Fieldgate product documentation . . . . . . . . 28
5.7 Adobe Acrobat Reader . . . . . . . . . . . . . . . . . 28
5.8 Modifying, repairing or removing the application
29
6 Dialling in via Modem . . . . . . . . . . . . 30
6.1 Analogue modem . . . . . . . . . . . . . . . . . . . . . 30
6.2 GSM, GPRS modems . . . . . . . . . . . . . . . . . . 30
7 Configuring the Web Server . . . . . . 31
7.1 Logging on . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7.1.1 Disconnecting . . . . . . . . . . . . . . . . . . . 31
7.2 User interface . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.2.1 Menu bar . . . . . . . . . . . . . . . . . . . . . . . 32
7.2.2 Navigation bar . . . . . . . . . . . . . . . . . . . 33
7.2.3 Configuration & Information pages . . . 34
7.3 PROFIBUS setup . . . . . . . . . . . . . . . . . . . . . . 35
7.3.1 Communication settings . . . . . . . . . . . 35
7.3.2 Scan settings . . . . . . . . . . . . . . . . . . . . 36
7.3.3 Live list . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.4 Overview of selected devices . . . . . . . . . . . . . 37
7.5 Security setup . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.6 Network setup . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.6.1 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . 39
7.6.2 Analogue modem . . . . . . . . . . . . . . . . 40
7.6.3 GSM and GPRS modems . . . . . . . . . . 40
7.7 Fieldgate location page . . . . . . . . . . . . . . . . . 41
7.8 Java Applets setup . . . . . . . . . . . . . . . . . . . . . 42
8 Viewing Information (User Mode) 43
8.1 Logging on . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
8.2 Live list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8.3 Overview of selected devices . . . . . . . . . . . . . 45
8.4 Fieldgate information . . . . . . . . . . . . . . . . . . . 46
8.5 XML export . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.6 Other view functions . . . . . . . . . . . . . . . . . . . . 48
8.6.1 Refresh function . . . . . . . . . . . . . . . . . . 48
8.6.2 Endress+Hauser function . . . . . . . . . . 48
9FirmwareUpdate. . . . . . . . . . . . . . . . . 49
10 Trouble-Shooting . . . . . . . . . . . . . . . . . 50
10.1 Problems and remedies. . . . . . . . . . . . . . . . . . 50
10.2 FAQs - Frequently Asked Questions . . . . . . . . 50
11 Accessories . . . . . . . . . . . . . . . . . . . . . . . 51
11.1 E+H power supply units . . . . . . . . . . . . . . . . . 51
12 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . 52
12.1 Changing the Internet address
(Windows 2000) . . . . . . . . . . . . . . . . . . . . . . . 52
12.2 Changing the Internet address (Windows NT) 54
12.3 Troubleshooting on no connection . . . . . . . . . 55
12.4 XML data elements . . . . . . . . . . . . . . . . . . . . . 56
13 Technical Data . . . . . . . . . . . . . . . . . . . 57
Index . . . . . . . . . . . . . . . . . . . . . . . . . 60

Fieldgate FXA 720
2Endress+Hauser
List of Figures
Generic system architecture for web-based visualisation
and remote monitoring applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Typical example of a PROFIBUS DP control network . . . . . . . . . . . . . . . . . . . . . . . . 13
Fieldgate home page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Navigation bar in User mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Navigation bar in Administration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Fieldgate Configuration page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Fieldgate Information page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
PROFIBUS Setup page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Scan setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Live list page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Device selection from the live list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Overview of Selected Devices, Administration mode . . . . . . . . . . . . . . . . . . . . . . . . 37
Security Setup page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Network Setup page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Fieldgate Location page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Java Applet Setup view page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Fieldgate home page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Live List view page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Overview of Selected Devices view page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Fieldgate Information view page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
XML Export page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Sevice Setup page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
List of Tables
Pin assignment COM RS-232 port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Pin assignment of RS-485 PROFIBUS DP ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Fieldgate user roles and rights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Functions available in User mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Functions available in Administration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
PROFIBUS communication parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Scan setup parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Significance of Security Setup parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Parameters in Live List view page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Parameters in Oveview of Selected Devices view page . . . . . . . . . . . . . . . . . . . . . . 45
Service Setup parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Fieldgate FXA 720
Endress+Hauser 3
Revision History
Registered Trademarks
PROFIBUS®
Registered trademark of the PROFIBUS User Organisation, Karlsruhe Germany.
Microsoft® , Windows® , Windows NT® , Windows 2000®,Windows XP® and the
Microsoft logo are registered trademarks of the Microsoft Corporation.
All other brand and product names are trademarks or registered trademarks of the
companies and organisations in question
aÉëáÖå~íáçå `Ü~åÖÉë oÉã~êâë
BA030S/04/en/06.03 Original manual

Fieldgate FXA 720
4Endress+Hauser

Fieldgate FXA 720 1 Safety
Endress+Hauser 5
1 Safety
1.1 Designated use
Fieldgate FXA 720 is a PROFIBUS/Ethernet Gateway with integrated web server that
can be used:
• as a PROFIBUS DP/Ethernet gateway within a PROFIBUS monitoring and control
system
• as a remote data acquisition module for PROFIBUS devices connected to its
PROFIBUS DP channels.
More information on these applications is to be found in the manual, or visit the Fieldgate
web page at www.products.endress.com/fieldgate.
1.2 Installation, commissioning and operation
Fieldgate FXA 720 must be installed, connected, operated and maintained according
to the instructions in this manual: personnel must be authorised and suitably qualified.
t~êåáåÖ>
• You require a unique IP address to set up Fieldgate. The use of IP addresses is
strictly controlled. Usually your system administrator will be authorised to allocate
unique addresses for your Fieldgates. Assigning an unauthorised address to a
Fieldgate may result in conflicts within your system and the failure of the associated
devices!
1.3 Operational safety
The unit must not be used in explosion hazardous areas. The permissible ambient
conditions given in the technical data must be complied with.
oÉé~áê Do not open the housing of the Fieldgate FXA 720. It does not contain any parts that
need to be maintained or repaired by the user. In the event of a fault or defect, return
the unit to the vendor. Opening the unit will void the warranty!
1.4 Technical improvement
Endress+Hauser reserves the right to make technical improvements to its hardware and
software at any time and without prior notification. Where such improvements have no
effect on the operation of the equipment, they are not documented. If the improvements
effect operation, a new version of the operating instructions is normally issued, see
Revision History.

1 Safety Fieldgate FXA 720
6Endress+Hauser
1.5 Declaration of conformity
`b=kçíáÅÉ Fieldgate FXA 720 complies with the requirements of the EC Directives 89/336/EEC
"Electromagnetic Compatibility" (EMC directive).
• Emission: EN 50022:1998 Class A (ITE Product Standard)
EN 50011:1998 Group 1 Class A (ISM Product Standard)
• Immunity: EN 61000-4-5:1999 Generic Immunity Standard
EN 61000-4-3: 1996 RF Electromagnetic Fields
A Declaration of Conformity in compliance with the above standards has been made
and can be inspected at Endress+Hauser Process Solutions AG on request.
kçêíÜ=^ãÉêáÅ~ Fieldgate FXA 720 conforms with the following North American Electromagnetic
Compatibility standards:
• UL 508: Industrial Control Equipment
• CSA C22.2 # 14.795: Industrial Control Equipment
kçíÉ>=
·For compliance with the legal EMC requirements, the other components (AC adapter,
PROFIBUS stations, etc.) must also meet these requirements.
·To meet the EMC conditions, the device must be installed and connected in
accordance with the Installation Instructions.
t~êåáåÖ>
·This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
c`` This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in
a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.

Fieldgate FXA 720 1 Safety
Endress+Hauser 7
1.6 Writing conventions
The following writing conventions and symbols have been used to provide the user with
a better overview of the contents of this manual and to highlight important information:
qÉñí=ÉãéÜ~ëáë The following table provides you with a brief overview of the methods used to
emphasise text in this manual.
p~ÑÉíó=ÅçåîÉåíáçåë Safety relevant information is highlighted by an icon in the margin plus the note, caution
or warning text.
.
qÉñí=ÉãéÜ~ëáë= cìåÅíáçå= bñ~ãéäÉ=
"_çäÇ=áå=áåîÉêíÉÇ=
Åçãã~ë="
Keys, buttons, program icons, tabs,
menus, commands
"pí~êí==>mêçÖê~ãë=
=>båÇêÉëëHe~ìëÉê" or "båíÉê="
Select "mêáåí=" in the "cáäÉ=" menu.
With the CTRL key (CONTROL key) held
down, press the SHIFT key.
Keep the "`qoi=âÉó=" pressed and
press the "pefcq=âÉó".
With the CTRL key (CONTROL key) held
down, click the left mouse button.
Keep the "`qoi=âÉó=" pressed and
left-click the mouse.
CAPS Details on paths and file names in the text DOKUFMR2XX.PDF or WIN.HLP
Angle brackets Variables <CD-ROM drive>
fÅçå jÉ~åáåÖ
kçíÉ>
A note highlights actions or procedures which, if not performed correctly, may indirectly affect
operation or may lead to an instrument response which is not planned
`~ìíáçå>
Caution highlights actions or procedures which, if not performed correctly, may lead to
personal injury or incorrect functioning of the instrument
t~êåáåÖ>
A warning highlights actions or procedures which, if not performed correctly, will lead to
personal injury, a safety hazard or destruction of the instrument

1 Safety Fieldgate FXA 720
8Endress+Hauser
1.7 Drawing conventions
The following symbols may be found within technical drawings.
bñéäçëáçå=éêçíÉÅíáçå .
bäÉÅíêáÅ~ä=ëóãÄçäë .
fÅçå jÉ~åáåÖ
aÉîáÅÉ=ÅÉêíáÑáÉÇ=Ñçê=ìëÉ=áå=Éñéäçëáçå=Ü~ò~êÇçìë=~êÉ~
If the device has this symbol embossed on its name plate it can be installed in an explosion
hazardous area in accordance with the specifications in the certificate or in a safe area
bñéäçëáçå=Ü~ò~êÇçìë=~êÉ~
Symbol used in drawings to indicate explosion hazardous areas. Devices located in and
wiring entering areas with the designation “explosion hazardous areas” must conform with the
stated type of protection
p~ÑÉ=~êÉ~=EåçåJÉñéäçëáçå=Ü~ò~êÇçìë=~êÉ~F
Symbol used in drawings to indicate, if necessary, non-explosion hazardous areas. Devices
located in safe areas stiill require a certificate if their outputs run into explosion hazardous
areas.
fÅçå jÉ~åáåÖ
aáêÉÅí=îçäí~ÖÉ
A terminal to which or from which a direct current or voltage may be applied or supplied
^äíÉêå~íáåÖ=îçäí~ÖÉ
A terminal to which or from which an alternating (sine-wave) current or voltage may be
applied or supplied
dêçìåÇÉÇ=íÉêãáå~ä
A grounded terminal, which as far as the operator is concerned, is already grounded by
means of an earth grounding system
mêçíÉÅíáîÉ=ÖêçìåÇáåÖ=EÉ~êíÜF=íÉêãáå~ä
A terminal which must be connected to earth ground prior to making any other connection to
the equipment
bèìáéçíÉåíá~ä=ÅçååÉÅíáçå=EÉ~êíÜ=ÄçåÇáåÖF
A connection made to the plant grounding system which may be of type e.g. neutral star or
equipotential line according to national or company practice

Fieldgate FXA 720 2 Identification
Endress+Hauser 9
2 Identification
2.1 Device designation
The device designation is to be found on the nameplate affixed to the righthand side of
the module. The device type can be derived from the product code as follows:
2.2 Scope of delivery
The scope of delivery comprises the following parts:
• Fieldgate FXA 720 gateway
• 24V female plug connector
• Profibus drivers and installation manual (on CD-ROM)
• "Getting Started" manual (printed document)
• If appropriate, additional software licences including documentation
Please check whether the delivery is complete and free of defects before starting
installation.
2.3 Licensing agreement
The software required for start-up and commissioning is freely available or is subject to
the licensing conditions of its manufacturer. Installation of the software on your computer
implies that you accept the terms of the corresponding licensing agreement.
.
oççí aÉëÅêáéíáçå
FXA 720-
1
2
3
9
kçK=çÑ=`Ü~ååÉäë
1x PROFIBUS port
2x PROFIBUS ports
3x PROFIBUS ports
Special version
E
Y
mçïÉê=pìééäó
24 VDC (+/- 20%)
Special version
1
2
9
jçÇÉã=fåíÉêÑ~ÅÉ
Ethernet 100Base-Tx/10Base-T
Analog Modem (in preparation)
Special version
A
Y
a^q=jçÇìäÉ
Without DAT module
Special version

3 Function and System Design Fieldgate FXA 720
10 Endress+Hauser
3 Function and System Design
3.1 Function
Fieldgate FXA 720 connects host systems to PROFIBUS DP networks via Ethernet or
modem. It can be equipped with up to three RS-485 ports, each giving access to up to
126 PROFIBUS DP devices.
Fieldgate is designed for Windows and web-based applications such as Information &
Configuration, monitoring, and visualisation. Process data can be monitored, e.g. by
Java Applets or Microsoft Office applications. Fieldgate can also be integrated into
system applications via OPC, DTM or XML, eg.:
• OPC for exchanging data with applications such as SCADA/HMI OPC clients, e.g.
P View SPV 100
• DTM for exchanging data with FDT frame applications, e.g. FieldCare
• XML for exchanging data with Microsoft Office applications or simple visualisation
applications such as Java Applets for Fieldgate SPV 60

Fieldgate FXA 720 3 Function and System Design
Endress+Hauser 11
3.2 Design
A schematic of the front panel of the Fieldgate FXA 720 is shown in Fig. 3.1 below.
Fig. 3-1: Front panel of the Fieldgate FXA 720
3.2.1 Connectors
3.2.2 Display elements (LEDs)
mçïÉê=ëìééäó • 24 VDC: a female plug connector is supplied with the device.
`çããìåáÅ~íáçå=éçêíë • Ethernet 10Base-T/100Base-TX connection
• Depending on type, up to three RS-485 ports for PROFIBUS DP
• COM service port (not relevant to normal operation
mto Green LED indicating the power supply status:
• On: internal power supply is ensured.
• Off: the supply voltage (24 V) is missing or the internal voltage generation is defective.
In this case, the unit needs to be returned to the manufacturer for repair..
bqe Green Ethernet LED:
• On: proper communication (link connection to a hub/switch/NIC) via Ethernet is
possible. It goes out temporarily during transmission and blinks when Browser clients
are connected to the Fieldgate
ork Available for application-specific purposes and is off by default.
c^fi Available for application-specific purposes and is off by default.
amNI=amOI=amP Green LEDs that are the token LEDs of the PROFIBUS Master. The corresponding LED
lights as soon as the master has received the token (communication authorization).
• DPx LEDs will normally not light when the device is used as a pass-through gateway
and the scan service for the corresponding channel is set to off.
• DPx LEDs will normally light when a channel has been scanned by the web-server
within the Fieldgate such as in remote monitoring applications via web.
• DPx LEDs may also light up if the bus has not been connected or is defective.

3 Function and System Design Fieldgate FXA 720
12 Endress+Hauser
3.3 System architecture
tÉÄJÄ~ëÉÇ=~ééäáÅ~íáçåë Fig. 3.1 shows the generic architecture for web-based applications. The devices to be
monitored or configured are connected to the Fieldgate FXA 720 via max. 3 RS-485
ports, to which PROFIBUS DP devices can be connected directly. PROFIBUS PA
devices are connected to the DP segment via a segment coupler or link.
The remote connection is made either by:
• Ethernet port/Internet
• Ethernet port/Remote wireless LAN access points
• Ethernet port/modem
The following applications may be running on the monitoring station:
• Via XML/CSV format: Microsoft Office applications (on-line/off-line data acquisition
and display)
• Via XML: Java Applets (on-line data acquisition and visualisation)
• Via OPC: SCADA/HMI OPC clients, e.g. P View (data acquisition and visualisation
with trends and historian)
• Via DTMs: FDT frame applications such as FieldCare (asset management,
Information & Configuration) or other Information & Configuration tool
• Any other OPC client, FDT-based or XML/HTML application.
kçíÉ>=
·Depending upon application or architecture requirements, each channel can be
connected to an independent PROFIBUS DP network or used to access the same
network.
Fig. 3-2: Generic system architecture for web-based visualisation and remote monitoring applications

Fieldgate FXA 720 3 Function and System Design
Endress+Hauser 13
kÉíïçêâ=~ééäáÅ~íáçåë When used as a Ethernet/PROFIBUS gateway, Fieldgate FXA 720 will normally provide
the connection between host applications running on Ethernet and PROFIBUS devices
connected to a PROFIBUS DP or PROFIBUS PA network. Fig. 3.3 shows a typical
example.
Examples of applications running on Ethernet are:
• Via OPC: SCADA/HMI OPC clients, e.g. P View
• Via DTM: Asset management tools based on FDT frames, e.g. FieldCare
• Information & Configuration tools, e.g. FieldCare, Commuwin II or ToF Tool
• Via XML/CSV format: Microsoft Office and e-Commerce applications
• Any other OPC client, FDT-based or XML/HTML application.
kçíÉ>=
·When Fieldgate is used in connection with the Commuwin II or ToF Tool Information &
Configuration tool, the single port version or Port 1 of the dual or three-port version
must be used.
Fig. 3-3:Typical example of a PROFIBUS DP control network

3 Function and System Design Fieldgate FXA 720
14 Endress+Hauser
3.4 System requirements
oÉãçíÉ=ãçåáíçêáåÖ=îá~=
ïÉÄ=ÄêçïëÉê
oÉãçíÉ=fåÑçêã~íáçå=C=
`çåÑáÖìê~íáçå=ïáíÜ=
molcf_rp=`äáÉåí
p`^a^=~åÇ=îáëì~äáë~íáçå
léÉê~íáåÖ=ëóëíÉã= pÉêîáÅÉ=m~Åâ=L=ÉñíÉåëáçåë=
táåÇçïë=kq=QKññ= SP 6a or higher
táåÇçïë=OMMM= SP 1 or higher
táåÇçïë=um= Professional
tÉÄ=ÄêçïëÉê= pÉêîáÅÉ=m~Åâ=L=ÉñíÉåëáçåë=
jp=fåíÉêåÉí=bñéäçêÉê= > 5.0 with current security updates
kÉíëÅ~éÉ=k~îáÖ~íçê= > 4.7 with current security updates
léÉê~= > 6.0 with current security updates
jçòáää~= ³1.0 with current security updates
léÉê~íáåÖ=ëóëíÉã= pÉêîáÅÉ=m~Åâ=L=ÉñíÉåëáçåë=
táåÇçïë=kq=QKññ= SP 6a or higher
táåÇçïë=OMMM= SP 1 or higher
táåÇçïë=um= Professional
^ÇÇJçå= sÉêëáçå= cìåÅíáçå=
`çããìïáå=ff ³2.08-1 Commuwin II is the general tool for device Information &
Configuration for all smart Endress+Hauser field devices.
m=sáÉï ³1.0 P View is Endress+Hauser’s SCADA tool
cáÉäÇ`~êÉ ³1.0 FieldCare is Endress+Hauser’s FDT-based Plant Asset
Management tool which can be used to configure all devices
qçc=qççä ³3.10 Service and operating program for time-of-flight level transmitters
léÉê~íáåÖ=ëóëíÉã= pÉêîáÅÉ=m~Åâ=L=ÉñíÉåëáçåë=
táåÇçïë=kq=QKññ= SP 6a or higher
táåÇçïë=OMMM= SP 1 or higher
táåÇçïë=um= Professional
^ÇÇJçå= sÉêëáçå= cìåÅíáçå=
m=sáÉï ³1.0 P View is Endress+Hauser’s SCADA tool
g~î~=^ééäÉíë ³1.0 Java Applets for Fieldgate SPV 60 is a simple web viewer for
device process values (does not support Windows NT)

Fieldgate FXA 720 4 Hardware Installation
Endress+Hauser 15
4 Hardware Installation
4.1 Mounting
Fieldgate is intended for mounting on TS35 DIN carrier rails (EN 50022) installed in a
control cabinet.
The device is convection-cooled. It therefore needs to be installed in such a way that
the ventilating ducts are at the top and bottom of the unit.
Please ensure a ventilation space of at least 30 mm above and below the device.

4 Hardware Installation Fieldgate FXA 720
16 Endress+Hauser
4.2 Wiring
4.2.1 Power supply
The Fieldgate FXA 720 is powered by 24 V DC. The power supply female plug
connector is included in the delivery. The power supply male socket connector on the
front panel is labeled 24VDC (see Fig. 4.1).
The two power supply terminals are labeled L+ and L–.
• Connect L+ to +24 VDC and connect L– to 0 VDC.
The two terminals are provided with an internal reverse-polarity protection.
dêçìåÇáåÖ Proper grounding is prerequisite for compliance with the EMC directives and for
ensuring a proper operation.
• The functional ground terminal is labeled and must be connected to the
protective ground.
• For use in an environment that is highly subject to electromagnetic interference, an
additional ground connection can be provided at the grounding screw below the
"ETH" connector.
The power supply is connected to the plug connector via flexible wires with a cross-
section of 0.75 to 1.5 mm². The ground connection wire must have a cross-section of
1.5 mm².
cìëÉ The Fieldgate FXA 720 has an internal safety fuse which blows if an overvoltage occurs
in the power supply (of approx. 30V or higher) or if a fault occurs in the device. The
safety fuse can be replaced by the device manufacturer only.
kçíÉ>=
·The start-up current of the Fieldgate FXA 720 may be up to 3A. The power supply must
provide this starting current in compliance with the voltage range to ensure a safe
startup.

Fieldgate FXA 720 4 Hardware Installation
Endress+Hauser 17
4.2.2 Communication ports
bíÜÉêåÉí The Ethernet port is labeled "ETH" and has been implemented as a 10Mbit/s or
100 Mbit/s (10Base-T/100Base-TX) connection with automatic baudrate recognition.
The connection is made using a RJ45 connector and a twisted pair category 5 cable.
• Use a crossover cable if Fieldgate is to be connected directly to a Ethernet NIC card
in the personal computer
• Use a straight through cable if the connection is to be made via a hub or switch
`lj The COM port is a RS-232C serial interface and for Service use only. The connection is
made using a 9-pin male D-sub connector with the following pin assignment:
Table 4-1: Pin assignment COM RS-232 port
molcf_rp= Fieldgate FXA 720 may be equipped with up to three PROFIBUS DP channels (RS-485)
labeled "PROFIBUS 1", "PROFIBUS 2" and "PROFIBUS 3". Each channel is electrically
isolated up to a voltage of 500V DC. The connecting element is a 9-pin female D-sub
connector with the following pin assignment:
Table 4-2: Pin assignment of RS-485 PROFIBUS DP ports
kçíÉ>=
·Please observe the installation guidelines for PROFIBUS devices, which are available
from the PROFIBUS Trade Organization, at www.profibus.com or in Endress+Hasuer
Operating Instructions BA034S/04/en.
máå=@ páÖå~ä aÉëÅêáéíáçå
1 Reserved Do not connect
2 RXD Receive Data
3 TXD Transmit Data
4 Reserved Do not connect
5 GND Signal Ground
6 Reserved Do not connect
7 Reserved Do not connect
8 Reserved Do not connect
9 Reserved Do not connect
máå=@ páÖå~ä aÉëÅêáéíáçå
1SHIELD Housing
2 NC Not assigned
3 RxD/TxD-P PROFIBUS signal B/B’
4/RTS RTS
5 GND Ground
6 VCC Bus-termination power supply (load 10mA max.)
7 NC Not assigned
8 RxD/TxD-N PROFIBUS signal A/A’
9 NC Not assigned

5 Getting Started Fieldgate FXA 720
18 Endress+Hauser
5 Getting Started
Before you start the installation:
• Check that you have administrator rights for your computer.
• Check that you have a unique IP address for each Fieldgate to be installed.
t~êåáåÖ>
• The use of IP addresses is strictly controlled. Usually your system administrator will
be authorised to allocate unique addresses for your Fieldgates. Assigning an
unauthorised address to a Fieldgate may result in conflicts within your system and
the failure of the associated devices!
5.1 Installing Fieldgate tool
mêçÅÉÇìêÉ 1. Place the Fieldgate CD-ROM in your CD-ROM drive, the Setup menu appears just
after the CD has been inserted.
2. First check if your computer fulfils the minimum requirements as described below,
see also Section 3.4..
3. Then it is advisable to carefully read the ?oÉäÉ~ëÉ=kçíÉë? before starting the
installation.
