Brief Operating Instructions
Cerabar S PMP71
with MID Part Certificate
Process pressure measurement
These Instructions are Brief Operating Instructions; they are not
a substitute for the Operating Instructions pertaining to the
device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
– Internet: www.endress.com/deviceviewer
– Smart phone/tablet: Endress+Hauser Operations App

Cerabar S 4 to 20 mA HART
2Endress+Hauser
A0023555
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.

Cerabar S 4 to 20 mA HART Table of contents
Endress+Hauser 3
Table of contents
1 Document information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Document function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Symbols used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Registered trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4 Terms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.5 Turn down calculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Basic safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1 Requirements concerning the staff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3 Workplace safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.5 Hazardous area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.6 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.7 Functional Safety SIL3 (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
3.1 Product identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Device designation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.4 Certificates and approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
4.1 Incoming acceptance, transport and storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2 Installation conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.3 General installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4 Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.5 Post-installation check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
5.1 Connecting the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Connecting the measuring unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.3 Potential equalization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.4 Post-connection check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
6.1 Onsite display (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.2 Operating elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.3 Onsite operation –
onsite display not connected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.4 Onsite operation –
onsite display connected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.5 HistoROM®/M-DAT (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.6 Operation via HART handheld terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.7 Endress+Hauser operating program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.8 Locking/unlocking operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.9 Factory setting (reset) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7 Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
7.1 Configuring messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.3 Selecting language and measuring mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.4 Position adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.5 Pressure measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.6 Lead sealing plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Document information Cerabar S 4 to 20 mA HART
4Endress+Hauser
1 Document information
1.1 Document function
These Operating Instructions contain all the information that is required in various phases of
the life cycle of the device: from product identification, incoming acceptance and storage, to
mounting, connection, operation and commissioning through to troubleshooting, maintenance
and disposal.
1.2 Symbols used
1.2.1 Safety symbols
1.2.2 Electrical symbols
Symbol Meaning
A0011189-DE
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
seriousor fatal injury.
A0011190-DE
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
seriousor fatal injury.
A0011191-DE
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minoror medium injury.
A0011192-DE
NOTICE!
This symbol contains information on procedures and other facts which do not result in
personalinjury.
Symbol Meaning Symbol Meaning
Direct current Alternating current
Direct current and alternating current Ground connection
A grounded terminal which, as far as
the operator is concerned, is grounded
via a grounding system.
Protective ground connection
A terminal which must be connected to
ground prior to establishing any other
connections.
Equipotential connection
A connection that has to be connected
to the plant grounding system: This may
be a potential equalization line or a star
grounding system depending on
national or company codes of practice.
DANGER
WARNING
CAUTION
NOTICE
)

Cerabar S 4 to 20 mA HART Document information
Endress+Hauser 5
1.2.3 Tool symbols
1.2.4 Symbols for certain types of information
Symbol Meaning
A0011221
Allen key
A0011222
Hexagon wrench
Symbol Meaning
A0011182
Permitted
Indicates procedures, processes or actions that are permitted.
A0011184
Forbidden
Indicates procedures, processes or actions that are forbidden.
A0011193
Tip
Indicates additional information.
A0028658
Reference to documentation
A0028659
Reference to page
A0028660
Reference to graphic
A0031595
Series of steps
A0018343
Result of a sequence of actions
A0028673
Visual inspection
A
,… ,
1. 2. 3.

Document information Cerabar S 4 to 20 mA HART
6Endress+Hauser
1.2.5 Symbols in graphics
1.2.6 Symbols at the device
1.3 Registered trademarks
KALREZ, VITON, TEFLON
Registered trademarks of E.I. Du Pont de Nemours & Co., Wilmington, USA
TRI-CLAMP
Registered trademark of Ladish & Co., Inc., Kenosha, USA
HART
Registered trademark of the HART Communication Foundation, Austin, USA.
GORE-TEX®
Registered trademarks of W.L. Gore & Associates, Inc., USA
Symbol Meaning
1, 2, 3, 4, ... Item numbers
A0031595
Series of steps
A, B, C, D, ... Views
Symbol Meaning
A0019159
Safety instructions
Observe the safety instructions contained in the associated Operating Instructions.
,… ,
1. 2. 3.

Cerabar S 4 to 20 mA HART Document information
Endress+Hauser 7
1.4 Terms and abbreviations
A0029505
URL OPLMWP
LRL
0
p
LRV URV
1
2
3
4
Position Term/Abbreviation Explanation
1 OPL The OPL (over pressure limit = sensor overload limit) for the sensors depends
on the lowest-rated element, with regard to pressure, of the selected
components, i.e. the process connection must be taken into consideration in
addition to the measuring cell. Also observe pressure-temperature dependency.
For the relevant standards and additional notes, see technical information.
The OPL may be applied for a limited time period.
2 MWP The MWP (maximum working pressure) for the sensors depends on the
lowest-rated element, with regard to pressure, of the selected components, i.e.
the process connection has to be taken into consideration in addition to the
measuring cell. Also observe pressure-temperature dependency. For the
relevant standards and additional notes, see technical information.
The MWP may be applied for an unlimited time.
3 Maximum sensor
measuring range
Range between LRL and URL
This span is the maximum calibratable/adjustable measuring span.

Document information Cerabar S 4 to 20 mA HART
8Endress+Hauser
1.5 Turn down calculation
A0029545
Fig. 1:
1 Calibrated/Adjusted measuring span
2Zero-basedspan
3 Upper range limit
4 Calibrated/Adjusted
measuring span
Range between LRV and URV
Factory setting: 0...URL
Other calibrated spans can be ordered with customised settings.
p- Pressure
- LRL Lower range limit
- URL Upper range limit
- LRV Lower range value
-URV Upperrangevalue
-TD Turndown
Position Term/Abbreviation Explanation
LRV URLURV LRL
1 = 2 3
Example
• Sensor: 10 bar (150 psi)
• Upper range limit (URL) = 10 bar (150 psi)
Turn down (TD):
• Calibrated/Adjusted measuring span: 0...5 bar
(0...75 psi)
• Lower range value (LRV) = 0 bar
• Upper range value (URV) = 5 bar (75 psi)
TD = URL
|URV - LRV|
TD = 10 bar (150 psi) =2
|5 bar (75 psi) - 0 bar (0 psi)|
In this example, the TD is thus 2:1.
This span is based on the zero point.

Cerabar S 4 to 20 mA HART Basic safety instructions
Endress+Hauser 9
2 Basic safety instructions
2.1 Requirements concerning the staff
The personnel for installation, commissioning, diagnostics and maintenance must fulfill the
following requirements:
• Trained, qualified specialists: must have a relevant qualification for this specific function and
task
• Are authorized by the plant owner/operator
• Are familiar with federal/national regulations
• Before beginning work, the specialist staff must have read and understood the instructions in
the Operating Instructions and supplementary documentation as well as in the certificates
(depending on the application)
• Following instructions and basic conditions
The operating personnel must fulfill the following requirements:
• Being instructed and authorized according to the requirements of the task by the facility's
owner-operator
• Following the instructions in these Operating Instructions
2.2 Designated use
The Cerabar S is a pressure transmitter for measuring pressure.
2.2.1 Incorrect use
The manufacturer is not liable for damage caused by improper or non-designated use.
Verification for borderline cases:
For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in
verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or
liability.
2.3 Workplace safety
For work on and with the device:
• Wear the required personal protective equipment according to federal/national regulations.
• Switch off the supply voltage before connecting the device.
2.4 Operational safety
Risk of injury!
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable

Identification Cerabar S 4 to 20 mA HART
10 Endress+Hauser
dangers:
‣If, despite this, modifications are required, consult with Endress+Hauser.
Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to repair of an electrical device.
‣Use original spare parts and accessories from Endress+Hauser only.
2.5 Hazardous area
To eliminate a danger for persons or for the facility when the device is used in the hazardous
area (e.g. explosion protection, pressure vessel safety):
• Based on the nameplate, check whether the ordered device is permitted for the intended use
in the hazardous area.
• Observe the specifications in the separate supplementary documentation that is an integral
part of these Instructions.
2.6 Product safety
This measuring device is designed in accordance with good engineering practice to meet
state-of-the- art safety requirements, has been tested, and left the factory in a condition in
which they are safe to operate. It fulfills general safety requirements and legal requirements. It
also conforms to the EC directives listed in the device-specific EC declaration of conformity.
Endress+Hauser confirms this fact by applying the CE mark.
2.7 Functional Safety SIL3 (optional)
If using devices for applications with safety integrity, the Functional Safety Manual must be
observed thoroughly.
3 Identification
3.1 Product identification
The following options are available for identification of the measuring device:
• Nameplate specifications
• Order code with breakdown of the device features on the delivery note
• Enter serial numbers from nameplates in W@M Device Viewer
(www.endress.com/deviceviewer): All information about the measuring device is displayed.
For an overview of the technical documentation provided, enter the serial number from the
nameplates in the W@M Device Viewer (www.endress.com/deviceviewer).

Cerabar S 4 to 20 mA HART Identification
Endress+Hauser 11
3.2 Device designation
3.2.1 Nameplates
• The MWP (maximum working pressure) is specified on the nameplate. This value refers to a
reference temperature of +20 °C (68°F) and may be applied to the device for an unlimited
time. Observe temperature dependency of the MWP. The pressure values permitted at higher
temperatures can be found in the standards EN 1092-1: 2001 Tab. 18 (With regard to their
stability-temperature property, the materials 1.4435 and 1.4404 are grouped together under
13EO in EN 1092-1 Tab. 18. The chemical composition of the two materials can be identical.),
ASME B 16.5a – 1998 Tab. 2-2.2 F316, ASME B 16.5a – 1998 Tab. 2.3.8 N10276, JIS B
2220.
• The test pressure corresponds to the over pressure limit (OPL) of the device = MWP x 1.5 1).
• The Pressure Equipment Directive (2014/68/EU) uses the abbreviation "PS".
The abbreviation "PS" corresponds to the MWP (maximum working pressure) of the
measuring device.
3.2.2 Identifying the sensor type
See parameter "Sensor Meas.Type" in Operating Instructions BA00413P.
3.3 Scope of delivery
The scope of delivery comprises:
• Cerabar S pressure transmitter
• For devices with the "HistoROM/M-DAT" option:
CD-ROM with Endress+Hauser operating program
• Optional accessories
Documentation supplied:
• Operating Instructions BA00412P and BA00413P are available via the Internet.
See: www.endress.com Download.
• Brief Operating Instructions KA01095P
• Fold-out flyer KA00298P
• Final inspection report
• Also Safety Instructions with ATEX, IECEx and NEPSI devices
• Optional: factory calibration certificate, inspection certificates
1) The equation does not apply for PMP71 and PMP75 with a 40 bar (600 psi) or a 100 bar (1500 psi) measuring cell.

Installation Cerabar S 4 to 20 mA HART
12 Endress+Hauser
3.4 Certificates and approvals
CE mark, Declaration of Conformity
The device is designed to meet state-of-the-art safety requirements, has been tested and left the
factory in a condition in which it is safe to operate. The device complies with the applicable
standards and regulations as listed in the EC Declaration of Conformity and thus complies with
the statutory requirements of the EC Directives. Endress+Hauser confirms the successful testing
of the device by affixing to it the CE mark.
4 Installation
4.1 Incoming acceptance, transport and storage
4.1.1 Incoming acceptance
• Check the packaging and the contents for damage.
• Check the shipment, make sure nothing is missing and that the scope of supply matches your
order.
4.1.2 Transport
WARNING
!
Incorrect transportation
Housing, diaphragm and capillaries may become damaged, and there is a risk of injury!
‣Transport the measuring device to the measuring point in its original packaging or by the
process connection (with secure transport protection for the diaphragm).
‣Follow the safety instructions and transport conditions for devices weighing more than 18
kg (39.6 lbs).
‣Do not use capillaries as a carrying aid for the diaphragm seals.
4.1.3 Storage
The device must be stored in a dry, clean place and protected against damage from impact
(EN 837-2).
Storage temperature range:
See Technical Information TI00383P.
4.2 Installation conditions
4.2.1 Dimensions
For dimensions, please refer to the "Mechanical construction" section in TI00383P.

Cerabar S 4 to 20 mA HART Installation
Endress+Hauser 13
4.3 General installation instructions
• Devices with a G 1 1/2 thread:
When screwing the device into the tank, the flat seal has to be positioned on the sealing
surface
of the process connection. To avoid additional strain on the process isolating diaphragm, the
thread should never be sealed with hemp or similar materials.
• Devices with NPT threads:
– Wrap Teflon tape around the thread to seal it.
– Tighten the device at the hexagonal bolt only. Do not turn at the housing.
– Do not overtighten the thread when screwing. Max. torque: 20 to 30 Nm (14.75 to 22.13
lbf ft)
• For the following process connections a tightening torque of max. 40 Nm (29.50 lbf ft)
is required:
– Thread ISO228 G1/2 (Order option "1A" or "1B")
– Thread DIN13 M20 x 1.5 (Order option "1N" or "1P")
4.3.1 Mounting sensor modules with PVDF thread
WARNING
!
Risk of damage to process connection!
Risk of injury!
‣Sensor modules with PVDF thread must be installed with the mounting bracket provided!
WARNING
!
Material fatigue from pressure and temperature!
Risk of injury if parts burst! The thread can become loose if exposed to high pressure and
temperatures.
‣The integrity of the thread must be checked regularly and the thread may need to be
re-tightened with the maximum tightening torque of 7 Nm (5.16 lbf ft). Teflon tape is
recommended for sealing the ½" NPT thread.
4.4 Installation instructions
• Due to the orientation of the Cerabar S, there may be a shift in the zero point, i.e. when the
container is empty or partially full, the measured value does not display zero. You can correct
this zero point shift either directly at the device using the "E" key or by remote operation. See
ä27, "Function of the operating elements – onsite display not connected" or
ä34, "Position adjustment".
• To ensure optimal readability of the onsite display, it is possible to rotate the housing up to
380°. ä16, "Rotating the housing".
• Endress+Hauser offers a mounting bracket for installing on pipes or walls.
ä16, "Wall and pipe mounting (optional)".

Installation Cerabar S 4 to 20 mA HART
14 Endress+Hauser
4.4.1 Installation instructions
NOTICE
Damage to the device!
If a heated Cerabar S is cooled during the cleaning process (e.g. by cold water), a vacuum
develops for a short time, whereby moisture can penetrate the sensor through the pressure
compensation (1).
‣If this is the case, mount the Cerabar S with the pressure compensation (1) pointing
downwards.
• Keep the pressure compensation and GORE-TEX®filter (1) free from contamination and
water.
• Cerabar S devices are mounted as per the norms for a manometer (DIN EN 837-2). We
recommend the use of shutoff devices and siphons. The orientation depends on the
measuring application.
• Do not clean or touch process isolating diaphragms with hard or pointed objects.
• To comply with ASME-BPE requirements regarding cleanability (Part SD Cleanability), the
device must be installed as follows:
1
1
1
FIELD TERMINALS
FIELD TERMINALS
FIELD TERMINALSFIELD TERMINALS
FIELDTERMINALS
FIELD TERMINALS
FIELDTERMINALS
FIELD TERMINALS
FIELDTERMINALS
FIELD TERMINALS

Cerabar S 4 to 20 mA HART Installation
Endress+Hauser 15
Pressure measurement in gases
Mount Cerabar S with shutoff device above the tapping point so that
any condensate can flow into the process.
Pressure measurement in steam
• Use siphons for pressure measurement in steam. The siphon reduces the temperature to
almost ambient temperature. Preferably mount the Cerabar S with the siphon below the
tapping point.
Advantages:
– defined water column only causes minimal/negligible measured errors
– only minimal/negligible thermal effects on the device
Mounting above the tapping point is also possible. Pay attention to the maximum permitted
ambient temperature of the transmitter!
• Fill the siphon with liquid before commissioning.
Pressure measurement in liquids
Mount Cerabar S with shutoff device below or at the same level as the tapping point.
4.4.2 Seal for flange mounting
NOTICE
Corrupted measurement results.
The seal is not allowed to press against the process isolating diaphragm as this could affect the
measurement result.
‣Ensure that the seal is not touching the process isolating diaphragm.
A0017743
Fig. 2:
1 Process isolating diaphragm
2Seal
12

Installation Cerabar S 4 to 20 mA HART
16 Endress+Hauser
4.4.3 Wall and pipe mounting (optional)
See operating instructions.
4.4.4 Rotating the housing
The housing can be rotated up to 380° by loosening the Allen screw.
A0019996
1. T14 housing: Loosen setscrew with a 2 mm (0.08 in) Allen key.
T15 andT17 housing: Loosen setscrew with a 3 mm (0.12 in) Allen key.
2. Rotate housing (max. up to 380 °).
3. Retighten setscrew with 1 Nm (0,74 lbf ft.
4.4.5 Closing the housing cover
NOTICE
Devices with EPDM cover seal - transmitter leakiness!
Mineral-based, animal-based or vegetable-based lubricants cause the EPDM cover seal to swell
and the transmitter to become leaky.
‣The thread is coated at the factory and therefore does not require any lubrication.
NOTICE
The housing cover can no longer be closed.
Damaged thread!
‣When closing the housing cover, please ensure that the thread of the cover and housing are
free from dirt, e.g. sand.If you feel any resistance when closing the cover, check the thread
on both again to ensure that they are free from dirt.
T14 T15 T17
2 3

Cerabar S 4 to 20 mA HART Wiring
Endress+Hauser 17
Close cover on a hygenic stainless steel housing (T17)
P01-PMD75xxx-17-xx-xx-xx-000
Fig. 3: Close cover
The covers for the terminal and electronics compartment are hooked into the casing and closed
with a screw. These screws should be finger-tightened (2 Nm (1.48 lbf ft)) to the stop to ensure
that the covers sit tightly.
4.5 Post-installation check
After installing the device, carry out the following checks:
• Are all the screws firmly tightened?
• Are the housing covers screwed down tight?
5Wiring
5.1 Connecting the device
WARNING
!
Risk of electric shock!
If the operating voltage is > 35 VDC: Dangerous contact voltage at terminals.
‣In a wet environment, do not open the cover if voltage is present.
WARNING
!
Limitation of electrical safety due to incorrect connection!
• When using the measuring device in hazardous areas, installation must comply with the
corresponding national standards and regulations and the Safety Instructions or Installation
or Control Drawings.
• Devices with integrated overvoltage protection must be grounded.
• Protective circuits against reverse polarity, HF influences and overvoltage peaks are
integrated.

Wiring Cerabar S 4 to 20 mA HART
18 Endress+Hauser
• The supply voltage must match the supply voltage on the nameplate (ä11, "Nameplates").
• Switch off the supply voltage before connecting the device.
• Remove the housing cover of the terminal compartment.
• Guide the cable through the gland. Preferably use twisted, shielded two-wire cables.
• Connect the device in accordance with the following diagram.
• Screw down the housing cover.
• Switch on the supply voltage.
P01-xMx7xxxx-04-xx-xx-xx-001
Fig. 4: Electrical connection 4 to 20 mA HART. Please also note ä 20, "Supply voltage".
1Housing
2 Jumper for 4 to 20 mA test signal.
ä 20, Section "Taking 4 to 20 mA test signal".
3 Internal earth terminal
4 External earth terminal
5 4 to 20 mA test signal between plus and test terminal
6 Minimum supply voltage = 10.5 V DC, jumper is inserted in accordance with the illustration.
7 Minimum supply voltage = 11.5 V DC, jumper is inserted in "Test" position.
8 Devices with integrated overvoltage protection are labeled OVP (overvoltage protection) here.
4…20 mA
➅10.5 V DC
➆11.5 V DC
4... 20mA Test
Test
➀
➁
➂
➃
➄
Test
➇
4... 20mA Test

Cerabar S 4 to 20 mA HART Wiring
Endress+Hauser 19
5.1.1 Connecting devices with Harting plug Han7D
A0019990
Fig. 5:
A Electrical connection for devices with Harting plug Han7D
B View of the plug connector at the device
5.1.2 Connecting devices with an M12 connector
5.1.3 Connecting the cable version
P01-PMx4xxxx-04-xx-xx-xx-010
Fig. 6: rd = red, bk = black, gnye = green-yellow
Han7D
–
+
+–
–
+
1
5
4
6
7
8
2
3
AB
PIN assignment for M12 connector PIN Meaning
A0011175
1 Signal +
2 Not assigned
3 Signal –
4Earth
2
1
34
–
+
+
PE
–
rd
bk
gnye
4...20 mA

Wiring Cerabar S 4 to 20 mA HART
20 Endress+Hauser
5.2 Connecting the measuring unit
5.2.1 Supply voltage
WARNING
!
Supply voltage might be connected!
Risk of electric shock and/or explosion!
‣When using the measuring device in hazardous areas, installation must comply with the
corresponding national standards and regulations and the Safety Instructions or Installation
or Control Drawings.
‣All explosion protection data are given in separate documentation which is available upon
request. The Ex documentation is supplied as standard with all devices approved for use in
explosion hazardous areas.
Taking 4 to 20 mA test signal
A 4 to 20 mA signal may be measured via the positive and test terminal without interrupting
the measurement. The minimum supply voltage of the device can be reduced by simply
replugging the jumper. As a result, operation is also possible with lower voltage sources. To keep
the measured error below 0.1%, the current measuring device should exhibit an internal
resistance of < 0.7 . Observe the position of the jumper in accordance with the following table.
Electronic version Jumper for 4 to 20 mA test signal in
"Test" position (order configuration)
Jumper for 4 to 20 mA test signal in
"Non-Test" position
4 to 20 mA HART, version for
non-hazardous areas
11.5 to 45 V DC 10.5 to 45 V DC
Jumper position for test signal Description
– Taking 4 to 20 mA test signal via plus and test terminal:
possible. (Thus, the output current can be measured without
interruption via the diode.)
– Order configuration
– Minimum supply voltage: 11.5 V DC
– Taking 4 to 20 mA test signal via plus and test terminal:
not possible.
– Minimum supply voltage: 10.5 V DC
Test
TestTest
