Endress+Hauser RMA42 User manual

Products Solutions Services
Operating Instructions
RMA42
Process transmitter
BA00287R/09/EN/07.22-00
71563194
2022-03-04
Valid from version
01.03.xx (device software)

RMA42 Table of contents
Endress+Hauser 3
Table of contents
1 About this document ................ 4
1.1 Symbols .............................. 4
1.2 Documentation ........................ 5
2 Safety instructions .................. 7
2.1 Requirements for the personnel ............ 7
2.2 Intended use .......................... 7
2.3 Workplace safety ....................... 7
2.4 Operational safety ...................... 7
2.5 Product safety ......................... 8
3 Incoming acceptance and product
identification ....................... 9
3.1 Incoming acceptance .................... 9
3.2 Product identification .................... 9
3.3 Certificates and approvals ................ 9
3.4 Storage and transport .................. 10
4 Mounting ......................... 11
4.1 Installation requirements ................ 11
4.2 Dimensions .......................... 11
4.3 Mounting procedure ................... 12
4.4 Post-installation check .................. 12
5 Wiring ............................ 13
5.1 Electrical connection ................... 13
5.2 Post-connection check .................. 16
6 Operation ......................... 17
6.1 Operating elements .................... 17
6.2 Display and device status indicator / LED .... 19
6.3 Symbols ............................. 20
6.4 Quick guide to the operating matrix ........ 21
7 Commissioning .................... 24
7.1 Post-installation check and switching on the
device .............................. 24
7.2 General information about configuring the
device .............................. 24
7.3 Notes on setup access protection .......... 24
7.4 Device configuration ................... 25
7.5 In operation .......................... 37
8 Diagnostics and troubleshooting ... 41
8.1 General troubleshooting ................. 41
8.2 Overview of diagnostic information ........ 41
8.3 Diagnosis list ......................... 41
9 Maintenance ...................... 42
10 Repair ............................ 43
10.1 General notes ........................ 43
10.2 Spare parts .......................... 43
10.3 Return .............................. 44
10.4 Disposal ............................ 44
11 Accessories ....................... 46
11.1 Communication-specific accessories ........ 46
12 Technical data .................... 47
12.1 Input ............................... 47
12.2 Output ............................. 47
12.3 Power supply ......................... 49
12.4 Performance characteristics .............. 50
12.5 Installation .......................... 51
12.6 Environment ......................... 52
12.7 Mechanical construction ................ 53
12.8 Operability .......................... 54
12.9 Certificates and approvals ............... 55
13 Appendix ......................... 56
13.1 Further explanations regarding the
differential pressure application in level
measurement ........................ 56
13.2 Display menu ......................... 58
13.3 Setup menu .......................... 59
13.4 Diagnostics menu ..................... 68
13.5 Expert menu ......................... 70
Index .................................. 77

About this document RMA42
4 Endress+Hauser
1 About this document
1.1 Symbols
1.1.1 Safety symbols
DANGER
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
WARNING
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
This symbol contains information on procedures and other facts which do not result in
personal injury.
1.1.2 Electrical symbols
Symbol Meaning
Direct current
Alternating current
Direct current and alternating current
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a
grounding system.
Potential equalization connection (PE: protective earth)
Ground terminals that must be connected to ground prior to establishing any other
connections.
The ground terminals are located on the interior and exterior of the device:
• Interior ground terminal: potential equalization is connected to the supply network.
• Exterior ground terminal: device is connected to the plant grounding system.
1.1.3 Symbols for certain types of information
Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Preferred
Procedures, processes or actions that are preferred.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation
A
Reference to page

RMA42 About this document
Endress+Hauser 5
Symbol Meaning
Reference to graphic
Notice or individual step to be observed
1.
,
2.
,
3.
… Series of steps
Result of a step
Help in the event of a problem
Visual inspection
1.1.4 Symbols in graphics
Symbol Meaning Symbol Meaning
1, 2, 3,... Item numbers
1.
,
2.
,
3.
… Series of steps
A, B, C, ... Views A-A, B-B, C-C, ... Sections
-
Hazardous area
.
Safe area (non-hazardous area)
1.2 Documentation
Document Purpose and content of the document
Technical Information (TI) Planning aid for your device
The document contains all the technical data on the device and provides
an overview of the accessories and other products that can be ordered for
the device.
Brief Operating Instructions (KA) Guide that takes you quickly to the 1st measured value
The Brief Operating Instructions contain all the essential information
from incoming acceptance to initial commissioning.
Operating Instructions (BA) Your reference document
The Operating Instructions contain all the information that is required in
various phases of the life cycle of the device: from product identification,
incoming acceptance and storage, to mounting, connection, operation
and commissioning through to troubleshooting, maintenance and
disposal.
Description of Device Parameters
(GP)
Reference for your parameters
The document provides a detailed explanation of each individual
parameter. The description is aimed at those who work with the device
over the entire life cycle and perform specific configurations.

About this document RMA42
6 Endress+Hauser
Document Purpose and content of the document
Safety Instructions (XA) Depending on the approval, Safety Instructions (XA) are supplied with the
device. The Safety Instructions are an integral part of the Operating
Instructions.
Information on the Safety Instructions (XA) that are relevant for
the device is provided on the nameplate.
Supplementary device-dependent
documentation (SD/FY)
Additional documents are supplied depending on the device version
ordered: Always comply strictly with the instructions in the
supplementary documentation. The supplementary documentation is an
integral part of the device documentation.
The document types listed are available:
• In the Download Area of the Endress+Hauser Internet site: www.endress.com →
Download
• Enter the serial number from the nameplate in the W@M Device Viewer
(www.endress.com/deviceviewer): all data relating to the device and an overview of
the Technical Documentation supplied with the device are displayed.
• Enter the serial number on the nameplate into the Endress+Hauser Operations app
or scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser
Operations app: all data relating to the device and the Technical Documentation
pertaining to the device is displayed.

RMA42 Safety instructions
Endress+Hauser 7
2 Safety instructions
2.1 Requirements for the personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill
the following requirements:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task.
‣Are authorized by the plant owner/operator.
‣Are familiar with federal/national regulations.
‣Before starting work, read and understand the instructions in the manual and
supplementary documentation as well as the certificates (depending on the
application).
‣Follow instructions and comply with basic conditions.
The operating personnel must fulfill the following requirements:
‣Are instructed and authorized according to the requirements of the task by the facility's
owner-operator.
‣Follow the instructions in this manual.
2.2 Intended use
The process transmitter evaluates analog process variables and displays them on its
multicolored screen. Processes can be monitored and controlled with the device's outputs
and limit relays. The device is equipped with a wide array of software functions for this
purpose. Power can be supplied to 2-wire sensors with the integrated loop power supply.
• The device is an associated apparatus and may not be installed in the hazardous area.
• The manufacturer accepts no liability for damages resulting from incorrect use or use
other than that intended. It is not permitted to convert or modify the device in any way.
• The device is designed for operation in an industrial environment and may only be
operated in an installed state.
2.3 Workplace safety
When working on and with the device:
‣Wear the required personal protective equipment as per national regulations.
2.4 Operational safety
Risk of injury!
‣Operate the device only if it is in proper technical condition, free from errors and faults.
‣The operator is responsible for the interference-free operation of the device.
Modifications to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers!
‣If modifications are nevertheless required, consult with the manufacturer.
Repair
To ensure continued operational safety and reliability:
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to the repair of an electrical device.
‣Use only original spare parts and accessories.

Safety instructions RMA42
8 Endress+Hauser
2.5 Product safety
This product is designed in accordance with good engineering practice to meet state-of-
the-art safety requirements and has been tested and left the factory in a condition in
which it is safe to operate.

RMA42 Incoming acceptance and product identification
Endress+Hauser 9
3 Incoming acceptance and product
identification
3.1 Incoming acceptance
Proceed as follows on receipt of the device:
1. Check whether the packaging is intact.
2. If damage is discovered:
Report all damage immediately to the manufacturer.
3. Do not install damaged material, as the manufacturer cannot otherwise guarantee
compliance with the safety requirements and cannot be held responsible for the
consequences that may result.
4. Compare the scope of delivery to the contents of the order.
5. Remove all the packaging material used for transportation.
3.2 Product identification
The device can be identified in the following ways:
• Nameplate specifications
• Extended order code with breakdown of the device features on the delivery note
• Enter the serial number from the nameplate in the W@M Device Viewer
(www.endress.com/deviceviewer): all data relating to the device and an overview of the
Technical Documentation supplied with the device are displayed.
• Enter the serial number on the nameplate into the Endress+Hauser Operations App or
scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser
Operations App: all the information about the device and the technical documentation
pertaining to the device is displayed.
3.2.1 Nameplate
The right device?
Check the information on the nameplate of the device:
• Product name and manufacturer ID
• Order code, extended order code and serial number
• Power supply and power consumption
• Approvals
• Temperature range
• Firmware version and device revision
3.2.2 Name and address of manufacturer
Name of manufacturer: Endress+Hauser Wetzer GmbH + Co. KG
Address of manufacturer: Obere Wank 1, D-87484 Nesselwang
Model/type reference: RMA42
3.3 Certificates and approvals
For certificates and approvals valid for the device: see the data on the nameplate
Approval-related data and documents: www.endress.com/deviceviewer → (enter the
serial number)

Incoming acceptance and product identification RMA42
10 Endress+Hauser
3.4 Storage and transport
Please note the following:
• Pack the device so that is protected against impact for storage and transport. The
original packaging provides optimum protection.
• The permitted storage temperature is –40 to 85 °C (–40 to 185 °F); it is possible to store
the device at borderline temperatures for a limited period (48 hours maximum).

RMA42 Mounting
Endress+Hauser 11
4 Mounting
4.1 Installation requirements
NOTICE
High temperatures reduce the life-time of the display.
‣To avoid heat accumulation, ensure the device is sufficiently cooled.
‣Do not operate the device in the upper temperature range over a longer period of time.
The process transmitter is designed for use on the DIN rail (IEC 60715 TH35). Connections
and outputs are provided on the top and underside of the device. Inputs are located on the
top, while outputs and the power supply connection are located on the underside of the
device. The cables are connected via labeled terminals.
Operating temperature range:
Non-Ex/Ex devices: –20 to 60 °C (–4 to 140 °F)
UL devices: –20 to 50 °C (–4 to 122 °F)
4.1.1 Orientation
Vertical or horizontal.
4.2 Dimensions
Note the width of the device: 45 mm (1.77 in).
• Maximum depth incl. DIN rail clip 118 mm (4.65 in).
• Maximum height incl. terminals 115 mm (4.53 in).
• Housing width 45 mm (1.77 in).
115 (4.53)
45 (1.77) 118 (4.65)
A0011792
 1 Dimensions of the process transmitter in mm (in)

Mounting RMA42
12 Endress+Hauser
4.3 Mounting procedure
2.
1.
3.
3.
1.
A0011766
1. Slide the upper DIN rail clip upwards and the lower clip downwards until they click
into place.
2. Fit the device on the DIN rail from the front.
3. Slide the two DIN rail clips back together until they click into place.
To disassemble the device, push the DIN rail clips up or down (see 1.) and remove the
device from the rail. It also suffices to open just one of the DIN rail clips and then tilt the
device to remove it from the rail.
4.4 Post-installation check
• Is the DIN rail clip clicked into place?
• Is the device securely seated on the DIN rail?
• Are all plug-in terminals securely engaged?
• Are the temperature limits observed at the mounting location →  11?

RMA42 Wiring
Endress+Hauser 13
5 Wiring
LWARNING
Danger! Electric voltage!
‣The entire connection of the device must take place while the device is de-energized.
‣The protective ground connection must be established before all other connections. If
the protective ground is disconnected, this can be a source of danger.
‣Before commissioning the device, make sure that the supply voltage matches the
voltage specifications on the nameplate.
‣Provide suitable switch or circuit breaker in building installation. This switch must be
provided close to the device (within easy reach) and marked as a circuit breaker.
‣An overcurrent protection element (rated current ≤ 10 A) is required for the power
cable.
• Observe the terminal designation on the side of the device.
• The mixed connection of safety extra-low voltage and dangerous contact voltage to
the relay is permitted.
5.1 Electrical connection
A loop power supply (LPS) is provided for every input. The loop power supply is primarily
designed to supply power to 2-wire sensors and is galvanically isolated from the system
and the outputs.
HART®
PC interface
A0011800-EN
 2 Terminal assignment of process transmitter (channel 2 and relay optional)
We recommend you connect a suitable surge arrester upstream if high-energy
transients can be expected on long signal cables.

Wiring RMA42
14 Endress+Hauser
5.1.1 Overview of possible connections on the process indicator
Terminal assignment of analog inputs, channel 1 and 2 (optional)
CH2 CH1
13 12 11
1516
17
18
14 23 22 21
2526
27
28
24
A0011916
Loop power supply connection
2-wire
+_
I
x8
x2
x4 x1
A0011925
4-wire
+_
I
x8
x2
x4 x1
+_
0/4...20 mA
A0011926
Analog input connection
RTD/resistor, 2-wire
x7
x8
x2
x4
x6 x5
A0011917
RTD/resistor, 3-wire
x7
x8
x2
x4
x6 x5
A0011918
RTD/resistor, 4-wire
x7
x8
x2
x4
x6 x5
A0011919
Thermocouple
x7
x8
+_
A0011920
U ≤ 1 V
+
_
x7
x8
=
A0011921
U > 1 V
x3
_
+
x8
=
A0011922
Current
+
_
x8
x4
A0011923

RMA42 Wiring
Endress+Hauser 15
Illustrated contact position of the relays if the limit value is breached or the power supply
fails:
(Optional) relay connection
Relay 1
R12 R11 R13
A0011801
Relay 2
R22 R21 R23
A0011802
Analog output connection
Analog output 1
O15 O16
+ -
A0011803
Analog output 2 (optional)
O25 O26
+ -
A0011804
Digital output connection
Digital output / open collector
D12D11
+_
A0011806
Power supply connection
24 to 230 V AC/DC (-20 % / +10 %) 50/60 Hz
L/+ N/-
A0011805
Interfaces
Interface for configuring with PC software
A0012418
HART® connection sockets
CH1 /
CH2
A0012403
The HART® terminals are connected to the internal resistor of the loop power supply.
There is no internal connection to the current input. If the transmitter power supply of
the device is not used, an external HART® resistor must be used in the 4 to 20 mA
current loop.

Wiring RMA42
16 Endress+Hauser
x4+
x8-
x1
x2
10 Ω
4
200 Ω
24 V
1
3
2
A0029250
 3 Internal circuitry of the HART® connection sockets
1 Current input
2 HART® connection sockets
3 Transmitter power supply
4 A/D converter
5.2 Post-connection check
Device condition and specifications Notes
Are cables or the device damaged? Visual inspection
Electrical connection Notes
Does the supply voltage match the specifications on the nameplate? 24 to 230 V AC/DC (-20 % / +10
%) 50/60 Hz
Are all terminals firmly engaged in their correct slot? Is the coding on the
individual terminals correct?
-
Are the mounted cables strain-relieved? -
Are the power supply and signal cables correctly connected? See the wiring diagram on the
housing.

RMA42 Operation
Endress+Hauser 17
6 Operation
Thanks to the device's simple operating concept, it is possible to commission the device for
many applications without a printed set of Operating Instructions.
The FieldCare operating software is a quick and convenient way of configuring the device.
It contains brief explanatory (help) texts that provide additional information on individual
parameters.
6.1 Operating elements
6.1.1 Local operation at the device
The device is operated by means of the three keys integrated in the front part of the device
• Open the Configuration menu
• Confirm an entry
• Select a parameter or submenu offered in the menu
Within the Configuration menu:
• Scroll step-by-step through the parameters/menu items/characters offered
• Change the value of the selected parameter (increase or decrease)
Outside the Configuration menu:
Display enabled and calculated channels, as well as min. and max. values for all the active
channels.
You can always exit menu items / submenus by selecting "x Back" at the end of the menu.
Leave the setup directly without saving the changes by pressing the ‘-’ and ‘+’ keys
simultaneously for longer (> 3 s).
6.1.2 Configuration via interface & PC configuration software
LCAUTION
Undefined states and switching of outputs and relays while configuring with the
configuration software
‣Do not configure the device when the process is running.
To configure the device using the FieldCare Device Setup software, connect the device to
your PC. You need a special interface adapter for this purpose, e.g. the Commubox
FXA291.
Installing the communication DTM in FieldCare
Before the indicator can be configured, FieldCare Device Setup must be installed on your
PC. The installation instructions can be found in the FieldCare instructions.
Then install the FieldCare device driver according to the following instructions:
1. First install the device driver "CDI DTMlibrary" in FieldCare. It can be found in
FieldCare under "Endress+Hauser Device DTMs → Service / Specific → CDI".
2. The DTM catalog in FieldCare must then be updated. Add the new installed DTMs to
the DTM catalog.

Operation RMA42
18 Endress+Hauser
Installation of the Windows driver for TXU10/FXA291
Administrator rights are required to install the driver in Windows. Proceed as follows:
1. Connect the device to the PC using the TXU10/FXA291 interface adapter.
 A new device is detected and the Windows installation wizard opens.
2. In the installation wizard, do not allow the device to automatically search for
software. For this, select "No, not this time" and click "Next".
3. In the next window, select "Install software from a list or specific location" and click
"Next".
4. In the next window, click "Browse" and select the directory where the driver for the
TXU10/FXA291 adapter is saved.
 The driver is installed.
5. Click "Finish" to finish the installation.
6. Another device is detected and the Windows installation wizard starts again. Again,
choose "No, not this time" and click "Next".
7. In the next window, select "Install software from a list or specific location" and click
"Next".
8. In the next window, click "Browse" and select the directory where the driver for the
TXU10/FXA291 adapter is saved.
 The driver is installed.
9. Click "Finish" to finish the installation.
This completes the driver installation for the interface adapter. The COM port that has
been assigned can be seen in the Windows device manager.
Establishing the connection
Proceed as follows to establish the connection with FieldCare:
1. Firstly, edit the connection macro. For this, start a new project and in the window
that is displayed, right-click the symbol for "Service (CDI) FXA291" and select "Edit".
2. In the next window, to the right of "Serial interface", select the COM port which was
assigned during the installation of the Windows driver for the TXU10/FXA291
adapter.
 The macro is now configured. Select "Finish".
3. Start the "Service (CDI) FXA291" macro by double-clicking it and confirm the
subsequent query with "Yes".
 A search for a connected device is performed and the suitable DTM is opened.
Online configuration is started.
Continue with device configuration in accordance with these Operating Instructions for the
device. The complete Setup menu, i.e. all of the parameters listed in these Operating
Instructions, can also be found in the FieldCareDevice Setup.
In general, it is possible to overwrite parameters with the FieldCare PC software and
the appropriate device DTM even if access protection is active.
If access protection by means of a code should be extended to the software, this
function should be activated in the extended device setup.
For this, select Menu → Setup / Expert → System → Overfill protect → German WHG
and confirm.

RMA42 Operation
Endress+Hauser 19
6.2 Display and device status indicator / LED
The process indicator provides an illuminated LC display which is split into two sections.
The segment section displays the value of the channel and additional information and
alarms.
In the dot matrix section, additional channel information, such as the TAG, unit or bar
graph, is displayed in the display mode. Operating text in English is displayed here during
operation.
The parameters for configuring the display are described in detail in the "Configuring the
device" section.
1
2
3
4
5
6
7
8
A0011767
 4 Display and operating elements of the process transmitter
1 HART® connection sockets
2 Display
3 Operating keys
4 PC interface connection socket
5 Green LED; on = supply voltage applied
6 Red LED; on = error/alarm
7 Yellow LED; on = relay 1 energized
8 Yellow LED; on = relay 2 energized
3
5
46
2
1
A0011765
 5 Display of the process transmitter
1 Channel indicator: 1: analog input 1; 2: analog input 2; 1M: calculated value 1; 2M: calculated value 2
2 Measured value display
3 Dot matrix display for TAG, bar graph, unit
4 Limit value indicators in the bar graph
5 "Operation locked" indicator
6 Minimum/maximum value indicator
In the event of an error, the device switches automatically between displaying the error
and displaying the channel, →  38 and →  41.

Operation RMA42
20 Endress+Hauser
6.3 Symbols
6.3.1 Display symbols
The device is locked / operator lock; the device setup is locked for changes to parameters; the
display can be changed.
1 Channel one (Analog in 1)
2 Channel two (Analog in 2)
1M First calculated value (Calc value 1)
2M Second calculated value (Calc value 2)
Max Maximum value/value of the maximum indicator of the channel displayed
Min Minimum value/value of the minimum indicator of the channel displayed
In the event of an error:
The display shows: , the measured value is not displayed
Underrange/overrange:
The error and the channel identifier (TAG) are specified in the dot matrix section.
6.3.2 Icons in the editing mode
The following characters are available for entering customized text:
‘0-9’, ‘a-z’, ‘A-Z’, ‘+’, ‘-’, ‘*’, ‘/’, ‘\’, ‘%’, ‘°’, ‘2’, ‘3’, ‘m’, ‘.’, ‘,’, ‘;’, ‘:’, ‘!’, ‘?’, ‘_’, ‘#’, ‘$’, ‘"’, ‘´’, ‘(’,
‘)’, ‘~’
For numerical entries, the numbers ‘0-9’ and the decimal point are available.
Furthermore, the following icons are used in the editing mode:
Symbol for setup
Symbol for expert setup
Symbol for diagnostics
Accept entry.
If this symbol is selected, the entry is applied at the position specified by the user, and you quit
editing mode.
Reject entry.
If this symbol is selected, the entry is rejected and you quit editing mode. The previously set text
remains.
Jump one position to the left.
If this symbol is selected, the cursor jumps one position to the left.
Delete backwards.
If this symbol is selected, the character to the left of the cursor position is deleted.
Delete all.
If this symbol is selected, the entire entry is deleted.
