Enel X Waybox Pro User guide

Installer Manual
Waybox Pro
Waybox Plus
Waybox Pro MID
Waybox Plus MID
ENGLISH

In this document
Purpose of this document 5
Installation Process 5
Document Structure 5
A: Hardware installation manual 7
1 Waybox 8
1.1 Features 9
1.2 Dimensions 10
2 Impoant safety information 11
2.1 Electric and electronic equipment end of life user’s information 11
3 Package Contents 12
4 Tools Needed 13
5 Installation Prerequisites 14
5.1 Protections 16
5.2 Power and signal cables 18
5.3 JB4Installers App 18
5.4 Enel X Way App 18
6 Standard Installation 19
7 Special Installation Cases 36
7.1 Three phase Waybox installed on a Single-phase or Bi-phase supply system 36
7.2 Other special cases 36
8 Firmware Update 36
9 Load Optimization Pro 37
10 Waybox Commissioning through the Enel X Way App 38
11 Charging Test 39
11.1 Charging in Unlock to Charge mode 40
11.2 Charging in Connect&Charge Mode 41
11.3 Recording the Charging Session in the Charging history 42
11.4 Checking Charging Power 42
11.5 Testing Load Optimization Pro 42

12 LED indicator 43
B: Waymeter installation manual 44
1 Waymeter 45
1.1 Electric and electronic equipment end of life user’s information 45
2 Single-phase Waymeter 46
2.1 Features 46
2.2 Installation 48
2.3 Waybox connection diagrams 52
3 Three-phase Waymeter 54
3.1 Features 54
3.2 Installation 56
3.3 Waybox connection diagrams 63
C: JB4Installer app manual 66
1 Purpose of the Manual 67
2 Pre-requisites 67
3 Login 67
4 New rmware download 69
5 Loading the Waybox serial on the app 70
6 Connecting the Waybox to the App 72
7 Firmware Update 75
8 Waybox Connectivity Check for Cellular Versions 78
9 Waybox Conguration 80
9.1 Conguration of the “Supply System” Parameter 80
9.2 Wi-Fi Conguration 81
9.3 Waymeter Conguration (for Waybox Pro) 82
9.4 Conguration of the Waybox in Standalone Mode 83
9. 5 Conguration of the Waybox in Absence of Cellular Connectivity 84
9.6 Conguration of the Waybox in case of installation on the IT network or in absence
of neutral 88
9.7 GPD disabling procedure 88

10 Viewing Waybox Diagnostics 89
D: Web Manager manual 90
1 Procedure for accessing the Web Manager tool 91
2 Procedure for seing the Waybox in “standalone” mode in case of lack of connectivity
and for commissioning 92
3 Seing the Waybox access mode, power, and Supply System 93
4 Association of the Waybox with Waymeter 96
5 Wi-Fi 99
E: Procedure for installing the external protection release solution for
Waybox with control board 100
1 Introduction 101
2 Procedure for installing the external protection release solution 101
3 Composition of Siemens Protection Kits 103
F: What-if Manual - Special installation cases 105
1 Purpose of the Manual and Method 106
2 List of Special Installation Cases 107
2.1 Data network signal with SIM is insucient 108
2.2 Single-phase IT power grid 109
2.3 Customer smaphone connectivity not adequate 110
2.4 Lockable garage with shuer (or other type) that weakens signal 111
2.5 Single-phase TT/TN power grid 112
2.6 Three-phase TT/TN power grid 113
2.7 Single-phase TT electrical grid without neutral 114
2.8 Waybox with control board in Italy and in Holland 114
2.9 EV ready Installation 115
2.10 Waybox with Load Optimization Pro (without photovoltaics) 115
2.11 Waybox with Load Optimization Pro (with photovoltaics) 116
2.12 Customer's vehicle not available during installation 116
2.13 Renault Zoe, Sma 22 kW, Twingo Electric 117
2.14 Load Optimization Pro with transformer 117

5
REV.2 - 03/2023
Purpose of this document
The purpose of this manual is to provide the installer with all the information necessary for
the correct installation and commissioning of the Waybox Pro and Waybox Plus charging
stations.
Installation Process
The following process is recommended to carry out the installation operations:
1. Please read this Installer Manual.
2. Carry out a feasibility inspection at the installation site by lling out a checklist provided
for this purpose by Enel X Way. This checklist allows you to nd out whether you can
proceed with standard installation (see Standard Installation) or whether you need to
follow the special installation procedures (see What-if Manual);
3. Obtain tools, materials, apps, and everything needed for installation (see Tools Needed);
4. Proceed with installation, commissioning, congurations, testing, and acceptance test.
Document Structure
The manuals that comprise this document are listed below.
DOCUMENT
SECTION MANUAL TOPIC
A: Hardware
installation manual
Waybox Pro & Waybox Plus
Installation Manual
Physical installation of the Waybox,
introduction to congurations,
commissioning via Enel X Way app,
and charging test
B: Waymeter
installation manual
Waymeter Installation
Manual
Physical installation of single-phase
and three-phase Waymeter device
to enable Load Optimization Pro
feature (available only with Waybox
Pro)

6
REV.2 - 03/2023
C: JB4Installer app
manual
Waybox4Installer App
Manual
Guide for the use of the
"Waybox4Installer" app, necessary
to carry out the Waybox
conguration activities (if not carried
out with the Enel X Way app) and
Waymeter
D: Web Manager
manual Web Manager Manual
Guide for the use of the "Web
Manager" web app, which can be
used by all users to carry out the
Waybox conguration activities (if
not carried out with the Enel X Way
app) and Waymeter
E: Procedure
for installing the
external protection
release solution
for Waybox with
control board
Procedure for installing the
external protection release
solution for Waybox with
control board
Guide to install protection
components for Waybox equipped
with control board
F: What-if Manual -
Special installation
cases
What-if Manual - Special
installation cases
Procedures to be followed after
verication of a non-standard
installation case

7
REV.2 - 03/2023
A: Hardware installation manual

8
REV.2 - 03/2023
1 Waybox
Waybox Pro and Waybox Plus charging stations are available in two versions.
WAYBOX CABLE VERSION (1):
1Cable
2RFID reader
3LED indicator
4Connector
1RFID reader
2LED indicator
3Socket
WAYBOX SOCKET VERSION (2):
The Waybox Pro diers from the Waybox Plus by the possibility to enable the Load
Optimization Pro feature, which allows the Customer to always charge at the maximum
available power without triggering the meter. The activation of this function requires the
installation of an additional device, the Waymeter.
>Waybox Pro installation: hardware installation of the Waybox, hardware installation of
the Waymeter, conguration, testing and acceptance test
>Waybox Plus installation: hardware installation of the Waybox, conguration, testing
and acceptance test
1
2
1
2
3
3
4

9
REV.2 - 03/2023
1.1 Features
Output power
Single-phase
Up to 3.7 kW, 16 A
Up to 7.4 kW, 32 A
Three-phase Up to 22 kW, 32 A
Input voltage
Single-phase 230 VCA
Three-phase 400 VCA
Charging mode Mode 3
LED Dynamic LEDs indicating charging status
Protection
IP55, IK08
The Waybox has an internal detector for DC fault
currents above 6 mA.
The following external protections are required:
> Type A residual current device (RCD)
> Curve C Miniature Circuit Breaker (MCB)
Operating temperature From -30°C to +50°C (Pro & Plus)
From -25°C to +50°C (Pro MID & Plus MID)
Standards and
ceications
IEC 61851-1
CE Ceication
RED 2014/53/EU
Waybox with control board: The cable version Waybox to be installed in Italy and Holland
has the control board.
Waybox to be installed according to EV ready requirements also are equipped with the
control board.

10
REV.2 - 03/2023
1.2 Dimensions
NOTE:
All dimensions are in mm.
> Base (mounting holes circled in red)
> Waybox cable version
> Waybox socket version and Waybox socket version with control board

11
REV.2 - 03/2023
2 Impoant safety information
Read all safety information before installing the product.
> WARNING: Do not leave this unit unaended if children are nearby.
> WARNING: Do not put your ngers into the electric vehicle connector.
> WARNING: Do not use this product if the exible power cord is frayed, has damaged
insulation, or shows other signs of damage.
> WARNING: For use with electric vehicles only.
> WARNING: Do not use this unit with an extension cord.
> WARNING: Do not remove the cover or aempt to open the housing. There are no user-
serviceable pas inside. Refer all servicing to qualied service personnel.
> WARNING: Install and use the Waybox away from ammable, explosive, irritating, or
combustible chemicals, materials, or vapors.
> WARNING: Do not turn on the Waybox outside of its operating temperature range of
-30°C to +50°C.
> WARNING: This unit is intended only for electric vehicles that do not require ventilation
while charging.
> WARNING: This product must be grounded. In the event of a failure or breakdown,
grounding ensures a path of least resistance for electrical current to reduce the risk of
electric shock.
> WARNING: Improper connection of the equipment-grounding conductor may result in
a risk of electric shock. If you are unsure whether the product is properly grounded,
consult a qualied electrician or service technician.
2.1 Electric and electronic equipment end of life user’s
information
Pursuant to local laws and regulations and according to a.14 of Directive 2012/19 / EU
on waste electrical and electronic equipment (WEEE), crossed-out waste bin symbol on
equipment or on its packaging means that the product shall be disposed of
separately from household waste. When this product reaches its end of life, take
it to a collection point designated by local authorities. The separate collection
and recycling of product at the time of disposal will help to conserve natural
resources and ensure that it is recycled in a manner that protects human health
and the environment.

12
REV.2 - 03/2023
Enel X Way Waybox™ charging station
with M3-0.5 x 12 mm screws (x3) and
washers (x3)
Base with M5 x 50 mm screws (x4) and
washers (x4)
Terminal block
Dowels M8 x 40 mm (x4)
Ferrite
Terminals (x5)
NOTE:
These terminals must be used only
when using cables with a cross section
of 4 mm2and 6 mm2
Wateight gasket for external antenna
NOTE:
This item must be installed in case you
need an external antenna.
3 Package Contents

13
REV.2 - 03/2023
4 Tools Needed
>Phillips screwdriver.
>Flat screwdriver.
>Pencil or marker.
>Hex wrench size 4.
>Wrench size 8.
>Phillips screwdriver (dynamometric 1.3 Nm).
>Crimping tool.
>Wire stripper.
>Electrician's scissors.
>Silicone.
>Android smaphone (required for conguration tasks).
>Measuring tape and level.
For masonry or concrete buildings:
>Hammer.
>Drill bit for M8 wall plugs.
Gasket kit for single-phase Enel X Way
Waybox™ installation with 10 mm2cross
section cables
> Gasket 6 for PE
> Gasket 2/6 for L1 and N/L2
Gasket kit for three-phase Waybox
installation with 10 mm2cross section
cables
> Gasket 6 for PE
> Gasket 4/6 for L1, L2, L3, N
Gasket for installation of connection cables
with control board (included only in versions
with control board)
> Gasket 2/3

14
REV.2 - 03/2023
DEVICE NOTE POWER/OPERATING BANDS
Wi-Fi
IEEE 802.11 b 17 dBm (50mW)
IEEE 802.11 g 13 dBm (20mW)
IEEE 802.11 n 12 dBm (15mW)
Operating bands 2400 – 2483,5 MHz
RFID
RF Power 27dBm (0.5W)
Operating bands Fo: 13,56 MHz; bandwidth: 2,26 kHz
5 Installation Prerequisites
The Waybox must be installed in accordance with the following specications:
>Within a useful distance of the vehicle's charging po.
>For Wi-Fi enabled units: Within range of local Wi-Fi network (suppos IEEE 802.11b/g/n
at 2.4 GHz).
>For units equipped with a cellular data connection (Waybox Pro Cellular and Waybox
Plus Cellular): in an area with good mobile data network coverage. If the reception is
not sucient, an external antenna will also need to be installed and connected to the
Waybox. The optimal signal strength is greater than or equal to -80 dBm (e.g. -75 dBm is
greater than -80 dBm, because of the minus sign). If the measured signal is less than -80
dBm (e.g. -85 dBm) could be necessary to install a dedicated external antenna. Anyway,
also if an antenna is installed it could not be sucient.

15
REV.2 - 03/2023
NOTE:
The system shall be installed in accordance with applicable local codes.
The Waybox is compatible with the networks in the following table:
Cellular
2G LB Class 4 33dBm (2W)
2G LB Class E2: 27dBm (0.5W) @ EDGE
2G HB Class 1: 30dBm (1W)
2G HB Class E2: 26dBm (0.4W) @ EDGE
3G (WCDMA) Class 3: 24dBm (0.25W)
4G (FDD & TDD) Class 3: 23dBm (0.2W) @ 1RB
Operating bands
B28A: 703 – 788 MHz
B20: 791 – 862 MHz
B8: 880 – 960 MHz
B3: 1710 – 1880 MHz
B1: 1920 – 2170 MHz
B7: 2500 – 2690 MHz
DISTRIBUTION NEUTRAL VOLTAGE
Single-phase
TT
Yes 230 VAC
Three-phase Yes 400 VAC
Single-phase
TN-S
TN-C-S
Yes 230 VAC
Three-phase Yes 400 VAC
Single-phase IT No 230 VAC
NOTE: Waybox MID version is not compatible with IT grid

16
REV.2 - 03/2023
WAYB OX MINIATURE CIRCUIT
BREAKER
RESIDUAL CURRENT
DEVICE
Single-
phase
Up to 3.7 kW, 16 A
> Curve C
> ICC: 10 kA
> In: 20 A
> Poles: 2
> Type A
> Id: 30 mA
> In: 20/25 A
> Poles: 2
Up to 7.4 kW, 32 A
> Curve C
> ICC: 10 kA
> In: 40 A
> Poles: 2
> Type A
> Id: 30 mA
> In: 40 A
> Poles: 2
Three-
phase Up to 22 kW, 32 A
> Curve C
> ICC: 10 kA
> In: 40 A
> Poles: 4
> Type A
> Id: 30 mA
> In: 40 A
> Poles: 4
5.1 Protections
The installation of the Waybox should include dedicated protection devices. Below are the
recommended protections for the installation:
NOTE:
MCB shall have a magnetic throughput energy I2t ≤ 60000 A2s
WARNING
Some electric vehicles require the Neutral (N) on the charging station to have direct
contact with the Ground. This has an impact on charging in case of IT networks. In
this case, a transformer must be installed upstream of the RCD and MCB and the
Waybox to have a local TN system.

17
REV.2 - 03/2023
Control board location Clean contact on control board
The characteristics of the clean contact of the control board are as follows:
>The contact is NO (normally open).
>The maximum voltage the contact can withstand is 60V.
>The maximum sustained current in continuous mode is 100 mA.
>The cross-section of the connecting cables to the contact is between 1 mm2
and 1,5 mm2.
>The diameter of the connecting cables is between 3 mm and 3.5 mm.
The change in status of this contact is used to control an external release solution
(motor with MCB adapter). For more information on the installation of the release
device, please refer to “Procedure for installing the release solution for external
protections for Waybox cable version and socket version with control board”.
WAYBOX WITH CONTROL BOARD
Waybox with control board are equipped with a clean contact on the board itself that
changes its status from NO (normally open) to closed in case of a fault on the internal
contactor of the Waybox. In this case, the control board is used to command the
opening of a protection (dierential or magnetothermal) to cut o the power supply
circuit.

18
REV.2 - 03/2023
5.2 Power and signal cables
The choice of cross-sections, insulating materials and composition of the power cables
shall be made in line with the size of the switches and in accordance with local standards
in force.
The following table shows the minimum recommended cross sections for a standard
installation using copper cables.
WAYBOX MINIMUM SECTION
Single-
phase
Up to 3.7 kW, 16 A 4 mm2
Up to 7,4 kW, 32 A 6 mm2
Three-
phase Up to 22 kW, 32 A 6 mm2
5.3 JB4Installers App
Enel X Way paners will need to install the JB4Installers app on their smaphone to peorm
Waybox conguration and diagnostic tasks. To use the app, they will need to receive
authorization from Enel X Way and complete a registration process. Please refer to the
JB4Installers App Manual for more information.
5.4 Enel X Way App
Enel X Way paners will need to install the Enel X Way app on their smaphone to peorm
Waybox conguration tasks. Enel X Way app is available on the iOS App Store e Google Play.
For more information, see section 10 of this manual.
NOTE:
The maximum conductor cross-section of cables that can be used for Waybox is 10 mm2.
In this case the maximum conductor diameter shall be 4 mm.
WAYBOX WITH CONTROL BOARD:
Waybox with control board require signal cables with section between 1 and 1.5 mm2and
external diameter between 2.5 and 3.5 mm.

19
REV.2 - 03/2023
6 Standard Installation
The following is the standard installation procedure, valid for all versions of Waybox in this
manual. The procedure also includes optional steps, which must be carried out only in the
following cases:
>Installation of a Waybox with control board.
>Installation of an external antenna.
NOTE:
The Waybox must be installed by a qualied electrician.
1. Make sure no voltage is applied to the input cable.
WARNING
Do not continue this procedure until you are ceain that no voltage is present at the
input cable.
2. When installing 4 mm2and 6 mm2cross-section cables, install the terminals on the input
cable wires with the crimping tool.
NOTE:
When installing 10 mm2cables, strip only the cables, do not install the terminals.

20
REV.2 - 03/2023
3. Remove the gasket block cover using a 4mm hex wrench.
4. Identify the nut screws that secure the gasket block. Hold the nut in place with a size 8
wrench, then loosen the screw with a size 4 hex wrench.
