Enel X Waypole User manual

Installation Manual
Waypole
ENGLISH

2
Sommario
1. Purpose 3
2. Field of application 3
3. Denitions/Abbreviations 3
4. Equipment 4
5. Material supplied by the manufacturer 5
6. Unpacking 6
7. The Plinth 8
8. Installation 9
8.1. Warnings 9
8.2. Exploded diagram 10
8.3. Preparing the Waypole 11
8.4. Placing the Waypole in position 14
8.5 Wiring the power supply and eah 16
8.6. Concluding steps 19
9. Final steps 20
10. Waypole specications 21
Appendix A 23
Appendix B 24
Appendix C 25

3
1. Purpose
The purpose of this document is to describe how to install the equipment named “Enel X
Way Waypole™”.
2. Field of application
It is used to document installation activities for such equipment as pa of an Electric Vehicle
Charging System.
CAUTION: The safety of the equipment is only guaranteed if the instructions below
are used correctly. It is therefore necessary to keep them. Only qualied personnel
can carry out installation or any other work on stations in operation, and only in
accordance with the safety requirements in force.
PI INSTALLATION REQUIREMENTS (This document)
RCCB RESIDUAL CURRENT CIRCUIT BREAKER
TMCB THERMAL-MAGNETIC CIRCUIT BREAKER

4
4. Equipment
Anyone who secures the pole to the ground and connects it electrically to the mains power
must have at least the following tools:
TOOL SIZE USE
Long socket wrench for
hexagon head screws 13 mm Power terminals, 400 Vac + PE
Socket wrench for
hexagon head screws 17 mm Nuts for securing anchors
Hexagon key 3 mm Doors
Hexagon key 4 mm Lexan guard
Hexagon key 5 mm Fastening metal cable clamp
Open-end wrench 22 mm Small cable glands
Open-end wrench 55 mm Large cable glands

5
5. Material supplied by the manufacturer
The table below lists the materials that the manufacturer supplies for each Waypole to be
used for installation.
POSITION THE
“LONG SIDE”
AT THE FRONT
REF. CODE DESCRIPTION QT Y.
1
467015221 P. S. 4G Enel Three-phase Three-phase 1
467015231 P. S. 4G Enel Single-phase Three-phase 1
467015371 P. S. 4G Enel Three-phase Three-phase Siemens 1
467015381 P. S. 4G Enel Single-phase Three-phase Siemens 1
467015391 P. S. 4G Enel Single-phase Single-phase Siemens 1
467015401 P. S. 4G Enel Single-phase Three-phase 1
2161192211 P. S. 4G Cap Unit 1
3161107391 Plate with anchors 1

6
6. Unpacking
Remove the pole from its packaging (cardboard box) by sliding out the cardboard protection
pieces, and then place it veically on the paving, taking care not to damage it.
Also take out the accessory material need to install the pole, and keep it carefully on-site
until it is used.
Main package
EXAMPLE

7
Take the plate with anchors out of the packaging.
The plate with anchors
NOTE: Obviously, this will be done a reasonably long time before unpacking the
Waypole, when the civil works are carried out.

8
7. The Plinth
EXAMPLE
Cables protruding
at least 100 cm
Position the plinth where
it ensures at least one
metre from walls and
obstacles to the sides of
the pole (sides with the
sockets on them).
Section of the plinth area
Place the pole on
the anchors with
the “long side”
towards the front
NOTE: See also Appendix A.

9
8. Installation
8.1. Warnings
CAUTION: All of the activities described in this manual must be carried out with no
power connected, which must be veried in accordance with the procedures set
out in the regulations in force.

10
8.2. Exploded diagram
Below there is an exploded diagram of the installation.

11
8.3. Preparing the Waypole
Once you have removed the pole from its packaging and placed it veically on the paving,
it is necessary to prepare it for installation, while taking care not to damage it.
Remove the protective transparent lm from the stickers on the front and rear of the
head.
Remove the two side panels (blue arrows) by opening the locks with the key, then unscrew
the lower panel (yellow arrow) and nally unscrew the Lexan guard (light blue arrow).
Overall weight = 60.2 kg
Weight without side panels = 41.8 kg
NOTE: The specied sequence is illustrated in the pictures below, which show an
example of the activities carried out in the factory.

12
Use the key to open the two side panels, and temporarily place them veically on a suitable
suace in a stable manner.
Unscrew the 6 screws holding the front panel (without a power screwdriver), and place it to
one side.

13
Unscrew the Lexan guard from the terminal block and put it in a safe place together with
the screws.

14
8.4. Placing the Waypole in position
EXAMPLE
Place the “cap unit” on the “plate with anchors” (in
the direction shown), centring the 4 holes on the 4
studs (light blue arrow).
Place the pole on the “plate with anchors” with the
“cap unit” on top (in the direction shown), centring
the 4 holes on the 4 studs (green arrow).
Take care to inse the sections of
cable.
Where the
power cable
passes from
outside
Where the
eah cable
passes from
outside

15
Finally, inse the drain hose into the straight hose tail (light blue arrow) and inse the loose
end of the eah into the “Faston” terminal provided (yellow arrow).
Fasten it to the ground with washers and nuts (x 4) (violet arrows).

16
Arm the 6 circuit breakers (thermal-magnetic and residual current) and connect the baery
terminal.
8.5 Wiring the power supply and eah
Unscrew the metal cable clamp at one end only.

17
Prepare the power supply cable (see Appendix B) and the main eah (with ring terminals for
M8 screws) and then connect them to the terminal block.
The cable must pass where shown by the violet arrow to be held by the metal cable clamp
(red arrow).
CAUTION: All the activities described in this manual must be carried out with no
power connected, which must be veried in accordance with procedures set out
in the regulations.

18
Each terminal must be connected as shown in the gure below.
Use a long socket wrench to tighten the nuts properly, applying a minimum torque of 6 Nm.
Base plain
washer
Ribbed
washer (at
the top).
In contact
with the
closing nut.
Layout of the
power supply
input terminal
Area reserved
for the cable
terminals
Power supply
to inside the
pole
Power supply
from outside
going to the
pole
EXAMPLE

19
8.6. Concluding steps
>Ret the transparent Lexan guards (light blue arrow)
>Screw the front panel back on, being careful of the eah cable (yellow arrow)
>Ret the side panels in position and lock them with the key (blue arrow).
>Keep the key in accordance with the established procedures.

20
9. Final steps
When all the steps have been completed:
>check that the equipment has been anchored and closed correctly;
>check that the equipment is in a “working state”;
>retrieve all tools and put them away carefully;
>retrieve any rubbish produced;
>leave the “environment” as you found it.
The pole after closing.
EXAMPLE
