Eneo VMC-19LEDMD User manual

EN
Quick Installation Guide
VMC-19LEDMD
Professional Monitor 19”
(48cm) LCD/TFT, 1280x1024,
12V, Protection Glass, HDMI,
Desktop
All manuals and user guides at all-guides.com
all-guides.com

SHORT KEY FUNCTION
KEY BUTTON
OSD Key Function
Activates and exit the OSD
Select input source, and select the OSD menu
Move the OSD menu and auto adjustment of RGB source
Decrease the level of volume and move the previous menu
Increase the level of volume and select rhe OSD menu
Turns the power ON or OFF. There will be a few seconds
delay before the display appears.The power LED (next to the
power switch) lights with green when the power is turned ON.
The power is turned off by pressing the power switch again
and the power LED goes red.
All manuals and user guides at all-guides.com

CONNECTION
9
10
11
1 2 3 4 5 6 7 8
DC12V
1
VIDEO-2 IN / OUT
DC adapter input
VIDEO-2 signal input / looping out
6
AUDIO (PC)
2
VIDEO-1 IN / OUT
Stereo audio input for VGA
VIDEO-1 signal input / looping out
7
3
TRIGGER
TRIGGER signal input
8
AUDIO (VIDEO-2)
4
HDMI
Stereo audio input for VIDEO-2 HDMI signal 1 / 2 input
9
AUDIO (VIDEO-1 / S-VIDEO)
5
DVI
Stereo audio input for VIDEO-1 or S-VIDEO DVI signal input
10
S-VIDEO IN / OUT VGA
S-VIDEO signal input / looping out VGA (PC RGB) signal input
11
All manuals and user guides at all-guides.com

MODE SETTING
PICTURE MENU
VIDEO1
Select VIDEO1 mode
VIDEO2
Select VIDEO2 mode
S-VIDEO
Select S-VIDEO mode
RGB PC
Select VGA mode
DVI
Select DVI mode
HDMI1
Select HDMI1 mode
HDMI2
Select HDMI2 mode
VIDEO1
VIDEO2
S-VIDEO
√RGB PC
DVI
HDMI 1
HDMI 2
▼/▲:MOVE ▶:ENTER
INPUT
Inputs can be set to VIDEO1, VIDEO2, S-VIDEO, RGB PC, DVI, HDMI1, HDMI2 mode
CONTRAST : Adjust visual color contrast
BRIGHTNESS : Adjust color brightness
COLOR : Adjust visual color of screen
TINT : Adjust tint of color
SHARPNESS : Adjust sharpness of screen
COLOR TEMP : Switch color temperature of
screen
MODE SELECT : Adjust mode of screen
(DVI, HDMI mode only)
CONTRAST 60%
BRIGHTNESS 50%
COLOR 50%
TINT 50%
SHARPNESS 50%
PEAKING CONTROL 50%
COLOR TEMP ◀ MEDIUM
RED 50%
GREEN 50%
BLUE
▼/▲ : MOVE ◀/▶ : ADJUST ▶ : ENTER MENU : EXIT VER : *.*
50%
SCREEN
SETUP
RGB
SETUP
SETUP
CYCLE
TRIGGER
▶
MODE SELECT ◀ 1080P ▶
All manuals and user guides at all-guides.com

SCREEN MENU
SCAN MODE : Select the scan mode of screen
PIP : Activates PIP/PBP mode
SCREEN
SCAN MODE
PIP
PIP INPUT
PIP SWAP
PIP SIZE
PIP R/T
SCREEN
SETUP
RGB
SETUP
SETUP
CYCLE
TRIGGER
◀ R/B ▶
◀ SMALL ▶
▶
◀ VIDEO2 ▶
◀ OFF ▶
◀ FULL ▶
▼/▲ : MOVE ◀/▶ : ADJUST ▶ : ENTER MENU : EXIT VER : *.*
PIP, PBP - COMBINATION OF SIGNAL INPUT
VIDEO-1 VIDEO-2 S-VIDEO VGA DVI HDMI
VIDEO-1
MAIN SUB
X O O X X X
VIDEO-2
O X O X X X
S-VIDEO
O O X X X X
VGA
O O O X X X
DVI
O O O X X X
HDMI
O O O X X X
All manuals and user guides at all-guides.com

SETUP MENU
RGB SETUP MENU
INPUT : Select an input source for main screen
LANGUAGE : Set to different language mode
SOUND MUTE : Turn on/off the sound
BUTTON LOCK : Locking the button
NOISE REDUCTION : Set a noise reduction mode
OSD TIME : Set a time duration of OSD menu
DEFAULT : Factory default setting
NO OPERATION : Set a no operation mode
LINE SHIFT : Move a little to protect the screen
SETUP
INPUT
LANGUAGE
SOUND MUTE
BUTTON LOCK
NOISE REDUCTION
OSD TIME
SCREEN
SETUP
RGB
SETUP
SETUP
CYCLE
TRIGGER
DEFAULT ▶
LINE SHIFT ◀ ON ▶
NO OPERATION ◀ OFF ▶
◀ ON ▶
◀ OFF ▶
◀ OFF ▶
◀ ENGLISH ▶
◀ VIDEO1 ▶
▼/▲ : MOVE ◀/▶ : ADJUST ▶ : ENTER MENU : EXIT VER : *.*
15s
RGB SETUP
H-POSITION
V-POSITION
CLOCK
PHASE
AUTO ADJUST
POWER SAVING
SCREEN
SETUP
RGB
SETUP
SETUP
CYCLE
TRIGGER
AUTO REPEAT ◀ OFF ▶
▶
◀ OFF ▶
▼/▲ : MOVE ◀/▶ : ADJUST ▶ : ENTER MENU : EXIT VER : *.*
100%
0%
0%
0%
H-POSITION : Adjust horizontal position of monitor
V-POSITION : Adjust vertical position of monitor
CLOCK : Adjust clock of monitor
PHASE : Adjust phase of monitor
AUTO ADJUST : Auto adjust position of screen
POWER SAVING : Power saving mode
AUTO REPEAT : Adjust auto repeat of monitor
All manuals and user guides at all-guides.com
all-guides.com

TRIGGER MENU
CYCLE SETUP MENU
CYCLE TIME : Adjust cycle time to displayed on
the screen
CYCLE : Selected mode keep change continuously
CYCLE SETUP
CYCLE TIME
CYCLE
VIDEO1
VIDEO2
S-VIDEO
RGB PC
SCREEN
SETUP
RGB
SETUP
SETUP
CYCLE
TRIGGER
DVI
HDMI 1 ◀ OFF ▶
HDMI 2 ◀ OFF ▶
◀ OFF ▶
◀ OFF ▶
◀ OFF ▶
◀ OFF ▶
◀ OFF ▶
◀ OFF ▶
▼/▲ : MOVE ◀/▶ : ADJUST ▶ : ENTER MENU : EXIT VER : *.*
10s
TRIGGER MODE : Set the trigger mode
trigger mode
TRIGGER DWELL : Set the display time of
trigger mode
TRIGGER INPUT : Select the input source of
TRIGGER
TRIGGER MODE
TRIGGER INPUT
TRIGGER DWELL
SCREEN
SETUP
RGB
SETUP
SETUP
CYCLE
TRIGGER
◀ OFF ▶
◀ VIDEO1 ▶
▼/▲ : MOVE ◀/▶ : ADJUST ▶ : ENTER MENU : EXIT VER : *.*
10s
All manuals and user guides at all-guides.com

eneo® is a registered trademark of
VIDEOR E. Hartig GmbH
Exclusive distribution through specialised
trade channels only.
VIDEOR E. Hartig GmbH
Carl-Zeiss-Straße 8
63322 Rödermark/Germany
Tel. [phone] / 888-0
Fax [phone] / 888-100
www.videor.com
www.eneo-security.com
Technical changes reserved
© Copyright by VIDEOR E. Hartig GmbH
Version 04/2015
