ENFORCER Enforcer MVE-AT11-01NQ User manual

Note: Products with model numbers that end with “Q” or that have a round green “Q” sticker are RoHS compliant.
Extenders for HDMI
over Single Cat5e/6
Manual
Extend HDMI signals up to 230ft (70m) at 1080p over a single Cat5e/6 cable
Plug and play operation –comes as a complete set
Choose from either a tabletop model (MVE-AT11-01NQ) or a double-gang
wall-plate model (MVE-AT11-W1NQ)
The tabletop and wall-plate models are compatible with each other. Mix
and match the transmitter from one model to the receiver of the other.
MVE-AT11-01NQ
Extender for HDMI over Cat5e/6
MVE-AT11-W1NQ
Wall-plate Extender for HDMI over Cat5e/6
MVE-AT11-01NQ
MVE-AT11-W1NQ

ENFORCER Enhanced Extenders for HDMI®over Single Cat5e/6
2SECO-LARM U.S.A., Inc.
Introduction:
The ENFORCER Enhanced Extenders for HDMI over Single Cat5e/6 extend the range of HDMI
signals by using an active transmitter and receiver to send video and audio over a single Cat5e/6
cable. 1080p HDMI Signals can be transmitted up to 230ft (70m) between the two units with zero
signal loss. The extender supports IR signals using the included adapters, allowing the user to use
a remote control from one end of an installation to control a device such as a TV or media player at
the opposite end of the installation.
Features:
Signal Strength –Active operation ensures that the signal strength will remain strong over
the length of the cable.
Distance –The Enhanced Extenders for HDMI over Single Cat5/e6 can transmit a clear
HDMI signal up to 230ft (70m).
Formats Supported –The Enhanced Extenders for HDMI over Single Cat5e/6 support both
progressive and interlaced formats: 1080p/1080i/720p/576p/576i/480p/480i.
Plug and Play –The Enhanced Extenders for HDMI over Single Cat5e/6 come as a complete
set consisting of a transmitter, receiver, power supplies, and IR adapters. No adjustments or
settings need to be made. The unit is ready to use right out of the box.
Zero Signal Loss –Integrated circuits in the transmitter and receiver clean, buffer, and
amplify the HDMI signal. This prevents signal loss and ensures a clear signal regardless of
the length of the cable up to the maximum range.
Connect Multiple Units –Repeat up to four sets to extend HDMI range up to 918ft (280m).
Mix and Match –The tabletop and wall-plate models are compatible with each other.
Connect a transmitter from one model to the receiver of another.
Specifications:
Input video signal
0.5~1.0 Vp-p
Input DDC signal
5Vp-p (TTL)
Maximum single link range
1920x1200, 1080p
Deep color
36-bit
Video formats supported
High-speed HDMI with 3D, HDCP 1.2
Audio formats supported
LPCM, Dolby-AC3, DTS 7.1, DSD
Output video
HDMI
Resolutions supported
1080p/1080i/720p/576p/576i/480p/480i
Range –1080p
Cat6: Up to 230’ (70m)
Video amplifier bandwidth
10.2Gbps
Cat5e/6 Wiring standard
T568-B
Operating voltage
5VDC
Power supply
2A@5VDC (2 adapters) (2.1mm plug)
Current draw
Transmitter
450mA@5VDC
Receiver
900mA@5VDC
Operating temperature
5°~131° F (-15°~55° C)
Operating humidity
5~90% RH (no condensation)
Dimensions
MVE-AT11-01NQ
45/16”x215/16”x7/8” (110x75x23mm)
MVE-AT11-W1NQ
41/16”x41/2”x5/16” (116x115x34mm)
Weight
MVE-AT11-01NQ
9.2-oz (260g)
MVE-AT11-W1NQ
9.3-oz (264g)

ENFORCER Enhanced HDMI® Extenders over Single Cat5e/6
SECO-LARM U.S.A., Inc. 3
Overview:
Back View
Front View
MVE-AT11-01NQ
Top View
Front View
MVE-AT11-W1NQ
Top View
Installation:
1. Determine where the transmitter and receiver will be wired as well as how much Cat5e/6 cable
will be necessary.
2. Connect the HDMI cable to both the transmitter and the source device.
3. Connect the HDMI cable to both the receiver and the display.
4. Connect the Cat5e/6 cable to both the receiver and transmitter units.
Note: For best results, use Cat6 cable.
5. Connect one 5VDC adapter to the transmitter and another to the receiver.
6. Determine which device, if any, will be controlled by the remote control. Install the IR
transmitter to the IR-TX port of the closest extender unit, pointing the IR transmitter at the
device. Install the IR receiver to the IR-RX port of the other extender unit. Point the remote
control at the IR receiver when in use.
7. MVE-AT11-W1NQ Only: Install the MVE-AT11-W1NQ using a standard double-gang box.
8. Switch on the HDMI source and display to verify that the system is functioning properly.
Steady ON
Flashing
OFF
Active
N/A
Unit is working
Unit is not
working/powered
Link
Connection OK
Check connection
Not connected
HDCP
Video has HDCP
Video does not have
HDCP
No video
Power
Power ON
Check power
Power OFF
45/16”
7/8”
Status LED Chart:
Status LEDs
Status LEDs
HDMI Port
HDMI Port
5VDC
Power input
RJ45 Port
5VDC
Power input
IR Adapter ports
IR Adapter
ports
Parts List
1 x Transmitter
1 x Receiver
2 x 5VDC Power adapters
1 x IR Transmitter
1 x IR Receiver
1 x Manual
41/2”(114mm)
49/16”
(116mm)
15/16”
(34mm)
Extender for HDMI over Cat5e/6
215/16”
(75mm)
www.seco-larm.com
Please use T568-B wiring standard.
Extender for HDMI over Cat6e/6
HDMI In
Note: Only transmitters are shown above. The transmitters and receivers have the same dimensions and similar parts.

ENFORCER Enhanced Extenders for HDMI®over Single Cat5e/6
4SECO-LARM U.S.A., Inc.
HDMI device does not function
correctly
Use T568-B wiring standard
Make sure the extender is powered on both sides.
Make sure the source and the display are powered.
Test the Cat5e/6 cable between the receiver and transmitter and make sure
it is functional.
Make sure that there are no problems with the HDMI source, HDMI cables,
or HDMI display by plugging the source directly into the display using an
HDMI cable
Make sure that the transmitter and receiver are plugged into the correct units
Make sure the HDMI source is compatible with the HDMI display.
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal service for a period of one (1) year from the
date of sale to the original consumer customer. SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned,
transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, r epair, or alteration, improper or abnormal
usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects
in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser’s exclusive remedy, shall be limited to replacement or repair only, at SECO-LARM option. In no event shall
SECO-LARM be liable for any special, collateral, incidental, or consequential personal or property damages of any kind to the purchaser or anyone else.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the SECO-LARM policy is one of continual
development and improvement. For this reason, SECO-LARM reserves the right to change specifications without notice. SECO-LARM is also not responsible for
misprints or typographical errors.
Copyright © 2013 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission
of SECO-LARM.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLCC in the United States and other
countries.
SECO-LARM®U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Website: www.seco-larm.com
PICHN1
Tel: [phone] | [phone]
Email: [e-mail]
MiMVE-AT11-x1NQ_1404.docx
Sample Application:
Troubleshooting:
Transmitter
Receiver
HDMI Source
IR Rx
IR Tx
HDMI
Cable
Remote
control
Display
Transmitter
Receiver
HDMI Source
IR Rx
IR Tx
Remote control
Display
Standard installation of MVE-AT11-01NQ
Installing MVE-AT11-01NQ transmitter with MVE-AT11-W1NQ receiver
Cable Legend:
HDMI
Cat5e/6
Power
IR
Up to 230ft
(70m)
Up to 230ft
(70m)
