ENFORCER MVE-AH1E1-41NQ User manual

MVE-AH1E1-41NQ
4K HDMI Extender over Single Cat5e/6
Manual
Up to 984ft (300m)
4K
Resolution
Up to
196ft
(60m)
Range
Cat5e/6
Single Cable
Plug
and
Play
Operation
Features:
Extend HDMI over a single Cat5e/6 cable
Supports resolutions from 480i to 4K with
zero signal loss
Transmits 4K@30Hz up to 164’ (50m) or
1080p@60Hz up to 196' (60m) over
Cat6 cable
Plug and play operation
Active operation ensures signal strength
Bi-directional IR for two-way remote
control extension
One (1) 12VDC power supply included –
set can be powered at either end

ENFORCER 4K HDMI®Extender over Single Cat5e/6
2SECO-LARM U.S.A., Inc.
The ENFORCER 4K HDMI Extender over Single Cat5e/6 extends the range of traditional HDMI cabling
methods by using an active transmitter and receiver to send video and audio over a single Cat5e/6. HDMI
formats as large as 4K can be transmitted up to 164ft (50m) between the two units with zero signal loss by
using integrated circuits in the receiver and transmitter.
Signal Strength –Active operation ensures that the signal strength will remain strong over the length of
the cable.
Distance –The 4K HDMI Extender over Single Cat5e/6 is capable of providing a clear HDMI signal up to
164ft (50m) at 4K resolution or 196ft (60m) at 1080p resolution.
Formats Supported –The 4K HDMI Extender over Single Cat5e/6 supports both progressive and
interlaced formats: 4K@30Hz/1080p/1080i/720p/576p/480p/480i.
Plug and Play –The 4K HDMI Extender over Single Cat5e/6 comes as a complete set consisting of a
transmitter and receiver, power supply, and IR dongles.
Zero Signal Loss –Integrated circuits in the transmitter and receiver clean, buffer, and amplify the HDMI
signal to prevent signal loss and ensure a clear signal regardless of the length of the cable.
Bi-directional IR –Send IR signals from the source to the monitor or from the monitor to the source for
discrete operation of devices.
Input video signal
3.3V
Input DDC signal
5Vp-p (TTL)
Maximum single link range
4K@30Hz
Deep color
8bit
Video formats supported
High-speed HDMI, HDCP 2.2
Audio formats supported
LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+,
DolbyTrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
Output video
HDMI
Resolutions supported
4K@30Hz/1080p/1080i/720p/576p/576i/480p/480i
Range
4K@30Hz
Cat6: Up to 164' (50m); Cat5e: Up to 82' (25m)
1080p
Cat6: Up to 196' (60m); Cat5e: Up to 98' (30m)
Video amplifier bandwidth
10.2Gbps
Video input connector
HDMI Type A 19-pin female
Video output connector
HDMI Type A 19-pin female
Cat5e/6 wiring standard
T-568B
IR Pass-through frequency
30~60 kHz
Operating voltage
12VDC
Power supply
1A@12VDC (1 Adapter) (2.1mm plug)
ESD Protection (human body model)
±8kV (air-gap discharge), ±4kV (contact discharge)
Current draw
Transmitter
85mA@12VDC
Receiver
125mA@12VDC
Operating temperature
32°~104° F (0°~40° C)
Operating humidity
20~90% RH (no condensation)
Dimensions
37/16"x23/8"x11/16" (88x61x17 mm)
Weight
5.08-oz (144g) (each)
1x Transmitter
2x IR Transmitters (w/ double sided tape)
1x 12VDC power adapter
1x Receiver
2x IR Receivers (w/ double sided tape)
1x Manual
Introduction:
Features:
Parts List:
Specifications:

ENFORCER HDMI®Extender over Single Cat5e/6
SECO-LARM U.S.A., Inc. 3
1. Determine the location where the MVE-AH1E1-41NQ units will be wired as well as how much Cat5e/6
cable will be necessary.
2. Connect the transmitter to the HDMI output of the source device.
3. Connect the Cat5e/6 cable to both the receiver and transmitter units.
NOTE: For maximum range use a Cat6 cable.
4. Connect the receiver to the HDMI input of the display device.
5. Connect the 12VDC adapter to either the transmitter or receiver depending on where you want to place it.
6. Determine which device, if any, will be controlled by the remote control. Install the IR transmitter to the
IR Tx port, pointing the IR transmitter at the device to be controlled. Install the IR receiver to the IR Rx
port of the other device, pointing the IR receiver to where the remote control will be. Point the remote
control at the IR receiver when in use.
7. Switch on the HDMI source and display to verify that the system is functioning properly.
8. Switch on the HDMI source and display to verify that the system is functioning properly.
Transmitter:
Transmitter:
Transmitter:
*Transmitter and Receiver unit have the same dimensions
Cable Legend:
Cat5e/6
Power
IR
HDMI
Overview:
Installation:
Sample Application:
HDMI Source
Cat5e/6
Up to 164' (50m) at 4K@30Hz
Up to 196' (60m) at 1080p
12VDC Power Supply
HDMI
Display
IR TX
IR RX
Remote
23/8"
(61mm)
11/16" (17mm)
37/16" (88mm)
Cat5e/6
12VDC Input
Power LED
Link LED
HDMI Input
IR Rx Port
IR Tx Port

ENFORCER 4K HDMI®Extender over Single Cat5e/6
4SECO-LARM U.S.A., Inc.
Troubleshooting:
Bi-directional IR:
The MVE-AH1E1-41NQ supports bi-directional IR pass-through signals. This allows for remote operation of
either the source device from the display location, or the display device from the source location. The
MVE-AH1E1-41NQ bi-directional IR Transmitter unit and IR Receiver unit support signals from 30~60 kHz.
HDMI device does not function correctly
Use T-568B wiring standard
Make sure the extender is powered
Make sure the source and the display are powered
Test the Cat5e/6 cable between the receiver and transmitter
and make sure it is functional
Make sure that there are no problems with the HDMI
source, HDMI cables, or HDMI display by plugging the
source directly into the display using an HDMI cable
Screen flickering or brief image loss
Use a higher grade of twisted pair category cable
(Cat6 is recommended)
Switch the source device to a lower HDMI output
(i.e., 4K@30Hz to 1080p)
Restart the handshake process by powering everything
down then powering up and connecting each device in
succession starting with the HDMI source
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.
IR Transmitter
IR Receiver
NOTICE: The SECO-LARM policy is one of continual development and improvement. For that reason, SECO-LARM
reserves the right to change specifications without notice. SECO-LARM is also not responsible for misprints. All trademarks
are the property of SECO-LARM U.S.A., Inc. or their respective owners. Copyright © 2018 SECO-LARM U.S.A., Inc. All
rights reserved.
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for one (1) year from the date of sale to the original customer. SECO-LARM’s obligation is limited to the repair or
replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if
damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration,
improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is
not operating properly as a result of causes other than defects in material and workmanship. The sole obligation of
SECO-LARM and the purchaser’s exclusive remedy, shall be limited to the replacement or repair only, at SECO-LARM’s
option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential personal or property
damage of any kind to the purchaser or anyone else.
