EnGenius ESR-9752 User manual

ESR-9752
802.11b/g/n SOHO Router
2.4 GHz 11N AP/Router 300 Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
EnGenius Networks Singapore Pte Ltd
215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554
Tel: [phone] Fax: [phone]
Website: www.engeniustech.com.sg Email: [e-mail]
February 17, 2009
PRODUCT DESCRIPTION
ESR-9752 is a 2T2R Wireless Single chip 11N Broadband Router that
delivers up to 6x faster speeds and 3x extended coverage than
802.11g devices. ESR-9752 supports home network with superior
throughput and performance and unparalleled wireless range. With
easy to use on the WPS function, it helps users to connect to wireless
device with just one push button.
There's also a built-in 4-port full-duplex 10/100 Fast Switch to connect your wired-Ethernet devices
together. The Router function ties it all together and lets your whole network shares a high-speed cable
or DSL Internet connection.
PACKAGE CONTENT
1* 802.11n SOHO Router (ESR-9752)
1* 12V/1A Power Adapter
1*QIG
1*CD (User’s Manual)
Technical Specifications
HARDWARE SPECIFICATIONS
PCB dimension 100mm * 90mm
WAN: One 10/100 Fast Ethernet RJ-45
LAN: Four 10/100 Fast Ethernet RJ-45
Rest button
Power Jack
Physical Interface
WPS (WiFi Protected Setup)

ESR-9752
802.11b/g/n SOHO Router
2.4 GHz 11N AP/Router 300 Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
EnGenius Networks Singapore Pte Ltd
215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554
Tel: [phone] Fax: [phone]
Website: www.engeniustech.com.sg Email: [e-mail]
February 17, 2009
Power Status
WAN (Internet connection)
10/100Mbps LAN1~LAN4
LEDs Status
WLAN(Wireless connection)
Power Supply: 200 to 240 VDC ± 10％(ETSI) 100
to 120 VDC ± 10％(FCC)
Power Requirements
Device: 12V/1A
Top Panel (LED status)
WAN 1 ( Link-> blue on, traffic->blink)
LAN 4 ( Link-> blue on, traffic->blink)
WLAN 1 ( Link-> blue on, traffic->blink)
Power/Status 1 ( On-> red Test/reset default->blink)
Power LAN1WLAN LAN2 LAN3 LAN4WPS
WPS
WAN

ESR-9752
802.11b/g/n SOHO Router
2.4 GHz 11N AP/Router 300 Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
EnGenius Networks Singapore Pte Ltd
215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554
Tel: [phone] Fax: [phone]
Website: www.engeniustech.com.sg Email: [e-mail]
February 17, 2009
Rear Panel (Interface)
RF SPECIFICATION
Frequency
Band 2.400～2.484 GHz
Modulation
Technolog
y
OFDM: BPSK, QPSK, 16-QAM, 64-QAM
DBPSK, DQPSK, CCK
Operating
Channels 11 for North America, 14 for Japan, 13 for Europe
LAN 10/100 WAN
DC Jack
ANT ANT
Rest

ESR-9752
802.11b/g/n SOHO Router
2.4 GHz 11N AP/Router 300 Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
EnGenius Networks Singapore Pte Ltd
215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554
Tel: [phone] Fax: [phone]
Website: www.engeniustech.com.sg Email: [e-mail]
February 17, 2009
Wireless
Setting Wireless Mode – 11b/ 11g /11n
Channel Selection (Setting varies by Country)
Channel Bandwidth (Auto, 20Mhz, 40Mhz)
Transmission Rate
-11g: Best. 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps
Guard Interval 800ns Guard Interval 400ns
MCS index 20MHz(Mbps) 40MHz(Mbps) 20MHz(Mbps) 40MHz(Mbps)
0 6.5 13.5 7.2 15
1 13 27 14.4 30
2 19.5 40.5 21.7 45
3 26 54 28.9 60
4 39 81 43.3 90
5 52 108 57.8 120
6 58.5 121.5 65 135
7 65 135 72.2 157.5
8 13 27 14.4 30
9 26 54 28.9 60
10 39 81 43.3 90
11 52 108 57.8 120
12 78 162 86.7 180
13 104 216 115.6 240
14 117 243 130 270
15 130 270 144.4 300
Receive
Sensitivity
(Typical)
IEEE802.11n(2RX)
MCS0/8 @ -91dBm
MCS7/15@ -74dBm
IEEE802.11g (2RX)

ESR-9752
802.11b/g/n SOHO Router
2.4 GHz 11N AP/Router 300 Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
EnGenius Networks Singapore Pte Ltd
215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554
Tel: [phone] Fax: [phone]
Website: www.engeniustech.com.sg Email: [e-mail]
February 17, 2009
6Mbps@ -92dBm
54Mbps@ -75dBm
IEEE802.11b (1RX)
1Mbps@ -93dBm
11Mbps@ -91dBm
Available
transmit
power
IEEE802.11N
MCS 0~15@ >16dBm
IEEE802.11g
6~54 Mbps@ 16dBm
IEEE802.11b
1, 11Mbps@ 19dBm
Antenna *2 Peak Gain = 2 dBi
SOFTWARE FEATURES
Router and Gateway
Topology Infrastructure
Operation Mode AP/Router
LAN DHCP Server
Static Routing Table
UPNP
WAN PPTP
PPPoE
Static IP
DHCP Client
Clone MAC

ESR-9752
802.11b/g/n SOHO Router
2.4 GHz 11N AP/Router 300 Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
EnGenius Networks Singapore Pte Ltd
215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554
Tel: [phone] Fax: [phone]
Website: www.engeniustech.com.sg Email: [e-mail]
February 17, 2009
Router NAT/ NAPT
Static Routing
Dynamic Route
Virtual server mapping
IP address mapping
Port Forwarding
Port Triggering
Special application
ALG(Application Layer Gateway) support (RTP/RTSP, AOL, FTP, ICMP,
WMP/MMS, NetMeeting, SIP)
DNS Relay
DDNS
Time Zone(NTP client)
Firewall Blocking Ping
DoS(Blocking Ping, Port scan, Sync Flood)
MAC / IP Filtering
ICMP Blocking
SPI (Stateful Packet Inspection)
DMZ (Demilitarized Zone) Host
Policy Based Parental Controls
Port Range / Service Filtering
Internet Domain Restriction
Dynamic URL Filtering (OEM subscription service)
VPN VPN pass-through (PPTP, L2TP, IPSEC)

ESR-9752
802.11b/g/n SOHO Router
2.4 GHz 11N AP/Router 300 Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
EnGenius Networks Singapore Pte Ltd
215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554
Tel: [phone] Fax: [phone]
Website: www.engeniustech.com.sg Email: [e-mail]
February 17, 2009
Wireless Power saving(Green technology)
64/128 bit WEP Encryption
WPA Personal (WPA-PSK using TKIP or AES)
WPA Enterprise (WPA-EAP using TKIP)
802.1x Authenticator
Hide SSID in beacons
Wi-Fi Protection Setup (WPS)
WDS
ACL control
Best channel selection
Speed/Bandwidth monitor
QoS WMM
Application base
Priority Queue
Bandwidth Allocation
Management
Configuration Web-based configuration (HTTP)
Firmware
Upgrade
Via webpage upgrade
Auto recovery once firmware upgrade fail
Administrator
Setting
Administrator password change
Idle time out
Reset Setting Reboot
Reset to Factory Default
System Speed and Bandwidth monitoring

ESR-9752
802.11b/g/n SOHO Router
2.4 GHz 11N AP/Router 300 Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice.
EnGenius Networks Singapore Pte Ltd
215 Henderson Road #01-04 Henderson Industrial Park Singapore 159554
Tel: [phone] Fax: [phone]
Website: www.engeniustech.com.sg Email: [e-mail]
February 17, 2009
monitoring
Scheduling Enable Firewall
Enable power saving
Easy access User can type model name and access the main page.
Install wizard Guide user to set-up Router smoothly
ENVIRONMENT & PHYSICAL
Temperature Range 0 to 45° C - Operating, -10 to 70 ° C - Storage
Humidity (non-condensing) 15%～95% typical
Dimensions 125mm (L) x 98mm (W) x 25mm (H)
