Eonon D2207 User manual

Sb02 9201N 4301 1616 0 /4301 J1617 0 /4301 J16179 0 145x210( mm
D2207
PWRPWR OPENOPEN ADJADJ MUTEMUTE BANDBAND BTBT VOL+VOL+VOLVOL
--
Model:D2207
User Manual
Please read this manual before using and
save this manual for furture reference.

Warnings and Precautions
1
Warnings

Never disassemble orservice the unitwithout professional guidance.For details, please
consult a professionalcar shop/dealer.
If the frontpanel or displayis dirty, use aclean silicone clothand neutral detergentand wipe
any moisture fromdiscs.Using a roughcloth and non-neutraldetergent such asalcohol for
cleaning may resultin scratching ordiscoloration to theunit.
If the unitmalfunctions, please referto troubleshooting sectionof this manual.
If the vehiclehas been parkedin hot orcold weather fora long time,please wait untilthe
temperature in thecar becomes normal before operating theunit.
Using an in-carheater in alow-temperature environment maycause condensation toform
inside the unitand upon anydisc in theunit,and therefore preventany disc insidethe unit
from playing. Ifthis happens, ejectand dry wipeoff the disc,then try playing it again. Ifa
disc fails toplay after afew hours, thenturn the unit off and contact an after-sales service
center.
To prevent damage to the unit, avoid hard impactsto the displaywhen it isin the open
position.
To prevent damage to the display, avoid touchingit with sharpobjects.
The display hasits own motor. To prevent damageto that motor, do notpush, pull, orswivel
the display byhand.
During operation ofthe unit, if" " isdisplayed, that operationis unavailable
Operate the unitaccording to thismanual to preventdamaging the unit.The warranty willbe
void if problemsare the result of improper use.
Precautions
2
Warnings and Precautions

Install
Before installing the receiver, fit it in the approximate place in your car and connect the equipment
according to the speakers and electrical connections. When your system is operated properly,
follow the instructions for permanent installation of your system.
INSTALLTHE UNIT
1. Install the snapclose.
2. Lock up the unit in a car through screwdriver.
REMOVE THE UNIT
1. Remove the unit through screwdriver.
2. Remove the snapclose . Make the unit
deviate from the car, then take the connecting pin down.
1. MOUNTING BRACKETS
2. screw
3

General Features
PWR OPEN ADJ MUTE BAND BT VOL+
MIC VOL
-
2345678910 11
1
1
2
3
4
5
7
6
8
9
10
11
Power on/ off
Panel ejection button
Position adjustment button
The microphone
Mute button
Band button
Bluetooth button
Remote control sensor
Reduce volume button
Increase volume button
The reset button
4
12 13
14
15
Note: If thisunit does nothave bluetooth function,
there will beno MIC onthe panel.
Map SD cardslot
SD card slot
Disc eject button
USB port
12
13
14
15

Remote Control
Pull out
Loading and replacingthe battery
f the remotecontrol
doesn't work, change the battery.
DO NOT recharge,disassemble, heat orexpose the batterytofire.
Insert the batteryin proper directionaccording to the
The remote controluses infrared signals,not radio signals,soyou must aim the remote
at the unitwhen using it.
If the batterywill not beenused for amonth or longer, then removethe battery from the
remotecontrol or inserta battery insulator.
DO NOT storethe remote controlunder direct sunlight or in ahigh temperature
environment,otherwise it maymalfunction.
The battery canwork for 6months under normalconditions.I
Only use thelithium, button cellbattery CR-2025.
Store the batteryout of thereach of children to avoid accidents.Should a
child swallow abutton cell battery, seek medicalattention immediately!
(+) and (- ) poles.
Notes for usingthe remote control:
5

6
Remote Control
5
1
3
4
2
MuteMute
Sub-TSub-T
BandBand
APSAPSAPSAPSAPSAPS
EQEQEQEQ S TS T
R/LR/L
SRCSRC PWRPWR
112233
445566
778899
00
EnterEnter
SELSEL
CLKCLK
TitleTitleTitleTitle
AFAF
TATA
PTYPTY
RPTRPT
PBCPBC
OSDOSD
I D3I D3
##
ABCABC DEFDEF
GHIGHI JKLJKL MNOMNO
PQRSPQRS TUVTUV WXYZWXYZ
RO/SNRO/SN
10+10+
**
LanguageLanguage
7
6
RECREC
Button and Function
[PWR] Button: Power
[REC/Sub-T]Button: Transfer recording
/Language switch
[MUTE] Button: Mute
[SRC] Button: Playsource switch
Note: Remote picture justfor confernce.
1
[BAND] Button: Bandswitch
[APS] Button: Scan
[ST/RPT] Button: Stereoswitch/Repeat
2
[ ]Button: Play/Pause
[ ]Button: Stop
[Title] Button: Title Menu
[ENTER] Button: Play/Confirm
[ ][ ][ ][ ]Button: Up/down/left/rightbutton
[0~9]Button:0~9
[RO/SN] Button: Radioscan
[AF] Button: Searchstations automatically
[TA] Button: Traffic broadcast
[PTY] Button: Programstyle
[ ]Button: Forward/Next chapter
[ ]Button: Rewind/Lastchapter
[+/-]Button: Increase/recluce volume
[SEL] Button: Systemsetting
[CLK] Button: Clockdisplay
[EQ] Button: Sound effect
[R.L/LANGUAGE] Button: Left/right sound
track switch dialoguelanguage.
3
4
5
6
7
[ ] Button:Ring on
[OSD/ Id3] Button:Screen Display/ Id3
information
[ ] Button:Ring off
Note: If this unit doesn't have RDSfunction, AF/
TA/PTY are invalid.
If this unit doesn't have bluetooth function,
[ ] / [ ] are invalid.

Basic Operation
Press [ADJ] button repeatedly canadjust
the screen angle gradually. The unit has 3
angles for adjustment. Each timeyou press
thebutton, the screen will movefrom one
angle to another angle onthe same
direction. The
screen angle will
move on the
opposite
direction
if you operate it again.
Press [ADJ] button can adjust angle of screen:
Turn on the unit again, theanglewill back to
original setting.
Display position adjustment
SRC
OPEN
Press [OPEN] button, the screen will turn down,
press again,it will back to originality.
Volume
Increasing Volume:
Decreasing Volume:
Press the [VOL+]buttonto increase the
volume.
Press the [VOL- ]button to decreasethe
volume
MUTE
Press this buttonto turn offvolume and again
to resume.
Eject
EJECT: Press [ ] to exit the disc.
NOTE: About 10 seconds after the disc ejected, if not
taken out, the disc will be absorbed in again.
Press [SRC] buttonshortly will turnthe unit on.
Press [SRC] buttonshortly turn off.
Adjust Angle
CAUTION
Do not placeany object onthe screen, or
push it rudely.
Do not movethe screen rudely.The movable
range of the
screen may belimited to differenttypes of car
and install positions,etc.
7

Setup Operation
Enter the mainmenu, touch thesetup
button will display:
SETUP
BASS 0
TREBLE
- 07
BALANCE R 06
AUDIO
FADER R 06
EQ FLAT
BRIGHT 14
COLOR
14
CONTRAST 13
VIDEO
MODE USER
RADIO USA
BEEP ON
CLOCK 00:00
BASIC
Video mode:
Audio mode:
Basic mode:
Menu operation
BRIGHT 14
COLOR
14
CONTRAST 13
VIDEO
MODE USER
Touch [ ]/[ ] to choosemenu.
Touch [ ]/[ ]to adjust parameter.
Touch [ ]to back mainmenu.
Menu operation
BRIGHT 14
COLOR
14
CONTRAST 13
VIDEO
MODE USER
Touch [ ]/[ ] to choosemenu.
Touch [ ]/[ ]to adjust parameter.
Touch [ ]to back mainmenu.
Menu operation
BRIGHT 14
COLOR
14
CONTRAST 13
VIDEO
MODE USER
Touch [ ]/[ ] to choosemenu.
Touch [ ]/[ ]to adjust parameter.
Touch [ ]to back mainmenu.
Video setup
Bright Color Contrast.
Mode
STAD USER
BRIG SOFT
Audio setup
Audio setup Bass Treble Balance Fader
setup between 7.
EQ setting
Basic setup
Loud ON and OFF
Beep ON and OFF
Time Adjust press [ ]or[ ] buttonto
select hour/minute thenpress [ ]or[ ]
button to setup.
FLAT
ROCK
POPCLAS
NORM
+
8

Radio Operation
AF TA PTY
BAND
FM1 FM2
AM1AM2
FM3
Press [BAND] on the screen to select among
three FM or two AM bands.
(FM1-FM2-FM3-AM1-AM2)
Note: If the unitdoesn't have RDSfunction,
the touch-screan won'tshow "AF, TAand PTY".
Band Tune
Manually Tune
Automatically Tune
Press[ ] button: adjust to higher
frequency.(such as87.5,87.55...)
Press[ ] button: adjust to lowerfrequency
(such as 105.5,105.0...)
Holding down the [ ] button: search higher
frequency
station, and will stop whenmeeting one.
Holding down the [ ] button: search lower
frequency
station, and will stop whenmeeting one.
Press [APS] icon
Seek Tune:
Under radio playingmode, long touch
[APS] icon canseek and storestrong
frequency stations automatically.
Select station
9

Radio Operation
AF(Alternative Frequency)
TA(Traffic announcement)
Press TA, the unit willprior to seek the traffic information.If the machinereceives the traffic
information, it willchoose this signaland quit other radio signal orCD program. Ifpress TA
again, other programwill recover andthe traffic information program will quit.
PTY(Program type)
Turn on PTY , then press PTY and 1-6 buttonsto choose onecertain program style.
After this, theunit will scanthe same style programs automatically. Such as select News
programs. The unitwill only scanNews programs.
Among AF, TAand PTY, TAhas the absolutepriority to bechosen.
Turn "AF",the unitwill switch tothe stronger signal of thesame stationautomatically.
Note: If the unitis without RDSfunction, pls skipthis page.
10

Note: when play DVD not have multi caption this
function invalidation.
OFF
1/3
1/3
Play operation
TITLE
T 001/003 TITLE C 002/025
BACK
REP
00:33:11/01:45:44
DVD-V
OFF
1/2
BACK
REP
00:33:11/01:45:44
DVD-V
OFF
Note: Because the different situation of Disc REC,
some of the CD-R,CD-RW,DVD-R,DVD-RW,
DVD+R,DVD+RW Disc may can not be readed.
And the Disc without final treatment can not be
readed too. Regarding the final treatment,
please make conference to the guide of REC
set or REC manual.
TITLE: In play mode, press [TITLE] on the screen
or remote control to back to the title menu,
and re-select the items needed.
REP
BACK
Insert DVD disc, touchscreen will show
menu as follows:
Repeat mode:
CHAPTER/OFF/TITLE /CANCEL.
When playing DVD, press [REP], you can
switch on
Back to Mutimedia:
When playing DVD, press [BACK], it will
back to player media.
OFF
Caption choose
Caption choose: If DVD contain several
langrage you can switch
caption.
Choose angle
Choose angle: If DVD support multi angle
function, touch [ ]or press
[ANGLE] icon or remote, you
can switch different angle.
Note: when play DVDnot have multi angle, this
function invalidation.
Volume Control
Volume control: Touch [ ], can switch,
between 1, have volume and
music ; 2, not have volume
but have music;
3, volume and music separate.
Note: general DVD onlyhave two mode.
You can choose any icon to play or setup.
OFF
11

Play/pause: Press [ ] button to play or pause.
MUSIC
NONE
FILE NAME: 004 MP3
ALBUM: NONE
00:00:30/00:04:12
REPEAT BACK
PLAYING
001 001 MP3
001 CD
MUSIC
002 002 MP3
003 003 MP3
004 004 MP3
005 005 MP3
Back
MUSIC
CDDA
TRACK12
00:00:30/00:04:12
REPEAT BACK
PLAYING
001 001 MP3
001
MUSIC
002 002 MP3
003 003 MP3
004 004 MP3
005 005 MP3
Back
Media
Insert MP3 disc,touchscreen will show
menu as follows:
Insert CD disc,touchscreen will show
menu as follows:
Chapter choose: When play CD/MP3,
press[ ] to choose the pre music, press [ ]
to next music.
Select chapter or section:
press [ ] to choose the last chapter; press [ ]
to choose the next chapter.
In the DVD mode,
REPEAT
T 001/003 STEREO
PBC
BACK
REP
00:33:11/01:45:44
VCD
PBC
REP
Insert VCD disc,touchscreen will show
menu as follows:
Repeat mode:
TRACK/OFF/FOLDER/ALL.
When playing DVD, press [REP],
you can switch on
PBC menu: when playing VCD, press [PBC],
you can switch between ON/OFF/CANCEL.
Repeat mode: when playing VCD, press [REP],
you can switch between TRACK/OFF/
ALL/CANCEL.
Track switch
Track switch: you can switch STEREO/LEFT/
RIGHT by touch the right up letter.
12
Play operation

USB/SD play opration
USB SD
USB/SD operation
Press [ ]button to play or pause.
PLAY/PAUSE:
Under USB or SD play mode, press[ ] button to select
tracks.
,
Select:
CHAPTER
TITLE CANCEL
OFF
Note: when playing, press[BAND] to radiomode.
USB/SD mode
Inset USB/SD,the play will to the USB/SD playing mode
antomaticly.
USB/SD mode
When playing, you can switch the function by touch
[REPEAT].
Repeat mode:
13

The Bluetooth is wireless modeof transmission in short distance.ThroughBluetooth function,
the DVD unit establishes connectionwith Bluetooth handset. And then,these units can
realize mutually contrdling and filetransfering.
Press [BT] ortouch BT icon, can enter BTmode when calling.
BT Choose
Bluetooth
Working mode of Bluetooth
Bluetooth has thefollowing functions:
A: Paring
'
Make DVD Bluetoothfunction as handsets facility through pairing.
B: Connecting
After connecting withthe handset,you canoperate the mobilephone through
DVD unit(such asH,F, call, callrecord etc.)
BT Choose:
(NO.1)
Paring
Phone set pairingstep as follows:
A: Turn onBluetooth, then touch On/Off icon to turn on this function.
B: Turn on Bluetooth function .
C: When the mobile phone set finds the signal, input pairing number. Initial Pairing
Code Number 0000
D: After pairing, TFT screen shows pairing succeed and quit the pairing.
'
handsets
NO.2
(NO.2)
14

13590201359020
13590201359020
13590201359020
Mobile phone
After connected, you can make phone call through,
touch screen or phone record.
A: Making mobile phone call
After making phonecall, the [ ]will shining.
B: Making touchscreen call
Input the numberson the screen, press [ ]
con can correctthe numbers;
Press [ ]icon to answerphone call;
Press[ ] iconto cancel orhang up.
Answering
Answering functions asfollows:
A: After connected, the unit canuse the
telephone function.
B: When thereis a phonecall, the Bluetooth
will switch tophone function andshow the
calling number automatically.
C: Touch Transfer icon canswitch to phone
answer mode. Touch it againcan return to
Bluetooth function ofthe unit.
Hang up
Youcan press the[ ]button tohang up.
Note: If the unitdoes not havethis function,
pls skip it.Somemodels of mobilephones are
not supported bythe Bluetooth moduleof this
unit.
15
Bluetooth

Note: If theunit does nothave this function,please skip thispage.
ESC
TV
AMS PREV NEXT
TV
TV tuner
TV operation
You need install TV antenna, when receive program.
TV mode:
Press [MENU] enterinto main menu,then press TVicon to enter.
[PREV]: choose channelup.
[NEXT]: choose channeldown.
Press [AMS] canseek TV programsand restore them
automatically.
[ESC] prss [ESC] backTV mode tomain menu.
Without touch function, without these icons.
Channel seek:
Channel choose:
Back:
16

Electric Connection
GPS Antenna
Video in(YELLOW)
Video out(YELLOW)
Front right RCA out(RED)
Front left RCA out(WHITE)
Back a car video in(YELLOW)
Subwoofer(BROWN)
AUX left in(WHITE)
AUX right in(RED)
Back right RCA out(BLUE)
Back left RCA out
WHITE/BLACK
GRAY
To front left speaker
To front right speaker
To rear left speaker
To rear right speaker
GREEN
Ignition wire (RED)
Battery wire+12V (YELLOW)
Battery
Car fuse box
(main fuse)
Ignition key
sw tchi
Ground wire(BLACK)
WHITE
GRAY/BLACK
GREEN/BLACK
PURPLE
PURPLE/BLACK
Connect control for antenna
Reverse
GRAY
BROWN
BLUE
ORANGE Dimmer
FRONT.L
FRONT.R
REAR.L
REAR.R
Remote control for amplifier. PINK
TV antenna plug
Fuse(10A)
Radio Antenna
(PURPLE)
Parking-
Connect to switched side of
parking brake circuit(-)
GRAY
GRAY
BLACK
GRAY
GRAY
GRAY
BLACK
BLACK
BLACK
GRAY
17

The use of any accessories except
of those provided might result in damage
to the unit .Make sure onlyto use the
accessories shipped with the unit ,as
shown above.
Accessories
The included attachmentsof the unitare as belowsheet:
GPS antenna.......... ..........................onepiece
USB connected wire..........................one piece
Mounting brackets............................two pieces
Screw............................................... six pieces
What appears tobe trouble isnot always serious.Please check thefollowing points
before calling aservice center.
Troubleshooting
Familiar characters and their meanings
Characters
Causes Remedies
NO Disc
Bad Disc
Unkown Disc
Region Error
Disc is too dirty.
Disc is inserted upside down.
No disc in the unit.
Disc is extreme dirty.
Disc is inserted upside down.
The disc is not compatible with
the unit.
The disc's region code is not the
same as the unit's.
Clean the disc or change the disc.
Insert the disc correctly.
Insert a disc.
Clean the disc or change the disc.
Insert the disc correctly.
Clean the disc.
Clean the disc.
18
