Bump Bar –KB1700
About this Guide
This guide consists of 3 sections:
•Overview –Discusses the supported KB1700.
•Bump bar Functionality - Describes how to use the bump bar with the KDS.
•Appendix A –Key map for the KB1700.
This guide is relevant for:
KDS FW: v2.50 and above
KDS Utility (Windows): v2.5.0.0 and above
Overview
The bump bar allows the operator to bump off orders and interact with the KDS screen.
It connects to the KDS printer or controller via USB. Part number for the KB1700 bump
bar supported:
Logic Controls KB1700U-D-BK
This part number is a Black, USB bump bar with Legend sheet D:
Figure 0.1 –KB1700U-D-BK Bump Bar
Note: The bump bar is programmable so if you have a KB1700 with a different legend
sheet you can consult the appendix for the key mapping. How to program is beyond the
scope of this document.

Bump Bar –KB1700
Quick User Manual
111-38-QUM-007
Rev 2.50
Bump Bar Functionality
Main Screen Operations
Bumping orders in tiles 1 to 9:
Single press of the key to will bump the order associated with that tile
number.
Bumping orders in tiles 10 to 19:
1. Press the 0/10 key:
2. Single press of the key to to selecttheseconddigit0–9.
Bumping orders in tiles 20 to 21:
1. Press the 0/10 key:
2. Press
3. Single press of the key to toselecttheseconddigit0–1.
Force Bump:
Pressing followed by the tile number will force bump the order associated with
that tile. This is useful in the rare circumstance an order becomes stuck on the Expo
screen.

Bump Bar –KB1700
Quick User Manual
111-38-QUM-007
Rev 2.50
Viewing Off Screen Orders
To see new orders that are not visible on the main screen press:
Will shift tiles (not orders) one at a time. To shift tiles back one at a time press:
Scroll Mode
Scroll mode allows the user to select individual items within an order for the purpose of
bumping only that item or displaying that item’s recipe or instructions.
Entering/Exiting Scroll Mode
Press to enter/exit Scroll mode. Scroll will appear on the KDS screen header
to indicate you are in Scroll Mode, and disappear when Scroll mode is exited.
Selecting Tiles 1-9 in Scroll Mode
Press the tile number to to select the tile associated with the
desired order. The first item in that tile will become highlighted.
Selecting Tiles 10-19 in Scroll Mode
Press the tile followed by the second digit to to select the tile
associated with the desired order. The first item in that tile will become highlighted.

Bump Bar –KB1700
Quick User Manual
111-38-QUM-007
Rev 2.50
Selecting Tiles 20-21 in Scroll Mode
Press the tile .
Press ..
Press to select tile 20 or to select tile 21. The first item in that tile will
become highlighted.
Selecting the next item in an order
Press to select the next item in the order. Only items within the current
order are selectable.
Selecting the previous item in an order
Press to select the previous item in the order. Only items within the current
order are selectable.
Bumping/Un-bumping an item
Press to bump the item and associated modifiers. If it is the only item in an
order or the last item to be bumped off the entire order will be bumped off and Scroll
mode exited. If there are other un-bumped items in the order then the item will become
struck-through. Items can be un-bumped by pressing Bump again.

Bump Bar –KB1700
Quick User Manual
111-38-QUM-007
Rev 2.50
Viewing Recipe/Instructions for an item
Press to bring up the recipe/instructions for the item currently selected. It
will appear in a popup window which can be removed by pressing Summary again.
Order Recall
Orders that have been bumped can be viewed in a list in the Order Recall window.
Opening/Closing the Order Recall Window
Press to open/close the Order Recall Window. Bumped orders appear
in a list –with the last bumped order at the top and highlighted.
Selecting Orders
To select the next order press To select the previous order press:
Recalling an Order
To recall an order, select the desired order and press:
Reprinting an Order
Press to re-print the bumped order. Note the printing functionality must
be enabled for this to work.

Bump Bar –KB1700
Quick User Manual
111-38-QUM-007
Rev 2.50
Expanded Order View
An order can be selected to be viewed in its own pop-up window. This is convenient if
orders span multiple windows and it’s desirable to see the entire order in its own window
or if an order in the last tile extends off screen.
Selecting an Order
Press followed by the tile number for the order:
Selecting Tiles 1-9:
Press the tile number to to select the tile associated with the
desired order.
Selecting Tiles 10-19:
Press the tile followed by the second digit to to select the tile
associated with the desired order.
Selecting Tiles 20-21:
Press the tile .
Press ..
Press to select tile 20 or to select tile 21.

Bump Bar –KB1700
Quick User Manual
111-38-QUM-007
Rev 2.50
Appendix A –Key Mapping
KB1700’s that may have other template/legends installed can be reprogrammed
according to the mapping in the following table using KB1700 keyboard USB Software
Utility:
Top Row Keys
Bottom Row keys
Key name
Key command
Key name
Key command
BUMP (Bump)
[Ctrl]
1
[1]
RECALL (Recall)
[PAD-]
2
[2]
SUM (Summary)
[Space]
3
[3]
PAGE (Scroll)
[ArrowDown]
4
[4]
↑ (Scroll up)
[ArrowLeft]
5
[5]
↓ (Scroll down)
[ArrowRight]
6
[6]
7
[7]
8
[8]
9
[9]
10
[0]
REDRAW (Enter)
[Enter]
