Ergotron StyleView SV21-91008 User manual

888-SV-21MN-00 rev C
1
1
1 Riser
2 Notebook Enclosure
3 Worksurface
4 Electronic Autolock Drawer
5 Tilting Keyboard Tray and Wrist Rest
6 Right/Left Mouse Tray and Holder
7 Cable Management
8 Riser Lift Brake
9 Locking Front Casters
10 Scanner Holder Bracket
11 Ergonomic Rear Handle
12 Storage Basket
Features - SV21-91008
Please read all parts of this guide.
When set-up is complete, do not discard
this guide. The guide should be led in a
secure place for future reference.
For more information
on this or other Ergotron
products, visit our website:
www.ergotron.com
50.8"
1290 mm
22.3"
566 mm
38"
965 mm
28"
711 mm
18"
457 mm
24"
610 mm
Vertical Adjustment Range: 20" (508 mm)
Tilt: ±15° Viewing Angle
Based on a 10" High x 1/2"
deep Notebook
STAND SIT
18"
457 mm
21"
533 mm
v
157 mm
v
533 mm
70.5"
1791 mm 44"
1118 mm
Riser at Full Height
Riser in Lowest Position
17
"
432 mm
< 1.5"
< 38 mm
12.5"
318 mm
Maximum
Notebook Size
Dimensions
Cart Specications
Range of motion
CAUTION: The lift brake locks vertical lift of riser during normal use but it DOES NOT increase
load capacity. DO NOT load riser with equipment totalling more than the maximum weight
capacity specied by Ergotron. Ensure optimum lift function by testing and if necessary, re-adjusting
tension whenever the weight mounted to the riser changes (i.e., equipment is removed or added). See
"Set Riser Lift Tension" adjustment instructions in step 7 on page 4.
Weight capacities
Keyboard Tray Tilt: -12°
Notebook 6-18 lbs 2.72-8.26 kg
Drawer 4 lbs 1.8 kg
Worksurface 2.5 lbs 1.1 kg
CPU Holder 25 lbs 11 kg
Keyboard Tray 2.5 lbs 1.1 kg
Mouse Holder .5 lb .23 kg
Scanner Holder .5 lb .23 kg
Basket 5 lbs 2.3 kg
EN

888-SV-21MN-00 rev C
2
8
a Make sure riser is locked (lift brake down), then remove the two
capped screws anchoring the riser to the tower.
bSave the screws and caps in the provided
bag to be used if the riser needs to be
anchored to the tower at a later time.
2
Remove anchor screws connecting riser to tower.
riser
tower
a
b
WARNING: The riser can move up on its own
very quickly when a counter-balancing force is
removed! Therefore, always lock the riser down with
the lift brake when adding or removing equipment
and when removing or inserting the anchor screws
which secure the riser to the tower during ship-
ping. Failure to lock the riser at such times can
result in serious personal injury and possible
damage to cart and/or equipment.
a Lift up work surface and place notebook into enclosure.
b Attach adhesive velcro to bumpers and adhere to enclosure
to keep notebook in place.
3
Attach notebook
ab
Mounting Equipment
4
Personalize autolock drawer code.
a Unlock drawer with master key (identical dupli-
cate keys are provided). Pull drawer open to access
battery box; remove box cover; insert the four pro-
vided AA batteries. Replace cover and close drawer.
b Remove the Master Code sticker located near
the number pad and place it in the box at right for
safe keeping and future reference.
cProgram Personal Code:
1 Enter Master Code
2 Press 3 and 5 at the same time
3 Enter a new personal code - any
series of five numbers
The drawer is now programmed to unlock
when either the personal code or the
master code is entered. The drawer remains
unlocked for 2 minutes and the number 5
remains lighted. At the end of two minutes, the
drawer automatically locks. You can manually
lock the drawer at any time by pressing 1 and 2
on the number pad simultaneously.
*Store this guide along with the master keys
in a secure place to prevent unauthorized ac-
cess to autolock drawer.
a
Master Code
Four AA
1 2 3 4 5
b
c
1
Prepare for cart set-up.
2
1
a Gather tools for cart
set-up.
b To prevent the riser
from moving during
set-up, lock riser by
pushing the lift brake
down.
a
b
• 9/16"
• 3/8" (10mm)

C
888-SV-21MN-00 rev C 3
Mounting Equipment
a Apply double-sided tape to bottom of wrist rest and place on tray.
bUse hook & loop tape to x keyboard on tray.
cSnap mouse pouch on right or left side of tray.
dAttach reference card to handle with cable tie.
5
Mount keyboard accessories & reference card
*For optimum bonding,
clean all surfaces with alcohol
wipe and allow to dry for one
minute before applying tape.
Alcohol Prep
Sterile
888-24-039-00revA
2
1
3
5
4
6
1
6
3
5
2
Moving
stow - before you go
1 Lookwhere you’re going: unlock
lift brake and lowerriser for an unob-
structed view.
2 Tuckaway open trays and return
mouse,scanner and other accessories
totheir places.
3 Locklift brake to k eep riser down
and equipment securewhile car t is in
motion.
4 Unlock both frontcasters.
5 Pushcar t from rearwith elbows
bentat about 90° to maximize control
and minimizemuscle strain.
6 Don’trun out!
Beforemoving, make sure cord is
unplugged fromoutlet and hook ed
tobask et forsafe travel. Remember,
chargebatter y fully 100% every day!
Working
customize - to your size
1 Set monitor screenabout one
inch aboveeye level - unlock brake
toallow riser to lift or lower as shown
below.
2 Tilt screenfor comfortable view-
ing and toreduce eye and neck strain.
3 Pullkeyboard tray forward and
position mouse trayand mouse pouch
on right or left,as needed.
4 Workwith elbows bent at about
90° tominimize muscle strain.
5 If the riser movesup and down
with difficulty,or if it drifts out of set
position,consult the product manual
foradjustment information.
6 Stay in charge!
Poweredcarts should be plugged into
outlet as often as possible to keep bat-
tery charged and computer running.*
RiserLift Brake Operation
“Acharged battery is a happy battery! ”
4
Up = Unlocked Down = Locked
Formore information on thisor other
Ergotronproducts, visit our website:
www.ergotron.com
*PowerCart Users: refer to the other side of this
cardto learn how to respond to RUI messages about
thestatus of your battery charge!
Basic Drawer Functions
To Unlock Drawer - 3 methods
• Key - turn counter clockwise 1/8 turn
• Enter Master Code
• Enter Personal Code
To Program Personal Code
1 Enter Master Code
2 Press 3and 5simultaneously (while blinking)
3 Enter new code - any series of five numbers
To Erase Personal Code
1 Enter Master Code
2 Press 3 and 5 simultaneously (while blinking)
3 Press 1 and 2 on number pad at the same time
To Lock Drawer - 2 methods
• Press 1and 2on number
pad simultaneously
or
• Wait two minutes for
drawer to lock automatically
Drawer Troubleshooting
• Number pad numbers are dark
-Touch anywhere on number pad to activate back-light, (drawer remains locked until you
enter valid code)
-If touching number pad does not activate back-light, batteries may need to be replaced,
see instructions 4a.
• Number 4 on number pad is blinking = Low Voltage Warning
-Batteries may need to be replaced, see instructions 4a.
• Drawer won’t open when Personal Code is entered
-Test system by entering Master Code. If drawer doesn’t unlock,
replace batteries as instructed 4a.
Low Voltage Alert
Master Code
Master Code
New Code
Master Code
Personal Code
Manual Auto

888-SV-21MN-00 rev C
4
8
Cable Routing.
6
Cable Routing
a Cover cables on riser. b Attach tower cover. c Attach top of riser cover. d Lock riser cover.
8
Attach covers.
dcab
a Unlock riser (lift brake up).
b Move the riser up and down. If you feel excessive resistance within the range of motion, or if the
riser does not stay in the desired position, the lift tension should be adjusted.
c Remove tower cover.
7
Set riser lift tension.
b
IMPORTANT
Lift riser to highest position before making
any adjustments to the tension nut!
a
d
e
9/16"
d Lift riser to highest position on tower.
e Turn tension nut up or down as needed.
fAfter adjustment, check lift tension by moving riser up and down (as described in step 7b, above.
If more adjustment is necessary, continue turning nut until the riser lift is satisfactory.
c
Decrease Lift
turn toward MINUS sign
Increase Lift
turn toward PLUS sign
Riser Lift Adjustment
a Remove side covers of cable box mounted under the
drawer. Route the computer cables down riser and into the
cable box. Route keyboard and mouse cables into the cable
box. Use cable box to store excess cable and power bricks.
b Replace cable box side covers. Move riser up
and down to ensure cables are routed properly
and movement of the riser is not restricted.
Adjust if necessary.
CAUTION: Route cables on Cable Channel
(right) side of Cart only.
Do not store power brick
inside base covers. Storing power brick inside base
covers may damage electrical wires and interfere with
riser operation, resulting in damage to both Cart and
mounted equipment or injury from electrical shock.
Set-up is complete - your Cart is ready to go!
The following pages contain important guidelines for safe
operation and maintenance of the SV Cart.
Refer to our website for more information about the StyleView Cart and
other Ergotron products.
www.ergotron.com

C
888-SV-21MN-00 rev C 5
Working
customize - to your size
1 Set monitor screen about one
inch above eye level - unlock brake
to allow riser to lift or lower as
shown below.
2 Tilt screen for comfortable
viewing and to reduce eye and neck
strain.
3
Pull keyboard tray forward and
position mouse tray and mouse
pouch on right or left, as needed.
4
Work with elbows bent at about
90° to minimize muscle strain.
5 If the riser moves up and down
with diculty, or if it drifts out of
set position, consult the product
manual for adjustment information.
6 Stay in charge!
Powered carts should be plugged
into outlet as often as possible to
keep battery charged and computer
running.
2
1
3
5
4
6
Moving
stow - before you go
1 Look where you’re going: unlock
lift brake and lower riser for an unob-
structed view.
2 Tuck away open trays and return
mouse, scanner and other accesso-
ries to their places.
3 Lock lift brake to keep riser down
and equipment secure while cart is in
motion.
4 Unlock both front casters.
5 Push cart from rear with elbows
bent at about 90° to maximize con-
trol and minimize muscle strain.
6 Don’t run out!
Before moving, make sure cord is
unplugged from outlet and hooked
to basket for safe travel. Remember,
charge battery fully 100% every day!
1
6
3
5
2
4
Cart Ergonomics

888-SV-21MN-00 rev C
6
8
Equipment Changes and Cart Transfers
Always anchor the riser to the tower BEFORE making changes to cart such as:
• removing or adding equipment
• preparing the cart for transit to another site
See step 2 on page 2 for more information.
Cleaning and Maintenance
The following procedures are not guaranteed to control infection. The hospital infection control admin-
istrator or epidemiologist should be consulted regarding cleaning procedures and processes.
To avoid risk of electric shock, do not expose electrical components to water, cleaning
solutions or other potentially corrosive liquids or substances.
Do not immerse Cart or Cart components in liquid or allow liquids to ow into the Cart.
Wipe all cleaners o surface immediately using a damp cloth. Thoroughly dry surface after
cleaning.
Do not use ammable cleaners on Cart surfaces due to close proximity of electrical
power and equipment.
All paints and plastic Cart components will withstand cleaning by most commonly used, diluted, non-
abrasive solutions such as quaternary ammonia compounds, ammonia enzyme cleaners, bleach or
alcohol solutions.
• Pen and permanent and dry erase markers can be removed with 91% isopropyl alcohol and a soft
cloth.
• Iodine stains can be removed with commonly used cleaners and a soft cloth.
• Never use steel wool or other abrasive materials that will damage the surface nish.
It is recommended that any cleaning solution be tested on a small, inconspicuous area to ensure
surface is not harmed.
Adjustment, Service, Replacement - DO NOT attempt to adjust, service or re-
place any part of the StyleView Cart unless directed to do so through Ergotron-approved documenta-
tion (i.e. installation instructions). Only Ergotron, Inc. or an Ergotron-certied entity may adjust, service
or replace StyleView Cart components. If any component on the Cart is missing or damaged, the Cart
must not be used, contact Ergotron Customer Care immediately to request a replacement part.
Cables - Keep cables neatly organized on the Cart (a variety of solutions are provided with
your cart for this purpose). Excess cables should be routed away from moving components with cable
clips. Review Cable Routing section of this guide, or contact Ergotron Customer Care for more informa-
tion.
Casters - Check casters periodically to make sure they are clean and free of debris that would
prevent smooth travel. Avoid moving Cart across uneven, dirty or damaged surfaces.
Customer Equipment- Make sure equipment is balanced and mounted se-
curely to Cart. Do not reposition Cart components on riser or tower unless instructed to do
so in the installation instructions. Moving Cart components too high or too low on the Riser
may create an unstable condition, leading to equipment damage or even personal injury.
Contact Ergotron Customer Care for information about moving Cart components.
Cart Stability - When moving cart, the riser MUST be in the lowest position and the lift
brake MUST be locked to protect against possible tipping. Failure to lock the riser in the lowest position
with the lift brake may result in personal injury or equipment damage.
CAUTION: The lift brake helps stablilize the worksurface and keyboard tray during normal
use but it DOES NOT increase load capacity. DO NOT load riser with equipment totalling more
than the maximum weight capacity specied by Ergotron. Ensure optimum lift function by test-
ing and if necessary, re-adjusting tension whenever the weight mounted to the riser changes
(i.e., equipment is removed or added). See "Set Riser Lift Tension" adjustment instructions in step
7 on page 4.
CAUTION: Do not operate StyleView Cart with missing or damaged components! Do not
remove, modify or substitute Cart components without consulting Ergotron. If you encounter
problems with Cart installation or operation, contact Ergotron Customer Care.
CAUTION: DO NOT overtighten fasteners. Overtightening may cause damage to your
equipment.
CAUTION: Riser is under spring tension. Rapid rise or fall of riser can occur prior to
counterbalancing. Lock riser down with Brake before removing Riser Anchor Screws or loading/
unloading equipment. Do Not put yourself in path of movable riser or mounted components until
riser is properly counterbalanced. Failure to comply with this caution may result in equipment
damage or personal injury.
CAUTION: DO NOT loosen, tighten or remove any other nuts or bolts on the riser or top of
tower. Tampering with nuts or bolts may result in an unstable Cart, leading to equipment damage
and/or personal injury.
WARNING: Unlock Lift Brake before moving work surface! Moving work surface while Lift
Brake is locked may cause serious damage to Lift Engine.
WARNING: In the event that repair of the StyleView Cart is needed, contact Ergotron Cus-
tomer Care immediately. Cart repair can only be performed by Ergotron, Inc. or by an Ergotron
authorized agent.
CAUTION: Route cables on Cable Channel (right) side of Cart only. Do not store power brick
inside base covers. Storing power brick inside base covers may damage electrical wires and interfere with
riser operation, resulting in damage to both Cart and mounted equipment or injury from electrical shock.
Safety Alerts Associated with this Product
The following Warnings/Cautions appear in this reference guide or on the cart:
NOTE: Failure to adhere to these guidelines may result in equipment damage or personal injury.
Cart Safety Guidelines

C
888-SV-21MN-00 rev C 7
Product Marks
Color Symbol Signal
Word Level of Hazard
Red DANGER Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Orange WARNING Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Yellow CAUTION Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
None CAUTION
Used without the safety alert symbol indicates a poten-
tially hazardous situation which, if not avoided, may
result in property damage.
Red,
Orange
or
Yellow
Electrical Indicates an impending electrical hazard which, if not
avoided, may result in personal injury, re and/or death.
Hazard Symbols Review
The Meaning of Symbols appearing in this Guide, on the Cart or on the Power System
These symbols alert you to a safety condition that demands your attention. You should be able to
recognize and understand the significance of the following Safety Hazards if you encounter them on
the Cart or within Cart documentation such as this Set-up Guide.
Troubleshooting
visit our website:
www.ergotron.com
Symptom Probable Cause Solution
Riser moves up or
down too easily or with
difficulty; or equipment
on riser does not stay
in desired position.
Improper riser
counterbalance.
Follow "Set Riser Lift Tension" Adjustment
procedure in step 7 on page 4.
Mounted equipment
exceeds weight capacity.
Compare weight of mounted equipment to
recommended weight capacities in specifications
section.
Contact Ergotron Customer Care: North America
1-800-888-8458; Europe [phone]
The autolock drawer has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Changes or modications not expressly approved by Ergotron, Inc.
could void the user’s authority to operate the equipment.
Ergotron's Autolock Drawer - FCC Compliance

888-SV-21MN-00 rev C
8
