Ergotron SV DC Power System User manual

1 of 6
888-97-392-G-00 rev. C • 08/19
SV DC Power System
www.ergotron.com | USA: 1-800-888-8458 | Europe: [phone] | China: 400-120-3051 | Japan: [email protected]
English, Español, Français, Deutsch, Nederlands, Italiano, Svenska, 日本語, 汉语
AB C D
1
2
M5 x 10mm
M6 x 10mm
2x 2x 1x
5x
2x
24
1x
1x
M3 x 25mm
User's Guide
English
For the latest User Installation Guide please visit: www.ergotron.com
Components
Attach to Rear of Cart Attach to Front of Cart
(Only for carts with no drawers)
Tools Needed

2 of 6
888-97-392-G-00 rev. C • 08/19
2
1
180˚
abc
d
ba
c
M5 x 10mm
2x
Attach to Rear of Cart

3 of 6
888-97-392-G-00 rev. C • 08/19
a
b
cd
3
41x
5x
Attach to Rear of Cart
Leave 20" (508 mm) of cable slack
to allow cart to raise and lower
through its full range of motion.
END OF INSTALLATION

4 of 6
888-97-392-G-00 rev. C • 08/19
M6 x 10mm
2x
1
21x
5x
3
1x
1x
M3 x 25mm
ab
Attach to Front of Cart
(Only for carts with no drawers)
Route cables with wrap and ties.
Attach the Travel Stop
bracket to the lift engine
to keep SV DC Power
System from hitting the
base.

5 of 6
888-97-392-G-00 rev. C • 08/19
14mm (9/16")
ab c
3Adjustment Step
Increase Lift Strength
If the mounted weight is too heavy or this
product does not stay up when raised, then
you'll need to increase Lift Strength:
Decrease Lift Strength
If the mounted weight is too light or this product
does not stay down when lowered, then you'll
need to decrease Lift Strength:
Release Brake to move riser.
Follow these instructions to tighten or loosen tension.
It is important that you adjust this product according to the weight of the mounted equipment as described in the following steps. Any time equipment is added or removed from this product, resulting
in a change in the weight of the mounted load, you should repeat these adjustment steps to ensure safe and optimum operation.
Adjustments should move smoothly and easily through the full range of motion and stay where you set it. If adjustments are dicult and do not stay in the desired position, follow the instructions to
loosen or tighten the tension to create a smooth, easy adjustment motion. Depending on your product and the adjustment, it may take several turns to notice a dierence.
Lift – Up and down
NOTE: Adjustment
may require 40 - 60
revolutions.
Attach to Front of Cart
(Only for carts with no drawers)
END OF INSTALLATION
