Ergotron StyleView SV41 User manual

1 of 8
888-24-286-G-00 rev. C • 04/14
User's Guide - English
Guía del usuario - Español
Manuel de l’utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l’utente - Italiano
Användarhandbok - svenska
ユーザーガイド:日本語
用户指南 : 汉语
StyleView Transfer Cart
4x 1x
ENGLISH
For the latest User Installation Guide please visit: www.ergotron.com
Drawers sold separately.
User's Guide
Components
This cart is compatible with SV41, SV42, SV43, and SV44 drawers.
It is not compatible with SV31 or SV32 drawers.
After unpacking the cart, remove the 4
protective layers from the ends of the cart.
Tools Needed

2 of 8
888-24-286-G-00 rev. C • 04/14
1
2
3
4
ENGLISH
Unlock cart using provided key then lift right handle up to open door.
To install batteries for electronic lock function.
Open right door then left door.
Push top cover tabs in and up to release top cover.
Lift front edge of top cover up a little then pull rear tabs out of slots to remove top cover.

3 of 8
888-24-286-G-00 rev. C • 04/14
5
6
4x
abc
ENGLISH
Install the 4 provided D batteries.
a. Slide top cover tabs into slots.
b. Lower cover so tabs slide into slots.
c. Make sure all 4 cover tabs click into place to secure top cover.

4 of 8
888-24-286-G-00 rev. C • 04/14
7
ENGLISH
Install drawers by sliding onto shelves.
NOTE: Drawers sold separately.

5 of 8
888-24-286-G-00 rev. C • 04/14
a
b
8
ENGLISH
How to adjust height of, or remove, scanner holder.
Do not remove screws! Loosen screws just enough to slide holder up or down in the T-slot.
To remove holder, slide cup down and off the bottom of the cart.
Open doors on other side of cart for shelf access.
a. Unlock doors with key, then lift up on right handle to open door after unlocked.
b. Slide drawers onto shelves.

6 of 8
888-24-286-G-00 rev. C • 04/14
ENGLISH
How to Use and Program Key Pad
Unlock Door (3 methods):
• Enter Master PIN.
• Enter User PIN.
• Key - turn clockwise 1/4 turn
NOTE: User should change Master PIN upon receipt of cart.
Lock Door (2 methods):
• Wait 4 seconds for door to lock automatically
• Press 1 and 2 on number pad simultaneously
Lost Master PIN
Contact Ergotron Customer Care for instructions.
Drawer Troubleshooting
• Key pad numbers are dark.
-Touch anywhere on number pad to activate back-light, (drawer remains locked until you enter valid PIN).
-Check to make sure battery pack is connected.
• PIN is accepted but door does not open.
-Make sure door is fully closed before entering PIN.
• #4 LED is ashing.
-Replace batteries (D-cell alkaline only).
• Door won’t open when User PIN is entered.
-Test system by entering Master PIN. If door doesn’t unlock, contact Ergotron customer care for "Lost Master PIN" instructions.
Flashing LED: Meaning
3 & 5: Unit is ready to program master or user PINs (see Programming New PIN)
All: New PIN accepted
4: Battery power is low
Erase All Personal PINs and reset factory default Master PIN (cannot erase only one PIN):
1 Enter Master PIN.
2 Press 3 and 5 simultaneously (while blinking).
3 Press 1 and 2 simultaneously.
Programming New PIN (Default Master PIN: 12345)
1
2
3
4
5
6
7
8
Enter Master PIN.
Numbers 3 and 5 on the Keypad will start ashing, indicating the Master PIN has been accepted.
Simultaneously press 3 and 5 while they are ashing.
All the numbers will light (you have 3 seconds to enter a PIN).
Enter a new PIN—any sequence of 5 numbers. (The rst PIN programmed is the new Master PIN.)
When the PIN is accepted, all of the LEDs will ash once in acknowledgement (you have 3 seconds to enter the next PIN).
You can then proceed to program up to 11 PINs by repeating steps 5 and 6.
When nished entering new PINs, system will exit program mode after 3 seconds with a series of LED ashes.

7 of 8
888-24-286-G-00 rev. C • 04/14
a
a
b
b
ENGLISH
How to remove shelves.
a. Push in and up on the 2 tabs under the shelf edge at the center of the cart.
b. With shelf angled, slide out of cart.
How to attach shelves.
a. Slide shelf into desired slot at an angle.
b. Lower center edge down onto shelf holders until tabs click into place.
NOTE: Shelf tabs are at the center of the cart under each shelf.

8 of 8
888-24-286-G-00 rev. C • 04/14
ENGLISH
For local customer care phone numbers visit: http://contact.ergotron.com
NOTE: When contacting custom-
er service, reference the serial
number.
Cleaning and Maintenance
The following procedures are not guaranteed to control infection. The hospital infection control administrator or epidemiologist should be consulted regarding cleaning procedures
and processes.
To avoid risk of electric shock, do not expose electrical components to water, cleaning solutions or other potentially corrosive liquids or substances.
Do not immerse Cart or Cart components in liquid or allow liquids to ow into the Cart. Wipe all cleaners o surface immediately using a damp cloth. Thoroughly dry surface
after cleaning.
Do not use ammable cleaners on Cart surfaces due to close proximity of electrical power and equipment.
All paints and plastic Cart components will withstand cleaning by most commonly used, diluted, non-abrasive solutions such as quaternary ammonia compounds, ammonia
enzyme cleaners, bleach or alcohol solutions.
• Pen and permanent and dry erase markers can be removed with 91% isopropyl alcohol and a soft cloth.
• Iodine stains can be removed with commonly used cleaners and a soft cloth.
• Never use steel wool or other abrasive materials that will damage the surface nish.
• Do not use strong solvents such as trichloroethylene and acetone. These solvents will damage the surface nish.
It is recommended that any cleaning solution be tested on a small, inconspicuous area to ensure surface is not harmed.
Casters - Check casters Monthly for wear and to make sure they are clean and free of debris that would prevent smooth travel. Avoid moving Cart across uneven, dirty or
damaged surfaces.
Please dispose of all batteries in accordance with local law.
Always replace with similar size battery (D-cell) and always replace all 4 at the same tiime.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
FCC Compliance Statement
The cart has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Changes or modications not expressly approved by Ergotron, Inc. could void the user’s authority to operate the equipment.
Please contact Ergotron for complete EMC compatibility information.
Maintenance & Safety
