ERNITEC MicroView MVIC-04IR-E User manual

0
Camera
Network Cube Camera
Quick Start Guide
MVIC-04IR-E

Network Cube Camera·Quick Start Guide
1
About this Manual
This Manual is applicable to MVIC-04IR-E Network Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to
firmware updates or other reasons. Please find the latest version in
the company website
Please use this user manual under the guidance of professionals.
Legal Disclaimer
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY
SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. OUR COMPANY SHALL NOT BE LIABLE IN THE
EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Regulatory Information
FCC Information

Network Cube Camera·Quick Start Guide
2
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum
distance 20cm between the radiator and your body.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.

Network Cube Camera·Quick Start Guide
3
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU, RE Directive 2014/53/EU.
2012/19/EU (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product contains
a battery that cannot be disposed of as unsorted
municipal waste in the European Union. See the
product documentation for specific battery
information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
For proper recycling, return the battery to your supplier or to a
designated collection point. For more information see:
www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards
requirements.

Network Cube Camera·Quick Start Guide
4
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radioexempts de licence. L'exploitation est
autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful
communication.
Conformément à la réglementation d'Industrie Canada, le présent
émetteur radio peut fonctionner avec une antenne d'un type et d'un
gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie
Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à
l'établissement d'une communication satisfaisante.

Network Cube Camera·Quick Start Guide
5
This equipment should be installed and operated with a minimum
distance 20cm between the radiator and your body.
Cet équipement doit être installé et utilisé à une distance minimale
de 20 cm entre le radiateur et votre corps.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
Warnings Follow these
safeguards to prevent serious
injury or death.
Cautions Follow these
precautions to prevent potential
injury or material damage.

Network Cube Camera·Quick Start Guide
6
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 VAC or 12 VDC
according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
●Do not connect several devices to one power adapter as adapter
overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
●Proper configuration of all passwords and other security settings
is the responsibility of the installer and/or end-user.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a

Network Cube Camera·Quick Start Guide
7
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of sensor
will not be exposed to the laser beam.
●Do not place the camera in extremely hot, cold (the operating
temperature shall be -10°C to +40°C (14°F to 104°F)), dusty or
damp locations, and do not expose it to high electromagnetic
radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all the
users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in hazard
of explosion. Replace with the same or equivalent type only.
Dispose of used batteries according to the instructions provided
by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any

Network Cube Camera·Quick Start Guide
8
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Cube Camera·Quick Start Guide
9
Table of Contents
1 Appearance Description ............................................................. 10
2 Notice ........................................................................................ 14
3 Installation ................................................................................. 16
Memory Card Installation.............................................. 17
Stand Mounting ............................................................ 18
Ceiling Mounting........................................................... 19
4 Setting the Network Camera over the LAN ................................. 22
Wiring ........................................................................... 22
Activating the Camera................................................... 23
Activation via Web Browser................................ 23
Activation via SADP Software ............................. 24
Modifying the IP Address .............................................. 26
5 Accessing via Web Browser ........................................................ 28
0504011060704

Network Cube Camera·Quick Start Guide
10
1Appearance Description
There are two types of appearances for 24 series camera. Please refer
to the figure below. And one appearance will be taken as an example
in the chapter below.
Type I Appearance
Type II Appearance

Network Cube Camera·Quick Start Guide
11
2
1
3
4
6
5
7
8
14
15
9
10
12
13
11
Overview

Network Cube Camera·Quick Start Guide
12
Description
No. Description
1 Lens
2 Microphone
3 IR LED
4 Indicator
Alarm: Solid red when the camera is
armed; Solid blue when the camera is
unarmed
Status: Solid blue when the camera is
added to the Guarding Vision
Link: Flashing amber when network is
connected; Unlit when network is
disconnected
4 PIR(Passive Infrared) sensor
5 Light Sensing
6 Memory Card Slot
7 3-axis Bracket
8 10M/100M self-adaptive Ethernet interface & PoE
9 WPS (Wi-Fi Protected Setup)/Reset Button
10 I: Alarm Input Interface
11 G: Grounding

Network Cube Camera·Quick Start Guide
13
No. Description
12 O: Alarm Output Interface
13 Power supply interface (12 VDC)
14 Speaker
Note:
Press RESET about 10s when the camera is power on or
rebooting to restore the default settings, including the user
name, password, IP address, port No., etc.
A wireless router with the WPS function is required to enable
the WPS function of the camera. Refer the steps below.
Steps:
Press the WPS button on the router.
Press the WPS button (about 2s) on the camera within 120s
you enable the WPS of the router to join in the wireless
network.
Note:
The WPS button works as a reset button only when you
press it when the camera is powering on.
Press the WPS button on the camera, and then press the
WPS button on the router will work as well, and the expire
time of WPS connection on the camera is 120s.
The link indicator blinks if the wireless connection
succeeded.

Network Cube Camera·Quick Start Guide
14
2Notice
Do not install the
camera in the extreme
whether condition.
Do not touch the lens
with your fin g e r.
Do not install the
camera towards the
strong light or in the
unstable lightening
condition.
Do not subject the
camera to vibration,
shock or heavy pressure.

Network Cube Camera·Quick Start Guide
15
High humidity may
damage the camera
hardware; put it in dry
and well-ventilated
place.
Under no circumstances
should you submerge the
camera in any type of
liquid.
Electromagnetic radiation may affect the video data
transmission and the image quality. Do not install the
camera near

Network Cube Camera·Quick Start Guide
16
3Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 12V DC or 24V AC, please make
sure your power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four times
the weight of the camera and the bracket.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
●Dust or grease on the dome cover will cause IR reflection. Please
do not remove the dome cover film until the installation is

Network Cube Camera·Quick Start Guide
17
finished. If there is dust or grease on the dome cover, clean the
dome cover with clean soft cloth and isopropyl alcohol.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
●The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring and
the dome cover are attached seamlessly.
Memory Card Installation
This series of camera supports memory card installation. Follow the
steps below to install the memory card.
Insert the memory card into the card slot on the side of the
camera.
(Optional) Push the inserted memory card to get it sprung out.
Memory Card
Install Memory Card

Network Cube Camera·Quick Start Guide
18
Stand Mounting
Steps:
Take the bracket out from the package.
Bracket
Align the camera body to the bracket, and rotate the camera
body to fix it with the bracket.

Network Cube Camera·Quick Start Guide
19
Install the Camera Body
Assemble the camera as the steps above, and put the camera on
the flat surface.
Ceiling Mounting
Drill the screw holes according to the drill template.
Drill Template
Screw hole All:for Mounting Base
11
Drill Template
Disassemble the 3-axis bracket. Hold the base with one hand,
and rotate the pole anticlockwise to disassemble the pole from
the base.
