ESAB SDE-100 User manual

SDE-100
Instruction manual
0448 019 001  GB  20230315

TABLE OF CONTENTS
0448 019 001 -3- © ESAB AB 2023
1 SAFETY ...................................................................................................................................... 4
1.1 Meaning of symbols .................................................................................................... 4
1.2 Safety precautions ...................................................................................................... 4
2 INTRODUCTION ......................................................................................................................... 4
2.1 Oven use and purpose................................................................................................ 4
3 TECHNICAL DATA ..................................................................................................................... 5
4 INSTALLATION........................................................................................................................... 5
4.1 Operation...................................................................................................................... 5
ORDERING NUMBERS ......................................................................................................................... 6
WIRING DIAGRAM ................................................................................................................................ 7
ORDERING SPARE PARTS .................................................................................................................. 8

1  SAFETY
0448 019 001 -4- © ESAB AB 2023
1 SAFETY
1.1 Meaning of symbols
As used throughout this manual: Means Attention! Be Alert!
DANGER!
Means immediate hazards which, if not avoided, will result in immediate, serious
personal injury or loss of life.
WARNING!
Means potential hazards which could result in personal injury or loss of life.
CAUTION!
Means hazards which could result in minor personal injury.
WARNING!
Before use, read and understand the instruction manual and
follow all labels, employer´s safety practices and Safety Data
Sheets (SDSs).
1.2 Safety precautions
ELECTRIC SHOCK - Can kill
• Do not touch live electrical parts or electrodes with bare skin, wet gloves
or wet clothing.
• Insulate yourself from work and ground.
• Ensure your working position is safe.
FIRE HAZARD
• Do not use if the power cord is broken or abnormal temperature variation
(not recommended as per manual/factsheet) seen on the oven as it may
can cause fire.
• Make sure that there are no inflammable materials nearby.
HOT SURFACE - Parts can burn
• Do not touch parts bare handed.
• Allow cooling period before handling or working with the equipment.
• To handle hot parts, use proper tools and/or insulated welding gloves to
prevent burns.
2 INTRODUCTION
2.1 Oven use and purpose
The SDE-100 oven model is designed to dry and store stick welding electrodes at a desired
temperature to remove moisture. Desired temperature can be set, based on the recommendation from
the electrode manufacturer to achieve correct drying, ensuring the moisture content and for storage.
This oven should only be used for its recommended setting and usage.

4  INSTALLATION
0448 019 001 -5- © ESAB AB 2023
3 TECHNICAL DATA
SDE-100
Capacity 100kg (220lbs.)
Voltage 3 phase 380-415V
Frequency 50/60Hz
Output 3000W
Temperature Up to 400°C (752°F) Digital thermostat
Outer dimensions (L*W*H, cm) 53 × 72 × 138
Weight (Without electrodes) 90kg (198lbs.)
NOTE!
Oven heating temperature can be set from surrounding ambient to 400°C.
4 INSTALLATION
NOTE!
Make sure that the technical specification on the product corresponds to the electrical supply
in your network.
Check the voltage, frequency information and check that there is no fault that will affect the
operation of the product.
4.1 Operation
WARNING!
When the oven is not in use, turn the power knob to “O” position and remove power cord plug
from electrical outlet.
• Connect oven power cord plug to a power outlet as recommended in the technical
information. Make sure the power outlet socket matches the oven power plug type.
• Load electrodes onto oven shelfs (trays). Do not place anything else (packaging
material, etc. as high temperature can burn it and cause fire inside the oven) besides
electrodes on these metal trays. Do not overfill trays and make sure the door can be
latched properly.
• Lock the door.
• On the oven control panel, to turn on the oven change power knob to “I” position.

APPENDIX
0448 019 001 -6- © ESAB AB 2023
• Once the power is turned on, depending upon the type of your oven i.e 1Φ one green
lamp will glow or 3Φ three green pilot lamps will glow. If the lamps or not glowing,
then check the power connection. Refer the below image.
• Setting the desired temperature
○ When the unit is turned on the controller display will show the current
temperature and set value.
○ Press and hold the SET button for 2 seconds to set a different
temperature. Use up and down keys to reach the desired set
temperature. Once the controller read out shows the desired
temperature, press SET key again.
○ The oven will now automatically heat up or cool down to the set
temperature. The oven will automatically turn off heating when the set
temperature is reached. The green lamp will also turn off.
• To remove electrodes from oven, when they have been dried at the desired
temperature.
○ Open and release the release valve on the top to avoid the hot smoke
exhaust when opening the front door.
○ Either turn off the oven completely or cautiously remove from the metal
trays and transfer to a portable oven (like PSE 5 or 10).
WARNING!
To achieve the maximum drying of electrode it is recommended to use FIFO (First In First Out)
principle. Must be cautious to not over-dry electrodes by leaving old electrodes inside oven
while only removing the newly added electrodes.
APPENDIX
ORDERING NUMBERS
Ordering number Denomination Type Notes
0700 100 068 Stationary welding electrode drying oven SDE-
100
Three phase
380-
415VAC50/60Hz
Technical documentation is available on the Internet at: www.esab.com

APPENDIX
0448 019 001 -7- © ESAB AB 2023
WIRING DIAGRAM

APPENDIX
0448 019 001 -8- © ESAB AB 2023
ORDERING SPARE PARTS
Item no. Qty. Ordering number Description Notes
1 1 0700 100 002 Digital thermostat DT-109A
23 0700 100 003 Signal lamp 220V
3 0700 100 004 Signal lamp 110V
3 1 0700 100 074 Fiberglass wick
4 1 0700 100 018 Power switch
5 1 0700 100 020 Air valve
6 1 0700 100 006 Door handle
7 2 0700 100 054 Tray
82 0700 100 008 Castors without brake Back
2 0700 100 009 Castors with brake Front
9 1 0700 100 031 Cable gland
10 2 0700 100 011 Heating element 220V
2 0700 100 012 Heating element 110V
11 1 0700 100 017 Contactor 220V UNI 220V
1 0700 100 023 Contactor 110V UNI 110V
12 2 0700 100 015 Fuse (automatic) 10A
1 0700 100 016 Fuse (automatic) 2A
13 1 0700 100 019 Terminal Set
14 1 0700 100 013 Power cable with plug CEE 5x32A 400V plug
1 0700 100 014 Power cable with plug 110V
15 1 0700 100 165 Thermocouples

APPENDIX
0448 019 001 -9- © ESAB AB 2023
