Escea DN1150 Corner 400 Installation and maintenance instructions

Installaon &
Service Instrucons
DN1150 LH-RH Corner 400
GAS FIREPLACE
630719_5

IMPORTANT:
The appliance shall be installed in accordance with;
ͳThis installaon instrucon booklet
ͳLocal gas ng regulaons
ͳMunicipal building codes
ͳElectrical wiring regulaons
ͳAny other relevant statutory regulaons.
ͳAS/NZS 5601.1 Gas Installaons
NOTE: NOT INTENDED FOR FIREPLACE INSERT
WARNING:
THIS APPLIANCE MUST BE INSTALLED BY A QUALIFIED PERSON. THIS APPLIANCE MUST BE INSTALLED INTO A
CAVITY STRICTLY IN ACCORDANCE WITH THE FOLLOWING INSTRUCTIONS.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
DO NOT USE OR STORE FLAMMABLE MATERIALS IN OR NEAR THIS APPLIANCE.
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE.
DO NOT MODIFY THIS APPLIANCE.
This appliance is not intended for use by young children or inrm persons unless they have been adequately
supervised by a responsible person to ensure that they can use the appliance safely.
Young children should be supervised to ensure that they do not play with the appliance. Failure to follow these
instrucons could cause a malfuncon of the heater, which could result in death, serious bodily injury, and/or
property damage. Failure to follow these instrucons may also void your re insurance and/or warranty.
Who can install this product:
Installaon must be carried out by a registered installer who, on compleon of the installaon, must issue a:
AUS: Cercate of Compliance
NZ: Cercates that comply with the latest legislaon in accordance with naonal and/or local codes. If these are
not issued then the Escea warranty may be void.
Warranty Repair and Annual Servicing:
Please contact Escea if you require warranty work. Warranty repair work must be carried out by a recognised gas
re technician. It is recommended that recognised Escea Gas Fire Technicians are also used to carry out annual
servicing requirements (parcularly during the warranty period). For contact details of recognised Escea Gas
Fire Technicians in your area, or for replacement parts, please contact the retailer from whom the appliance was
purchased or visit our website.
The heater must be installed according to these instrucons and in compliance with all relevant building, gas
ng, electrical and other statutory regulaons (eg. AS/NZS 5601). Any shortcomings in the appliance and ue
installaon will be the responsibility of the installer, and Escea will not be accountable for any such failings or their
consequences.
Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: [phone]
For contact details of your local Escea distributor or dealer please visit www.escea.com or email:
[e-mail]. From Australia, visit www.escea.com.au or call: WA : 1-800 730 140;
EA : 1-800 460 832

DN1150 Corner 400 PRODUCT SPECIFICATION
MODEL NAME DN1150 Corner 400
Descripon of Appliance Indoor Gas Fire Heater
Star Rang 3.4 Stars
Max. Heat Output 6.6 kW
Compliant to : AS/NZS 5263.1.3
Gas Type Natural Propane ULPG
Gas input High 33 MJ/h 33 MJ/h 33 MJ/h
Low 24 MJ/h 24 MJ/h 24 MJ/h
Inlet Pressure Max 5KPa 5KPa 5KPa
Min 1.13KPa 2.75KPa 2.75KPa
Operang Pressure on High 0.74KPa 1.5KPa 1.5KPa
Operang Pressure on Low 0.34KPa 0.76KPa 0.76KPa
Burner Jet Size LH & RH: 1.5mm
Middle: 1.95mm
LH & RH: 0.95mm
Middle: 1.25mm
LH & RH:
0.95mm
Middle: 1.25mm
Burner Aeraon
LH & RH: 2xClosed
Collar
Middle: 1xClosed
LH & RH: 2x6mm
Middle: 1xSpacer
(no restricon)
LH & RH: 2x6mm
Middle: 1xSpacer
(no restricon)
Pilot injector #42 #27 #27
Product Dimensions (mm)
Width 1288 mm
Height 795 mm
Depth 378 mm
Weight Kg 140 kg
Ignion System Electronic Ignion to pilot system
Escea PCB
Ignion Acvaon 20 secs (approx)
Flame Safeguard Flame Reccaon
Consumpon 160W @ 0.69A 230V
Remote controls Yes
Timers Yes
Clock Yes
Funcon lock / child Yes
Temperature control Yes
Connecons
Electric 230V AC
G a s 1/2" BSPT female lower centre of replace chassis
Flue Type Aluminium Flexi Flue
Flue Size
(ID) 75mm and 100mm Flexi Flue
Spigot
Locaon Right hand top
Data badge locaon On Chassis Base

CONTENTS
  6
A1 ProductDescripon 6
A2 ProductDimensions 6
  8
B1 Cavity Shape 8
B2 DesigningtheCavity 8
B3 Hearth 9
B4 Cavity Base 9
B5 WallLinings 9
B6 Television&MantelClearances 9
C Installing the Flue 10
C1 FlueConguraon(Iflessthan8muelengthisrequired) 10
C2 FlueConguraon(Ifmorethan8muelengthisrequired) 11
C3 InstallingtheHorizontalPowerueWallTerminalOpon 12
C4 InstallingtheInternalVercalPowerue(UVP) 15
C5 InstallingtheExternalVercalPowerue(UVP) 17
C6 InstallinginAccordancewithRelevantCodes 18
C7 RunningtheFlue 19
C8 RunningthePowerueElectricalCable 20
D Installing the Electricity and Gas to the Appliance 21
D1 PowerSupply 21
D2 NetworkCable 21
D3 GasPipeSizing 22
D4 GasPipePosion 22
D5 GasIsolangValve 23
E Installing the Appliance 24
E1 ConnecngtheFlue 24
E2 Installaon 24
E3 Removing(andReplacing)theGlass 24
E4 RemovetheInll&Burners 25
E5 GasTypeConversion 25
E6 OperangtheAppliance 27
E7 CheckingtheGasOperangPressure 27
E8 RemotePairingBuon 30
E9 HomeAutomaonSetup 30

  32
F1 Gem/CrystalightorCoalFuelbedInstallaon 32
F2 LogandWoodlandLogFuelbedRetainerSetup 32
F3 LogFuelbedInstallaon 33
F4 WoodlandFuelbedInstallaon 34
F5 Flame Picture 35
F6 WallLinings 36
F7 LocangWallMountCradleforWirelessControl 38
F8 OperangtheAppliance 38
F9 NormalOperangSoundsandSmells 39
 40
H Service Manual 41
H1 AnnualServiceProcedure 41
H2 ErrorCodes 42
H3 CleaningtheFuelbedandGlass 43
H4 CheckingOperangPressure 43
H5 ReplacingaRemoteControl 44
H6 ReplacingtheBurners 44
H7 SerialNumber 44
H8 RemovingorCleaningFan 45
H9 RemovingtheControlTray 45
H10 PressureSwitchRemoval 46
H11 ReplacingtheThermalCutOut(TCO) 47
H12 ServicingtheHorizontal/UniversalVercalPowerue 49
H13 WiringDiagram 50

6
A PRODUCT DESCRIPTION AND DIMENSIONS
A1 
The DN1150 Corner 400 gas re is a room sealed gas appliance designed to be built into a false self
supporng cavity. It is a powerful gas heater that, on the lowest seng (eect only) will sll generate
approximately 50% heat. The appliance is ued using co-linear exible aluminium ue. The user will
control their re with the Radio Frequency (RF) remote that will normally be located in its wall mount
cradle. In addion to the RF remote the appliance has a single auxiliary On/O buon on the unit. When
not in operaon it is in a standby mode unless it is physically isolated from the mains supply.
A2 
NOT TO BE MISTAKEN FOR CAVITY DIMENSIONS.
All dimensions are in mm +/- 5mm tolerance.
NOTE: Contractors and installers should verify all dimensions on site prior to the manufacture or
construcon of any structure or nishes.
For more details, contact the Escea architectural advisory team Email: [e-mail]
IMPORTANT
INSTALLATIONS THAT ARE NOT SPECIFICALLY OUTLINED IN THIS MANUAL SHOULD BE REFERRED TO THE
ESCEA ARCHITECTURAL ADVISORY TEAM.

277
213
1320 min*
850 min*
365 min*
45 max*
1288
1056
795
415
217
404
1111
404
378
394

7
A

LIMITED TO SEALED CAVITIES, UNDER BENCH INSTALLATIONS, A RECESSED FIRE, OR WITH OVERHANGS



UNDESIRABLE LEVELS OF HEAT, OR LEVELS OF HEAT GREATER THAN THEIR TOLERANCES ALLOW.
SPECIFIERS AND INSTALLERS MUST CHOOSE MATERIALS WHEN IN THESE SCENARIOS THAT MEET THE

PRODUCT. ESCEA TAKES NO RESPONSIBILITY FOR MATERIAL CHOICE AND REFERENCE SHOULD ALWAYS

SUITABILITY OF USE.

FOR MORE INFORMATION ON MATERIALS SELECTION AND FOR FURTHER GUIDANCE PLEASE CONTACT OUR


page 40.

8

B CREATING THE CAVITY
B1 Cavity Shape
The DN1150 Corner 400 is suitable for self supporng mber/steel framed cavies.
Most exisng masonry cavies will not be suitable.
B2 Designing the Cavity
The following aspects must be considered when designing this installaon:
ͳAppliance is NOT load bearing
ͳAppliance physical size
ͳWall nishing and interacon with appliance
ͳPosioning of appliance in regards to wall lining (depth into wall)
ͳExhaust terminaon aspect – horizontal / vercal and ue conguraon
ͳFlue exhaust fan noise
ͳExhaust cowl access for maintenance
ͳGas pipe layout
ͳGas isolaon valve / pressure test point posion
ͳElectrical isolaon switch
ͳHome automaon network connecons - ethernet cable layout
THIS DN1150 CORNER 400 FIRE IS TO BE INSTALLED PRIOR TO ANY WALL LINING.
THE WALL LINING IS THE VERY LAST TASK TO BE COMPLETED IN THIS INSTALLATION.
The cavity and wall linings may be constructed from standard mber framing materials and do not need
to be non-combusble.
It is not necessary to line the sides or back of the cavity.

Note: Dimensions shown do not include allowances for clearance to combusbles to the ue.
277
213
1320 min*
850 min*
365 min*
45 max*
1288
1056
795
415
217
404
1111
404
378
394

9
B
B3 Hearth
A hearth is not required. If a hearth is installed below the re,
it must be at least 100mm below the boom of the glass or
be composed enrely of non-combusble materials.
B4 Cavity Base
This appliance MUST be fully supported on its base, over the
enre area of the underside of the appliance. The base must
also be level and strong enough to support the total product
weight, which is approximately .
The replace can be recessed into the ground but must
maintain the clearances detailed in the diagram (shown right)
for any combusble ooring materials.
B5 Wall Linings
Only aer all applicable secons up to secon F5 on page 35 have been completed, can you
commence with the nal wall linings detailed in secon F6 on page 36.
Wall lining cutout dimensions around the glass must be adhered to.
Please refer to secon F6 on page 36 for wall nishing dimensions surrounding glass.
B6 Television & Mantel Clearances
Television
The diagram (shown right) shows the recommended
minimum clearances for the locaon of any electrical
equipment (such as Plasma TV, LCD TV or home theatre)
above a DN1150 gas re. A mantel/recess is not required
to comply with our recommendaon of TV installaon.
Note: Dimensions from the top edge of the glass frame.
Note: The television clearance recommendaons are to be
treated as a suggeson of a suitable installaon only. It is
the responsibility of the end user to check the installaon
instrucons of their electrical appliances to ensure that
the locaon in relaon to the gas re is suitable. Escea
in no way guarantees or takes responsibility that the
recommended installaon suggeson will be suitable for
all electrical or home entertainment appliances.
Mantel
Please refer to the diagram (shown right). Mantels or
protruding ledges above the heater must not be installed
lower than the dimension shown.
Note: Dimension from the top edge of the glass frame.
Fireplace Glass
Fireplace
100mm
Min.
Flooring or Hearth
Fireplace
Fireplace Glass

10

C INSTALLING THE FLUE
C1 
If your ue system is less than 8m long (as shown in diagrams below), then a simple aluminium exible
ue is required. If you wish to install a longer ue run, then contact the Escea Advisory Team.

The horizontal oset of the terminal can be any amount up to the total ue length listed below. Please
consult with Escea’s technical sta if your intended ue conguraon falls outside of the bounds of the
ue conguraons shown below.
8m MAX Y
X
X + Y = 8m MAX
= 0.4m MIN*
1.2m Co-axial Flue
* Excess noise may be present at this distance
Note: When ueing above the re, the pipe must slope towards re - NOT towards the terminal. Also when
ueing below the re, the pipe must slope towards the terminal - NOT towards the re.
X
Y
X+ YMaximum = 8m
YMaximum = 1.5m
YMinimum = 0m
XMaximum = 8m
XMinimum = 0m
X+ YMinimum = 0.4m

11
C
0.4m Min.
8m Max.
Overall ue length:

8m MAX
1.2m Co-axial Flue
8m MAX
1.2m F-F Liner
UVP Cowl
Vertical PowerFlue
Cowl (Duravent)
Internal
C2 
If your ue system is greater than 8m long (up to 40m long), then please contact the Escea Advisory Team
at [e-mail] for further guidelines.
Liner
UVP Unit
8m MAX
1.2m Co-axial Flue
8m MAX
Vertical PowerFlue
Cowl (Duravent)
External

12 
C
C3 
The horizontal powerue wall terminal must be installed in
the correct orientaon (the small horizontal slot should be at
the boom). This allows for the correct operaon of the ue
system and prevents the ingress of water.
The horizontal powerue wall terminal must be weather-
ght when installaon is complete to prevent damage to the
dwelling. It must be installed by a suitably qualied person.
Fit the horizontal powerue wall terminal into the hole and x
in place, making sure the installaon is sealed appropriately to
prevent the ingress of water from outside the wall cladding.
Take noce of the label on the terminaon which shows the
correct orientaon of the terminal.
Note: It is the responsibility of the installer to ensure the
horizontal powerue wall terminal is installed to all relevant
building codes to ensure weather ghtness.

13
C

When cung the hole in the outside wall, be mindful of how the installaon of the horizontal powerue
wall terminal will be nished; the installaon must be weatherproof.

Without Side Brackets With Side Brackets
 298mm 360mm
Y 298mm 298mm
Z 175mm Excluding allowance for ue which exits here
The horizontal powerue wall terminal can be aached to the wall in two ways:
A) From the front of the terminal:
B) By aaching the oponal wall terminal installaon brackets to the sides of the cavity and aaching the
horizontal powerue wall terminal to these, from the front:
Aach the Ø100mm and Ø75mm exible aluminium ues to the spigots on the rear of the horizontal
powerue wall terminal using the hose band clamps supplied. Plug the powerue electrical cable into the
back of the horizontal powerue wall terminal.
Ensure that the electrical cable is rmly secured to the wall terminal or building to prevent damage or
disconnecon if pulled.
A
B

14 
C
Fit the horizontal powerue wall terminal into the hole
and x it in place, making sure the installaon is sealed
appropriately to prevent the ingress of water from
outside the wall cladding.
Note: It is the responsibility of the installer to ensure
the horizontal powerue wall terminal is installed to all
relevant building codes to ensure weather ghtness. This
may necessitate the use of appropriate ashing material
where appropriate.
IMPORTANT: ENSURE THAT FLASHINGS DO NOT RESTRICT THE AIR INTAKE SLOT AROUND THE PERIPHERY
OF THE COWL.

The following diagrams are excerpts from the Escea architect drawings and are available in full on our
website. These diagrams are recommendaons, and your installaon must comply with any local or
naonal building codes.
Head and Sill scale 1:5
Jamb scale 1:5
framing member with
wall wrap and flashing
tape over
cladding on cavity
batten
typical head flashing with
stop ends to comply with
relevant building code
horizontal powerflue
unit
terminal fixing brackets
(shown dashed) fixed
to framing
flashing tape over wall
wrap to opening
seal air gap to opening
terminal screw fixed to flange
with flange fixed to studs at
fixing brackets
packer to lift terminal off
sill
sill cover to cladding to comply
with relevant building code
300 min
360 min
10
cladding on cavity
batten
10
horizontal powerflue
unit
terminal screw fixed to flange
with flange fixed to studs at
fixing brackets
terminal fixing
brackets screw fixed
into framing
framing member with
wall wrap and flashing
tape over
continuous sealant strip
to jambs
scriber or plug may be
required - dependent on
cladding type
seal air gap to opening
cowl
198
138 60
scale: date:
ecn: drawn:
drawing no: revision:file:
Horizontal Powerflue Detail
as shown ECN-2155 EDA-0006 MGD-Series FLUE Master File.dwg V. 02 08.12.2017
Head and Sill scale 1:5
Jamb scale 1:5
framing member with
wall wrap and flashing
tape over
cladding on cavity
batten
typical head flashing with
stop ends to comply with
relevant building code
horizontal powerflue
unit
terminal fixing brackets
(shown dashed) fixed
to framing
flashing tape over wall
wrap to opening
seal air gap to opening
terminal screw fixed to flange
with flange fixed to studs at
fixing brackets
packer to lift terminal off
sill
sill cover to cladding to compl
y
with relevant building code
300 min
360 min
10
cladding on cavity
batten
10
horizontal powerflue
unit
terminal screw fixed to flange
with flange fixed to studs at
fixing brackets
terminal fixing
brackets screw fixed
into framing
framing member with
wall wrap and flashing
tape over
continuous sealant strip
to jambs
scriber or plug may be
required - dependent on
cladding type
seal air gap to opening
cowl
198
138 60
scale: date:
ecn: drawn:
drawing no: revision:file:
Horizontal Powerflue Detail
as shown ECN-2155 EDA-0006 MGD-Series FLUE Master File.dwg V. 02 08.12.2017

15
C
C4 
Note: For informaon regarding an external install of the UVP, go to secon
“Installing the External Vercal Powerue (UVP)” on page 17.
The Universal Vercal Powerue (UVP) internal conguraon is designed to have
the fan, mounted within the roof space of the house, and the vercal Ø225mm
diameter liner, containing a Ø100mm exi, penetrate through the roof. The UVP
internal conversion kit comes with a 1200mm liner that is specic to the internal
installaon and must always be used.
Note: The ue setup must comply with either secon “Flue Conguraon (If less
than 8m ue length is required)” on page 10 or “Flue Conguraon (If more
than 8m ue length is required)” on page 11.
Use standard methods to ash the roof penetraon. The installaon must be
weatherproof and conform to all local council standards including powered ue
terminaon rules.
Mount the fan mount bracket (1) to the roof framing and strapping using mber
ensuring that the ue is rigid and vercal. Ensure that the mounng mber does
not obstruct access to the 3xM5 screw threads on the side of the fan unit.
Aim to have the fan enclosure (2) mounted as high as possible, mainly to allow
sucient fall for condensaon drainage if the exi-ue is to run horizontally.
Ensure there is sucient space below fan enclosure (2) to have access to t the
exi-ue tubes (3) and allow owing bends if required.
Note: The UVP-Internal and the exi ue connecons must be installed in a
locaon accessible for service or replacement; a service hatch or removable
ashing to allow access may be required.
Note: When installing the unit onto a ue liner, ensure the length of ue liner above the roof is the
minimum required length. ENSURE the Ø43mm restricon plate is installed on the inlet.
(1)
(2)
(3)
290
229.1
ø226.8
31.6
221.8
250.2
31.6
103.4
TIMBER MUST NOT
OBSTRUCT THESE ZONES

16 
C
The UVP-Internal kit is intended for use within an accessible roof space or ‘chimney’ construcon.

Ensure installaon complies with relevant building codes and regulaons
To appliance
Typical Installation UVP Cowl
‘Decktite’ or similar ashing
1.2m F-F Liner
Hose band clamps
Ø75mmØ100mm
Ensure Power Flue unit
is securely braced using
integral brackets.
Roof Space
Power cord to
appliance
UVP Fan Unit

17
C
C5 
Note: For informaon regarding an internal install of the UVP, go to secon “Installing the Internal
Vercal Powerue (UVP)” on page 15.
The UVP is designed to have the enclosure containing the fan unit mounted externally; an example is
shown below.
Note: When installing the unit onto a ue liner, ensure the length of ue liner above the roof is the
minimum required length. ENSURE the Ø43mm restricon plate is installed on the inlet.
The cowl surround should be xed in place as shown.
Mount the UVP kit to the top of a chimney ashing plate or penetrate the roof with an oponal ue
liner accessory and t the UVP kit over the ue liner, sealing the penetraon with a deckte or similar
ashing. Ensure the terminal is vercal and rigidly mounted and the exi ue aached below is xed to
the terminal spigots using the supplied hose clamps. The exi ue is held in place by drilling 3 holes and
screwing 3 self tapping screws evenly around each hose band clamp (as shown in the picture below).

18 
C
C6 
The locaon of the horizontal powerue wall terminal must be installed in accordance with AS/NZS 5601
and any other relevant building codes. If possible, avoid installing the horizontal powerue wall terminal
in areas exposed to high winds and extreme weather.
Some of the minimum clearances for a fan assisted wall terminal are listed below; please refer to AS/NZS
5601 Gas installaon standard for full guidance on the design of the ue system. Where possible allow a
greater clearance.
ABelow eaves, balconies and other projecons 200mm
B From the oor, above a balcony or other surface 300mm
C From a return wall or external corner 300mm
D From a gas meter or regulator vent 1000mm
EFrom electricity meter or fuse box 500mm
F From a drain pipe or soil stack 75mm
G Horizontally from any building structure or obstrucon 500mm
H From any other ue terminal or combuson air intake 300mm
J Horizontally from any moving window, door, non-mechanical air inlet, or
any other opening into a building with the excepon of sub oor venlaon
300mm
KFrom a mechanical air inlet or spa blower 1000mm
LVercally below any moving window, door, non-mechanical air inlet, or any
other opening into a building with the excepon of sub oor venlaon
300mm
NHorizontally from a roof light 600mm
O Vercally from a roof light 500mm
QVercally from a at roof 500mm
RHorizontally from a vercal structure 500mm
SBelow a roof window 2000mm
T Above or either side of a roof window 600mm
UFrom a dormer window 1500mm
V Above the apex of the roof (see note 1 on following page) 300mm
W From an open ue 1500mm
N
R
F
S
W
U
A
V
K
Q
E
J
J
A
H
E
D
C
C
A
O
G
JL
B
M
P
Prohibited area for ues is
below or Distance 'E' to
the left and right of the
Electricity meter
or fuse box
M = Gas Meter
P = Electricity meter or Fuse box
H

19
C
Notes:
1. Should the ue not extend past the apex, the boom opening of the ue should extend at least 200mm from the roof
(or 300mm in regions with heavy snow).
2. The installaon of a ue into a carport is not recommended.
3. The ue terminal will get very hot when in use. Precauons should be taken to protect people and animals from
injury.
C7 Running the Flue


Run the Ø100mm and Ø75mm exible aluminium hoses from the cavity to the rear of where the
horizontal or vercal powerue terminal will be installed. Allow enough stretch in the exible aluminium
ue to allow it to protrude through the wall/ceiling/roof/ue liner to enable it to be connected to the
powerue terminal. The ue should be expanded at each end in order for the ue to be aached to the
re/powerue. It is advisable to secure the exi ue at regular intervals to prevent vibraon, movement
and sagging. Steel wire or ‘builders strapping’ may be used for this purpose.
Note: The exible ue is shipped in a ‘compressed’ form. Extend it to your desired length by stretching.
1.5m

20 
C
 
Note: The powerue terminal is powered from the appliance and must be connected to the appliance with
the supplied electrical cable only.
Note: Ensure that the appliance power supply is disconnected before making the connecon to the
terminal
The supplied electrical cable is 7m long; ue extension kits also include a powerue electrical cable
extension.
Run the electrical cable from the cavity where the appliance will be installed to the hole in the outside
wall. Ensure it is not draped over, or in contact with, the outer shell of the appliance or the ues.
The cable must be kept clear from any other possible heat sources, sharp edges, or moisture. Fix it
appropriately and allow enough cable to be able to pull both the appliance and the powerue terminal
out from their installed posions.
IF YOU DO NOT CONNECT THE POWERFLUE ELECTRICAL CABLE TO BOTH THE FIREPLACE AND THE
POWERFLUE, THIS WILL RESULT IN AN ERROR WHEN THE FIREPLACE IS TURNED ON.
TEST THE FAN BEFORE CONTINUING WITH THE REST OF THE INSTALLATION.
END OF SECTION C
BY THE END OF THIS SECTION, YOU SHOULD HAVE:



clearances


