ESENE HS118v2 User manual

HS118v2
IP
话机快速操作指南
注意：查询本话机 IP 地址方法为在待机状态下按“*1*1*1”则可查询到本话
机IP 地址。
LEDs
表1 线路键
LED 灯状态
描述
红色闪烁 对应线路有来电正在呼入
红色常亮 对应线路摘机且正在进入正常通话状态
表2状态灯（话机右上角）
LED
灯状态
描述
红色闪烁 有来电正在呼入
红色常亮 有未接电话，或话机处于非空闲状态
安装支架、话机接入安装支架、话机接入
1-1
发出呼叫
您可以摘机或按下
免提键
来进行一个呼叫。

直接呼叫：
直接拨打号码，然后按#
键
；

重拨：
按
重拨键
以拨打最近一个拨出的号码；
应答呼叫

直接应答：
您可以简单地摘机进行一个呼叫的应答，当然也可以按
免
提键
进行；
实现通话闭音：闭音(MUTE)键

闭音键
：在通话中按下
闭音键
，此时对方无法听到闭音端的声音，需
要恢复让对方听到，则再次按下
闭音键
，双方通话恢复正常。
呼叫保持与恢复
如果您想保持一个通话，只需按下
保持键
。
如果您想恢复保持的通话，再按下
保持键
则可恢复通话。
1-2
音量调节
您可以使用音量键调节不同状态的话机音量。
话机状态
对应所调节音量
待机状态 振铃铃声音量
手柄摘机状态 手柄听筒音量
耳麦状态 耳麦输出音量
您可以通过以下方式调节对应的麦克风输入音量：
登陆 WEB，选择“话机设置”>“基本设置”>“音量设置”。
三方会议
您可以在一个通话中邀请第三方进行三方会议通话：
在通话过程中，按下
会议键
，拨打一个第三方号码，等第三方接通后，
再按下
会议键
即可；
会议超过三方时，可使用多个话机级联成一个多方会议进行通话
*
更多的详细内容请参考本话机的用户手册。您也可以通过访问话机的
Web
页面来进行更详细的参数配置。
---------------------------------------------------------------------------------------------------
广州市亿景通信技术有限公司
地址：广州市天河区东圃镇黄村路 51 号粤安工业园 C栋4楼
网址：http://www.escene.cn
邮箱：[e-mail]
1-3

HS118v2
IP Phone Quick Operate Guide
Tips: Please check IP address by pressing the buttons
‘
*1*1*2
’
under idle
mode.
LEDs
Table 1 Line Buttons
LED Status Description
Red, flashing There is an incoming call.
Red, steady Pick up and enter normal call.
Table 2 Light-strip(top right corner)
LED Status Description
Red, flashing There is an incoming call.
Red, steady Missed Calls, or phone busy.
Mounting bracket, telephone accessMounting bracket, telephone access
2-1
Placing a Call
You can pick up the handset or press Headset/Speaker button to place a call.
Dial directly: Dial number directly, then press # button;
Redial: Press Redial button to dial the latest number;
Answeringa Call
Answer directly: You can answer a call by lifting the handset, or pressing
the Speaker button;
Press MUTE button when talking, the voice will be mute on you side and
other side cannot hear what you say. If you want to resume, just press
again the mute button.
2-2
Hold & Resume
If you want to hold an active call, you can press Hold button, and resume
it by pressing again.
You can switch to other lines and hold the active call by pressing line
button of other lines, and resume it by pressing the line button of
previous line.
Volume Adjustment
You can adjust the volume in different status with volume button.
Phone Status Corresponding volume
Standby Ring volume
Hook off Handset volume
Hand-free Speakerphone volume
You can adjust the corresponding microphone input volume as follow:
Log in WEB management, select “Phone setting”>”Basic setting”>”Volume
setting”.
3-way Conference
You can invite the third party into a conference during an active call:
Press Conference button in an active call, dial the third party number, and
press Conference button again when you have connected the third party.
When the number of conference members is more than 3, you can make
more phones to join the conference and it will become a multiparty
conference.
*For more detailed information, you can refer to the corresponding User
Manual.
-----------------------------------------------------------------------------------------------
Address: Floor 4 Building C YueAn Industrial Park No.54 Huangcun Road Tianhe
District Guangzhou China
Postal Code: 510665
E-mail: [email protected]
http://www.escene.cn/en
