esotec Cube User manual

3. Function and Intended Use
The solar lamp is designed for all season outdoor use. The solar lamp has to
be set up free from shadows and facing the sun. Recommended are south,
east or west sides. Shadowy north sides are not appropriate. The lamp
should be positioned on stones (e.g. pebbles) and must not stand in water
or oat on water.
The light color is alternating or lockable. This can be selected by the button
at the bottom of the lamp.
The integrated rechargeable battery is charged by the solar module
installed inside the lamp. The lamp is automatically switched on when it is
getting dark and switched off at dawn or if the battery is discharged.
Powerful light emitting diodes (LEDs) are used as light source. Those LEDs
guarantee a high luminosity with a low current consumption and a lifetime
of more than 50000 hours.
Note: During longer periods with insufcient insolation, the accumulator is
charged insufciently via the sunlight. However, that does not mean that
the solar lamp is defective. Please wait for the next sunny days and the
light will work accordingly.
The rechargeable battery has to be exchanged every 2 years on
average!
4. Putting into Operation
1. Please carefully take all parts out of the package.
2. Firmly press in the „ON/OFF“ switch at the bottom of the lamp (illustration
1). You will hear a light click when pressing the switch.
3. If required, you can fasten the lamp in the ground by means of the
ground spikes.
4. Now set up the lamp at a shadow-free, sunny place.
Note: The duration of illumination strongly depends on the intensity and
duration of the solar radiation during the day. During the winter months
please generally expect a shorter light ON time. If the lamp should not
shine on the rst evening, please wait for a sunny day.
5. Operating Modes (light variation or permanent light)
The individual light colors can be operated in alternating mode or rmly set
as a permanent light. The setting is done via the button „Mode“ (illustration
2) at the bottom of the globe. By pressing the button, you can change
between the alternating light and the rmly set light color.
If you want to set one light color rmly, please wait until this color lights up
in the alternating light mode. Now press the button “Mode” once. The color
is now rmly set and is illuminated identically every night.
To return to the alternating light mode, simply press the button „Mode“
again.
6. Exchange of the rechargeable Battery
On average, the battery pack has to be exchanged by a new and identical in
construction battery every two years. Used here is a NiMh battery with 1.2 V/
400 mAh. A new battery pack is available from your retailer or the manufacturer
under www.esotec.de
Proceed as follows when exchanging the battery:
1. Unscrew the black bottom part at the bottom of the lamp anti-clockwise
(illustration 3).
2. Loosen the screws at the bottom of the black bottom part with a suitable
screwdriver (illustration 4).
3. Take out the black plastic lid (illustration 5) and take out the black rubber
gasket (illustration 6).
Operating Instructions
Solar Smart “Cube“, “Sone” and „Mushroom“
1. Introduction
Dear customer, we thank you for purchasing the Solar Globelight.
With this Solar Light you have purchased a product that complies with the
latest and most up-to-date technology.
This product complies with the European and National
Standards. The relevant certificates of conformity are
deposited with the manufacturer.
To preserve this standard and in order to maintain safety
you must adhere to the use instructions!
2. Security Instructions
In the event of any problems arising or damage occur-
ring from not following these instructions, the warranty
is deemed cancelled. The manufacturer will not be held
responsible for any claims or damages arising from the
misuse of this product.
- For safety reasons and in order to maintain standards (CE) you are pro-
hibited from altering or changing any component in the product.
- Please follow the instructions very carefully.
- For commercial applications due care and attention must be paid to the
Health and Safety Standards in your jurisdiction.
Battery take-back
- Batteries must not be discarded into domestic waste.
- The consumer is legally required to return batteries
after use, e.g. to public collecting centers or to battery
distributors.
- Contaminant-containing batteries are labeled with the
sign “crossed-out trashcan“ and one of the chemical
symbols. Used batteries should be disposed environ-
mentally friendly and should not be discarded into
domestic waste. Your dealer is legally required to take
back old batteries.
NiMh
GB
Customer support:
If you have problems or questions regarding this product, simply contact us!
esotec GmbH, Industriegebiet Weberschlag 9, D-92729 Weiherhammer
By phone: [phone]
By e-mail for ordering spare parts: [email protected]
By e-mail for questions about the product: [email protected]
Internet: www.esotec.de Manufacturer-Art.-Nr: 106100, 106102, 106103
Rechargeable battery notes
- Rechargeable batteries should not be played with by children. Never
leave rechargeable batteries lying around; they could be swallowed
by children or pets.
- Rechargeable batteries must never be short-circuited, disassembled
or thrown into fire. This leads to a danger of explosion!
- Leaking or damaged rechargeable batteries can cause chemical
burns when they come into contact with skin. For this reason, please
make use of suitable protective gloves.
- Rechargeable batteries should only be replaced by structurally iden-
tical rechargeable batteries from the same manufacturer. Normal
batteries must not be used since these are not rechargeable.
- Make sure the rechargeable batteries are inserted with the correct
polarity.
- For long periods of time of non-use (for example, storage), remove
the inserted rechargeable batteries to avoid damages via the leaking
rechargeable batteries.
Disposal:
Dear customer,
please cooperate in avoiding waste. When you intend to
dispose of the product in future, please consider that it
contains valuable raw materials suited for recycling.
Therefore, do not dispose it of with domestic waste but
bring it to a collection point for the recycling of waste
electrical and electronic equipment.
Thank you very much for your cooperation!
!
1. 2.

4. Now take out the used battery and replace it by a new, identical in
construction battery (illustration 7).
5. Now correctly attach the rubber gasket onto the bottom part. In doing so,
make sure that it sits correctly! The bulges have to sit above the buttons.
6. Now reattach the black plastic lid exactly and screw the screws back in
with a suitable screwdriver.
7. Now rmly screw in the black bottom part into the bottom side of the lamp
clockwise.
Note: Used batteries or accumulators must be disposed of in a non-polluting
way and do not belong into the domestic waste. Your dealer is legally obliged to
take back the old accumulators.
7. Malfunctions
The lamp is not activated at darkness
- A source of extraneous light (e.g. street lamp) simulates daylight
on the solar module and prevents the activation. Place the solar
module at a darker place.
The lamp is not switched on at darkness at all or only for a short time?
- Is the light switched on
- Battery weak or defective?
Exchange of the battery pack every 2 years at the latest!
8. Technical Data
• Solar module: 0,4 Wp crystalline
• Illuminants: 2 LEDs
• Light color white: 4500 K (day-light white)
• Material lamp: PE
• Protection type light globe: IP 65
• Protection class: III
• Temperature range: -10°C up to +40°C
• Duration of illumination with
a fully charged battery: max. 10 h
• Rechargeable battery: 1 x NiMh 1,2 V/ 400 mAh (Mignon)
All spare parts are available under www.esotec.de
Copyright esotec GmbH
3. 4.
5. 6.
7.
unscrew
unscrew
Unscrew
the screws
Take out Take out
Change battery
