ESS SC-EB OWNER’S MANUAL
Made in the USA

ESS SC-EB OWNER’S MANUAL
OWNER’S MANUAL
SC-EB
SPRAYER
Electrostac Spraying Systems, Inc.
62 Morrison St. · Watkinsville, GA 30677-2749
CE cercaon applied for
Copyright © 2008, Electrostac Spraying Systems, Inc. - All Rights Reserved
This manual last updated December 2, 2020.

ESS SC-EB OWNER’S MANUAL
CONGRATULATIONS!
You have just purchased one of the most advanced spraying systems on the market
today. Electrostac Spraying Systems, Inc.1 (ESS) is commied to providing you with
powerful spraying systems that are easy to operate and maintain.
The ESS electrostac sprayers are the result of the eorts and creavity of a variety of
people. In addion to input from engineering, markeng, and manufacturing
personnel, suggesons from our customers have been implemented into the design
of our equipment. We would like to hear your ideas as well! If you have any
suggesons or comments regarding the products or service of ESS, write or call us at:
Electrostac Spraying Systems, Inc.
62 Morrison Street
Watkinsville, GA 30667-2749
Phone: [phone]
1-800-213-0518
Fax: [phone]
Email: suppo[email protected]
Please take me to read this manual before operang your new ESS SC-EB Sprayer.
This manual contains important instrucons for the safe operaon of this equipment.
It also includes helpful suggesons to maximize producve use of the SC-EB. Essenal
cleaning instrucons should be followed to maintain your spraying at peak eciency.
Please carefully read and follow all instrucons for your own safety and the safety of
those around you.
Thank you!
We appreciate your business, and we are proud that you have selected an ESS
sprayer for your operaon.
Your new sprayer has been thoroughly tested and calibrated at our factory. If you
have problems with it, please get in touch with us immediately. We will be glad to
answer any quesons you have concerning our equipment or service. ESS strives to
support its customers with ecient, helpful, and friendly service. We appreciate your
business and sincerely hope that Electrostac Spraying Systems can meet your
present and future spraying equipment needs.
For your personal
records
Please record the model
and serial numbers of your
new sprayer here.
SC-EB
Model Serial Number
Spraywand Serial Number
Date of Purchase
1 ESS SC-EB HD Sprayer ™, MaxCharge ™ and the ESS logo are copyrights or registered trademarks of Electrostac Spraying Systems, Inc.

ESS SC-EB OWNER’S MANUAL
Notes

ESS SC-EB OWNER’S MANUAL
TABLE OF CONTENTS
Overview of ESS SC-EB Air Assisted Electrostac Sprayer 1
Where Does the Spray Go? 1
Safe operaon of the SC-EB sprayer 2
Operator’s Responsibility 2
Cauon 2
Chemical safety precauons 3
About the low-voltage system of the MaxCharge™ Spraywand 3
Pacemaker Disclaimer 4
Say Decals 4-5
Labeled diagram of SC-EB sprayer 6
Quick List: Operang Instrucons 7
Steps for operaon 7
Helpful Hints 7
Quick List: To clean the SC-EB aer operaon 8
Reference
Spraywand 10
Trigger 11
Nozzle Assembly 12
Pre-Spray Check 13
Post-Spray Check 13
The air and liquid delivery systems 13
Quick Connects 14
One-Liter Bole Connect 14
Air Connecon 14
Liquid Connecon 14
Nalgene Boles 15
To change the baeries 15
Spraying with your ESS Sprayer 16
Spray Technique 16
Siphoning 16
Preparing a Tank Mix 17
A note about operang temperatures 17
Trouble-Shoong Guide 18
Quick-Start Training Reference Guide 19-22
SC-EB Spraywand Parts 23
Spraywand Parts List 24
SC-EB Parts 25-30
CE Declaraon 31
Warranty 32
Yearly Spraying Service 33
Spraywand Repair/Yearly Service Return Form 34
Your SC-EB HD sprayer may appear slightly
dierent that the photographs and drawings in
this manual. We at ESS are constantly listening
to customer input and we make frequent
improvements to our sprayer designs.
______________________________________

ESS SC-EB OWNER’S MANUAL
Air-assisted electrostac sprayers produce electrically charged spray drops that
are carried to the target in a low pressure, gentle, air stream. The heart of the
SC-EB sprayer is the patented MaxCharge™ nozzle.
Air and liquid enter separately at the rear of the nozzle. Just before leaving the
nozzle, the air hits the liquid stream to make many thousands of ny spray
droplets are blown out of the nozzle and move onto the target where they are
aracted to surfaces by electrostac forces. The electrostac charge induced by
the MaxCharge™ nozzle is strong enough to allow the droplets to move in any
direcon to cover surfaces, even defying gravity to coat the underside of leaves
and the back side of the target objects. The result is uniform spray coverage on
hidden surfaces that other sprayers miss. Air-assisted electrostac sprayers give
more than twice the deposion eciency of hydraulic sprayers and non
electrostac types of air-assisted sprayers. The grower benets in terms of
signicant reducons in applicaon costs and opmized insect and disease
control, sanizaon of beef or other coverage.
The MaxCharge™ nozzle is easy to clean and corrosion-proof. The interior
ceramic outlet resists the wear three mes beer than stainless steel outlets.
These features combine to give the best spray coverage on the market. This
quality product is virtually maintenance free, and assures you of savings in the
applicaon of chemical.
The comparison of air-assisted electrostac spraying versus convenonal
spraying is dramac.
Overview of the ESS Model SC-EB Air Assisted
Electrostac Sprayer
Where Does The Spray Go?
The University of California completed a series of tests to
invesgate what happens to spray liquid aer it leaves the
nozzle.
Conclusion: ESS technology places over 4 mes the amount of
spray onto the plant surface using 1/2 the amount of chemicals.
Furthermore, they also reported that ESS sprayers send 2/3 less
chemicals to the ground and into the air. Less chemical used
overall, less waste, and less dri than convenonal equipment.
Imagine the environmental benet!
A Picture Worth A Thousand Words…
In this test, uorescent dye has been sprayed
on two round knobs. The le knob was
sprayed with the electrostac system ON;
the right knob was sprayed with the same
sprayer, but with the electrostac system
OFF. Note how even the coverage is on the
electrostac knob.
Electrostacally charged droplets
are strongly aracted to the
underside of surfaces.
1
The Maxcharge™ spray nozzle is
what makes ESS the industry leader
in the producon of electrostac
spraying equipment .
On Targeted Area
O Area On Targeted Area
O Area
Undetermined Undetermined
ESS SPRAYER CONVENTIONAL SPRAYER

ESS SC-EB OWNER’S MANUAL
Safe Operaon of the SC-EB Sprayer
Operators Responsibility
Read the Owner’s M anual! Failure to do so is considered a misuse of the equipment.
It is the responsibility of the user to read the Operator ’s Manual to understand the safe
and correct operating procedures for the sprayer and to maintain the sprayer according
to the manufacturer’s recommendations. It is the operator’s responsibility to ensure that
all who are using this equipment read this manual.
The operator is responsible for inspecting the equipment and for repairing and replacing
damaged or worn parts to prevent damage or excessive wear to other parts. It is also the
operator’s responsibility to deliver the machine for service or to replace defective parts
which are covered by the standard warranty.
Lack of aenon to safety can result in reducon of eciency, accident, personal injury, or death. Watch for safety
hazards and correct deciencies promptly. Use the following safety precauons as a guide when using the machine.
CAUTION: SHOCK HAZARD
The SC-EB sprayer has been engineered to be very safe during normal operaon. However, as with all
line-powered electrical equipment and tools, certain safety procedures need to be followed:
Use a GFCI (Ground Fault Circuit Interrupter) power outlet whenever posible.
If an extensión cord is necessary, use a three wire extensión cord with a 3-prong grounding type plug.
Turn o sprayer before unplugging.
Unplug sprayer when not in use.
Always unplug by grasping the plug. Do not unplug by pulling on the cord.
Never pull plug with wet hands.
Do not pull or carry the sprayer by its power cord. Do not crimp the cord or cause it to be damaged
by straining it around Sharp edges. Keep power cord away from heat sources.
Do not use the SC-EB sprayer with a damaged power cord. Call ESS for a replacement.
2
Read the Owner’s Manual. Failure to read the manual is considered a misuse of the equipment.
Use the SC-EB sprayer ONLY for its intended use as described in this manual.
Do not allow a child to operate the SC-EB sprayer. Do not allow adults to operate the sprayer without proper
instrucon.
Use extra care when spraying on stairs. Do not place sprayer on stairs.
Do not use without liquid bole in place.
Always empty liquid bole aer use and before transporng the sprayer.
Store sprayer in a dry place. Do not expose to freezing temperatures.
Do Not leave fully charged spraywand plugged into the charger for extended periods of me.
Do Not plug a charger into a fully charged spraywand.

ESS SC-EB OWNER’S MANUAL
CAUTION: HOT SURFACES
CHEMICAL SAFETY PRECAUTIONS
Be aware that the compressor inside the SC-EB, along with the metal connecons to the air
compressor, all become hot enough to burn you. DO NOT TOUCH, unl me has been allowed
for cooling down.
Use protecve clothing, eye protecon and gloves when mixing chemicals to be sprayed with the SC-EB
sprayer.
Some of the chemicals that can be used in the BP1 may be harmful to the skin or if inhaled. When in doubt, use
a respirator and eye protecon when spraying with the spraywand.
Follow the chemical’s manufacturer’s recommendaons in handling, mixing, applying, storing and disposing of
chemicals.
Be aware of poisoning symptoms and know the appropriate rst aid.
Know the length of me needed to pass before allowing people and pets to go back into the sprayed area.
About the low-voltage system of the MaxCharge™ Spraywand
For operator safety, the power supply for the MaxCharge™ spraywand is enrely separate form the power supply for
the sprayer’s compressor. The spraywand is powered by 9-volt baeries in the handle of the SC-EB sprayer. This
low-voltage charge is not enough to harm people. Some people report feeling a ”ngle” or a slight snging
sensaon when the spray from the spraywand falls on their bare skin.
3
Read and follow all instrucons on the chemical or pescide manufacturer’s label.
The compressor becomes hot to the touch during normal use. Do not touch the SC-EB compressor aer it has
been running. Allow compressor to cool down before risking a touch.
The metal air connecon on the top or side of the case, along with the metal quick connecon to the air hose,
both become very hot to the touch, and can burn you. Do not touch unl mes has been allowed for them to
cool down.
Stay clear of the hot compressor when making adjustments inside the SC-EB case or replacing the boles.
The sprayer’s compressor is equipped with a thermal overload switch. If it overheats, the compressor will stop
running. Unplug the sprayer and let it stand for one hour with the door open. The unit should then be able to
restart.

ESS SC-EB OWNER’S MANUAL
READ AND FOLLOW THE CHEMICAL
MANUFACTURER’S INSTRUCTIONS CAREFULLY.
It is extremely important for the owner/
operator’s safety as Well as the safety of other
people in the vicinity that all chemical safety
precauons are followed.
This label is placed on top of the SC-EB Sprayer
near the quick connect sockets.
The SC-EB compressor becomes hot during normal
operaon.
DO NOT TOUCH
This label is wrapped around the hose to remind
you to clean the lters regularly. The number one
cause of poor sprayer performance is a clogged or
ditry lter.
There will be a small shock when using our
sprayers. To avoid this shock place your thumb
on the bolt at the top of the spraywand.
Safety Decals
Appropriate safety decals are placed on ESS equipment in order to alert the operator to possible dangers.
4
If you have a pacemaker, we would recommend that you not operate an electrostac sprayer, or if you elect to
do so, know that you are accepng any risk associated therewith. Just to be clear, no one, with a pacemaker,
has ever had a problem using our electrostac sprayers, however, several years ago a physician expressed
concern, even though his opinion was un-tested and not founded in any research. Since that me, we have
taken the ulmate safe approach and recommended that those with pacemakers not operate our electrostac
sprayers.
Pacemaker Disclaimer:
SAFETY PRECAUTION
USE RECOMMENDED PERSONAL
PROTECTIVE EQUIPMENT (PPE) AS
INDICATED BY YOUR CHEMICAL
MANUFACTURER COMPANY AND
SPRAYING CONDITIONS

ESS SC-EB OWNER’S MANUAL
If you use a pacemaker, use our electrostac
sprayer at our own risk.
ESS is currently redesigning all sprayer labels.
Your sprayer may not have the same version of
these decals. If you desire an updated decal,
please contact Customer Service at
1-800-213-0518.
This label is placed inside the SC-EB case for
handy reference.
This label is placed on the charger of all spray-
wands.
5

ESS SC-EB OWNER’S MANUAL
Labeled Diagrams of the SC-EB_(side views)
6
Extended Pull Handle
Carry Handle
Carry Handle
Extended Pull Handle
Air Connecon
Labeled Diagrams of the Spraywand & Nalgene Bole Connecons, & SC-EB (inside
view)
Spraywand Connecons
On/O
Switch
Electrical
Cord Socket
On/O
Electrical
Cord Socket
Vents
Do not block.
Spraywand
Latch
Lockable
Spraywand Liquid
and Air Con-
Two—1 Liter
Boles
Extended Pull
Handle
30 Feet
(9.1 meters)
Air Hose
Carry Handle
(Stored in coils of Air
Hose) Bole cap with
Hose Assembly
Air Intake Filter
DO NOT BLOCK
Compressor
One Liter
Nalgene Bole
Spraywand
Liquid and Air
Connecons
Electrical Cord Fan & Heat
Exchanger

ESS SC-EB OWNER’S MANUAL
Quick List: Operang Instrucons
Steps for Operaon
1. Prepare the tank mix.
2. Fasten the Liquid Hose/Bole Cap Assembly ghtly on the Nalgene Bole.
3. Connect the red Air Hose to the sprayer air connecon on the side of the
SC-EB sprayer.
4. Connect the Liquid Hose to the liquid leader on the spraywand. Connect the
air hose to the spray wand air leader.
5. Plug the power cord into an appropriate receptacle. Turn on the air
compressor.
6. While either clipping the Nalgene bole to your belt or holding the
nalgene bole with one hand, spray with the other hand.
Thermal overload switch
The SC-EB compressor has a built-in thermal overload switch. If the SC-EB
overheats, the compressor will cut o. If this should happen, let the unit cool for
one hour with the case open.
Cauons:
ESS recommends that
you use an outlet with
a Ground-Fault Circuit
Interrupter (GFCI).
Do not operate the
SC-EB in standing
water
Do not immerse the
SC-EB compressor
The SC-EB compressor
becomes hot enough
to burn during
normal operaon.
DO NOT TOUCH .
7
The one-liter bole is easy to
remove. Just pull straight out in the
direcon of the arrows above.
Helpful Hints:
It’s easy to quickly switch between two chemical mixtures. Make sure the SC-EB is
turned o, then unscrew the hose assembly cap from one bole and place it in the
second bole. Tighten securely. (Also make sure to cap the rst bole.) Turn the
SC-EB on. You are ready to spray again. The unused bole may be stored inside
the SC-EB case
Extended Pull Handle
The latch for the Pull Handle simply pulls out to release the Pull Handle. Extend the
Pull Handle fully. To stow the handle again release the latch, then push the Pull
Handle in.
DO NOT BLOCK any of the vents or the Air Intake Filter. Doing so will case the
SC-EB compressor to overheat and trip the thermal overload switch.
Detailed instrucons on maintaining each of the SC-EB components follow in the next
secons.
Extended Pull
Handle Latch

ESS SC-EB OWNER’S MANUAL
1. Clean the exterior of the sprayer with a damp cloth.
2. Clean the nalgene boles and Hose/Cap assembly with clean water.
Triple rinse.
3. Disassemble and clean the liquid lter. Be careful not to lose the ow
disk.
A) Unthread the quick connect plug from the spraywand liquid
line leader. Use a 7/16” wrench on the plug and an 11/16” wrench on
the 1/8” NPT body.
4. Reassemble the liquid lter.
5. Fill one bole with a liter of clean hot water.
6. Turn on the air compressor and engage the trigger to ush the
spraywand and liquid line.
7. Aer the bole is empty run keep the trigger engaged for a few
seconds to make sure all liquid is ushed out of the liquid hose and
spraywand.
8. Apply silicone spray or similar lubricang oil to all quick connect
ngs.
8
Detailed instrucons on maintaining each of the SC-EB’s components follow in the next secons.
Quick List: To clean the SC-EB w/1st Gen Spraywand aer operaon:
How to tell if you have a 1st Gen or 2nd Gen spraywand:
2nd Gen Spraywand1st Gen Spraywand
A 1st Gen spraywand has a liquid
strainer and removeable ow
disc on the back of the
spraywand
A 2nd Gen spraywand has a ow
adaptor in the liquid hose.
Liquid strainer &
ow disc
Flow
adaptor

ESS SC-EB OWNER’S MANUAL
9
Detailed instrucons on maintaining each of the SC-EB’s components follow in the next secons.
Quick List: To clean the SC-EB w/2nd Gen Spraywand aer operaon:
1. Clean the exterior of the sprayer with a damp cloth.
2. Clean the nalgene boles and Hose/Cap assembly with clean water.
Triple rinse.
3. Fill one bole with a liter of clean hot water.
4. Turn on the air compressor and engage the trigger to ush the
spraywand and liquid line.
5. Aer the bole is empty keep the trigger engaged for a few seconds to
make sure all liquid is ushed out of the liquid hose and spraywand.
6. Apply silicone spray or similar lubricang oil to all quick connect
ngs.
How to inspect ow adaptor for a clog:
1. Use a 9/16” wrench on the ow adaptor and a 7/16” on the hose barb to remove the
hose from the ow adaptor.
2. Check the orice in the ow adaptor to see if it is clogged. To clear the clog use a pin
or small wire.
3. You might need to also remove the quick connect from the ow adaptor if the clog is
severe. To do this, use a 9/16” wrench on both the quick connect and the ow
adaptor.
4. To reassemble use the corresponding wrenches to ghten the ow adaptor back to
the quick connect and the hose barb. It is recommended to use Teon tape (Brass or
Stainless Steal) or pipe thread sealant (Brass) to prevent any leaks.
Note:
The 2nd Gen spraywand does not have a removeable ow disc and
strainer. It has a ow adaptor in the liquid hose.
Make sure to thoroughly ush the system aer use to prevent build
up from clogging the ow adaptor.
Flow
Adaptor
9/16”
Hose Barb
7/16”
Quick Connect
Flow Adaptor
Orice
Wire in ow
adaptor

ESS SC-EB OWNER’S MANUAL
REFERENCE
Spraywand
The spraywand is held by the operator during spraying. Acvaon of the trigger
causes liquid to spray. The Spraywand has the following user-serviceable parts: the
liquid lter assembly, the nozzle assembly, and the baeries. Except for baeries,
which are accessed by removing the baery cover, nothing inside the spraywand shell
is user-serviceable. Do not open the spraywand shell; doing so will void the
warranty on the spraywand.
The Spraywand
See also:
Changing the baeries
Yearly spraywand service
Spray technique
Brass Bolt Charging Indicator
Baery Housing
Trigger
Trigger lock
Nozzle
10

ESS SC-EB OWNER’S MANUAL
Trigger
The trigger turns the spray on and o. It can be connously held for operaon or it can be locked in place.
To engage/disengage the trigger:
1. Depress the trigger up towards the body of the spraywand to start spraying.
2. To keep spraying, either keep holding the trigger or lock it in place by
pulling up the lock and hooking the trigger.
3. To stop spraying when the trigger is not locked, let go of the trigger.
To clean the trigger:
1. Unthread the brass bolt on the top of the spraywand with a 5/8 ". Be careful
not to lose the spring, plunger, copper washer, and small brass bushing
inside the trigger. Note how they t inside so they may be replaced
properly.
2. Check inside the trigger for blockage. Clean out any debris with compressed
air and warm, soapy water.
3. Replace the spring and plunger; rethread the brass bolt into the top of the
spraywand unl ght.
Hose
To maintain opmal use of your sprayers hose, please remember the following;
· Do not kink or cut the hose
· Inspect the hose regularly for cuts, ruptures, tears or breaks.
· Do not pull the case around with the hose.
· Use the handles to move the case from one place to another.
Should you noce anything wrong with your hose, please contact ESS to have this hose
replaced.
Brass Bolt
Pull Trigger Lock for-
ward to engage Depress trigger
to spray
11

ESS SC-EB OWNER’S MANUAL
Nozzle Assembly
It is very important to follow all the maintenance and cleaning
procedures to ensure that the electrostac sprayer will funcon
properly. Although the MaxCharge™ nozzle will outperform all
electrostac spray technology on the market, regular cleaning will
ensure peak operang performance.
The nozzle assembly is located at the end of the spraywand wand. It is
composed of a nozzle body, internal o-ring, Teon ring, cover,
external o-ring, and a hood (see labeled drawing). To access the
nozzle components, just unscrew the nozzle cover by hand.
Cleaning the Spraywand
Always rinse the spraywand out with clean soapy water aer ever
day’s spraying. That is the most important thing you can do to
ensure trouble free operaon of your SC-EB sprayer. By cleaning aer
each and every working day you will avoid the long-term chemical
buildup that eventually causes clogs, poor spray paerns and shortens
nozzle life.
Establish maintenance intervals to disassemble and clean the nozzle.
Your nozzle maintenance schedule will vary depending on the types of
chemicals used and adherence to pre-and post-spray checks. In
general it is sucient to thoroughly clean nozzles aer 50 hours.
If heavy loads of weable powders are used, the cleaning schedule
should be sooner.
To Clean the Nozzle Assembly
1. Slide the hood over the nozzle cover.
2. Unscrew the cover from the nozzle base and remove the teon ring. Clean any debris from around the nozzle p.
NOTE: There is a small o-ring in the nozzle around the base of the p take cauon that it doesn’t fall o. If it
does, clean it and press back into place. Also, take care not to damage the nozzle p when the cover is
removed.
3. Soak the ring, cover and hood in a mild detergent soluon. Use a small brush (so or mild bristle) to clean the
inside of the cover and the hold through it. Also, be sure to clean the hood. It is important to clean inside the hood
and the two cavies. Rinse thoroughly.
4. Scrub the nozzle base with the detergent soluon using a so bristle brush. Clean the ceramic outlet. Be sure to
thoroughly clean the base cavity and take care not to damage the nozzle p. Rinse and make sure the small
o-ring is in place.
5. Reassemble nozzle by placing the teon ring on the base and screwing the cover on hand ght. Next slide the hood
over the nozzle and seat it securely against the external o-ring. Wipe clean the exterior of all hoses and ngs
connected to the nozzle.
The electrode cover should be hand ght. Never use pliers or other tools to ghten it. The insulang ring should be
loose.
NOTE: There will be a drip eect from the nozzle. The drip results from the accumulaon of ny
electrostacally charged droplets wrapping back and coang the spraywand nozzle.
12

ESS SC-EB OWNER’S MANUAL
It is important to inspect the lter for deterioraon. When handling, if the lter
begins to break apart or crumble, replace immediately.
Pre-Spray Check
1. Inspect Nozzles
Check nozzle cover to make sure it is on hand ght (do not overghten or use a
wrench). Make sure the hood is seated rmly to the nozzle base and against
the external o-ring.
2. Preparing the Tank Mix
If you will be spraying Weable powders it is a good idea to use a compability
agent with the water and tank mix. Compability agents are chemicals mixed
with the water that make mixing easier and keep heavy concentraons
uniformly in suspension. Some brand name addives are COMPLIMENT™,
UNITE®, and BALANCE™. Check with your local chemical supplier for others that
are available.
Post-Spray Check
Aer each spray it is essenal that hoses and spraywand be ushed with clean soapy
water. This will help prevent chemical build-up that can clog lines and nozzles.
The Air & Liquid Delivery System
The air compressor
The air compressor produces compressed air which atomizes and propels the
liquid. It plugs into a 110 or 220 volt electrical source. Use the SC-EB™ with a three
pronged extension cord of no more than 50 feet and rated for no less than 15 amp
service. The On/O switch is on the back of the case. Check the fans on the side of
the case for debris build up.
Cleaning the air lter
To clean the air lter, pull o the lter cap. Inside, remove foam lter, and wash in
warm, soapy water.
13
On/O
Switch
Cauons:
The SC-EB compressor becomes hot
enough to burn during normal
operaon.
DO NOT TOUCH.
The compressor has a build in
thermal overload switch. If the
SC-EB overheats, the compressor
will cut o. If this should happen,
let the unit cool for one our with
the case open.
Electrical
Cord
Socket

ESS SC-EB OWNER’S MANUAL
Quick Connects
There are four sets of quick connects (plug and socket) on the sprayer:
Compressor (air) outlet
Bole Cap/ Hose (liquid outlet
Spraywand air inlet
Spraywand liquid inlet
In all cases, the plug is on the outlet side of the connecon.
To connect the quick connects at the spraywand leaders:
1. Slide the sleeve of the quick connect socket up.
2. While holding the sleep up, push the socket onto the quick
connect plug.
3. Release the sleeve.
4. Pull on the socket body to ensure that it is properly seated and
cannot be pulled o the plug when the sleeve is down.
To disconnect the quick connects at the spraywand leaders:
1. Slide the sleeve on the quick connect socket up.
2. While holding th sleeve up, pull the socket o the quick connect
plug.
One-liter bole cap connector:
To disconnect push the gray latch at the side of the socket to reléase the plug. Pull the
plug out of the socket. Similarly, to connect, push the latch at the side of the socket
while pushing the plug in unl you feel it latch. Test the connecon by tugging gently
on the clear hose.
Air Connecon to the Base
To connect or disconnect the air connecon at the side of the base push back the quick
connect and insert to the Base. (images below)
To connect or disconnect the air or
liquid connecons on the
spraywand, pull back the outer
sleeve of the socket to release
____________________________
Note:
If the small brass rings are
visible once the socket is
placed on the quick connect
plug, the connecon is not
secure.
Be sure to connect the quick
connect and the socket
securely.
14
One-liter bole
cap connector

ESS SC-EB OWNER’S MANUAL
Nalgene Boles
The nalgene boles should be thoroughly rinsed and cleaned immediately aer each
use. A clean mild soapy water can be used.
15
Remember to charge the
spraywand baeries aer
every work session!
Baeries
To change the baeries:
1. Unscrew the two 6-32 x 1/2” Phillips head
machine screws which hold the baery cover in
place.
2. While holding the leads in one hand, gently
disconnect the baeries from the leads. Be
careful not to tear the leads o the wires or
tear the lead wires out of the power supply.
3. Connect the fresh baery pack to the leads.
4. Reconnect the baery cover. Screw the two
6-32 x 1/2” Phillips head machine screws back
in to secure the baery cover.
5. Charge the spraywand before aempng to
use it.
The nozzle charging system operates on two 9-volt rechargeable baeries which are located in the base of
the spraywand. Please charge the baeries fully before the rst use. In average condions, the baeries
will perform 5-6 hours of operaon on an individual charge. The baeries should be recharged when the
charging indicator light on top of the spraywand shell fails to glow even though air connues to ow
through the spraywand. Aer approximately 800-1000 hours of service, the baeries will no longer be able
to hold an adequate charge and will need to be replaced. Substute with 9-volt nickel-hydride
rechargeable baeries, unl the SC-EB’s replacement rechargeable baery pack from ESS can be ordered.
Be advised: Non-rechargeable 9-volt baeries can be used, however do not plug the baery
charger into the spraywand while non-rechargeable baeries are installed. This will result in
serious damage to the nozzle’s charging system and void the warranty.
We recommend charging depleted
baeries for 4-6 hours.
We do not recommend plugging a
charger into a fully charged spraywand.
This may cause baeries to over heat or
swell.
