ESS XT-3 User manual

ESS XT-3 OWNER’S MANUAL
Made in the USA

ESS XT-3 OWNER’S MANUAL
Owner’s Manual
ESS XT-3
Electrostac Spraying Systems, Inc.
62 Morrison St. · Watkinsville, GA 30677-2749
CE cercaon applied for
Copyright © 2009, Electrostac Spraying Systems, Inc. – All Rights Reserved
This manual last updated December 7, 2020.

ESS XT-3 OWNER’S MANUAL
CONGRATULATIONS!
You have just purchased one of the most advanced spraying systems on the market
today. Electrostac Spraying Systems, Inc.1 (ESS) is commied to providing you with
powerful spraying systems that are easy to operate and maintain. The products of ESS are
the result of the eorts and creavity of many people. In addion to input from
engineering, markeng and manufacturing personnel, suggesons from our customers
have been implemented into the design of our equipment.
We would like to hear your ideas also! If you have any suggesons or comments
regarding the products or service of ESS write or call us at:
Electrostac Spraying Systems, Inc.
62 Morrison St.
Watkinsville, Georgia 30677-2749
Phone: [phone]
1-800-213-0518
Fax: [phone]
[email protected]
Please take me to read this manual before operang your new ESS XT-3 Sprayer™. The
manual contains important instrucons for the safe operaon of this equipment. It also
includes helpful suggesons to maximize producve use of the XT-3. Essenal cleaning
instrucons should be followed to maintain your sprayer at peak eciency. Please
carefully read and follow all instrucons for your own safety and the safety of others
around you.
Thank you! We appreciate your business and are proud that you have selected an ESS
sprayer for your operaon.
Your new sprayer has been thoroughly tested and calibrated at the factory. If you have
any problems with it, please get in touch with us immediately. We will be glad to
answer any quesons you have concerning our equipment or service. ESS intends to
support its customers with ecient, helpful and friendly service. We appreciate your
business and sincerely hope that Electrostac Spraying Systems can meet your present
and future spraying equipment needs.
We encourage you to make copies of the “Spraywand Yearly Service” form in the back of
this manual. Use this form every year you send your wand in for maintenance and when
we service the wand, your warranty will renew for another year. The service will replace
the nozzle base, replace air and liquid hoses inside wand housing, replace lters, and
recalibrate the wand and thoroughly cleaning the enre spray wand.
1 ESS XT -3 Sprayer ™, XT ™, MaxCharge™, and the ESS logo are copyrights or registered trademarks
of Electrostac Spraying Systems, Inc.
For your personal records
Please record the model
and serial numbers of your
new sprayer here.
XT-3
______________________
Model #
______________________
Serial #
______________________
Date of purchase
i

ESS XT-3 OWNER’S MANUAL
Notes
ii

ESS XT-3 OWNER’S MANUAL
Table Of Contents:
Overview of ESS XT -3 Air-Assisted Electrostac Sprayer 1
Operator’s Responsibility 2
Chemical Safety Precauons 3
About the low-voltage system of the MaxCharge Spraywand 3
Safety Decals 4
Pacemaker Disclaimer 4
Front and Side view of the XT -3™ 5
Operang Instrucons 6
To clean the XT -3 aer operaon 7
REFERENCE
Spray wand 8
Air Filter 9
To clean the air lter 9
Trigger 10
To engage/disengage the trigger 10
To clean the trigger 10
Liquid Filter Assembly 11
To disassemble, clean, and reassemble the Liquid lter assembly 11
Nozzle Assembly 12
To clean nozzle assembly 12
Pre-spray check 13
Post-spray check 13
The Air & Liquid Delivery System 14
Air Compressor 14
Tank Pressure Regulator 14
The Quick Connects 15
Air connecon 15
Liquid connecon 15
Tank 16
Baeries 17
Spraying with Your ESS Sprayer 18
Preparing a Tank Mix 19
A note about operang temperatures 19
Trouble-Shoong Guide 20
Spraywand Service Parts 21
Parts List 22
Flow disk chart 22
XT -3 Service Parts 23–24
XT-3 Parts 25-33
CE Declaraon 34
Warranty 35
Yearly Spraywand Service 36
Spraywand Repair/Yearly Service Return Form 37
iii

ESS XT-3 OWNER’S MANUAL
Air-assisted electrostac sprayers produce electrically charged spray drops that are
carried to the plant canopy or onto the target in a low pressure, gentle, air stream.
The heart of the XT -3 Sprayer is the patented MaxCharge™ nozzle.
Air and liquid enter separately at the rear of the nozzle. Just before leaving the
nozzle, the air hits the liquid stream to make many thousands of ny spray
droplets that pass through the charging ring. An electrical charge is applied to the
spray droplets by the charging ring. Then the charged spray droplets are blown out
of the nozzle and move into the plant canopy where they are aracted to plant
material by electrostac forces. The electrostac charge induced by the Max-
Charge™ nozzle is strong enough to allow the droplets to move in any direcon
to cover all plant surfaces, even defying gravity to coat the underside of leaves and
the back side of fruits, vegetables, and objects. The result is uniform spray
coverage on hidden surfaces that other sprayers miss. Air-assisted
electrostac sprayers give more than twice the deposion eciency of hydraulic
sprayers and non-electrostac types of air-assisted sprayers. The grower benets
in terms of signicant reducons in applicaon costs and opmized insect and
disease control, sanizaon of beef or other coverage.
The MaxCharge™ nozzle is easy to clean and corrosion-proof. The interior ceramic
outlet resists wear three mes beer than stainless steel outlets. These features
combine to give the best spray coverage on the market. This quality product is
virtually maintenance-free, and assures you of savings in the applicaon of
chemical.
The comparison of air-assisted electrostac spraying versus convenonal
spraying is dramac.
Electrostacally charged droplets are
aracted to plant surfaces.
A picture is worth a thousand words…
In this test, orescent dye has been
sprayed on two round knobs. The le
knob was sprayed with the electrostac
system ON; the right knob was sprayed
with the same sprayer, but with the
electrostac system OFF. Note how even
the coverage is on the electrostac
knob.
Where Does The Spray Go?
1
Overview of the ESS Model XT-3 Air-Assisted Electrostac Sprayer
The University of California completed a series of tests to invesgate what
happens to spray liquid aer it leaves the nozzle.
Conclusion: ESS technology places over 4 mes the amount of spray
onto the plant surface using 1/2 the amount of chemicals. Furthermore,
they also reported that ESS sprayers send 2/3 less chemicals to the
ground and into the air. Less chemical used overall, less waste, and less
dri than convenonal equipment.
Imagine the environmental benet!
On Targeted Area
O Area On Targeted Area
O Area
Undetermined Undetermined
ESS SPRAYER CONVENTIONAL SPRAYER

ESS XT-3 OWNER’S MANUAL
Lack of aenon to safety can result in reducon of eciency, accident, personal injury, or death. Watch for safety hazards
and correct deciencies promptly. Use the following safety precauons as a guide when using this machine.
Read the Owner's Manual. Failure to read the manual is considered a misuse of the equipment.
Use the XT -3 sprayer ONLY for its intended use as described in this manual.
Use the XT -3 sprayer indoors only.
Do not allow a child to operate the XT -3 sprayer. Do not allow adults to operate the sprayer without proper instrucon.
Use extra care when spraying on stairs. Do not place sprayer on stairs.
Do not use without tank in place.
Always empty tank aer use and before transporng the sprayer.
Store sprayer in a dry place. Do not expose to freezing temperatures.
Do Not leave fully charged spraywand plugged into the charger for extended periods of me.
Do Not plug a charger into a fully charged spraywand.
2
Operators Responsibility
Re ad the Owner ’s M anual! Failure to do so is considered a misuse of the equipment.
It is the responsibility of the user to read the Operator’s Manual to understand the safe
and correct operating procedures for the sprayer and to maintain the sprayer according
to the manufacturer’s recommendations. It is the operator’s responsibility to ensure that
all who are using this equipment read this manual.
The operator is responsible for inspecting the equipment and for repairing and replacing
damaged or worn parts to prevent damage or excessive wear to other parts. It is also the
operator’s responsibility to deliver the machine for service or to replace defective parts
which are covered by the standard warranty.
CAUTION: SHOCK HAZARD
The XT-3 sprayer has been engineered to be very safe during normal operaon. However, as with all line-powered
electrical equipment and tools, certain safety procedures need to be followed.
Use a GFCI (Ground Fault Circuit Interrupter) power outlet whenever possible.
If an extension cord is necessary, use a three-wire extension cord with a 3-prong grounding type plug.
Turn o sprayer before unplugging.
Unplug sprayer when not in use.
Always unplug by grasping the plug. Do not unplug by pulling on the cord.
Never pull plug with wet hands.
Do not pull or carry the sprayer by its power cord. Do not crimp the cord or cause it to be damaged by straining it around
sharp edges. Keep power cord away from heat sources.
Do not use the XT -3 sprayer with a damaged power cord. Call ESS for a replacement.

ESS XT-3 OWNER’S MANUAL
About the low-voltage system of the MaxCharge Spray gun
For operator safety, the power supply for the MaxCharge spraywand is enrely separate from the power supply for
the sprayer’s compressor. The .spraywand is powered by 9-volt baeries in the handle of the XT -3 sprayer. This
low-voltage charge is not enough to harm people. Some people report feeling a “ngle” or a slight snging
sensaon when the spray from the spraywand falls on their bare skin.
CHEMICAL SAFETY PRECAUTIONS
Read and follow all instrucons on the chemical or pescide manufacturer’s label.
Use protecve clothing, eye protecon and gloves when mixing chemicals to be sprayed with the XT -3 sprayer.
Some of the chemicals that can be used in the BP1 may be harmful to the skin or if inhaled. When in doubt, use a
respirator and eye protecon when spraying with the spraywand.
Follow the chemical manufacturer’s recommendaons in handling, mixing, applying, storing and disposing of
chemicals.
Be aware of decontaminaon methods in case a person, clothing, or equipment is accidentally sprayed.
Be aware of poisoning symptoms and know the appropriate rst aid.
Know the length of me needed to pass before allowing people and pets to go back into the sprayed area.
3

ESS XT-3 OWNER’S MANUAL
READ AND FOLLOW THE CHEMICAL
MANUFACTURER’S INSTRUCTIONS CAREFULLY.
It is extremely important for the owner/
operator’s safety as Well as the safety of other
people in the vicinity that all chemical safety
precauons are followed.
This label is placed on top of the XT-3 Sprayer
near the quick connect sockets.
The SC-EB compressor becomes hot during normal
operaon.
DO NOT TOUCH
This label is wrapped around the hose to remind
you to clean the lters regularly. The number one
cause of poor sprayer performance is a clogged or
ditry lter.
There will be a small shock when using our
sprayers. To avoid this shock place your thumb
on the bolt at the top of the spraywand.
Safety Decals
Appropriate safety decals are placed on ESS equipment in order to alert the operator to possible dangers.
4
If you have a pacemaker, we would recommend that you not operate an electrostac sprayer, or if you elect to
do so, know that you are accepng any risk associated therewith. Just to be clear, no one, with a pacemaker, has
ever had a problem using our electrostac sprayers, however, several years ago a physician expressed concern,
even though his opinion was un-tested and not founded in any research. Since that me, we have taken the
ulmate safe approach and recommended that those with pacemakers not operate our electrostac sprayers.
Pacemaker Disclaimer:
SAFETY PRECAUTION
USE RECOMMENDED PERSONAL
PROTECTIVE EQUIPMENT (PPE) AS
INDICATED BY YOUR CHEMICAL
MANUFACTURER COMPANY AND
SPRAYING CONDITIONS

ESS XT-3 OWNER’S MANUAL
5
Liquid Flow Regulator
Air Filter
Tank Air Inlet
Tank Liquid Outlet
Front and side view of the ESS XT-3 TM
Spraywand Liquid Line Leader
Spraywand Air Line Leader
Air Line Female Ball Swivel
Liquid Line Female Ball Swivel
Electrical Plug
Air Compressor On/O Switch
Adjustable Air Compressor Check Relief Valve Set Between 70-100 PSI
Connects to Spraywand Liquid Line Leader
Connects to Spraywand Air Line Leader
Connects to Air Line Fe- male Ball Swivel (Red Hose)
Connects to Liquid Line Female Ball Swivel (Grey Hose)

ESS XT-3 OWNER’S MANUAL
Operang Instrucons
Steps for Operaon
1. Prepare the tank mix.
2. Connect the twin line hose to the front panel.
3. Connect the twin line hose to the liquid and air leaders on the handgun. If using
the plasc bole, connect the gray hose of the plasc bole hose assembly instead
of the gray hose of the twin line hose to the liquid leader.
4. Plug the power cord into an appropriate receptacle. Turn on the XT-3 air
compressor.
5. Engage the trigger and spray.
Cauons:
ESS recommends that you use
an outlet with
a Ground-Fault Circuit
Interrupter (GFCI).
Do not operate the
XT-3 in standing water.
Do not immerse the
XT-3 compressor.
If you use a pacemaker, use our
electrostac sprayer at our own
risk.
6
One of these labels is placed on the charger of
all spraywands.
LED LIGHT MODE
MAIN CHARGING
MODE
FINISHED
BATTERY PACK HAS
SHORT CIRCUIT OR
CONNECTOR HAS
SHORTED
When charging is complete LED Light
will automacally change to GREEN.
Remove AC plug and DC plug.
See owners manual for more
informaon.

ESS XT-3 OWNER’S MANUAL
To clean the XT-3 aer operaon:
1. Clean the exterior of the sprayer.
2. Clean the tank and/or the plasc boles.
3. Disconnect the twin line hose from the handgun air line and liquid line leaders.
4. Disassemble and clean the liquid lter. Be careful not to lose the ow disk.
5. Unthread the quick connect plug from the handgun liquid line leader. Use a 7/16”
wrench on the plug and an 11/16” wrench on the 1/8” NPT body.
6. Connect the quick connect plug to the grey hose of the twin line hose.
7. Fill the tank with 2 gallons of clean water.
8. Turn on the air compressor to ush the line with 1.75 gallons of water. Turn o the air
compressor.
9. Disconnect the quick connect plug from the twin line hose. Re-thread it into the
handgun liquid line leader.
10. Reassemble the liquid lter.
11. Turn on the air compressor and engage the trigger to ush the handgun lines with
the remaining water. Check the nozzles for a good spray paern while ushing. Allow air
to ow for 30 seconds aer the water has been sprayed.
12. Apply silicone spray or similar lubricang oil to all quick connect ngs.
Cooling Fan
Check the cooling fan on the back of the unit to make sure that debris does not clog
inside, blocking air ow into the heat exchanger. It may be necessary to use
pressurized air to clean debris out, remove the fan with screwdriver and clean the coils
if necessary.
Detailed cleaning instrucons for
each component are found in the
reference of this manual.
7

ESS XT-3 OWNER’S MANUAL
REFERENCE
Spraywand
The spraywand is held by the operator during spraying. Acvaon of the trigger causes
liquid to spray. The Spraywand has the following user-serviceable parts: the air lter, the
liquid lter assembly, the nozzle assembly, and the baeries. Except for the baeries,
which are accessed by removing the baery cover, nothing inside the Spraywand shell is
user-serviceable. Do not open the spraywand shell; doing so will void the warranty on the
spraywand.
8
Brass Bolt Charging Indicator
Baery Housing
Trigger
Trigger lock
Nozzle

ESS XT-3 OWNER’S MANUAL
Air lter
Note: XT-3 units manufactured aer March 2009 do not require an
air lter on the spraywand air leader.
For XT-3 units manufactured before March 2009, there is an in-line air lter located outside
the base of the spraywand in the air hose. It lters dirt out of the air lines. It’s easy to tell the
Air Filter from the Liquid Filter Assembly because the Air Filter is in a silver-colored casing.
Replacement parts for the air lter assembly are available as a kit. The kit includes a lter, and
large and small o-rings.
Order using ESS part number 231.
To clean the air lter:
1. Unthread the casing from the cap using a 3/4” wrench on both parts. Be careful not to lose
the spring or the air lter inside of the casing.
2. Check inside each part for debris. Clean any dirt out with compressed air or warm, soapy
water.
3. Reassemble the air lter, making sure to put it together as shown above.
Cleaning the air lter on the base unit
To clean the air lter for the compressor, pull o the lter cap, located inside the front panel.
Inside, remove lter and blow o to clean.
9
Cap O-Ring
Filter Element
Casing
Spring Filter O-Ring Cap Air Filter Assembly

ESS XT-3 OWNER’S MANUAL
Trigger
The trigger turns the spray on and o.
It can be connuously held for operaon or it can be locked in place.
To engage/disengage the trigger:
1. Depress the trigger up towards the body of the spraywand to start spraying.
2. To keep spraying, either keep holding the trigger or lock it in place by pulling
up the lock and hooking the trigger.
3. To stop spraying when the trigger is not locked, let go of the trigger.
To clean the trigger:
1. Unthread the brass bolt on the top of the spraywand with a 5/8”socket
wrench. Be careful not to lose the spring, plunger, copper washer, and small
brass bushing inside the trigger. Note how they t inside so they may be
replaced properly.
2. Check inside the trigger for blockage. Clean out any debris with compressed air
or warm, soapy water.
3. Replace the spring and plunger; rethread the brass bolt into the top of the
spray gun unl ght.
10
Brass Bolt
Pull Trigger Lock for-
ward to engage Depress trigger
to spray

ESS XT-3 OWNER’S MANUAL
To disassemble, clean and reassemble the liquid lter
(see labeled drawing above):
1. Using a 13/16” wrench on the cap (Item 8) and an 11/16” wrench on the 1/8”
NPT body (Item 12), unthread them. Note: When you disassemble the liquid
lter assembly, noce how the parts t together in order to reassemble them
properly. Be careful not to lose any parts, parcularly the ow disk (Item 10)
which is inside the cap. The sprayer will not funcon correctly without the ow
disk.
2. Remove the strainer (Item 11) from the 1/8” NPT body.
3. If the 1/8” NPT body contains residue, clean it with compressed air or clean
water.
4. Clean the strainer with compressed air or clean water. If residue sll remains in
the 50 mesh screen, disassemble the strainer. Unscrew the top brass part from
the boom brass part. The 50 mesh screen slides o the brass body and can be
cleaned with compressed air or clean water. If residue sll remains, soak the 50
mesh screen and screw the top brass part back on the lower brass part.
5. If the ow disk is sll in the cap, remove it. Check the aperture of the ow disk
for blockage. If there is any, clean it with compressed air or water. Replace the
ow disk so that the numbers on the disk face the strainer.
6. Replace the strainer in the 1/8” NPT body.
7. Rethread the 1/8” NPT body and the cap.
You may have to clean the liquid
lter more
frequently if the XT-3 is
being used to spray high-parcle
density soluons.
Liquid lter assembly
The liquid lter assembly is located outside the base of the spraywand.
It is composed of these parts: a 1/8” NPT body (Item 12), a strainer (Item 11), a
ow disk (Item 10), an adapter (Item 9) and a cap (Item 8). The strainer is the
acve ltering element in the volume of liquid that ows through the line. There is
an extra ow disk and an extra strainer in the XT-3 Parts Kit in case the
originals are lost or damaged.
11
Liquid Filter Assembly
1/8” NPT Body (Item 12) Flow Disk (Item 10) Cap (Item 8)
Strainer (Item 11) Adapter (Item 9)

ESS XT-3 OWNER’S MANUAL
Nozzle Assembly
It is very important to follow all the maintenance and cleaning
procedures to ensure that the electrostac sprayer will funcon properly.
Although the MaxCharge™ nozzle will outperform all electrostac spray
technology on the market, regular cleaning will ensure peak operang
performance.
The nozzle assembly is located at the end of the spray gun wand. It is
composed of a nozzle body, internal o-ring, Teon ring, cover, external
o-ring, and a hood (see labeled drawing at right). To access the nozzle
components, just unscrew the nozzle cover by hand.
Cleaning the spraywand
Always rinse the spraywand out with clean soapy water aer every day’s
spraying. That is the most important thing you can do to ensure trouble
free operaon of your XT -3 sprayer. By cleaning aer each and every
working day you will avoid the long term chemical buildup that
eventually causes clogs, poor spray paerns and shortens nozzle life.
Establish maintenance intervals to disassemble and clean the nozzle. Your
nozzle maintenance schedule will vary depending on the types of
chemicals used and adherence to pre- and post- spray checks. In general it
is sucient to thoroughly clean nozzles every 50 hours. If heavy loads of
weable powers are used, the cleaning schedule should be sooner.
12
To clean the nozzle assembly
1. Slide the hood over the nozzle cover.
2. Unscrew the cover from the nozzle base and remove the Teon ring. Clean any debris fromaround the nozzle p. Note: There
is a small o-ring in the nozzle around the base of the p – take care that it doesn’t fall o. If it does, clean it and press back into
place. Also, take care not to damage the nozzle p when the cover is removed.
3. Soak the ring, cover, and hood in a mild detergent soluon. Use a small brush (so or mild bristle) to clean the inside of the
cover and the hole through it. Also, be sure to clean the hood. It is important to clean inside the hood and the two cavies.
Rinse thoroughly.
4. Scrub the nozzle base with the detergent soluon using a so bristle brush. Clean the ceramic outlet. Be sure to thoroughly
clean the base cavity and take care not to damage the nozzle p. Rinse and make sure the small o-ring is in place.
5. Reassemble nozzle by placing the Teon ring on the base and screwing the cover on hand ght. Next, slide the hood over the
nozzle and seat it securely against the external o-ring. Wipe clean the exterior of all hoses and ngs connected to the nozzle.
The electrode cover should be hand ght. Never use pliers or other tools to ghten it. The insulang ring should be
loose.

ESS XT-3 OWNER’S MANUAL
Pre-Spray Check
I. Inspect Nozzles
Check nozzle cover to make sure it is on hand ght (do not over ghten or use a wrench). Make
sure the hood is seated rmly to the nozzle base and against the external o-ring.
II. Preparing the Tank Mix
If you will be spraying weable powders it is a good idea to use a compability agent with the
water and tank mix. Compability agents are chemicals mixed with the water that make mixing
easier and keep heavy concentraons uniformly in suspension. Some brand name addives are
COMPLIMENT™, UNITE®, and BALANCE™. Check with your local chemical supplier for others that
are available.
Post-Spray Check
Aer each spray it is essenal that hoses and spray gun be ushed with clean soapy water. This will
help prevent chemical build-up that can clog lines and nozzles. Also, it is recommended that the
nozzle exterior (black poron of nozzle) and nozzle hoods be cleaned with soapy water at this me.
13
Locaon of the XT-3 power switch.

ESS XT-3 OWNER’S MANUAL
The Air & Liquid Delivery System
Air compressor
The air compressor produces compressed air which atomizes and propels
the liquid. It plugs into a 110 volt electrical source. Use the XT-3™ with a
three-pronged extension cord of no more than 50 feet and rated for no less
than 15 amp service. The On/O switch is on the side of the air compressor.
The XT-3 is also available with a
220-volt compressor.
14
Tank pressure regulator
As of January 1, 2010, the XT model no longer has a regulator and gauge. If you
have a model aer that date, you can no longer regulate the tank pressure.
Once you turn the sprayer on, the tank will ll with pressure and the sprayer will
funcon as it did before. If you have a model before, see the paragraph below.
There is a pressure regulator to control air pressure to the tank. It corresponds with the pressure gauge on the
le side of the front panel. This regulator is operated by pulling out the dial and turning it clockwise to
increase pressure or counter-clockwise to decrease pressure in the tank. This regulator controls the air
pressure going to the tank not to the spraygun. Generally tank pressure should be 15 psi. There are two
purposes for the tank pressurizaon: rst, to push the liquid soluon from the tank to the spraygun, and
second, to agitate the liquid in the tank, so that the chemical stays in soluon. Once the desired pressure is
achieved, push in the dial to lock it in place. Some chemicals have a tendency to foam. If you see any foam
coming out the pressure release tank value, either reduce the tank air pressure or add an “anfoaming” agent to
the soluon. In some occasions, it may be necessary to lower tank pressure to avoid foaming, to even as low as
5 psi. When adjusng tank pressure, one should dial pressure up to desired seng, rather than down. Two air
lines run from the tank pressure regulator. One line runs to the tank pressure gauge on the front panel. The
other runs to the inlet quick connect on the tank.

ESS XT-3 OWNER’S MANUAL
Quick connects
There are four sets of quick connects (plug and socket) on the sprayer:
Compressor (air) outlet
Tank (liquid) outlet,
Spray gun air inlet
Spray gun liquid inlet
In all cases, the plug is on the outlet side of the connecon.
Air connecon
The air hose is the larger of the two hoses that make up the blue twin
line hose. The quick connect for the air connecon is on the front panel of the
XT-3 body. The air socket and plug are larger in diameter than the liquid
connecons – it is not possible to connect the air hose to the liquid socket. The
other end of the air hose connects to the air leader of the spraywand (lower
leader). It’s easily recognizable because its plug is larger than the liquid
connector.
Liquid connecon
The liquid line is noceably smaller than the air hose. Its quick connect socket
is also on the front panel of the XT -3 body. It is smaller than the air quick
connect socket – it is not possible to connect the liquid hose to the air socket.
The other end of the liquid hose connects to the liquid leader of the
spraywand (upper leader).
To connect the quick connects at the spray gun leaders:
1. Slide the sleeve of the quick connect socket up.
2. While holding the sleeve up, push the socket onto the quick connect plug.
3. Release the sleeve.
4. Pull on the socket body to ensure that it is properly seated and cannot be
pulled o the plug when the sleeve is down.
To connect the quick connects at the front panel of the XT-3:
1. Push the liquid and air plugs into their respecve sockets unl you feel
them latch.
2. Pull gently to make sure the connector is properly seated.
To disconnect the quick connects at the spray gun leaders:
1. Slide the sleeve on the quick connect socket up.
2. While holding the sleeve up, pull the socket o the quick connect plug.
To disconnect the quick connects at the front panel of the XT-3:
1. Push the sleeve on the quick connect socket towards the sprayer body.
2. While holding the sleeve down, pull the plug out of the quick connect
socket.
To connect or disconnect the air or
liquid connecons on the sprayer or
spray gun, pull back the outer sleeve of
the quick-connect to release.
15
