ETAS ES5300.2-A User manual

ES5300.2-A Housing
ES5301.2-A Housing
User’s Guide

2
Copyright
The data in this document may not be altered or amended without special noti-
fication from ETAS GmbH. ETAS GmbH undertakes no further obligation in rela-
tion to this document. The software described in it can only be used if the
customer is in possession of a general license agreement or single license. Using
and copying is only allowed in concurrence with the specifications stipulated in
the contract.
Under no circumstances may any part of this document be copied, reproduced,
transmitted, stored in a retrieval system or translated into another language
without the express written permission of ETAS GmbH.
© Copyright 2019 ETAS GmbH, Stuttgart
The names and designations used in this document are trademarks or brands
belonging to the respective owners.
V1.0.0 R03 EN - 11.2019

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 3
Contents
ETAS Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Basic Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1.1 Labeling of Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1.2 General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1.3 Requirements for Users and Duties for Operators. . . . . . . . . . . . . . . 8
1.1.4 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.1.5 Transport and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.1.6 Electrical Safety and Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1.7 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.1.8 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.1.9 Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.2 Identifications on the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.2.1 CE Marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.2.2 KC Mark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.2.3 RoHS Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.3 Taking the Product Back and Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.4 Materials Subject to Declaration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.5 About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.5.1 Using This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2 Features and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.2 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.2.1 Connection Modules for the Breakout Box . . . . . . . . . . . . . . . . . . 25
2.2.2 Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.3 Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.3.1 Supported Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.3.2 Backplane Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.3.3 Connections between the Backplane and the Real-Time PC. . . . . . 28

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide4
Contents ETAS
2.4 Slots for I/O Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.4.1 Supported PCI Express Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
2.4.2 PCI Express Carrier Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
2.4.3 Integrating Housings with VMEbus Boards. . . . . . . . . . . . . . . . . . . 32
2.5 Real-Time PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
2.5.1 Mainboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
2.5.2 LAN Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
2.5.3 Hard Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
2.5.4 Expansion Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
2.5.5 CMOS Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2.5.6 Power Supply Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2.6 Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.7 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2.7.1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2.7.2 Fuse Concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
2.7.3 Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
3 Configuration and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.1 Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.1.1 Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3.2 Preparing the Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3.2.1 Installing Connection Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3.2.2 Opening the Cable Duct . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3.2.3 Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3.3 Installing Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
3.3.1 Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
3.3.2 Attaching the PCI Express Board on the ES5370.1 Carrier Board . . 48
3.3.3 Angle Clock Bus Connection between ES5370.1 Carrier Board and
ES5340.1 / ES5340.2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
3.3.4 Gigabit Link between Master and Slave Board in an ES5370.1 . . . . 51
3.3.5 Inserting the ES5370.1 Carrier Board into a Slot . . . . . . . . . . . . . . 52
3.4 User PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
3.4.1 Connecting the User PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
3.4.2 Configuring RTIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
3.5 Powering on the ES5300.2-A / ES5301.2-A . . . . . . . . . . . . . . . . . . . . . . . . . 54
3.6 Opening/Removing the Real-Time PC Drawer . . . . . . . . . . . . . . . . . . . . . . . 55
3.7 Removing and Cleaning the Filter Mat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4 Pin Assignment and Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4.1 Backplane Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4.2 Power Supply Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
4.2.1 Wiring Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
4.2.2 Backplane Power Supply Connectors . . . . . . . . . . . . . . . . . . . . . . . 67
4.3 Real-Time PC Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5.1 Fulfilled Standards and Norms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 5
ETAS Contents
6 Ordering Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7 ETAS Contact Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide6
Contents ETAS

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 7
ETAS Introduction
1 Introduction
This chapter contains information on the following topics:
• "Basic Safety Instructions" on page 7
• "Identifications on the Product" on page 15
• "CE Marking" on page 15
• "KC Mark" on page 16
• "RoHS Conformity" on page 16
• "Taking the Product Back and Recycling" on page 16
• "Materials Subject to Declaration" on page 16
• "About This Manual" on page 18
1.1 Basic Safety Instructions
Please adhere to the safety instructions in this manuals to avoid injury to yourself
and others as well as damage to the device.
1.1.1 Labeling of Safety Instructions
The safety instructions contained in this manual are shown with the standard
danger symbol shown below:
The following safety instructions are used. They provide extremely important
information. Please read this information carefully.
1.1.2 General Safety Information
Please read the product safety advice as well as the following safety instructions
to avoid injury to yourself and others as well as damage to the device.
CAUTION!
indicates a low-risk danger which could result in minor or less serious
injury or damage if not avoided.
WARNING!
indicates a possible medium-risk danger which could lead to serious
or even fatal injuries if not avoided.
DANGER!
indicates a high-risk, immediate danger which could lead to serious
or even fatal injuries if not avoided.
Note
Please read the documentation accompanying the product (product safety
advice and this User’s Guide) carefully before using the product.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide8
Introduction ETAS
ETAS GmbH cannot be made liable for damage which is caused by incorrect use
and handling and not adhering to the safety instructions.
1.1.3 Requirements for Users and Duties for Operators
Only install, operate and maintain the products if you have the required qualifi-
cations for and experience with them.
Incorrect operation or operation by users without sufficient qualifications may
lead to injuries, death or property damage.
General Safety at Work
The existing regulations for safety at work and accident prevention must be fol-
lowed. When using these products, all applicable regulations and laws concern-
ing their operation must be observed.
1.1.4 Intended Use
ES5300.2-A Housing / ES5301.2-A Housing
The ES5300.2-A Housing / ES5301.2-A Housing is a system housing for building
a hardware-in-the-loop (HiL) test system. The ES5300-based hardware-in-the-
loop test system consists of:
• A real-time PC which is part of the ES5300.2-A Housing / ES5301.2-A
Housing
• Digital and analog interfaces to the ECU which can be integrated into the
ES5300.2-A Housing / ES5301.2-A Housing as PCI Express, SPI or I2C-
based boards
• Load simulation for connecting to ECU output stages which can be inte-
grated into the ES5300.2-A Housing / ES5301.2-A Housing in the form of
SPI or I2C based boards
• Battery node simulation (e.g. K15, K30, …) for connecting to the ECU
which can be integrated into the ES5300.2-A Housing / ES5301.2-A Hous-
ing in the form of SPI or I2C based boards
– The simulation of the vehicle battery itself is not a component part of
the ES5300.2-A Housing / ES5301.2-A Housing and cannot be inte-
grated here.
The ES5300.2-A Housing / ES5301.2-A Housing must always be installed in the
ETAS housing (ES4015.2 Housing 9U) intended for this purpose or a 19" rack
system, and must not be operated as a stand-alone unit.
The whole ES5300-based HiL system consists of a real-time computer, which is
part of the ES5300.2-A Housing / ES5301.2-A Housing, and one or more plug-in
boards. The plug-in boards provide the connected ECU with analog and/or digital
interfaces, as well as the simulation of loads and battery nodes.
Note
The system integrator is responsible for the safety of systems that use the prod-
ucts.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 9
ETAS Introduction
ES5370.1 Carrier Board PCI Express x16 socket, GEN1/2 x1 Link
The ES5370.1 is a plug-in board for the ES5300 system housing. The ES5370.1
must only ever be used in the ETAS ES5300 system housing intended for this
purpose and must not be operated as a stand-alone unit.
The ES5370.1 is a carrier board that is designed for accommodating the
ES5340.1, ES5340.2 and ES5335.1 PCI Express boards and third party hardware
that has been approved by ETAS for the ES5370.1.
The intended use of the products is as follows:
• Use as a component in industrial lab equipment or at industrial work-
places
• Use as a hardware interface for ECUs in a hardware-in-the-loop test sys-
tem
• Use in conjunction with ETAS software that supports the ES5300.2-A
Housing / ES5301.2-A Housing and the ES5300.1-B Housing
• Use as an interface in conjunction with software programs that operate
the standardized, documented and open APIs from ETAS software prod-
ucts
The products are not intended for the following:
• Use within on-road vehicles
• Use as part of a life support system
• Use as part of a medical application
• Applications in which misuse may result in injury or damage
• Use in environments in which conditions prevail that fall outside the spec-
ified ranges (see "Environmental Conditions" on page 71)
• Use with signal conditioning that falls outside the specified ranges
Requirements for the Technical State of the Products
The products reflect the state of the art and comply with recognized safety rules.
The products must only be operated in a technically flawless state, in accordance
with their intended purpose and in a safety-conscious and hazard-aware manner
under consideration of the documentation regarding each product. If the prod-
ucts are not used in accordance with their intended purpose, their product safety
may be impaired.
In order to operate the ES5300.2-A Housing / ES5301.2-A Housing and the
ES5300.1-B Housing safely, you must observe the section "Safety Instructions"
on page 41.
Requirements for Operation
• Only use the products in accordance with the specifications in the corre-
sponding User's Guides. If the products are used in any other way, product
safety is no longer ensured.
• Do not use the products in a wet or damp environment.
• Do not use the products in potentially explosive atmospheres.
• Keep the surfaces of the products clean and dry.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide10
Introduction ETAS
1.1.5 Transport and Installation
Transport
Installation
Requirements for the Installation Location
CAUTION!
The ES5300.2-A Housing / ES5301.2-A Housing weighs at least
20.5 kg. Only lift or carry the transport box or the housing with two
people.
CAUTION!
The ES5300.2-A Housing / ES5301.2-A Housing and the ES5300.1-B
Housing together weigh at least 30 kg. Only lift and carry the trans-
port box or the housing with two persons or using a lifting device.
CAUTION!
Danger of falling parts!
The rail guides on the 19" rack system must be specified for double
the total weight (A Housing or B Housing + fitted plug-in boards).
Only use rail guides that are designed to hold at least 100 kg per pair.
If the rail guides are designed for too light a weight, they could bend
or break.
CAUTION!
In order to prevent damage to the plug-in boards and the LABCAR
housing, and thereby also avoid damage to property or health,
observe the installation instructions and information contained in the
relevant User's Guides.
CAUTION!
Some components of the ES5370.1 Carrier Board may be damaged
or destroyed by electrostatic discharges. Leave the plug-in board in its
transport packaging until it is installed. Only remove, configure and
install the product at a workplace that is protected against electro-
static discharges.
WARNING!
This is class A equipment. This equipment can cause radio interfer-
ence in residential areas. Should that be the case, the operator may
be requested to institute reasonable measures.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 11
ETAS Introduction
Calibration
Ventilation
When operating the ES5300.2-A Housing / ES5301.2-A Housing and the
ES5300.1-B Housing in its casing, please observe the following points:
• The enclosure and particularly the ventilation openings must have a dis-
tance to walls or objects in the environment of at least 15 cm.
• Leave the enclosure open at the rear.
When operating the ES5300.2-A Housing / ES5301.2-A Housing and the
ES5300.1-B Housing in the 19" rack, please observe the following points:
• The ventilation openings must have a distance to walls or objects in the
environment of at least 15 cm. Keep a distance of at least 44.5 mm (1 RU)
from the next module at the top and bottom.
• The ambient temperature in the rack must not exceed the maximum value
of 40 °C/104 °F.
1.1.6 Electrical Safety and Power Supply
Observe the regulations applicable at the operating location concerning electrical
safety as well as the laws and regulations concerning work safety!
CAUTION!
If cards (e.g. for startup or calibration) are unlocked but not com-
pletely removed from the housing, they must be pulled out far
enough that the distance between the respective card and the back-
plane of the housing is at least 1 cm.
Otherwise, contacts may be established between the cards and lead
to their destruction.
CAUTION!
The six right-hand slots (above the PC power supply unit) are cooled
by one fan only. Do not insert any boards with high heat development
into these slots.
CAUTION!
The air circulation inside the ES5300.2-A Housing / ES5301.2-A Hous-
ing and the ES5300.1-B Housing can be ensured only if all free slots
are covered with front plates. Otherwise, it may lead to overtempera-
tures and trip the overtemperature protection of the ES5300.2-A /
ES5301.2-A or the ES5300.1-B. For this reason, install front plates in
all free slots!

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide12
Introduction ETAS
Safety Concept:
The power supply unit of the ES5300.2-A / ES5301.2-A has safety features that
protect against short-circuiting, overload, overvoltage and overcurrent. In addi-
tion, it is fitted with an internal safety fuse; however, this cannot be replaced by
the user.
Grounding/Grounding Contact
For additional information see also "Grounding/Protective Contact" on page 42.
To check the connections of the PE conductors after assembling ES5300.2-
A / ES5301.2-A and ES5300.1-B:
1. After assembling both housings, check the electrical
connections of all PE conductors between the star
point and the PE contacts on the interior of the
front doors on the ES5300.2-A Housing / ES5301.2-
A Housing and the ES5300.1-B Housing.
2. Check the mechanical connections and the installa-
tion of all PE conductors (visual check).
3. Document the results of your check.
WARNING!
Fire hazard!
Only use fuses for the ES5370.1 Carrier Board that comply with the
specification in the ES5300.2-A / ES5301.2-A User's Guide. Never
bridge defective fuses!
DANGER!
Risk of electric shock!
- The grounding of the overall system is implemented via the PE con-
ductor of the power supply cord. If no proper grounding via the PE
conductor is available, housing components that can be touched
could be live. For this reason, it must be ensured that the power cable
features correctly connected grounding contacts! If this cannot be
ensured, connect a ground to the PE terminal on the rear housing
side of the ES5300.2-A / ES5301.2-A in addition.
- The PE star point for the ES5300.2-A / ES5301.2-A / ES5300.1-B
Housing is in the drawer in the ES5300.2-A Housing / ES5301.2-A
Housing. The PE star point must be secured using 0.8 Nm torque. If
the PE star point is connected too loosely, there is no guarantee that
grounding will provide reliable protection.
Failure to observe these instructions can lead to serious or fatal injury.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 13
ETAS Introduction
Power Supply Cord
The respective requirements for the power supply cord, which vary according to
regional differences in the power supply, and the ETAS order number can be
found in the ES5300.2-A / ES5301.2-A User's Guide. To avoid injuries and dam-
age to hardware, please only use the power supply cord specified here
(see"Power Cables" on page 39).
Use only primary power cables in accordance with IEC 60320 with C13 plug at
one end and non-locking plug approved according to national safety standards
at the other end. Plug and cable must be rated for at least 250 VAC/10 A or
125 VAC/15 A.
Power Supply to the ES5370.1
The product is powered by the ES5300.2-A Housing / ES5301.2-A Housing or the
ES5300.1-B Housing via the PCIe Backplane Connector.
Supply Voltage Disconnect Device
The switch next to the power supply plug on the ES5300.2-A / ES5301.2-A acts
as a supply voltage disconnect device for the ES5300.2-A / ES5301.2-A and the
ES5300.1-B.
Disconnect the ES5300.2-A Housing / ES5301.2-A Housing from the supply
during a thunderstorm or install corresponding protective devices!
The power supply cord must be easy to access. It must not be longer than 3 m.
De-Energizing the ES5370.1
Switch off the ES5300.2-A Housing / ES5301.2-A Housing, the ES5300.1-B
Housing and external power supplies, and unplug the power plug and other con-
nectors attached to the plug-in board. Wait at least three minutes before remov-
ing the plug-in board.
Connecting Cables
Insulation Requirements for Lab Power Supplies to Circuits Connected to the HiL
System:
• The power supply to live circuitry must be safely isolated from the supply
voltage. For example, use a car battery or a suitable lab power supply.
• Only use lab power supplies with dual protection for the supply network
(with double/reinforced insulation (DI/RI)). This requirement is met by lab
power supplies that comply with IEC/EN 60950 or IEC/EN 61010.
• The lab power supply must be approved for use at a height of 2000 m and
in ambient temperatures of up to 40 °C.
WARNING!
Fire hazard!
Use only approved cables for creating cable assemblies (e.g. for con-
necting the ECU and external loads). The cables used must, in partic-
ular, be suitable for the currents, voltages and temperatures which
occur and must be flameretardant in accordance with one of the fol-
lowing standards
IEC 60332-1-2, IEC 60332-2-2, UL 2556/UL1581VW-1!

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide14
Introduction ETAS
Connecting/Disconnecting Devices
To avoid injuries and hardware damages, please observe the following precau-
tionary measures:
• Do not apply any voltages to the ports of the ES5300.2-A Housing /
ES5301.2-A Housing or the ES5300.1-B Housing that do not comply with
the specifications of the port in question. The exact specification of the I/
O hardware is located in the User's Guides of the corresponding plug-in
boards.
• Do not connect or disconnect any devices while the ES5300.2-A Housing
/ ES5301.2-A Housing, the ES5300.1-B Housing or connected devices are
switched on.
First, switch off the ES5300.2-A Housing / ES5301.2-A Housing by shut-
ting down the real-time PC and by activating the On/Off switch at the rear
and unplug the power cable.
• When plugging in connectors, ensure that they are inserted straight and
no pins are bent.
Opening the Housing
The ES5300.2-A Housing / ES5301.2-A Housing must only be opened by quali-
fied technical personnel!
1.1.7 Cleaning
ES5300.2-A / ES5301.2-A and ES5300.1-B
Before cleaning any parts of the housing, disconnect the power cable. Clean the
device only with a dry cloth. Do not use any cleaning agents or solvents!
Clean the filter of the rear ventilation opening on the ES5300.2-A / ES5301.2-A
once per year (see "Removing and Cleaning the Filter Mat" on page 61).
ES5370.1
The product is not expected to require cleaning.
1.1.8 Maintenance
The products do not require any separate maintenance by the user.
1.1.9 Repairs
If an ETAS hardware product needs to be repaired, return the product to ETAS.
DANGER!
Risk of electric shock!
The ES5300.2-A Housing / ES5301.2-A Housing and the ES5300.1-B
Housing must only be opened by qualified technical personnel. If the
ES5300.2-A Housing / ES5301.2-A Housing and the ES5300.1-B
Housing are not completely disconnected from the supply system,
there is a risk of electric shock.
Break the connection to the supply system by switching it off and
removing the power cable – wait at least three minutes until all of the
components (e.g. power supply unit, capacitors) have been dis-
charged.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 15
ETAS Introduction
If the power supply unit of the ES5300.2-A / ES5301.2-A is defective, you can
remove the drawer of the real-time PC (see "Opening/Removing the Real-Time
PC Drawer" in the ES5300.2-A / ES5301.2-A User's Guide) and send it to ETAS
to be repaired.
1.2 Identifications on the Product
The following symbols are used for identifying the product:
Observe the information in chapter "Technical Data" on page 69.
1.2.1 CE Marking
ETAS confirms that the product meets the product-specific applicable European
Directives with the CE marking affixed to the product or its packaging. The CE
Declaration of Conformity for the product is available upon request.
CAUTION!
In order to avoid damage to property and personal injury, the drawer
must only be removed by ETAS-trained specialist personnel. You must
observe the safety instructions in the section "Before You Start"
on page 41.
Symbol Description
Before using the product, carefully read the user’s guide!
Identification for CE (see "CE Marking" on page 15)
Marking for KCC conformity
(see "KC Mark" on page 16
Identification for China RoHS (see "RoHS Conformity"
on page 16)
Identification for WEEE directive
(see "Taking the Product Back and Recycling" on page 16)

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide16
Introduction ETAS
1.2.2 KC Mark
With the KC mark attached to the product and its packaging, ETAS confirms that
the product has been registered in accordance with the product-specific KCC
guidelines of the Republic of Korea.
1.2.3 RoHS Conformity
European Union
The EU Directive 2011/65/EU limits the use of certain dangerous materials for
electrical and electronic devices (RoHS conformity).
ETAS confirms that the product corresponds to this directive which is applicable
in the European Union.
China
ETAS confirms that the product meets the product-specific applicable guidelines
of the China RoHS (Management Methods for Controlling Pollution Caused by
Electronic Information Products Regulation) applicable in China with the China
RoHS marking affixed to the product or its packaging.
The concluding chapter "ETAS Contacts" gives you information about the inter-
national ETAS sales and service branch offices.
1.3 Taking the Product Back and Recycling
The European Union has passed a directive called Waste Electrical and Electronic
Equipment, or WEEE for short, to ensure that systems are set up throughout the
EU for the collection, treatment and recycling of electronic waste.
This ensures that the devices are recycled in a resource-saving way representing
no danger to health or the environment.
Fig. 1-1 WEEE Symbol
The WEEE symbol on the product or its packaging shows that the product must
not be disposed of as residual garbage.
The user is obliged to collect the old devices separately and return them to the
WEEE take-back system for recycling.
The WEEE Directive concerns all ETAS devices but not external cables or batteries.
For more information on the ETAS GmbH Recycling Program, contact the ETAS
sales and service locations (see "ETAS Contact Addresses" on page 75).
1.4 Materials Subject to Declaration
Some products from ETAS GmbH (e.g. modules, boards, cables) use components
with materials that are subject to declaration in accordance with the REACH reg-
ulation (EC) no.1907/2006.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 17
ETAS Introduction
Detailed information is located in the ETAS download center in the customer
information "REACH Declaration" < www.etas.com/Reach >. This information is
continuously being updated.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide18
Introduction ETAS
1.5 About This Manual
This manual consists of the following chapters:
• "Introduction" on page 7
This chapter
• "Features and Functions" on page 21
This chapter contains an overview of the features and functions of the
components of the ES5300.2-A Housing / ES5301.2-A Housing.
• "Configuration and Operation" on page 41
This chapter contains information on connecting, configuring and operat-
ing the ES5300.2-A Housing / ES5301.2-A Housing.
• "Pin Assignment and Connections" on page 63
This chapter describes the various connections of the ES5300.2-A Housing
/ ES5301.2-A Housing.
• "Technical Data" on page 69
This chapter contains the technical data on the ES5300.2-A Housing /
ES5301.2-A Housing.
1.5.1 Using This Manual
Representation of Information
All activities to be carried out by the user are shown in what we call a "Use-
Case" format, i.e. the target to be achieved is defined briefly in the title and the
individual steps necessary to achieve this target are then listed. The information
is displayed as follows:
Target definition
Any introductory information...
1. Step 1
Possibly an explanation of step 1...
2. Step 2
Possibly an explanation of step 2...
Any concluding remarks...
Concrete example:
To create a new file
If you want to create a new file, no other file may be open.
1. Select File → New.
The "Create file" dialog box appears.
2. Enter a name for the file in the "File name" field.
The file name must not exceed 8 characters.
3. Click OK.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide 19
ETAS Introduction
The new file is created and saved under the name specified. You can now work
with the file.
Typographic Conventions
The following typographic conventions are used:
Important notes for the user are shown as follows:
Select File →Open. Menu commands are shown in boldface/
blue.
Click OK. Buttons are shown in boldface/blue.
Press <ENTER>. Keyboard commands are shown in angled
brackets in block capitals.
The "Open File" dialog box
appears.
Names of program windows, dialog boxes,
fields etc. are shown in quotation marks.
Select the file setup.exe. Text in drop-down lists, program code, as
well as path and file names are shown in
the Courier font.
A conversion between the file types
logical and arithmetic is not possi-
ble.
Content markings and newly introduced
terms are shown in italics
Note
Important note for the user.

ES5300.2-A Housing, ES5301.2-A Housing - User’s Guide20
Introduction ETAS
