ETC Source Four LED Series User manual

ETC®Quick Guide
Source Four LED™Profile
Source Four LED Profile v1.3.0 Quick Guide Page 1 of 7 Electronic Theatre Controls, Inc.
Corporate Headquarters  3031 Pleasant View Road, P.O. Box 620979, Middleton, Wisconsin 53562-0979 USA  Tel [phone]  Fax [phone]
London, UK  Unit 26-28, Victoria Industrial Estate, Victoria Road, London W3 6UU, UK  Tel [phone]  Fax [phone]
Rome, IT  Via Pieve Torina, 48, 00156 Rome, Italy  Tel [phone]  Fax [phone]
Holzkirchen, DE  Ohmstrasse 3, 83607 Holzkirchen, Germany  Tel [phone]  Fax [phone]
Hong Kong  Rm 1801, 18/F, Tower 1 Phase 1, Enterprise Square, 9 Sheung Yuet Road, Kowloon Bay, Kowloon, Hong Kong  Tel [phone]  Fax [phone]
Service: (Americas) [email protected]  (UK) [e-mail]  (DE) [e-mail]  (Asia) [email protected]
Web: www.etcconnect.com  Copyright © 2012 ETC. All Rights Reserved.  Product information and specifications subject to change.
7460M1300-1.3.0  Rev B  Released 2012-04  ETC intends this document to be provided in its entirety.  US and international patents pending
Overview
For complete information and step-by-step instructions, see Source Four LED Profile v1.3.0 User
Manual.
Accessory
holder
Yoke
Accessory
retainer
Yoke
locking knob
Safety cable
loop
LCD
DMX Thru
DMX In
Keypad
Power In
Power Thru
Status
indicators
Light Bulb
Home
Back
Up
Enter
Down
Power – Indicates AC power is On.
DMX – Indicates control signal is Active.
Error – Indicates data error, high temperature, or other unusual status.

ETC Source Four LED Quick Guide
Install Lens Tube
Source Four LED Profile v1.3.0 Quick Guide Page 2 of 7 Electronic Theatre Controls, Inc.
Install Lens Tube
Step 1: Slide lens tube into shutter barrel.
Step 2: Install the lens zoom knob.
Step 3: Install the Phillips screw in the top of the lens barrel.
Install Fixture
Step 1: Hang or mount the fixture.
Step 2: Attach safety cable.
Step 3: Insert additional accessories such as a top hat, etc.
WARNING:
Use only hardware rated for total weight of fixture and accessories.
A safety cable (or other approved safety device) must be securely attached
to the safety cable loop before loosening the clamp.
Low clearance position
General use position

ETC Source Four LED Quick Guide
Connect
Source Four LED Profile v1.3.0 Quick Guide Page 3 of 7 Electronic Theatre Controls, Inc.
Connect
Step 1: Attach power cable to Power In.
Step 2: Attach 5-pin XLR cable to DMX In (if using external control).
Step 3: Connect power cable to AC power.
Step 4: Plug XLR cable (if using) into data source.
Step 5: Link additional fixtures via Power Thru and DMX Thru connectors.
Focus
Step 1: Supply power and wait for the fixture to boot up.
Step 2: Press [Light Bulb] to open Presets & Sequences.
Step 3: Select Focus and press [Enter] to turn on LED array.
Step 4: Adjust fixture's position.
Step 5: Once focus is set, press [Enter] to turn off LED array and then [Home] to return to home
screen.
WARNING:
No more than nine Source Four LED fixtures per circuit (non-dimming, 100
to 240 VAC, 50/60 Hz)
Up to 32 device loads on the DMX daisy-chain.
Disconnect Power and DMX before all cleaning and maintenance.
Power In
Power Thru
DMX In
DMX Thru

ETC Source Four LED Quick Guide
Soft Focus Diffuser
Source Four LED Profile v1.3.0 Quick Guide Page 4 of 7 Electronic Theatre Controls, Inc.
Soft Focus Diffuser
Step 1: Install the diffuser into an A-Sized Pattern holder.
Step 2: Install a pattern in front of the diffuser, if needed.
Step 3: Insert the pattern holder and diffuser into the Pattern holder slot, making sure the
writing on the diffuser faces the front of the fixture.
Address
Step 1: From the home screen, press [Enter] to open Main Menu.
Step 2: On the Main Menu, scroll to DMX Start Address, press [Enter].
Step 3: Use [Up] or [Down] to scroll to desired address.
Step 4: Press [Enter] to select address number.
Step 5: Press [Home] to return to home screen.
* DMX address is not needed if using standalone or master/slave control.
Features Quick Setup
Step 1: On the Main Menu, scroll to Quick Setups.
Step 2: Press [Enter].
Step 3: Scroll to the desired setup and then press [Enter].
An asterisk (*) indicates which setup is active.
Step 4: Press [Home] to return to the home screen.
The top line of the home screen displays the name of the active setup.
Individual features and settings are adjustable under the Advanced menu. Consult the User Manual for
more information on advanced features of Source Four LED fixtures.

ETC Source Four LED Quick Guide
Quick Setups
Source Four LED Profile v1.3.0 Quick Guide Page 5 of 7 Electronic Theatre Controls, Inc.
Quick Setups
Lustr+
Quick Setup Features Recommended For:
General Smooth dimming, good consistency, direct
color control, simple operation. General lighting, rentals.
Stage
Tungsten-like dimming, HSI color control with
Plus-7 fine tuning, fast color mixing and
consistency, console output snapshot to
record stand alone presets.
Theatrical lighting.
XT Arch Maximum consistency in extreme
applications, reduced brightness.
High-temperature environments, installations
with limited access.
High Impact Maximum brightness, quick response, RGB
color control, reduced consistency. Video-based control, effects lighting, concerts.
Studio
Three-point control—White Point (CCT),
Intensity and Tint, DMX, or standalone
operation.
Video and film lighting, white light-only
applications.
Parameter General Stage XT Arch High Impact Studio
DMX Settings
Profile Direct HSI HSI RGB Studio
Strobe Enabled Enabled Enabled Enabled Enabled
Data Loss
Setting Instant Instant HLL-4ever Instant N/A
Plus Seven N/A Enabled Disabled Disabled Disabled
Fan Control DMX DMX DMX DMX DMX
LED Settings
Output Setting Regulated Regulated Protected Boost Regulated
Dimming
Curve Standard Incandescent Standard Quick Linear
Red Shift N/A Disabled Disabled Disabled N/A
White Point N/A 3200 3200 5600 N/A
Local Settings
Status
Indicators On On On On On
Overtemp Dark Dark Visible Dark Visible

ETC Source Four LED Quick Guide
Quick Setups
Source Four LED Profile v1.3.0 Quick Guide Page 6 of 7 Electronic Theatre Controls, Inc.
Tungsten and Daylight
Quick Setup Features Recommended For:
Studio Linear dimming, simple standalone operation
via the UI.
Video or film lighting, installations without
DMX control.
Stage Tungsten-like dimming, stage-friendly
settings, DMX fan control.
Theatrical lighting, installations mixed with
tungsten.
Single
Channel
Standard dimming, automatic fan, only 1
DMX channel.
Architectural applications with streamlined
control.
Parameter Studio Stage Single Channel
DMX Settings
Profile Intensity Intensity Intensity
Strobe Enabled Enabled Disabled
Data Loss Setting N/A Instant Instant
Fan Control DMX DMX Automatic
LED Settings
Output Setting Regulated Regulated Regulated
Dimming Curve Linear Incandescent Standard
Local Settings
Status Indicators On On On
Overtemp Visible Dark Dark

ETC Source Four LED Quick Guide
DMX Profiles
Source Four LED Profile v1.3.0 Quick Guide Page 7 of 7 Electronic Theatre Controls, Inc.
DMX Profiles
Tungsten and Daylight
Lustr+
* When this feature is enabled.
Typical Power Consumption
Lustr+
Daylight
Tungsten
Channel Control
1Intensity
2Strobe*
3Fan control*
Channel HSI HSIC RGB Studio Direct
1Hue Hue Red Intensity Color 1
2Hue fine Hue fine Green Color temp Color 2
3Saturation Saturation Blue Tint Color 3
4Intensity Intensity N/A N/A Color 4
5Strobe* Strobe* Strobe* Strobe* Color 5
6Fan control*Fan control*Fan control*Fan control*Color 6
7N/A Color temp N/A N/A Color 7
8Plus7 on/off*Plus7 on/off*Plus7 on/off*Plus7 on/off*Intensity
9Plus7 - (1)*Plus7 - (1)*Plus7 - (1)*Plus7 - (1)*Strobe*
10 Plus7 - (2)*Plus7 - (2)*Plus7 - (2)*Plus7 - (2)*Fan control*
11 Plus7 - (3)*Plus7 - (3)*Plus7 - (3)*Plus7 - (3)*N/A
12 Plus7 - (4)*Plus7 - (4)*Plus7 - (4)*Plus7 - (4)*N/A
13 Plus7 - (5)*Plus7 - (5)*Plus7 - (5)*Plus7 - (5)*N/A
14 Plus7 - (6)*Plus7 - (6)*Plus7 - (6)*Plus7 - (6)*N/A
15 Plus7 - (7)*Plus7 - (7)*Plus7 - (7)*Plus7 - (7)*N/A
90V 120V 240V
Idle Power / Current 4.27W / 0.084A 4.38W / 0.079A 4.2W / 0.068A
100% Boost Power / Current 130.8W / 1.48A 129.9W / 1.11A 126.4W / 0.576A
90V 120V 240V
Idle Power / Current 4.3W / 0.083A 4.35W / 0.077A 4.04W / 0.066A
100% Boost Power / Current 165.2W / 1.87A 163.3W / 1.39A 160.3W / 0.718A
100V 120V 240V
Idle Power / Current 4.3W / 0.085A 4.35W / 0.078A 4.0W / 0.065A
100% Boost Power / Current 159.8W / 1.81A 157.4W / 1.35A 154.8W / 0.695A
