Eterna POLY10PIR User manual

Issue 2015
HELPLINE:
• T: 01933 673 144
• F: 01933 678 083
• E: [email protected]o.uk
Visit our website:
www.eterna-lighting.co.uk
These instructions are provided as a guideline to assist you.
PLEASE READ THESE INSTRUCTIONS BEFORE USING YOUR NEW FITTING
PLEASE RETAIN FOR FUTURE REFERENCE
INSTALLATION INSTRUCTIONS
A guide for qualied electricians
1M
Model:
POLY10PIR / POLY20PIR / POLY30PIR
10W / 20W / 30W Polycarbonate LED Floodlights With PIR
PG 6 PG 1
Made in China
EVENTUALLY, YOU MAY WANT TO
REPLACE THIS PRODUCT:
Regulations require the recycling of Waste from
Electrical and Electronic Equipment (European
“WEEE Directive” eective August 2005—UK
WEEE Regulations eective 2nd January 2007).
Environment Agency Registered Producer: WEE/
GA0248QZ.
WHEN YOUR PRODUCT COMES TO THE END OF
ITS LIFE OR YOU CHOOSE TO REPLACE IT, PLEASE
RECYCLE IT WHERE FACILITIES EXIST  DO NOT
DISPOSE WITH HOUSEHOLD WASTE.
IF YOU EXPERIENCE PROBLEMS:
If you believe your product is defective, please return
it to the place where you bought it. Our Technical
Team will gladly advise on any Eterna Lighting
product, but may not be able to give specic
instructions regarding individual installations.
LAMP SPECIFICATIONS: 10W 20W 30W
Lumens total ux 800 lm 2000 lm 3000 lm
Lumens 120° ux 750 lm 1870 lm 2800 lm
Rated Wattage 9.3W 19.9W 30W
Rated luminous ux 900 lm 2000 lm 3000 lm
Nominal life time of the lamp 25,000 hrs 25,000 hrs 25,000 hrs
Colour temperature 4000K 4000K 4000K
Number of switching cycles
before premature lamp
failure
15,000 15,000 15,000
Warm-up time up to 60 % of
the full light output Instant full light Instant full light Instant full light
Dimmable No No No
LED array dimensions (L/W) 42 x 22mm 60 x 30mm 77 x 33mm
Nominal beam angle 120° 120° 120°
Rated power 9.3W 19.9W 30W
Rated lamp lifetime 25,000 hrs 25,000 hrs 25,000 hrs
Lamp power factor >0.9 >0.9 >0.9
Lumen maintenance factor at
end of nominal life ≥70% ≥70% ≥70%
Starting time <0.5s <0.5s <0.5s
Colour rendering >65 >65 >65
Colour consistency Within 6 step
Macadam ellipse
Within 6 step
Macadam ellipse
Within 6 step
Macadam ellipse
Rated peak intensity 326cd 852cd 1300cd
Voltage 230V 230V 230V
Not suitable for accent lighting
Pack contents:
1 x LED oodlight with
PIR complete with 2 core
1.0mm2x 0.8m silicone
cable and quick x
mounting bracket
10W
20W
30W
TRADE
PRODUCT:
ENERGY
INFORMATION
AVAILABLE ON
APPLICATION

To avoid damage to the unit do not aim sensor
towards sun.
Avoid positioning the sensor unit adjacent to a
bright light source which may prevent the unit from
operating when the lux control is set to operate in
dark conditions.
Avoid nuisance / false triggering by directing sensor
away from:
• Trees and shrubs
• Reective surfaces such as smooth white walls
• Swimming pools
• Heat sources such as boiler ues
The PIR sensor scanning specications
(approximately 10 metres at 120°) may vary slightly
depending on the mounting height and location.
The detection range of the unit may also alter with
temperature change. Before selecting a place to
install your PIR oodlight you should note that
movement across the scan area is more eective
than movement directly towards or away from the
sensor. (Refer to g.2 opposite).
If movement is made walking directly towards or
away from the sensor and not across the sensor
the apparent detection range will be substantially
reduced (refer to g. 3 below).
INTRODUCTION:
The oodlight incorporates a PIR (Passive Infra Red)
sensing device which continuously scans a preset
operating zone and immediately switches the light
on when it detects movement in that area.
This means that whenever movement is detected
within the range of the sensor the light will switch
on automatically to illuminate the area you have
selected to light. While there is movement within
range of the unit the light will remain on.
READ THIS FIRST:
Check the pack and make sure you have all of the
parts listed on the front of this booklet. If not,
contact the outlet where you bought this product.
This product contains glass, care must be taken when
assembling, tting or handling to prevent personal
injury or damage to the product.
This product must be installed by a competent
person in accordance with the current building and
IEE wiring regulations.
As the buyer, installer and/or user of this product it
is your own responsibility to ensure that this tting
is t for the purpose for which you have intended
it. Eterna Lighting cannot accept any liability for
loss, damage or premature failure resulting from
inappropriate use.
This product is designed and constructed according
to the principles of the appropriate British Standard.
Switch o the mains before commencing installation
and remove the appropriate circuit fuse or lock o
MCB.
This unit is suitable for outdoor use.
This product is designed for permanent connection
to xed wiring: this must be a suitable circuit
(protected with the appropriate MCB or fuse).
Before making xing hole(s), check that there are no
obstructions hidden beneath the mounting surface
such as pipes or cables.
Make sure that the xings are strong enough to
support the considerable weight of the tting and
hold it rigidly.
The lamp must be positioned so that there is at
least 1M between the luminaire and any illuminated
surface.
When making connections ensure that the terminals
are tightened securely and that no
strands of wire protrude. Check that the terminals are
tightened onto the bared conductors and not onto
any insulation.
This product is double insulated. DO NOT CONNECT
ANY PART TO EARTH.
This product is not intended to be used by children
and persons with sensory, physical and/or mental
impairments that would prevent them from using it
safely.
You are advised at every stage of your installation to
double-check any electrical connections you have
made. After you have completed your installation
there are electrical tests that should be carried out,
these tests are specied in the current IEE wiring and
building regulations.
CLEANING:
• To avoid dust build-up and ensure proper
functioning of the oodlight, please wipe the
sensor lens lightly with a damp cloth every 3
months.
• Disconnect the power and clean the exterior only of
this tting with a moist (not wet) cloth.
• Do not use any chemical or abrasive cleaners.
LAMP REPLACEMENT:
This luminaire has a sealed LED lamp and is
maintenance free. No lamp replacement is required.
SPECIFICATIONS:
• Detection range: max. 10M at approx. 120° scan
• Duration time adjustment: (10±2) seconds to (10±2)
minutes
• Detection circuitry: Passive Infra-Red (PIR)
• Weatherproof: IP44
• Power required: 230V~ 50 Hz
• Recommended power supply cable: H05RN-F 3G
1.0mm2
• Protection: Class II
• Tempered glass
WHERE TO FIT YOUR PIR FLOODLIGHT:
To achieve best results we suggest you take the
following points into consideration:
Do not mount on a surface that has vibration.
Ideally the PIR ood light should be mounted 1.8 to
2.5 metres (6 to 8ft) above the area to be scanned
(refer to g.1 below).
INSTALLATION:
2.5M
4M 8M 10M
120˚
Approx
Fig 1
EFFECTIVE:
Movement across
scan area
LESS EFFECTIVE:
Movement
directly in front
of scan area
Fig 2
Fig 3
PG 2 PG 3
Fixing slots on bracket
70mm
For All Floodlights
Blue
(Power Cable)
Brown
(Power Cable)
Blue
(Power Cable)
Brown
(Power Cable)
NL
Terminal Block
Power
Cable
Fig 4

INSTALLATION:
When installing the PIR ood light refer to Fig.4 on
page 3.
01) Switch o the mains before commencing
installation.
02) Using the bracket as a template mark and then
drill the appropriate xing holes.
03) Secure the bracket with suitable xings (not
supplied).
04. Terminate loose ends of wire to an appropriate
IP rated junction box or similar, ensuring the Live
and Neutral polarities are observed.
The oodlight is supplied pre-wired but also
has a 3-way terminal block in the housing.
05) If wiring direct in to the tting re-t the terminal
block, tighten the cable restraint clamp, tighten
the gland nut and re-t the cover.
06) Adjust the direction of the oodlight and tighten
the head xings ensuring that you have used the
lock washers.
07) Restore mains power.
08) Adjust the PIR sensor oodlight to the desired
settings.
UNDERSTANDING THE CONTROLS:
(Please refer to Fig. 5 below)
ADJUSTING THE DURATION TIME:
The length of time the unit remains switched on
after activation can be adjusted from (10±2) seconds
to (10±2) minutes approximately. Rotating the TIME
screw from (+) to (-) will reduce the duration time.
Note: Once the light has been triggered by the PIR
sensor any subsequent detection will start the timed
period again from the beginning.
ADJUSTING THE LUX CONTROL LEVEL:
The Lux control module has a built-in sensing device
(photocell) that detects daylight and darkness. The
(R) position denotes that the oodlights can work
at day and night, and the () position only work at
night. You can set to operate the unit at the desired
level by adjusting the LUX screw.
SETTING THE CONTROLS: WALK TEST
Turn the Lux control screw to light (R) & ensure
that the TIME control screw is set at the minimum
duration time (-) position. The oodlight will now
switch on and remain on for about 10 seconds after
each detection.
01) Adjust time control to required setting.
02) To set the light level at which the oodlight will
automatically switch “on” at night, turn the LUX
control screw from daylight (R) to night (). If
the oodlight is required to switch on earlier, e.g.
dusk, wait for the desired light level, then slowly
turn the LUX control screw towards daylight while
someone walks across the center of the area to
be detected. When the oodlight switches on
stop adjusting. You may need to make further
adjustments to achieve your ideal light level
setting.
TROUBLESHOOTING AND USER HINTS:
Note: all passive infra red detectors are more sensitive in cold and dry weather than warm and wet weather.
PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY
Light does not switch on
when there is movement
in the detection area.
1. No mains voltage Check all connections, and MCB Fuses / switches
2. Nearby lighting is too bright Relocate the unit
3. Controls set incorrectly Adjust Lux setting
4. Wired incorrectly Check wiring and conrm its wired as per the
wiring diagram on page 3
5. Sensor positioned in wrong direction Relocate the unit
Light switches on for no
apparent reason (false
trigger)
1. Heat sources such as air-con, vents, heaters, ues,
other outside lighting, moving cars trees or shrubs
are activating sensor Relocate the unit
2. Interference from on/o switching of electric
fans or lights on the same circuit as your security
oodlight.
(This problem does not always occur but a faulty
switch or noisy uorescent light may cause the
security oodlight to switch on)
Should the false triggering become, troublesome,
consider:
(a) Replacing a faulty switch
(b) Replacing noisy uorescent tubes and/or
starters
(c) Connecting the oodlight to a separate
circuit (in most cases where one or more of
the above suggestions have been carried out,
false triggering has been reduced)
3. Reection from swimming pool, or reective
surface such as smooth white walls Relocate the unit
Light remains on Time is set too long Reduce time
Light remains on at
nighttime Possible heat source in detection zone
Cover PIR sensor lens with a thick cloth, if the
light turns o check detection area for heat or
reective source, reposition head and decrease
the sensitivity setting if this control is available
Light switches on during
daylight hours LUX control screw is set to daylight position Turn the LUX control screw to desired light level
setting
When setting the lux
controls in daylight
the detection distance
becomes shorter
Interference by sunlight Re-test at night
TIME LUX
Fig 5: PIR Controls
PG 4 PG 5
Pull PIR lid
down for
access to the
TIME and
LUX dials
