EtherWAN EL42011 Series User manual

W70G-EL42011Q2 Page 1
Installation Guide
EL42011 Series | Series Media Converter
Copyright 2023 EtherWAN Systems, Inc. All Rights Reserved 03/27/2023
1Unpacking
Open the carton and unpack the items. Your package
should include an EX42011 media converter and this
Quick Install Guide. If items are missing or damaged,
notify your EtherWAN representative.
Download the full manual at:
https://www.etherwan.com
2Select Installation Location
Place the equipment where it will not be subjected to
extreme temperatures, humidity, or electromagnetic
interference. Specifically, the site you select should
meet the following requirements:
▪The ambient temperature should be between -10
and 60 degrees Celsius (14 to 140 degrees
Fahrenheit).
▪The relative humidity should be less than 95
percent, non-condensing.
▪Make sure that the equipment receives adequate
ventilation. Do not block the ventilation holes on
each side of the equipment.
▪The power outlet should be within 1.8 meters of
the product.
3Connect Power
Power input is 12-18 VDC via three-pin terminal
block. Power consumption is 1.82W Max.
0.14A@12VDC, 0.07A@24VDC, 0.038A@48VDC. This
device has augmented 4 kV surge protection in
accordance with EN 61000-4-5
4Ports and Port Settings
The Converter provides one TX port and one FX port.
For the FX port, options of Multi-mode fiber using SC
or ST connector or Single-mode fiber using SC or ST
connector or WDM fiber using single SC connector are
provided.
The TX port uses RJ-45 connector and auto detects the
speed at 10/100Mbps.

W70G-EL42011Q2 Page 2
Installation Guide
EL42011 Series | Series Media Converter
Copyright 2023 EtherWAN Systems, Inc. All Rights Reserved 03/27/2023
5LED Indicators
The LED indicators give you instant feedback on status
of the converter:
LED
State
Indication
TX LNK/ACT
FX LNK/ACT
Steady
Valid network connection
established
Flashing
Transmitting or receiving
data
Off
Neither valid network
connection nor
transmitting/ receiving
data
Manufacturer information:
EtherWAN Systems, Inc.
33F, No. 93, Sec. 1, Xintai 5th Rd., Xizhi Dist., New
Taipei City, 221 Taiwan
The full product manual can be downloaded from:
www.etherwan.com
