EtherWAN EL900 Series User manual

User’s Guide
EL900 Series
Hardened Media Converter

All Rights Reserved
Dissemination or reproduction of this document, or its contents, is not authorized except where expressly
permitted. Violators are liable for damages. All rights reserved, for the purposes of patent application or trademark
registration.
Disclaimer of Liability
The information contained in this document is subject to change without notice. EtherWAN is not liable for any
errors or omissions contained herein or for resulting damage in connection with the information provided in this
manual.
Products Supported by this Manual:
EL900

iii
EL900 Media Converter Manual
Preface
Audience
This guide is designed for the person who installs, configures, deploys, and maintains the Ethernet
network. This document assumes the reader has moderate hardware, computer, and Internet skills.
Document Revision Level
This section provides a history of the revision changes to this document.
Revision
Document Version
Date
Description
A
Version 1
03/01/2023
Safety and Warnings
This guide uses the following symbols to draw your attention to certain information.
Symbol
Meaning
Description
Note
Notes emphasize or supplement important points of the main text.
Tip
Tips provide helpful information, guidelines, or suggestions for
performing tasks more effectively.
Warning
Warnings indicate that failure to take a specified action could result in
damage to the device, or could result in serious bodily injury.
Electric Shock
Hazard
This symbol warns users of electric shock hazard. Failure to take
appropriate precautions such as not opening or touching hazardous
areas of the equipment could result in injury or death.

iv
EL900 Media Converter Manual
Contents
Preface..................................................................................................................... iii
Safety and Warnings.................................................................................................iii
Contents.................................................................................................................. iv
Introduction.............................................................................................................. 5
Unpacking.................................................................................................................6
Select Installation Location........................................................................................6
Connect Power..........................................................................................................7
LED Indicators...........................................................................................................9
DIP Switches...........................................................................................................10
Link Fault Pass Through (LFPT)........................................................................11
Relay Output Alarm.................................................................................................11
Features..................................................................................................................12
Specifications..........................................................................................................13
Manufacturer’s Information......................................................................................15

Introduction
EL900 Hardened Media Converter
10/100BASE-TX to 100BASE-FX
This hardened media converter provides an affordable solution for rugged and outdoor environment,
transportation road-side cabinet, industrial floor shop, multitenant dwellings or Fiber To The Home
(FTTH) applications. Capable of operating at temperature extremes of -40°C to +75°C, this is the
media converter of choice for harsh environments constrained by space.
Plug-and-Play Solution:
The hardened media converter is a plug-and-play media converter in compact size. It doesn't require
any complicated software to set up.

6
EL900 Media Converter Manual
Unpacking
Open the carton and unpack the items. Your package should include an EL900 media converter, an
AC to DC power adaptor and cable (optional) and a Quick Install Guide. If items are missing or
damaged, notify your EtherWAN representative.
Select Installation Location
Installation is DIN rail-mount, or wall mount (in an enclosure or industrial panel).
Ensure that the power source is within 6 feet (1.8 meters), and check that there is
adequate airflow.
Place the media converter on the DIN rail from above using the slot. Push the
front of the media converter toward the mounting surface until it audibly snaps into
place.
Startup: Connect the supply voltage to start up the media converter via the
terminal block.
Dismantling: Pull out the lower edge and then remove the media converter from
the DIN rail.

7
EL900 Media Converter Manual
Connect Power
The media converter is equipped with an six-contact DC terminal block. The terminal block provides
dual DC power inputs, and a relay output contact. Redundant power supply is supported, but only one
power input is required for operation. Note that the media converter does not have a power switch; it is
turned on/off by connecting/disconnecting power. Input voltage is 10 to 48VDC.
DC Terminal Block Assignments
PWR1
Power Input 1 (10~48VDC)
GND
Power Ground
PWR2
Power Input 2 (10~48VDC)
GND
Power Ground
Earth Ground
1. Relay opens if PWR1 or PWR2 fails
2. Relay opens if the port link fails (When Link Down Detection
is enabled)
The media converter can also be powered via the 12VDC DC jack or an optional 24VAC, 0.185A AC
Terminal Block.
AC Block Terminal Assignments
PWR
Power Input 3A@12VDC)
GND
Power Ground
1. Relay opens if PWR1 or PWR2 fails
2. Relay opens if the port link fails (When Link Down Detection
is enabled)

8
EL900 Media Converter Manual
Note: Use qualified power supply by SELV or double insulation of UL 60950 or UL 61010-1 or
UL 61010-2-201 standards.
Insert the DC input wires into the corresponding terminals, and tighten the clamp screws to hold them
in place. Make sure that the plastic terminal block connector prongs are plugged firmly into the
terminal block receptacles.
Power wiring information:
Use cable type - AWG (American Wire Gauge) 18-24 and the corresponding pin type cable terminals.
Use torque value 1.7 lb-in, do not use excessive force when fixing wiring.

9
EL900 Media Converter Manual
LED Indicators
LED
State
Indication
Fault
Steady
Power redundancy or port malfunction
Off
Power redundancy/ports functioning
normally
PW1
Steady
Power1 on
Off
Power1 off
PW2
Steady
Power2 on
Off
Power2 off
100 (Mbps)
Steady
Connection at the speed of 100Mbps
Off
Connection at the speed of 10Mbps
LFP
Steady
LFPT function enabled
Off
LFPT function disabled
LNK/ACT
Steady
Connection established
Flashing
Transmitting or receiving data
Off
No connection established
FDX/COL
Steady
Connection in full duplex mode
Flashing
Collision occurred
Off
Connection in half-duplex mode

10
EL900 Media Converter Manual
DIP Switches
Port, power and LFPT settings are made very simple by means of DIP (Dual Inline Package) switches
on the bottom panel of the hardened media converter.
EL900 DIP Switches
No.
0
1
1
Disable LFPT*
Enable LFPT*
2
Enable auto negotiation for TX port
Enable forced mode for TX port
3
TX port forced to 100Mbps
TX port forced to 10Mbps
4
TX port forced to full duplex mode
TX port forced to half duplex mode
5
FX port forced to full duplex mode
FX port forced to half duplex mode
6
Disable link down alarm
Enable link down alarm
* LFPT = Link Fault Pass Through
If Force mode is enabled, the media converter must be restarted in order for the new setting to
take effect.
Pin 2 must be toggled to position 1 prior to speed and duplex mode manual setting.

11
EL900 Media Converter Manual
Link Fault Pass Through (LFPT)
LFPT (Link Fault Pass Through) is a feature that will pass a link fault through the device at each
segment. If either of the copper TX links fails, the media converter will pass the fail state on throughout
the link, taking down the middle fiber as well as the copper link on the opposite end. This prevents the
connected switches from sending packets that would end up lost. LFTP is designed for use with media
converters arranged in pairs, and both devices must support LFPT.
Link Fault of the FX port
TX Port
FX Port
LEDs
PWR
100
LNK/ACT
FDX/COL
LNK/ACT
FDX/COL
Media Converter A
ON
ON
OFF
OFF
OFF
OFF
Media Converter
ON
ON
OFF
OFF
OFF
OFF
Link Fault of the TX port of Media Converter A
TX Port
FX Port
LEDs
PWR
100
LNK/ACT
FDX/COL
LNK/ACT
FDX/COL
Media Converter A
ON
OFF
OFF
OFF
OFF
OFF
Media Converter B
ON
OFF
OFF
OFF
OFF
OFF
Relay Output Alarm
The media converter is equipped with relay output contacts on the terminal block for signaling of a
power or port failure. The relay output can be connected to an alarm signaling device. Current is 0.6A
@ 30VDC. Do not connect a power source to the relay output.

12
EL900 Media Converter Manual
Features
•Meets NEMA TS1/TS2 Environmental requirements: temperature, shock, and vibration for
traffic control equipment.
•Meets EN 61000-6-2 & EN 61000-6-3 EMC Generic Standard Immunity for industrial
environments.
•Supports 802.3/802.3u/802.3x. Auto-negotiation: 10/100Mbps, full/half-duplex; Auto MDI/MDIX.
•100Base-FX: Multi mode SC or ST type; Single mode SC or ST type; WDM Single mode SC
type.
•One DIP switch for configuring link-fault-pass-through, fixed speed, full/half duplex, and link
down alarm.
•Alarms for power and port link failure by relay output.
•Relay contact rating with current 1.5A @ 24VDC, 0.5A @ 120VAC.
•Operating voltage and Max. current consumption: 0.36A @ 12VDC, 0.18A @ 24VDC, 0.09A @
48VDC. Power consumption: 4.32W Max.
•Power Supply: Redundant DC Terminal Block power inputs or 12VDC DC JACK with 100-
240VAC external power supply.
•Field Wiring Terminal: Use Copper Conductors Only, 60/75℃, 12-24 AWG torque value 7 lb-in.
•-40℃to 75℃(-40℉to 167℉) operating temperature range. Tested for functional operation @ -
40℃to 85℃(-40℉to 185℉). UL 1604 Industrial Control Equipment certified Maximum
Surrounding Air Temperature @ 74℃(165℉).
•Supports DIN-rail, Panel, or Rack Mounting installation.
•UL 1604 Class I, Division 2 Classified for use in hazardous locations (Applicable to versions
with Terminal Block power option).
•This equipment is suitable for use in Class I, Division 2, Groups A, B, C and D OR non-
hazardous locations only.
WARNING –EXPLOSION HAZARD –Do not disconnect equipment unless power has been
removed or the area is known to be non-hazardous.
WARNING –EXPLOSION HAZARD –Substitution of components may impair suitability for
Class I, Division 2.

13
EL900 Media Converter Manual
Specifications
Applicable standards
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX/FX
Switching method
Store and Forward
Forwarding rate
14,880/148,810pps for 10/100Mbps
Speed 10Base-T
100Base-TX/FX
10/20Mbps for half/full-duplex
100/200Mbps for half/full-duplex
Cable
10Base-T
100Base-TX
100Base-FX
2-pair UTP/STP Cat. 3, 4, 5 up to 100m
2-pair UTP/STP Cat. 5 up to 100m
MMF (50 or 62.5μm), SMF (9 or 10μm)
LED Indicators
Per Unit- (4 LEDs):
PWR1, PWR2, FAULT, LFP
Per Port-
TX (3 LEDs): LNK/ACT, FDX/COL, 100
FX (2 LEDs): LNK/ACT, FDX/COL
Dimensions
50 x 110 x 135mm (W x D x H)
(1.97" x 4.33" x 5.31")
Weight
0.8Kg (1.76lbs.)
Power
DC Jack: 12VDC, External AC/DC required
Terminal Block: 10-48VDC
Operating Voltage & Max.
Current Consumption
0.36A @ 12VDC, 0.18A @ 24VDC,
0.09A @ 48VDC
Power Consumption
4.32W Max.
Operating Temperature
-40°C ~ 75°C (-40℉~ 167℉)
Tested for functional operation @ -40 ~ 85°C (-40 ~ 85℉)
UL1604 Industrial Control Equipment certified Maximum
Surrounding Air Temperature @ 74℃(165℉)
Storage Temperature
-40 ~ 85°C (-4 ~ 185℉)
Humidity
5 ~ 95%, non-condensing
Safety
Hazardous locations: Class I, Division 2 group A, B, C & D
UL 60950-1, EN 60950-1, IEC 60950-1

14
EL900 Media Converter Manual
EMI
FCC Part 15, Class A
EN 61000-6-3: EN 55022, EN 61000-3-2,
EN 61000-3-3
EMS
EN 61000-4-2 (ESD Standard)
EN 61000-4-3 (Radiated RFI Standards)
EN 61000-4-4 (Burst Standards)
EN 61000-4-5 (Surge Standards)
EN 61000-4-6 (Induced RFI Standards)
EN 61000-4-8 (Magnetic Field Standards)
Environmental Test
Compliance
IEC 60068-2-6 Fc (Vibration Resistance)
IEC 60068-2-27 Ea (Shock)
IEC 60068-2-32 Ed (Free Fall)
NEMA TS1/2 Environmental requirements for traffic control equipment

15
EL900 Media Converter Manual
Manufacturer’s Information
EtherWAN System, Inc.
www.etherwan.com
EtherWAN has made a good faith effort to ensure the accuracy of the information in this document and disclaims
the implied warranties of merchantability and fitness for a particular purpose, and makes no express warranties,
except as may be stated in its written agreement with and for its customers.
EtherWAN shall not be held liable to anyone for any indirect, special or consequential damages due to omissions
or errors. The information and specifications in this document are subject to change without notice.
Copyright 2023. All Rights Reserved.
All trademarks and registered trademarks are the property of their respective owners
EL900 Media Converter
March 21, 2023
USA Office
2301 E. Winston Road
Anaheim, CA 92806
TEL: [phone]
Email: [e-mail]
Pacific Rim Office
4F-7, No. 79, Sec. 1, Xintai 5th Road, Xizhi District
New Taipei City 221, Taiwan
TEL: [phone]
Email: [e-mail]
