EtroVISION EV6150A User manual

IP Camera & Video Server
User’s Manual
Firmware Version 1.9.5
Document Version 1.4

About This Guide
The User’s Manual provides functionality and instructions for Etrovision’s IP
cameras and video servers employing firmware version 1.9.5.
Before Using the IP Camera/Video Server
Check the PC requirements
Review the OS platform requirements
Read an special and import precautionary information
Having basic knowledge of network setup and configuration will be helpful
Important Announcements
NOTE: This icon represents a tip for operation.
CAUTION: This icon stands for an action that could affect an operation or mildly
impair the system.
WARNING: This icon indicates an action that will likely impair the system.
Disclaimer
© 2007 Etrovision Technology. All rights reserved.
EtroLink™ & AnyUSB™ are trademarks of Etrovision Technology; other product or
service names mentioned herein are the trademarks of their respective owners.
Information contained in this document may be superseded by updates. No
representation or warranty is given and no liability is assumed by Etrovision
Technology with respect to the accuracy or use of the information, or infringement of
patents or other intellectual property rights. No licenses are conveyed, implicitly or
otherwise, under any intellectual property rights.

1INTRODUCTION ...............................................................................1
1.1 Camera Model Differences..........................................................................1
2THE LIVE VIEW.................................................................................2
2.1 OSD (On-Screen Display)...........................................................................2
2.2 Setup, Snapshot and Record Video............................................................3
2.3 Video...........................................................................................................3
2.4 Audio...........................................................................................................3
2.5 SD Status....................................................................................................3
2.6 Control (PTZ Controls)................................................................................4
EV6250A Speed Dome...............................................................................5
2.7 Camera Info and Digital Output...................................................................5
Camera Info ................................................................................................5
Digital Output ..............................................................................................6
3THE SETTINGS PAGE – BASIC.......................................................7
3.1 Status..........................................................................................................9
3.2 Network.......................................................................................................9
Static IP.......................................................................................................9
Dynamic IP Address..................................................................................10
PPPoE Settings.........................................................................................11
UPnP.........................................................................................................11
3.3 Video.........................................................................................................12
Stream 1....................................................................................................12
Video Setting.............................................................................................12
Max Client.................................................................................................13
Stream 2....................................................................................................14
Color Setting .............................................................................................14
3.4 Audio.........................................................................................................16
3.5 Event Rule.................................................................................................17
Events Handled.........................................................................................17
Actions Triggered......................................................................................17
Events and Actions....................................................................................18
Activating Events.......................................................................................20
Modifying Activated Event Rules...............................................................20
Deleting Events.........................................................................................21
3.6 Date & Time ..............................................................................................21
Client PC Time..........................................................................................21
Time Server...............................................................................................22

3.7 OSD (On-Screen Display).........................................................................22
4THE SETTINGS PAGE – EXPERT .................................................24
4.1 PTZ Control (Pan, Tilt, Zoom) ...................................................................24
4.2 Port............................................................................................................25
4.3 DDNS (Dynamic DNS)..............................................................................25
4.4 SMTP/FTP ................................................................................................26
Remote SMTP Setup ................................................................................27
Remote FTP Setup....................................................................................28
4.5 Trigger Setup.............................................................................................28
Digital Input...............................................................................................29
Periodic Timer...........................................................................................29
Motion Detection .......................................................................................29
Video Loss ................................................................................................31
4.6 Pre/Post Setting ........................................................................................32
4.7 SD Card .................................................................................................... 32
4.8 NAS Setting (Network Attached Storage)..................................................33
4.9 Account.....................................................................................................34
The Administrator Account........................................................................35
User Accounts...........................................................................................36
Guest Permission......................................................................................36
4.10 Security.....................................................................................................37
Network Security.......................................................................................38
Power LED................................................................................................41
4.11 Maintenance..............................................................................................41
Language..................................................................................................42
Firmware Update.......................................................................................42
System Configuration (Backup / Restore).................................................44
Factory Default..........................................................................................45
5REBOOT..........................................................................................46
6SYSTEM LOG..................................................................................47
7LOGOUT..........................................................................................48
8WIRELESS CONNECTIVITY...........................................................49
8.1 Web Interface Configuration......................................................................49
8.2 EtroLink™ USB Configuration Port ........................................................... 53
9EV6156A COLOR SETTINGS.........................................................57
9.1 Menu Options............................................................................................59
IRIS...........................................................................................................59
AGC/SENS................................................................................................59

BACKLIGHT..............................................................................................59
WHITE BALANCE.....................................................................................60
GAMMA/ENHANCE..................................................................................60
IR-SET ......................................................................................................60
DIGITAL ZOOM ........................................................................................ 60
H/V REVERSE..........................................................................................60
MOTION DETECT.....................................................................................61
LANGUAGE..............................................................................................61
MASK........................................................................................................61
OSD ..........................................................................................................61
CROSS LINE/FREEZE .............................................................................62
POSI/NEGA ..............................................................................................62
DIGITAL OUT............................................................................................62
TITLE ........................................................................................................ 62
PRIORITY.................................................................................................62
PRESET/PHASE....................................................................................... 63
10 ADDITIONAL INFORMATION.........................................................64
11 GLOSSARY.....................................................................................65

1
1 INTRODUCTION
This document covers functionality and usage of the web interface for IP cameras
and video servers with firmware version 1.9.5. Specific model information can be
found in the model specification which can be found in the Installation Guide for the
corresponding model.
For the sake of convenience, “IP camera” and “camera” will be used to reference
both IP cameras and video servers. “Video server” will be used where there is a need
for clarity.
1.1 Camera Model Differences
Although most of the operations and functions being the same amongst models,
there are some differences. Differences are highlighted where applicable.
The following table highlights primary functionality that differs between models.
These differences will determine if certain items and settings will exist in the Live
View and/or Settings page.
SD
Card PTZ Capable WiFi Color OSD EtroLink
Box
EV6150A x x x x
EV6151A x x x x
EV6153A x x x x
EV6156A x x x x x
Dome
EV6551A x
EV6552A x
EV6552R
Megapixel
EV8150A x x x x
Outdoor
EV6353A x
EV6355A x
EV6356A x
Speed Dome
EV6250A x x
Video Server
EV3151 x x
EV3151A x x x
For example, if a camera isn’t PTZ capable (e.g. EV6552A), then the PTZ controls will
not be present in the Live View page and the PTZ settings option will not be present
in the Settings page.

2
2 THE LIVE VIEW
The IP camera web interface is made up of two main pages: the Live View page and
the Settings page. The Live View provides the current display from the IP camera
along with selected settings, configuration and functionality.
After logging into the IP camera via the browser, the user is first presented with the
Live View page.
Below is an example of the Live View page. Following the screenshot is a discussion
of the different areas within the Live View page.
2.1 OSD (On-Screen Display)
In the top left corner is the OSD (On-Screen Display).
By default, the date and time are displayed in the format MM-DD-YYYY
HH24:MI:SS; the camera name can also be displayed (see “OSD” section for
information on altering the OSD settings).

3
2.2 Setup, Snapshot and Record Video
In the top right corner of the screen are three controls.
“Setup” switches from the Live View page to the administration configuration
page where most of the IP camera configuration is performed.
“Snapshot” can be used to take snapshot pictures. The files are stored locally
on the PC.
“Record Video” starts and stops recording of video. The files are stored
locally on the PC.
2.3 Video
Below the Setup/Snapshot/Record controls are the video and resolution controls.
“Stream2” will also be displayed if it has been enabled (see the Settings Page
“Video” section for more information).
The resolution and bitrate can be modified here. In the drop down box, choose
one of the options.
Changes take place a few seconds after modification; the image on the screen
might briefly pause while changes are implemented.
2.4 Audio
The “Audio” check boxes enable/disable speaker and microphone (Mic)
capabilities. The appropriate cables need to be connected into the back of the
camera. (See the “Audio” section for more information).
2.5 SD Status
Note: Dome, Outdoor and Speed Dome models do not have SD Card
functionality as of this firmware version.

4
The “SD Status” is the secure digital (SD) card status. If no card is present then
the status will be “Invalid”. See the “SD Card” section for more information.
2.6 Control (PTZ Controls)
Note: Dome and Outdoor models do not have PTZ functionality as of this
firmware version.
The Control section allows operating the PTZ controls from the Live View.
The round dial with directional arrows controls the
directional movement of the camera.
“Preset” is used for configuring and using camera directional
presets. There are two buttons: Sand G.
Focus, zoom and iris controls are modified using the + and –
buttons.
Sis used to set a specific location view. First position the camera to view a
specific area. Next click Swhich displays a window prompting the ID to assign
the specific preset.
Enter an alphanumeric ID for a specific preset and click OK.
Gis used to move the camera to a specific preset. Click G, enter the desired
preset ID and click OK.

5
EV6250A Speed Dome
The EV6250A has some slight differences. Below are the PTZ controls in the
EV6250A.
The “PTZ Speed” controls how fast PTZ movement occurs. Values range from 1-6.
The EV6250A has a preconfigured PTZ setting number, 98.
This setting will result in the camera continuously panning 360° on the current
axis.
2.7 Camera Info and Digital Output
Camera Info
The 2 buttons on the bottom right are “Camera Info” and “Digital Output”.
The “Camera Info” button displays video information such as frame rate (fps),
model name, and resolution. This information is displayed where the OSD
information is normally displayed, the top left corner.
Below are two screenshots displaying when the “Camera Info” button is enabled.
Note that the OSD information is no longer viewable when the button is enabled.
