Eurotherm Nanodac User manual

nanodacTM
Recorder Controller
Part Number HA030554
Issue 9
March 2015
User Guide

This page is intentionally blank

nanodac RECORDER/CONTROLLER: USER GUIDE
Page i
HA030554
Issue 9 Mar 15
nanodac Recorder/Controller
User Guide
List of sections
Section Page
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
5 Modbus TCP slave comms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
6 iTools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
7 User Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287
8 USB Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
A Technical specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 293
B Control Loops . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
C Reference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
D Configuration menu overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335
E Web Server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 351
F Labview Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .361
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 367
Associated documents
HA028838 Printable version of iTools Help
HA025464 EMC installation guidelines
HA027962 Printable version of ‘Review’ Help
Application notes
HA030817U001 Archiving data from the nanodac recorder/controller
HA030817U002 Heat/Cool with carbon potential or oxygen level monitoring
HA030817U003 Heat only temperature control and carbon potential control
HA030817U004 Virtual channels using the nanodac recorder/controller.
Software effectivity
This manual refers to instruments fitted with software version 5.5.
Software versions 2.20 onwards are ‘backwards compatible’ so that it can be used on
all hardware versions of the unit.
Previous software versions are not compatible with instruments with hardware status
greater than 2.
The status level may be found on the instrument label and consists of a letter indicating
software status followed by a numeral indicating the hardware status (e.g. ‘B2’)

nanodac RECORDER/CONTROLLER: USER GUIDE
HA030554
Issue 9 Mar 15
Page ii
1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 UNPACKING THE INSTRUMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 MECHANICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1.1 Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1.2 Demounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1.3 Removing the Instrument from its Sleeve . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 ELECTRICAL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2.1 Termination details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2.2 Low Voltage Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2.3 Dual Input Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2.4 Modbus Master communications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2.5 EtherNet/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.1 Display Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.2 Navigation Pushbuttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.3 On Screen Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 PROCESS VARIABLE DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.1 Alarm Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.2 Status Bar Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.3 Breaks in recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3 TOP LEVEL MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3.1 Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3.2 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3.3 Go to View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3.4 History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.3.5 Faceplate Cycling on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.3.6 Operator Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.3.7 Demand Archiving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.3.8 Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.4 DISPLAY MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.4.1 Vertical Trend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.4.2 Horizontal Trend mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.4.3 Vertical Bargraph mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.4.4 Horizontal Bargraph mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.4.5 Numeric mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.4.6 Alarm panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.4.7 Control Loop1/Loop2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.4.8 Cascade Display Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.4.9 Programmer Display Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.4.10 Steriliser display mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
3.4.11 Promote list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3.4.12 Modbus Master display mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
3.4.13 EtherNet/IP display mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
3.5 TREND HISTORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
3.5.1 Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
3.5.2 History Options Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
3.6 TEXT ENTRY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
3.6.1 Numeric keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
3.6.2 USB keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
nanodac Recorder/Controller
User Guide
Contents List
Section

nanodac RECORDER/CONTROLLER: USER GUIDE
Page iii
HA030554
Issue 9 Mar 15
4 CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
4.1 INSTRUMENT MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
4.1.1 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
4.1.2 Locale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
4.1.3 Display configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
4.1.4 Info menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
4.1.5 Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
4.1.6 Security menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
4.1.7 I/O fitted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4.1.8 Save/Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4.1.9 Input adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4.1.10 Output adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
4.2 NETWORK MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
4.2.1 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
4.2.2 Archiving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
4.2.3 FTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
4.2.4 Modbus TCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
4.3 GROUP CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
4.3.1 Group Trend configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
4.3.2 Group Recording configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
4.4 INPUT CHANNEL CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
4.4.1 Channel Main . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
4.4.2 Channel Trend configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
4.4.3 Alarm 1 menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
4.4.4 Alarm 2 menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
4.4.5 Alarm types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
4.5 VIRTUAL CHANNEL CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
4.5.1 Maths channel configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
4.5.2 Totaliser configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
4.5.3 Wiring Example using a counter in combination with a totaliser . . . . . . . 99
4.5.4 Counter configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
4.6 LOOP OPTION CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
4.6.1 Main menu parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
4.6.2 Setup menu parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
4.6.3 Tune menu parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
4.6.4 PID menu parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
4.6.5 Setpoint menu parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
4.6.6 Output menu items . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
4.6.7 Loop diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
4.7 ADVANCED LOOP CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
4.7.1 Advanced Loop Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
4.7.2 Advanced Loop Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
4.7.3 Advanced Loop Tune menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
4.7.4 Advanced Loop Master PID menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
4.7.5 Advanced Loop Slave PID menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
4.7.6 Advanced Loop Master SP menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
4.7.7 Advanced Loop Slave SP menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
4.7.8 Advanced Loop Output menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123
4.7.9 Advanced Loop Diagnostics menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
4.8 PROGRAMMER CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
4.8.1 Programmer Features menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128
4.8.2 Programmer FTP menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130
4.8.3 Programmer Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131
4.8.4 Programmer Run menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
4.8.5 Connecting the programmer to a loop . . . . . . . . . . . . . . . . . . . . . . . . . . .136
4.8.6 Configuration by Modbus Comms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .138
4.9 MODBUS MASTER CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
4.9.1 Slave Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .140
4.9.2 Slave Diagnostics menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .141
4.9.3 Modbus master data configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
4.10 ETHERNET/IP CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145
4.10.1 Ethernet/IP Configuration Main menu . . . . . . . . . . . . . . . . . . . . . . . . . .145
4.10.2 Implicit inputs/outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .146
List of Contents (Cont.)
Section Page

nanodac RECORDER/CONTROLLER: USER GUIDE
HA030554
Issue 9 Mar 15
Page iv
4.10.3 Explicit inputs/outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .146
4.11 WEB SERVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
4.11.1 Configuration Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
4.12 DIGITAL I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149
4.12.1 Digital input/output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149
4.12.2 Relay outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149
4.12.3 Digital inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150
4.12.4 Digital outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150
4.13 DC OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151
4.13.1 Configuration display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151
4.14 USER LIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
4.14.1 User linearisation table rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152
4.15 CUSTOM MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .153
4.16 ZIRCONIA BLOCK OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .153
4.16.1 Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .153
4.16.2 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .154
4.16.3 Zirconia Probe Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .157
4.17 STERILISER OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158
4.17.1 Configuration parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158
4.18 HUMIDITY BLOCK OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160
4.18.1 Configuration parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160
4.19 BCD INPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161
4.19.1 Input rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161
4.19.2 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161
4.20 LOGIC (2 INPUT) BLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162
4.20.1 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162
4.21 LOGIC (8 INPUT) BLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
4.21.1 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
4.21.2 Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163
4.21.3 Invert input decoding table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .164
4.22 Multiplexer block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165
4.22.1 Configuration parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165
4.23 MATH (2 INPUT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166
4.23.1 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166
4.23.2 Sample and Hold details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
4.24 TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
4.24.1 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
4.24.2 Timer modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .168
4.25 USER VALUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170
4.25.1 Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170
4.26 ALARM SUMMARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171
4.27 REAL TIME EVENT CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .172
5 MODBUS TCP SLAVE COMMS . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
5.1 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
5.2 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
5.2.1 Function Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
5.2.2 Data types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
5.2.3 Invalid multiple register writes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
5.2.4 Master communications timeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
5.2.5 Non-volatile parameters in EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . .174
5.3 PARAMETER LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178
6 iTOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
6.1 iTools CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .257
6.1.1 Ethernet (Modbus TCP) communications . . . . . . . . . . . . . . . . . . . . . . . .257
6.1.2 Direct Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .259
6.2 SCANNING FOR INSTRUMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .260
6.3 GRAPHICAL WIRING EDITOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .261
6.3.1 Tool bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .262
6.3.2 Wiring Editor Operating Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .262
List of Contents (Cont.)
Section Page

nanodac RECORDER/CONTROLLER: USER GUIDE
Page v
HA030554
Issue 9 Mar 15
6.4 PARAMETER EXPLORER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .270
6.4.1 Parameter explorer detail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .271
6.4.2 Explorer tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .272
6.4.3 Context Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .272
6.5 WATCH/RECIPE EDITOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .273
6.5.1 Creating a Watch List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .273
6.5.2 Watch Recipe toolbar icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .274
6.5.3 Watch/Recipe Context Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .274
6.6 PROGRAMMER OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .275
6.6.1 Segment parameter editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .275
6.6.2 Digital Event display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .277
6.6.3 Program parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .277
6.6.4 Adding and deleting segments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .278
6.6.5 Loading and Saving programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .279
6.6.6 Toolbar icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .279
6.6.7 Context menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .280
6.6.8 Programmer menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .281
6.6.9 Two channel programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .282
6.6.10 To Set Up OEM Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .283
7 USER WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
7.1 DRIVE RELAY EXAMPLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .286
7.1.1 Wire removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .287
7.2 COUNTER EXAMPLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .288
8 USB DEVICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
8.1 MEMORY STICK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .291
8.2 BAR CODE READER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .291
8.3 USB KEYBOARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .292
Appendix A: TECHNICAL SPECIFICATION . . . . . . . . . . . . . . . . . . . 293
A1 INSTALLATION CATEGORY AND POLLUTION DEGREE . . . . . . . . . . . . . . . . . .293
Installation category II . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .293
Pollution degree 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .293
A2 RECORDER SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .294
A3 ANALOGUE INPUT SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .295
A4 RELAY AND LOGIC I/O SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .297
A5 DIGITAL INPUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .297
A6 DC OUTPUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .297
A7 BLOCKS SUPPORTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .297
A7.1 ‘TOOLKIT’ BLOCKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .297
A7.2 APPLICATION BLOCKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .298
Appendix B CONTROL LOOPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
B.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .299
B1.1 EXAMPLE (HEAT ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .299
B2 CONTROL LOOP DEFINITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .299
B2.1 AUTO/MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .299
B2.2 TYPES OF CONTROL LOOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .300
Note: B2.2.1 On/Off control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .300
Note: B2.2.2 PID Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .300
PROPORTIONAL BAND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .300
INTEGRAL TERM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .301
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .301
Note: B2.2.3 Motorised valve control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .302
MANUAL MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .302
MOTORISED VALVE OUTPUT CONNECTIONS . . . . . . . . . . . . . . . . . . . .302
List of Contents (Cont.)
Section Page

nanodac RECORDER/CONTROLLER: USER GUIDE
HA030554
Issue 9 Mar 15
Page vi
B2.3 LOOP PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .303
Note: B2.3.1 Relative cool gain (R2G) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .303
Note: B2.3.2 High and Low cutback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .303
Note: B2.3.3 Manual Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .303
Note: B2.3.4 Integral Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .304
Note: B2.3.5 Integral De-bump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .304
Note: B2.3.6 Loop Break . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .304
Note: B2.3.7 Gain Scheduling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .305
B2.4 TUNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .305
Note: B2.4.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .305
Note: B2.4.2 Loop Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306
UNDER DAMPED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 306
CRITICALLY DAMPED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306
OVER DAMPED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 306
Note: B2.4.3 Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306
SETPOINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306
OUTPUT HIGH, OUTPUT LOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306
REM. OUTPUT LOW, REM. OUTPUT HIGH . . . . . . . . . . . . . . . . . . . . . . .306
Ch2 DeadBand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306
MINIMUM ON TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306
FILTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306
RATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .307
CH1 TRAVEL TIME, CH2 TRAVEL TIME . . . . . . . . . . . . . . . . . . . . . . . . . .307
Note: B2.4.4 Other tuning considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . .307
Note: B2.4.5 Autotune . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .307
AUTOTUNE AND SENSOR BREAK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .308
AUTOTUNE AND INHIBIT OR MANUAL . . . . . . . . . . . . . . . . . . . . . . . . . .308
AUTOTUNE AND GAIN SCHEDULING . . . . . . . . . . . . . . . . . . . . . . . . . . .308
INITIAL CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .308
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .308
EXAMPLE 1: AUTOTUNE FROM BELOW SP (HEAT/COOL) . . . . . . . . . .309
EXAMPLE 2: AUTOTUNE FROM BELOW SP (HEAT ONLY) . . . . . . . . . .310
EXAMPLE 3: AUTOTUNE AT SP (HEAT /COOL) . . . . . . . . . . . . . . . . . . .311
AT.R2G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .312
FAILURE MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .313
Note: B2.4.6 Relative Cool Gain in Well Lagged Processes . . . . . . . . . . . . . .313
EXAMPLE 4: When Tune R2G = R2GPD, Autotune from below setpoint .314
Note: B2.4.7 Manual tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .314
CUTBACK VALUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .315
B2.5 SETPOINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .316
Note: B2.5.1 Setpoint function block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .316
Note: B2.5.2 Setpoint Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .318
Note: B2.5.3 Setpoint Rate Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .318
Note: B2.5.4 Setpoint Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .319
Note: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .319
Note: B2.5.5 Manual Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .319
B2.6 OUTPUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .320
Note: B2.6.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .320
Note: B2.6.2 Output Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .320
Note: B2.6.3 Output Rate Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .321
Note: B2.6.4 Sensor Break Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .321
SAFE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .321
HOLD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .321
Note: B2.6.5 Forced Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .321
Note: B2.6.6 Power Feed Forward . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .322
Note: B2.6.7 Cool Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .322
LINEAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .322
OIL COOLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .322
WATER COOLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .322
FAN COOLING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .322
Note: B2.6.8 Feed forward . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .323
Note: B2.6.9 Effect of Control Action, Hysteresis and Deadband . . . . . . . . . .323
CONTROL ACTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .323
HYSTERESIS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .323
List of Contents (Cont.)
Section Page

nanodac RECORDER/CONTROLLER: USER GUIDE
Page vii
HA030554
Issue 9 Mar 15
DEADBAND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .323
Note: B2.6.10 Valve nudge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .325
Note: B2.6.11 Time Proportioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .326
B2.7 DIAGNOSTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .326
Appendix C: REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
C1 BATTERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .327
C2 SETTING UP AN FTP SERVER USING FILEZILLA . . . . . . . . . . . . . . . . . . . . . . .328
C2.1 DOWNLOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .328
C2.2 SERVER SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .330
C2.3 PC SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .331
C2.4 RECORDER/CONTROLLER SET UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .331
C2.5 ARCHIVE ACTIVITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .332
C3 FUNCTION BLOCK DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .333
C3.1 EIGHT INPUT OR BLOCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .333
C4 TCP PORT NUMBERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .334
C5 ISOLATION DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .334
Appendix D: CONFIGURATION MENU OVERVIEW . . . . . . . . . . . . 335
D1 INSTRUMENT CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .336
D2 NETWORK CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .337
D3 GROUP CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .338
D4 CHANNEL CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .338
D5 VIRTUAL CHANNEL CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . .339
D6 LOOP CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .340
D7 ADVANCED LOOP CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . . . . . . .341
D8 PROGRAMMER CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .343
D9 MODBUS MASTER CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .344
D10 ETHERNET/IP CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .345
D11 WEB SERVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .345
D12 DIGITAL I/O CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .346
D13 DC OUTPUT CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .346
D14 USER LINEARISATION CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . .346
D15 CUSTOM MESSAGES CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . . .346
D16 ZIRCONIA CONFIGURATION MENUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .347
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .347
D17 STERILISER CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .348
D18 HUMIDITY BLOCK CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . .348
D19 BCD BLOCK CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .348
D20 LOGIC 2 INPUT BLOCK CONFGURATION MENU . . . . . . . . . . . . . . . . . . . . . . .349
D22 MULTIPLEX BLOCK CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . .349
D21 LOGIC 8 INPUT CONFGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .349
D23 MATH 2 CONFGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .349
D24 TIMER CONFIGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .350
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .350
D27 REAL TIME EVENTS CONFGURATION MENU . . . . . . . . . . . . . . . . . . . . . . . . .350
E Appendix E: WEB SERVER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 351
E.1 Browsers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .351
E.1.1 Connecting to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .351
E.1.2 Denied Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .351
List of Contents (Cont.)
Section Page

nanodac RECORDER/CONTROLLER: USER GUIDE
HA030554
Issue 9 Mar 15
Page viii
E.1.3 Error Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .351
E.1.4 Home Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .352
E.1.5 About Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .352
E.1.6 Contact Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .353
E.1.7 Bar Graph Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .354
E.1.8 Line Graph Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .355
E.1.9 Numeric Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .356
E.1.10 Alarm Summary Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .356
E.1.11 Message Summary Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .357
E.1.12 Promote Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .357
E.1.13 Historical Line Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .358
E.1.14 Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .359
E.1.15 DHCP Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .359
E.1.16 Network Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .359
E.1.17 Languages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .359
F Appendix F: Labview Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 361
F.1 Application Example 1 - Heat/Cool Control . . . . . . . . . . . . . . . . . . . . . . . . . . .361
F.2 Application Example 2 - Program Load by Program Number . . . . . . . . . . . . .364
F.3 Application Example 3 Steriliser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .365
F.4 Application Example 4 Configurable Steriliser . . . . . . . . . . . . . . . . . . . . . . . .365
F.5 Full driver capabilities list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .366
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .367
List of Contents (Cont.)
Section Page

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 1 HA030554 Issue 9 Mar 15
SAFETY NOTES
Warning: Any interruption of the protective conductor inside or outside the apparatus, or dis-
connection of the protective earth terminal is likely to make the apparatus dangerous
under some fault conditions. Intentional interruption is prohibited.
Warning: Live sensors: The unit is designed to operate if the temperature sensor is connected
directly to an electrical heating element. It must be ensured that service personnel
do not touch connections to such inputs whilst the inputs are live. With live sensors,
all cables, connections and switches for connecting the sensor must be mains rated
for use in 240V Cat II.
Warning: Grounding the temperature sensor shield: Where it is common practice to replace
the temperature sensor whilst the instrument is live, it is recommended that the
shield of the temperature sensor be grounded to safety earth, as an additional
protection against electric shock.
Warning: The instrument must not be wired to a three-phase supply with an unearthed star
connection, because, under fault conditions, such a supply could rise above 240V
RMS with respect to ground, thus rendering the instrument unsafe.
Note: Safety requirements for permanently connected equipment state:
a. A switch or circuit breaker shall be included in the building installation
b. It shall be in close proximity to the equipment and within easy reach of the operator.
c. It shall be marked as the disconnecting device for the equipment.
Note: Recommended external fuse ratings are: 2A Type T 250V.

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 2 HA030554 Issue 9 Mar 15
1. This instrument is intended for industrial temperature and process control applications within the require-
ments of the European directives on safety and EMC.
2. Installation may be carried out only by qualified personnel.
3. To prevent hands or metal tools coming into contact with parts that are electrically live the instrument
must be installed in an enclosure.
4. Where conductive pollution (e.g. condensation, carbon dust) is likely, adequate air conditioning/filtering/
sealing etc. must be installed in the enclosure.
5. The mains supply fuse within the power supply is not replaceable. If it is suspected that the fuse is faulty,
the manufacturer’s local service centre should be contacted for advice.
6. Whenever it is likely that protection has been impaired, the unit shall be made inoperative, and secured
against accidental operation. The manufacturer’s nearest service centre should be contacted for advice.
7. If the equipment is used in a manner not specified by the manufacturer, the protection provided by the
equipment might be impaired.
8. The unit must be wired according to the instructions in this manual.
9. Before any other connection is made, the protective earth terminal shall be connected to a protective con-
ductor. The mains (supply voltage) wiring must be terminated in such a way that, should it slip, the Earth
wire would be the last wire to become disconnected. The protective earth terminal must remain con-
nected (even if the equipment is isolated from the mains supply), if any of the I/O circuits are connected to
hazardous voltages*.
The protective earth connection must always be the first to be connected and the last to be disconnected.
Wiring must comply with all local wiring regulations, e.g. in the UK, the latest IEEE wiring regulations
(BS7671) and in the USA, NEC class 1 wiring methods.
10. Signal and supply voltage wiring should be kept separate from one another. Where this is impractical,
shielded cables should be used for the signal wiring.SAFETY NOTES (Cont.)
11.
The maximum continuous voltage applied between any of the following terminals must not exceed 240Vac.
1.Relay output to logic, dc or sensor input connections
2.Any connection to ground.
The ac supply must not be connected to sensor input or low-level inputs or outputs.
12. Over temperature protection: A separate over-temperature protection unit (with an independent tempera-
ture sensor) should be fitted to isolate the process heating circuit should a fault condition arise.
Alarm relays within the recorder/controller do not give protection under all fault conditions/
13. In order to allow the power supply capacitors to discharge to a safe voltage, the supply must be discon-
nected at least two minutes before the instrument is removed from its sleeve. The touching of the
exposed electronics of an instrument which has been removed from its sleeve should be avoided.
14. Instrument labels may be cleaned using iso-propyl alcohol, or water or water-based products. A mild
soap solution may be used to clean other exterior surfaces.
* A full definition of ‘Hazardous’ voltages appears under ‘Hazardous live’ in BS EN61010. Briefly, under nor-
mal operating conditions, hazardous voltages are defined as being > 30V RMS (42.2V peak) or > 60V dc.

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 3 HA030554 Issue 9 Mar 15
USB DEVICE PRECAUTIONS
1. Precautions against electrostatic discharge should be taken when the instrument terminals are being
accessed. The USB and Ethernet connections are particularly vulnerable.
2. Ideally, the USB device should be plugged directly into the instrument, as the use of extension leads may
compromise the instrument’s ESD compliance. Where the instrument is being used in an electrically
‘noisy’ environment however, it is recommended that the user brings the USB socket to the front of the
panel using a short extension lead. This is because the USB may ‘lock up’ or reset in noisy environments
and the only means of recovery is to remove the device, then re-insert it. For memory sticks, EMC-related
failure during a write operation might cause corruption of the data held on the stick. For this reason, the
data on the memory stick should be backed up before insertion and checked after removal.
3. When using a USB extension cable, a high quality screened cable must be used. The total length of USB
cable between the device and the USB port must not exceed 3 metres (10 ft.)
4. Most barcode readers and keyboards are not designed for use in industrial EMC environments, and their
operation in such environments may result in impaired performance of the recorder/controller.
32-BIT RESOLUTION
Floating point values are stored in IEEE 32-bit single precision format. Values which require greater resolution
than is available in this format are rounded up or down.
SYMBOLS USED ON THE RECORDER LABELLING
One or more of the symbols below may appear as a part of the recorder labelling.
Note: The use of U3 USB Flash drives is not recommended.
Refer to manual for instructions
This unit is CE approved
C-Tick mark for Australia (ACA)
and New Zealand (RSM)
Underwriters laboratories listed mark for
Canada and the U.S.A.
For environmental reasons, this unit must
be recycled before its age exceeds the
number of years shown in the circle.
Risk of electric shock
Precautions against static electrical dis-
charge must be taken when handling this
unit
Ethernet connector
USB connector
Protective conductive terminal
(Safety Earth)

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 4 HA030554 Issue 9 Mar 15
1 INTRODUCTION
This document describes the installation, operation and configuration of a paperless graphic recorder/control-
ler. The instrument comes, as standard with four input channels and is equipped, for secure archiving via FTP
transfer and/or to USB memory stick.
1.1 UNPACKING THE INSTRUMENT
The instrument is despatched in a special pack, designed to give adequate protection during transit. Should
the outer box show signs of damage, it should be opened immediately, and the contents examined. If there is
evidence of damage, the instrument should not be operated and the local representative contacted for instruc-
tions. After the instrument has been removed from its packing, the packing should be examined to ensure that
all accessories and documentation have been removed. The packing should then be stored against future
transport requirements.
2 INSTALLATION
2.1 MECHANICAL INSTALLATION
Figure 2.1.1 gives installation details.
2.1.1 Installation Procedure
1. If it is not already in place, fit the IP65 sealing gasket behind the front bezel of the instrument.
2. Insert the instrument through the panel cutout, from the front of the panel.
3. Spring the retaining clips into place, and secure the instrument by holding it firmly in place whilst pushing
both clips towards the rear face of the panel.
4. The protective membrane can now be removed from the display.
Figure 2.1.1 Securing the Instrument
Caution: Before installation, ensure that the specified instrument supply voltage matches the
facility supply
For the sake of clarity, the
panel is shown as though
transparent
Retaining spring (two places)
Push springs towards panel
Push springs towards panel

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 5 HA030554 Issue 9 Mar 15
2.1.2 Demounting
1. Isolate the mains supply and secure it against accidental operation. Remove all wiring and the USB
device and Ethernet cable (if any).
2. Remove the retaining springs by unhooking them from the sides using a small flat-blade screwdriver.
3. Pull the instrument forwards out of the panel.
2.1.3 Removing the Instrument from its Sleeve
The instrument is designed to be removed from its sleeve from the front panel. However, if a USB memory stick
or the Ethernet cable is fitted then this must be removed first.
When the instrument is shipped from the factory it is fitted with two small red clips, one in the top side of the
sleeve and the other below. These are intended as a safeguard against removal of the instrument from its
sleeve when an Ethernet cable is fitted. These clips must also be removed, using a small screwdriver, before
the instrument can be taken out of its sleeve.
Ease the latching ears (Figure 2.1) outwards and pull the controller forward.
When plugging back in ensure that the latching ears click into place to maintain the panel sealing.
Warning: Before removing the supply voltage wiring, isolate the supply voltage and secure it
against unintended operation.

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 6 HA030554 Issue 9 Mar 15
Mechanical Installation (Cont.)
Figure 2.1a Mechanical installation details (standard case)
Panel cutout:
92mm x 92mm (both -0 + 0.8mm)
3.62in x 3.62in (both -0.00 + 0.03in)
Minimum inter-unit spacing:
Horizontal (‘x’) = 10mm (0.4in)
Vertical (‘y’) = 38mm (1.5in)
Side View
Top View
Latching
ears

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 7 HA030554 Issue 9 Mar 15
Mechanical Installation (Cont.)
Figure 2.1a Mechanical installation details (wash down case option)
2.2 ELECTRICAL INSTALLATION
Figure 2.2 shows the locations of the various user terminations along with signal and supply wiring pinouts.
2.2.1 Termination details
The screw terminals accept single wires in the range 0.21 to 2.08 mm2(24 to 14 AWG) inclusive, or two wires
each in the range 0.21 to 1.31 mm2(24 to 16 AWG) inclusive.
Screw terminals should be tightened to a torque not exceeding 0.4Nm (3.54 lb in)
Panel cutout:
92mm x 92mm (both -0 + 0.8mm)
3.62in x 3.62in (both -0.00 + 0.03in)
Minimum inter-unit spacing:
Horizontal (‘x’) = 10mm (0.4in)
Vertical (‘y’) = 38mm (1.5in)
Side View
Top View
Latching
ears

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 8 HA030554 Issue 9 Mar 15
ELECTRICAL INSTALLATION (Cont.)
Figure 2.2 Connector locations and pinouts (rear panel)
1
8
mV
0 to 1V
0 to 10V
T/C
1R0≤R≤1k0
Supply
Voltage Safety Earth
Brown
Blue
Each wire connected to
LA, LB and LC must be
less than 30 metres in
length.
I/O1
Contact closure O/P2
O/P3 Dig InA Dig InB O/P4; O/P5
Relay output
Contact closure Relay outputContact closure
An In1; An In2; An In3; An In4
T/C, Volts, millivolts RTD (two wire)
RTD (three wire)
Milliamps Digital
R<200R = active
R>350R = inactive
100 to 230Vac±15%;
48/62 Hz
24Vac; -15%, +10%
48 to 62 Hz or
24V dc; -15%, +20%
(polarity irrelevant)
Isolated DC o/p (mA)
Ohms inputs
R>500R = inactive
R<150R = active
Relay output
Logic o/p (active high)
Isolated DC o/p (mA/ V)
Internal Link (0V)
R>600R = inactive
R<300R = active
Relay output
Logic o/p (active high) Isolated DC o/p (mA)
An In1; An In2; An In3; An In4
Dual mV/TC Dual mA
Dual input option (Section 2.2.3, below)
(Primary and secondary inputs are not electrically isolated from one another.)
For maximum accuracy, it is recommended that separate returns are made to
Mains (Line) supply voltage
Low voltage option wiring

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 9 HA030554 Issue 9 Mar 15
2.2.2 Low Voltage Option
This option allows the use of a low voltage ac or dc 24 V supply. The specification in Appendix A gives full
details. The polarity of the dc supply connection is not important - it may be connected either way round.
2.2.3 Dual Input Option
This is a cost option, enabled on a channel-by-channel basis by means of entering the relevant password in the
‘Feature3 Pass’ field in Instrument.Security menu described in Section 4.1.6.
For each enabled channel, a pairof thermocouple, mVor mA inputs can be connectedto the instrument. These
inputs are called ‘primary’ and ‘secondary’, and are terminated at the analogue input terminals (An In1 to An In
4) as shown in ‘figure 2.2, above. The primary inputs 1 to 4 are assigned to channels 1 to 4, as normal. Each
secondary input must be soft wired to a maths channel configured as Operation = ‘Copy’ if it is to be recorded/
displayed/alarmed etc.
Soft wiring is described in Section 7
Maths channels are described in Section 4.5.1
Channel configuration is described in Section 4.4.1
Input adjust is carried out as described in Section 4.1.9
SAMPLE RATE
For dual input channels, both primary and secondary sample rate is reduced to 4 Hz (250ms) from the normal
8Hz (125ms).
SENSOR BREAK DETECTION
Input sensor break detection is not supported for secondary inputs. The internal circuit acts as a ‘pull up’ on the
secondary input which therefore saturates high in the event of a sensor break.
DUAL MILLIAMP OFFSET CORRECTION
If ‘Dual mA’ is selected as input type, then an automatic offset correction will be made, according to the shunt
value entered in channel configuration.
INPUT RANGE LIMITATION
There is no 10V range associated with the secondary input. Any input greater than +2V or less than -2V is
deemed to be ‘bad range’.
2.2.4 Modbus Master communications
The master instrument can be connected directly to up to two slaves using standard ethernet network cable
either directly (single slave only) or via a hub or switch (one or two slaves). In either case, ‘straight through’ or
‘crossover’ cable may be used. The cable is terminated at the RJ45 socket at the rear of the unit.
2.2.5 EtherNet/IP
The Client and Server are connected in the same way as describedabove for Modbus Master communications,
except that there can be only one client and one server.
Note: Due to the nature of the input circuit, a large offset may appear for secondary thermocouple
inputs. This offset can be removed only by using the input adjust feature described in Sec-
tion 4.1.9 Because of this offset, the dual thermocouple input option is not suitable for
AMS2750D applications

nanodac RECORDER/CONTROLLER: USER GUIDE
Page 10 HA030554 Issue 9 Mar 15
3 OPERATION
On power up a default or custom splash screen appears and remains visible whilst the unit is ini-
tialising. If during this process a network broadcast storm is detected, the unit stops, displaying a
network failure icon until the broadcast storm has cleared, after which the initialisation process re-
sumes.
3.1 INTRODUCTION
The operator interface consists of a display screen and four push buttons.
3.1.1 Display Screen
The display screen is used both to display channel information (in one of a number of display modes), and to
display the various configuration screens which allow the user to setup the recorder to display the required
channels, to set up alarms and so on. Display modes are described in Section 3.4 below; configuration is de-
scribed in Section 4.
In display mode, the screen is split horizontally into three areas (figure 3.1.1)
1. a faceplate giving channel details.
2. the main display screen showing channel traces etc.
3. the status area, displaying instrument name, the current time and date and any system icons.
Figure 3.1.1 Display mode screen (vertical trend)
In configuration mode, the entire display screen is devoted to the selected configuration menu.
3.1.2 Navigation Pushbuttons
Figure 3.1.2 Top level menu (Engineer level access)
There are four navigation buttons, called ‘Page’, ‘Scroll’, ‘Lower’ and ‘Raise’ located below the screen. The gen-
eralproperties ofthesebuttons aredescribedin theremainderof thissection, butsome haveadditional,context
sensitive functions, which, for the sake of clarity are not described here but in the relevant sections (e.g. ‘Mes-
sage summary’) of the manual.
12:01:08
Channel 1 6.23V
Instrument name
Faceplate
Main display screen
Status area
Home
Configuration
Go to View
Faceplate cycling (On)
Operator Notes
Demand Archiving
Log out
History
