EVERSPRING ST113 User manual

1
SOLAR-POWERED POOL ALARM SYSTEM FOR SAFETY AID
TO READ ATTENTIVELY AND TO PRESERVE FOR FUTURE CONSULTATION
WARNING
This system is simply a safety aid which announces a danger (or risk of danger) when an
equivalent of 8kgs (18 pounds) object falls into a unsupervised swimming pool. The fast
intervention in less than 3 min of a responsible adult is obligatory when the signal of alarm
happens. Ensure the construction of the pool wall is solid enough, thus it can stand the drilling
of the screws and wall plugs without cracking the pool wall. After installation, ensure the pool
alarm itself cannot be shaken, otherwise it will affect the performance of pool alarm detection. In
the event of any injury or death to any person arising out of misuse, abuse, negligence, accident
or alteration, Everspring Tech USA, Inc., will not be liable for any consequence caused.
This system does not replace the good direction nor with the several liability. The purpose of it is
not to either replace the vigilance of the parents and/or the responsible adults, which remains the
essential factor for the protection of the children with less than five years;
The user who turns OFF the system must be conscious that the human monitoring must take
over;
It is imperative to react when the signal of alarm happens;
The greatest vigilance of the responsible parent /adult is necessary between the end of the bathe
and the reactivation of the product;
Never leave children unattended in or around the swimming pool or spa. Children under five years of
age are at the greatest risk for injury or death in pool-related accidents.
In the event of possibility of stroke with against current: "Cancel the stroke with against current at
the end of the bathe to allow the reactivation of the product".
Some of cleaning robots as a plunger robots type are incompatible with the systems of detection
of immersion

2
PRODUCT LAYOUT
Solar-powered Wireless Pool Alarm (ST113)
cBattery Cover
dSolar Panel
eTwo Indication Light (Top & Bottom)
fSensing Compartment
gDetachable Tube
hFlat Mounting Plate
○
7Adjustable Mounting Plate
○
8Spacers
○
9Mounting Feet
Wireless Keypad (SA802)
cSetting/Low Battery LED
dKeypad
eFunction Key
○
3
○
1
○
2
○
3

3
Siren & Strobe (SE802)
cStrobe Light
dRed & Green LED
eTamper Switch
fLearning Key
gDC Jack
hTwo-Phase Sound Jumper Link
iAnti-jamming Jumper Link
jTamper Jumper Link
kMounting Bracket
Wireless Remote Controller (SR803)
A LED indicator E Mute switch
B OFF MODE F Key Chain Ring
C ON MODE G Negative Polarity
D SWIM MODE H Positive Polarity
The kit includes one piece each of Solar-powered Wireless Pool Alarm, Siren & Strobe , Wireless Keypad and
Wireless Remote Controller, all of which products have been designed to aid in the detection of unwanted
intrusions into unclosed above ground or in ground swimming pools. THE SOLAR-POWERED WIRELESS
POOL ALARM IS NOT A LIFE SAVING DEVICE. It should be used along with other safety equipment and
precautions. It is intended to provide an additional level of security to your swimming pool and/or spa. This unit
is not intended to replace any other safety consideration: adult supervision, lifeguards, fences, gates, pool
21
9
3
4
5
6
7
8

4
covers, locks, and so forth… And some devices may not detect gradual entry.
INTRODUCTION
The Solar- Powered Pool Alarm uses seismic technology to detect unwanted intrusions into swimming pools.
In the event of a child or pet ( min. 18 lbs) accidentally falling into the pool the Pool Alarm would detect the
intrusion and sound an 110 db alarm at the pool and an 85db alarm in the house. Immediate adult response
is required upon activation of the alarm.
PACKAGE CONTENT
The Solar Powered Pool Alarm has specially designed packaging to minimize the chance of the contents
becoming damaged during shipping and handling. Please carefully check your unit for damage and confirm
that all the contents listed below are included. For replacement parts, please contact the retailer or store where
you purchased your Pool Alarm.
Item Qty
Base Unit 1
Flat Mounting Plate 1
Wireless Keypad (SA802) 1
Wireless Remote Controller (SR803) 1
Siren & Strobe (SE802) 1
LR20 Alkaline Battery 4
1.5V LR14 14A Size C 4
AA 1.5V alkaline battery 3
25mm Screws 2
30mm Screws 6
15mm Screws 4
18mm Screws 5
38mm Screws 2
Detachable tube 4
Plastic wall plug 9
Mounting feet 2
Adjustable Mounting Plate 1
Spacers 10
Operating instruction manual 1

5
SOLAR-POWERED WIRELESS POOL ALARM
INSTALLING THE POOL ALARM
There are four detachable tubes which can be connected to create a single, long tube. (Fig.1 &Fig. 2)You will
need to connect the appropriate number of tubes to ensure that the distance from the bottom end of the tube to
the water level is 9.65 inches (24.5 cm) (Fig. 3).
Fig.1
Tube
Fig.2
1. Connect the appropriate number of tubes together to ensure that the bottom of the tube is 9.65 inches
below the water line. If the length is longer trim the tube end so that the tube is 9.65 inches below the
water line.
2. Insert the tube to the sensing compartment of the Pool Alarm base using the screws provided (Fig. 2)
3. The base unit must be placed so that the tube is approximately 1 3/4” (4.5cm) from the pool wall. (Fig. 4)
4. Mounting the Pool Alarm Base Unit:
Pool Alarm can simply be placed on the pool deck or permanently installed using the provided mounting
plates. Two styles of mounting plates are included: Aflat mounting plate for mounting the unit on pool decks
with flat coping and an adjustable mounting plate designed for pools with coping edges that are sloped.
zFlat Mounting Plate
To permanently install the unit on flat coping use the attached flat mounting plate. Make sure the unit is
positioned as shown in (Fig.4) below. Using a marker – mark the deck through the 4 mounting slots located on
the sides of the mounting plate. Drill four ¼” holes through the marks. Install the plastic wall plug in the holes

6
with a small amount of silicone. Place the unit over the holes and attach using four 30mm screws provided.
(Fig.3)
Note: The pool alarm may not functional properly if your pool’s water level is not maintained
and the bottom of the tube is not at least 9.65 inches (24.5 cm) below the water line.
zAdjustable Mounting Plate
To permanently install the unit on coping that is sloped. Position the unit as shown in (Fig.7) Install the two
buttons on the front legs of the unit using the screws provided. Place the unit on the edge of the coping so that
the unit is positioned correctly. Place the rear leg mounting plate under the rear legs and add spacers to the
mounting plate’s cups until the Pool Alarm unit is level. Using the 30mm screws provided secure the rear leg
mounting plate to the unit (Fig.5). Next use a marker to mark the coping through the slots on the mounting
plate. Remove the unit and drill two ¼” holes through the marks. Install the plastic wall plug with a small
amount of silicone. Place the unit over the holes and attach using two of the 30mm screws provided. (Fig.6)
Fig.5
Fasten the
Mounting Feet.
Spacers can be used
to adjust the height.
Fig.4
Fig.3

7
Note: The pool alarm may not functional properly if your pool’s water level is not maintained
and the bottom of the tube is not at least 9.65 inches (24.5 cm) below the water line.
WIRELESS KEYPAD
The Wireless Keypad is used to control the Pool Alarm by using a four digit Administrator password. The
Keypad is powered by 3 x AA 1.5V alkaline battery. Under normal operating conditions this will provide an
expected life in excess of 1 year. When the battery level falls below an unacceptable level, the “Setting/Low
Battery” LED on the front of the Keypad will flash 4 times when pressing any key. When this occurs the
batteries should be replaced as soon as possible.
POSITIONING THE KEYPAD
The Keypad should be located and mounted inside the premises. To determine the proper location the keypad
should be placed on the interior wall closest to the pool at eye level near the door that provides access to the
pool. The range of wireless signal approximately 150” when using the device through walls. Do not fix the
keypad to metalwork or locate the unit within 3 feet of metalwork such as doorframes, radiators pipes, etc.
INSTALLING AND CONFIGURING THE KEYPAD
1. Undo and remove the fixing screw from the bottom edge of the Keypad and remove the wall mounting
bracket.(Fig.9)
Fig. 9 Fig.10.
Fig.6
Fig.7

8
2. Using the mounting bracket as a template, mark the positions of the two fixing holes on the wall.
3. Fix the mounting bracket to the wall using the screws and wall plugs provided. (Fig.10) Do not over-tighten
the fixing screws as this may distort or damage the mounting bracket.
4. There is one jumper link located above the battery compartment.(Fig .11)
Jumper link J1: Reset to Factory default
If unfortunately you forget the Administrator password, reset the Administrator password to factory default
by proceeding with the following steps in sequence:
(1) Remove the batteries.
(2) Set the Jumper link J1 to off position as shown on Fig. a
Fig.a Fig.b
(3) Refit the batteries. The keypad is reset properly by flashing back light 0~9 3 times.
(4) Set the Jumper link J1 to on position as shown on Fig. b.
5. Connect the 3 x AA alkaline batteries to the battery compartment.
6. Click the Keypad to the mounting bracket and screw the fixing screw.(Fig.4a &4b) Do not over-tighten the
fixing screw.
Note: The Keypad has back light illumination facility. The back light of digit number 0~9 won’t be off until
5-second illumination duration expires each time when you press any key. Once transmission is successful the
back light of digit number 0~9 will extinguish. Failure to input any key more than 5 seconds after each pressing
will be treated as invalid input. The back light of digit number 0~9 will flash 3 times as an indication.
CHANGING THE ADMINISTRATOR PASSWORD
The Keypad is supplied with a default Administrator password of: 1234. For security reasons, it is
recommended that this password is changed to another four digit number which only you and other users of
the system know. To change the Administrator password, press the following keys in sequence:
(1) Press
OriginalAdministratorpassword
1 2 3 1 2 3
Fig. 11
Fig. 4a. Fig. 4b.
ONOFF

9
(2) Enter
New Administrator password
SIREN & STROBE (SE802)
The Siren & Strobe serves as an auxiliary accessory to the Pool Alarm. When the Pool Alarm detects
unwanted intrusions into unclosed swimming pools, a full alarm condition will occur. Simultaneously, the
Siren & Strobe will initiate a full alarm condition as an intensive warning.
POSITIONING THE SIREN & STROBE
The Siren & Strobe should be located and mounted inside the premises. To determine the proper location the
Siren & Strobe should be placed on the interior wall closest to the pool approximately at door height near the
door that provides access to the pool. The range of the wireless signal approximately 150’ when using the
device through walls. Do not mount the Siren & Strobe to metalwork or locate the Siren within 3 feet of
metalwork such as doorframes, radiators, pipes, etc.
INSTALLING AND CONFIGURING THE SIREN & STROBE
(1) Undo and remove the fixing screws from the mounting bracket.
(2) Place 4 x 1.5V alkaline LR14 batteries to the battery compartment.
(3) Use the mounting bracket as a template to mark the positions of fixing holes on the wall.
(4) Fix the mounting bracket to the wall using the plastic wall plugs and fixing screws provided.
(5) According to the functions of the product layout, choose or justify the ones that suit you most.
Function Description
Red & Green LED Green LED: RF transmission
confirmation
Red LED: Warning indication
When red & green LED illuminate
simultaneously, orange LED will
be indicated
Strobe Light Warning indication
Learning Key Learning and cleaning out the
preset ID code
Tamper Switch A full alarm condition will be
initiated against the unit being
removed from the wall
A full alarm condition will be
initiated if the unit is removed from
the wall.
Tamper Jumper Link Enable or disable this function Jumper link fitted – enable
Jumper link removed - disable
Anti-jamming Jumper Link Enable or disable this function Jumper link fitted – enable

10
Jumper link removed - disable
Two-phase Sound Jumper Link Sound volume selectable – 90 or
100 dB/ 0.3 feet
Jumper link fitted – 100 dB
Jumper link removed – 90 dB
DC Jack Use AC/DC adaptor
Jumper link fitted Jumper link removed
Enable Disable
NOTE: The Anti-jamming Jumper Link is preset disabled due to its high sensitivity easily causes
Siren &Strobe abnormal alarm.
(6) By releasing the tamper switch from being pressed if the tamper jumper link is enabled, the unit will
generate a full alarm condition by flashing its strobe light for about 6.5 minutes and red LED illuminating
shortly.
(7) If the battery level drops below unacceptable level, the red LED of the unit will flash shortly every 30
seconds. When this occurs, the batteries should be replaced as soon as possible.
Wireless Remote Controller (SR803)
The Wireless Remote Controller is a hand-held transmitter which offers the pool owner to control Pool Alarm
from a distance within 150 feet. The Remote Controller adopts a CR2032 type Lithium cell which under normal
conditions will have typical life in excess of 1 year. Under normal battery conditions the LED on the Remote
controller will only illuminate when a button is pressed. However, under low battery conditions the orange LED
will illuminate every time the button is pressed. When this occurs the batteries should be replaced as soon as
possible.
SETTING THE REMOTE CONTROLLER
1. Remove the rear cover with a coin.
2. Insert the battery ensuring that the +v terminal faces upwards away from the PCB.
OPERATING INSTRUCTIONS
The Pool Alarm has been designed to function in pools up to 16’ x 32’ in size. For pools that are 16’ x 32’ or
smaller, the Pool Alarm must be installed at the midpoint of the longest side of the pool. (See illustration) The
unit must not be located within 18” of any water inlet or outlet in the pool. For pools with spillover spas the unit
