evertz 7700 Series User manual

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
Revision 1.6
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 1
2. INSTALLATION................................................................................................................................... 3
2.1. CARE AND HANDLING OF OPTICAL FIBER........................................................................... 4
2.1.1. Safety.............................................................................................................................. 4
2.1.2. Handling And Connecting Fibers .................................................................................... 4
3. SPECIFICATIONS............................................................................................................................... 5
3.1. OPTICAL INPUT......................................................................................................................... 5
3.2. SERIAL VIDEO OUTPUTS: ....................................................................................................... 5
3.3. ELECTRICAL ............................................................................................................................. 5
3.4. PHYSICAL.................................................................................................................................. 5
4. STATUS LEDS.................................................................................................................................... 6
5. JUMPERS............................................................................................................................................ 7
5.1. SELECTING RECLOCK OR NON-RECLOCK MODE............................................................... 8
5.2. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS.......................................................................................... 8
Figures
Figure 1-1: 7705OE-HD Block Diagram................................................................................................................2
Figure 2-1: 7705OE-HD Rear Panels ...................................................................................................................3
Figure 5-1: Jumper Locations for Rev A and Rev 1 DA Cards.............................................................................7
Figure 5-2: Jumper Locations for Rev B DA Cards...............................................................................................7
Figure 5-3: Jumper Locations for Rev C DA Cards...............................................................................................7

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
Revision 1.6
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 Original Version June 99
1.1 Bypass mode now called non-reclock mode Sept 99
Figure 1 updated, Figure 3, 4 added
1.2 Added Safety notice Mar 00
1.3 Added jumper locations for Rev C board (Figure 5 added) July 00
Added ST/PC and FC/PC connector options
Specifications updated
1.4 Specifications updated Feb 01
1.4.1 Figure 1 changed Jan 02
1.5 Added 8 new CWDM wavelengths Dec 02
1.6 Updated features and technical specifications Nov 08
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by
Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
Revision 1.6 7705OE-HD - 1
1. OVERVIEW
The 7705OE-HD Fiber to Electrical converter provides an economical method of converting incoming
optical distribution for SMPTE 292M (1.5 Gb/s) HDTV serial digital signals to in-plant coaxial distribution.
The companion 7705EO-HD Electrical to Fiber converter facilitates conversion from coaxial distribution at
the source. The converter features one optical input with three re-clocked serial digital outputs. The
7705OE-HD has been designed to be used primarily as a reclocking 1.5Gb/s distribution amplifier,
however, it can also be used as a non-reclocking SMPTE 310M (19.4 Mb/s), DVB-ASI, or SMPTE
259M(143 to 540 Mb/s) distribution product.
The 7705OE-HD is available in 2 different versions with different optical input sensitivity. (See
specifications for complete information)
7705OE-HD -15 dBm input sensitivity
7705OE-HD-L -22 dBm input sensitivity
Features:
•Operation from 19.4Mb/s to 1.5Gb/s
- Reclocking for SMPTE 292M (1.485Gb/s)
- Non-reclocking mode for all other rates from 19.4Mb/s to 1.5Gb/s including SMPTE 259M,
SMPTE 305M, SMPTE 310M, M2S, DVB-ASI, etc.
•Supports single-mode and multi-mode fiber optic cable
•Fully hot-swappable from front of frame with no fiber or BNC disconnect/reconnect required
•Can be housed in either a 1RU frame which will hold up to 3 modules, a 3RU frame which will hold
up to 15 modules, 3RU portable frame that holds up to 7 modules or a standalone frame which will
hold 1 module
•Comprehensive signal and card status monitoring via four digit card edge display
Input:
•Optical input range from 1270nm to 1610nm
•Input sensitivity up to -23dBm
•SC/PC, ST/PC, FC/PC connector options
Outputs:
•Three serial digital BNC outputs for fan-out, loop-through or monitoring
•Wideband Jitter < 0.2 UI (reclocked)
Status LEDs:
•Signal presence indication
•Module status indication

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
7705OE-HD - 2 Revision 1.6
3 Serial Outputs
1.5 Gb/s
(SMPTE 292M)
Optical to
Electrical
Conversion
Re-
cloc
k
*Non-
reclock
Cable Drivers
*Note: Non-reclock Mode will operate 19.4 Mb/s to 1.5 Gb/s
Optical Input
1.5 Gb/s
(SMPTE 292M) Optical
Receiver
Signal
Present
Module
Status
Figure 1-1: 7705OE-HD Block Diagram

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
Revision 1.6 7705OE-HD - 3
2. INSTALLATION
The 7705OE-HD comes with a companion rear plate that has 3 BNC connectors and 1 SC/PC (shown),
ST/PC or FC/PC optical connector. For information on mounting the rear plate and inserting the module
into the frame see section 3 of the 7700FR chapter.
Figure 2-1: 7705OE-HD Rear Panels
HD INPUT: There is a SC/PC (shown) ST/PC or FC/PC female connector for optical 10-bit serial
digital video signals compatible with the SMPTE 292M standard. The 7705OE-HD can
also be used in non-reclock mode with SMPTE 310M (19.4 Mb/s), SMPTE 259M (143 to
540 Mb/s) or DVB-ASI, or any other signal with bit rate less than 1.5 Gb/s. See section
5.1 for information on operating the module in non-reclock mode.
HD OUTPUT: There are three BNC connectors with reclocked serial component video outputs,
compatible with the SMPTE 292M standard. In non-reclock mode these outputs contain
an equalized copy of the input signal.

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
7705OE-HD - 4 Revision 1.6
2.1. CARE AND HANDLING OF OPTICAL FIBER
2.1.1. Safety
Never look directly into an optical fiber. Non-reversible damage to the eye can
occur in a matter of milliseconds.
The laser modules used in the Evertz fiber optic modules are Class I, with a maximum output power of
2mW, and wavelengths of 1310nm or from either 1270nm to 1610nm.
2.1.2. Handling And Connecting Fibers
"Never touch the end face of an optical fiber.
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that you maintain a minimum bending radius of 3 cm to avoid fiber-bending loss that will
decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with
cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the
frame that does not have a suitable I/O module. For further information about care and handling of fiber
optic cable see section 3 of the Fiber Optics System Design chapter of this manual.

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
Revision 1.6 7705OE-HD - 5
3. SPECIFICATIONS
Standard: SMPTE 292M, 259M, 297M, 305M, 310M, M2S, DVB-ASI, and other
Telecom/Datacom standards involving data rates from 19.4Mb/s to 1.5Gb/s
3.1. OPTICAL INPUT
Number of Inputs: 1
Connector: SC/PC, ST/PC, FC/PC Female housing
Operating Wavelength: 1270nm to 1610nm
Max. Input Power: -1dBm
Optical Sensitivity: -23dBm
-20 dBm (“L” – long haul version)
Fiber Size: 62 µm core / 125 µm overall
3.2. SERIAL VIDEO OUTPUTS:
Number of Outputs: 3 Reclocked outputs
Connector: 1 BNC per IEC 61169-8 Annex A
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: 270ps nominal
Overshoot: < 10% of amplitude
Return Loss: > 15dB to 1GHz, > 12dB to 1.5GHz
Jitter: < 0.2 UI Reclocked
3.3. ELECTRICAL
Voltage: + 12VDC
Power: 6 Watts
EMI/RFI: Complies with FCC Part 15, Class A
EU EMC Directive
3.4. PHYSICAL
7700 or 7701 frame mounting:
Number of slots: 1

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
7705OE-HD - 6 Revision 1.6
4. STATUS LEDS
MODULE OK This Green LED will be On when the module is operating properly.
LOCAL FAULT This Red LED will be On when input video is lost or there is a fault in the module
power supply.
CARRIER PRESENT: This Green LED will be On when there is a valid signal present at the module
input.

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
Revision 1.6 7705OE-HD - 7
5. JUMPERS
LOCAL FAULT / MODULE OK
CARRIER PRESENT
J8
RATE
HD / BYPASS
J9
J20
FRAME
STATUS
SFF POWER
+12V
EVERTZ (A) 7700DA-HD
RATE
HD / BYPASS
Figure 5-1: Jumper Locations for Rev A and Rev 1 DA Cards
LOCAL FAULT / MODULE OK
CARRIER PRESENT
EVERTZ (B) 7700DA-HD
J8
RATE
HD / BYPASS
J9
SFF POWER
+12V
J20
FRAME
STATUS
ON
RATE
HD / BYPASS
Figure 5-2: Jumper Locations for Rev B DA Cards
LOCAL FAULT / MODULE OK
CARRIER PRESENT
J8
J9
NON-RCLK
SFF POWER
+12V
J20
FRAME
STATUS
ON
NON
RCLK
RCLK
RCLK
EVERTZ (C) 7700DA-HD
Figure 5-3: Jumper Locations for Rev C DA Cards

7700 MultiFrame Manual
7705OE-HD HDTV Optical to Electrical Converter, 19.4Mb/s to 1.5Gb/s
7705OE-HD - 8 Revision 1.6
5.1. SELECTING RECLOCK OR NON-RECLOCK MODE
There are two jumpers J8 and J9 that determine whether the module will operate as a reclocking
distribution amplifier with SMPTE 292M (1.5 Gb/s) video signals or as a non-reclocking distribution
amplifier with other data rates.
For the A and B revision of the board:
HD / BYPASS: To select the normal reclocking mode remove both of these jumpers. For
convenience you may re-install the jumper so that only one side is connected.
To select the non-reclocking mode install both of these jumpers.
For the C revision and later of the board:
RCLK/NON-RCLK: To select the normal reclocking mode put both of these jumpers in the RCLK
position. To select the non-reclocking mode install both of these jumpers in the
NON-RCLK position.
5.2. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS
The FRAME STATUS jumper located at the front of the module determines whether local faults (as shown
by the Local Fault indicator) will be connected to the 7700FR frame's global status bus.
FRAME STATUS: To monitor faults on this module with the frame status indicators (on the PS
FRAME STATUS LED's and on the Frame's Fault Tally output) install this jumper in
the On position. On Rev A and B boards install the jumper. (default)
When this jumper is installed in the Off position local faults on this module will not
be monitored. On Rev A and B boards remove the jumper and re-install it so that
only one side is connected.
