evertz S622 User manual

Model S622, S622-VCG
VITC Reader
INSTRUCTION MANUAL
© Copyright 1986
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive
Burlington, Ontario, Canada, L7L 5Z9
Phone: [phone]
Fax: [phone]
Internet: Tech Support: [email protected]
Sales: [email protected]
Web Page: www.evertz.com
Written by Alan Lambshead
Revision 2.1, January 1986
The material contained in this manual consists of information that is the property of Evertz Microsystems and is
intended solely for the use of purchasers of EV-BLOC systems. Evertz Microsystems expressly prohibits the use
of this manual for any purpose other than the operation or maintenance of the EV-BLOC system.
All rights reserved. No part of this publication may be reproduced without the express written permission of
Evertz Microsystems Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz
Microsystems.

INFORMATION TO USERS IN EUROPE
NOTE
CISPR 22 CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to the European Union EMC directive. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
WARNING
Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could
void the user’s authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded
interface cables with the shield connected to the chassis ground of the device must be
used.

EV-BLOC
REVISION HISTORY
REVISION DESCRIPTION DATE
2.1 Original issue 01/86

EV-BLOC
This page left intentionally blank

EV-BLOC
TABLE OF CONTENTS
1. MODEL 622 VITC READER/TRANSLATOR ....................................................................................... 1-1
1.1. INSTALLATION ............................................................................................................................... 1-2
1.1.1. Video Input and Output......................................................................................................... 1-2
1.1.2. LTC Translator Output .......................................................................................................... 1-2
1.1.3. CTL/DATA Pin Assignments................................................................................................. 1-3
1.2. FORMAT FUNCTIONS .................................................................................................................... 1-3
1.3. CHARACTER GENERATOR FUNCTIONS ..................................................................................... 1-4
1.3.1. Character Position ................................................................................................................ 1-5
1.3.2. Background Selection ........................................................................................................... 1-5
1.3.3. Drop Frame Indication (NTSC units only) ............................................................................. 1-5
1.3.4. Field Indication...................................................................................................................... 1-5
1.3.5. Time/User Bits Display..........................................................................................................1-5
1.3.6. Source Identification ............................................................................................................. 1-5
1.3.7. Freeze Remote Control Input ............................................................................................... 1-5
1.4. PARALLEL OUTPUTS .................................................................................................................... 1-6
1.4.1. BCD Time/User Bit Output.................................................................................................... 1-6
1.4.2. Remote Control Switch Outputs............................................................................................ 1-7
1.5. TECHNICAL DESCRIPTION ...........................................................................................................1-7
1.5.1. Microcontroller (6220-30)...................................................................................................... 1-8
1.5.2. Sync Separator (6220-31) .................................................................................................... 1-8
1.5.3. VITC Reader (6220-31) ........................................................................................................ 1-8
1.5.4. Video Character Generator (6221-30) .................................................................................. 1-9
2. 4600T INSTALLATION ........................................................................................................................ 2-1
2.1. REAR PANEL .................................................................................................................................. 2-1
2.2. INSIDE THE 4600T:REMOVING THE FRONT PANEL................................................................... 2-1
2.3. MOUNTING ...................................................................................................................................... 2-2
2.3.1. Selecting the Correct Mains Voltage..................................................................................... 2-2
Figures:
Figure 1-1: Model 622 Block Diagram......................................................................................................... 1-1
Figure 1-2: BCD Output Waveforms ........................................................................................................... 1-7
Drawings: DWG. #
6031/6051 Rear Panels............................................................................................................... M6000-58RL
603-6031 I/O Modules................................................................................................................... S-6030-30A
6031 I/O Module Power Supply.........................................................................................................6031-31A
6220 VITC Reader Main Schematic................................................................................................. 6220-30H
TABLE OF CONTENTS i

EV-BLOC
6220 VITC Reader Circuit ................................................................................................................ 6220-31H
622/6221 Component Layout ............................................................................................................. 622-81H
6221 VCG Submodule Video Input/Output ....................................................................................... 6221-31J
6221 VCG Submodule Connector Interface...................................................................................... 6221-32J
6221 VCG Submodule Character Ram and Prom ............................................................................ 6221-33J
6221 VCG Submodule Timing Components ..................................................................................... 6221-34J
6221 Component Layout ................................................................................................................... 6221-80J
TABLE OF CONTENTS ii

EV-BLOC
1. MODEL 622 VITC READER/TRANSLATOR
The 622 module is a vertical interval time code reader and longitudinal time
code generator in one slim euro-card package containing features not found
anywhere else. When used as a translator from VITC to LTC, a unique soft
locking scheme assures error free play speed code regardless of speed
variations of the code being read. If the VTR is bumped in and out of sync by
an editor or synchronizer, the translated LTC framing follows gradually without
missing a beat. The 622 reader contains all the necessary video processing
circuits and therefore requires no external signals other than the video signal
containing the VITC.
The 622 module has several reading modes. The first valid line of code
encountered in each field will be processed in the 'AUTO' mode. This mode,
invoked automatically when the optional VCG is not installed, ensures smooth
reader operation from still frame to about 20 times play speed. The use of a
time base corrector will extend the recovery range. Two further modes,
available when the VCG option is installed, permit selective reading of one
VITC line pair, when several sets of VITC data are present.
Figure 1-1: Model 622 Block Diagram
An optional video character inserter allows this unit to be used as a direct
display reader. A broadcast quality keyer inserts white high resolution
characters with a black background into the program video. Character size and
raster position are switch selectable.
MODEL 622 1-1

EV-BLOC
Another application is source identification. A look-up table is used to decode a
special code (placed in the user bits of the VITC by a 621 encoder or other
VITC generator) and display source ID messages using the optional VCG. The
ID code may be “source only" for a camera (ie. CAM 1), on air status (ON AIR
blinking), or source ID plus timecode for a time coded source (ie. VTR 3).
Six Buffered outputs are provided for either multiplexed parallel BCD data
outputs, or grounding solid state switches used for remote machine control
applications. A two position front panel switch aids in selection of the various
operational modes such as VCG display characteristics, function of parallel
outputs, VITC line select, etc. Formatted modes are retained in non-volatile
memory even when power is removed.
1.1. INSTALLATION
All connections to the 622 VITC Reader are made using the Model 603-RD
Parallel I/O module. Refer to section 2.2 for instructions on fitting the 622 and
I/O modules into the rack frame.
1.1.1. Video Input and Output
The reader video with VITC recorded on it is connected to the VIDEO IN loop.
The internal sync separator has a high impedance input tapped off the loop
through, therefore, the input must be terminated with 75 ohms at the end of the
line. The input video is also used as a reference for phasing of the LTC
translator output and as an input to the optional character inserter. When video
is present at the reader input the µP OK LED will be on. When no video is
present, it will be flashing on and off. When VITC is being read from the input
video, the VITC LED will also be on.
Program video with characters inserted is available on two separate outputs.
1.1.2. LTC Translator Output
A 1/4" stereo phone jack is provided as an output from the LTC translator. This
output is play speed regenerated code from the VITC being read. When the
incoming code is at normal play speed, the output code is properly
synchronized to the input video. When there is no incoming VITC, the LTC
output disappears.
MODEL 622 1-2

EV-BLOC
1.1.3. CTL/DATA Pin Assignments
A nine pin subminiature 'D' connector is provided on the Model 603 Parallel I/O
module, for remote control of the reader functions and BCD data/remote control
outputs from the reader. The inputs are activated by a connection to ground.
The pin connections are described below:
Pin Name Description
5 FRZ Freeze time display input
9 RCT/DAT remote ctl/data select input
4 OP5/STB Address/data strobe/bit 5
8 OP6/CTS Clear to send / output bit 6
3 OP3 Data output bit 3
7 OP4 Data output bit 4
2 OP1 Data output bit 1
6 GND Ground
1 OP2 Data output bit 2
1.2. FORMAT FUNCTIONS
A two position toggle switch mounted on the front panel is used in conjunction
with the optional video character inserter to configure the following operational
modes. Each time the switch is pressed to the MODE position, the next mode
to be formatted is selected, and an appropriate message is displayed in the top
left corner of the VCG display. If you want to change that mode, press the
switch to the SELECT position to cycle through the possible configurations.
When the desired selection is displayed, release the switch to the centre
position. The next mode may be selected by pressing the switch to the MODE
position, etc. After 5 seconds with no switch action, the format display is turned
off, and the selections are stored in a non-volatile memory, for recall after a
power failure. The format modes are listed below in the order they occur.
When the optional VCG is not installed, the Model 622 uses AUTO reading mode. The
RCTL/DATA remote control input selects the DATA/RCTL mode.
"
DSPLY Pressing SELECT changes the display format of the VCG display to
show time, user bits (source ID or numeric), time and user bits, or
no VCG display. In the absence of incoming VITC, the VCG display
may be blanked (see VCG MODE below). Display mode selection
should be done with a valid VITC input. When Source ID user bits
are being read without running time code numbers, the time digits
will not be displayed.
SIZE Pressing SELECT alternates between one of two VCG sizes.
VCG MODE Pressing SELECT alternates between one of two modes for the
VCG display.
MODEL 622 1-3

EV-BLOC
When BLANK is displayed, the character display is blanked when there is no
incoming VITC on the lines it is programmed to read.
When SHOW is displayed, the character display shows the last value read after
VITC is removed from the programmed lines.
When code is present, the VITC data is displayed according to the formatted
DSPLY mode.
READ MODE One of three reading modes will be selected. When AUTO is
displayed, the first valid line of VITC encountered in each field will
be read.
When two line numbers are displayed, (ie. 12 14), only VITC
recorded on the displayed lines will be read.
When two line numbers separated by an arrow are displayed,
(ie. 12>14), then the first valid line of VITC encountered in the range
of lines selected will be read.
Selection of individual lines or a range of lines can only be used when the incoming
video with VITC is at play speed, or is time base corrected. If no VITC exists on the
selected lines, the 622 reader will turn the VITC IN indicator off and blank the character
display if the BLANK VCG mode is selected. If the SHOW VCG mode is selected, the last
valid time read will be displayed.
"
LINE1 Two line numbers will be displayed, with the leftmost one blinking.
Pressing SELECT will advance the blinking number. When the last
permitted line is reached, the number will return to the lowest
permitted number. Valid numbers are 10 to 20 for NTSC, and 6 to
21 for PAL.
LINE2 Two line numbers will be displayed, with the rightmost one blinking.
Line selection is accomplished as for LINE1 above.
OUTPUT One of two modes for the parallel outputs will be selected. When
DATA is displayed, the reader data is output as described in section
1.4.1. When RCTL is displayed, the outputs operate as remote
control switches as described in section 1.4.2.
1.3. CHARACTER GENERATOR FUNCTIONS
When fitted with the optional VCG sub module, the Model 622 VITC reader
provides a display of time or user bit information as characters keyed into the
program video.
MODEL 622 1-4

EV-BLOC
1.3.1. Character Position
The position of the reader display is selected by a 16 position rotary switch
located on the side of the module. A small screwdriver can be used to position
the characters to one of 15 positions on the screen. Selecting position 0 turns
the characters off.
1.3.2. Background Selection
The position of the shorting jumper on header J3, (located on the VCG sub
module near the position switch), determines whether characters will be keyed
into a black background or not. With the jumper in the 'B' position, (closest the
rear of the module), a black background will be used. When in the 'NB'
position, white characters will be keyed into the video without a background.
1.3.3. Drop Frame Indication (NTSC units only)
When displaying reader time information, the colon between the seconds and
frames will be replaced by a period if the data being read was recorded in the
EIA drop frame mode.
1.3.4. Field Indication
When displaying the VITC time numbers, the field number sequence will be
displayed to the right of the frames display. When the data being read was
recorded in the non colour frame mode, the field number sequence will be
1,2,1, etc (1,2,3,4,1,etc for PAL). When the data being read was recorded in
the colour frame mode, the field number sequence will be 1,2,3,4,1, etc
(1,2,3,4,5,6,7,8,1,etc for PAL).
1.3.5. Time/User Bits Display
Either the time or user bits or both may be displayed. The format toggle switch
is used to control the display mode. (See section 1.2 above) The colons are
blanked when the user bits are being displayed. When the incoming code
contains source ID user bits from a non time coded source, (i.e. the 'frames'
user bits are 94), the time numbers will be automatically blanked regardless of
the formatted display mode.
1.3.6. Source Identification
When reading code that has been recorded with source ID user bits, generated
by one of our VITC generators, these user bits will be displayed as alpha-
numeric character groups, and not their hexadecimal equivalents, when the
user bit display is turned on. (See section 1.3.5 above)
1.3.7. Freeze Remote Control Input
Momentarily grounding the Freeze input (on the 9 pin CTL/DATA connector)
freezes the character display. Grounding the input again restores normal
display of the reader data.
MODEL 622 1-5

EV-BLOC
1.4. PARALLEL OUTPUTS
Six transistor switches brought out to the 9 pin CTL/DATA connector are
configured to operate in one of two modes. When the optional VCG is
installed, the use of these outputs is configured using the mode select switch.
(see section 1.2) When the VCG is not installed, the CTL/DATA remote control
input on the 9 pin connector selects DATA when grounded and RCTL when left
open.
The table below shows the addresses for the respective time code digits.
ADDRESS DIGIT ADDRESS DIGIT
0000 1X Frm 1000 Bin Grp 1
0001 10X Frm 1001 Bin Grp 2
0010 1X Sec 1010 Bin Grp 3
0011 10X Sec 1011 Bin Grp 4
0100 1X Min 1100 Bin Grp 5
0101 10X Min 1101 Bin Grp 6
0110 1X Hrs 1110 Bin Grp 7
0111 10X Hrs 1111 Bin Grp 8
1.4.1. BCD Time/User Bit Output
When the DATA mode is formatted, parallel BCD time and user bit information
is available on 6 output lines on the 9 pin connector. The data is presented in a
multiplexed format as follows:
The CTS line is brought low at the beginning of the sequence.
Then a 4 bit address is presented with a positive going strobe
(STB). Four bits of BCD data are then presented along with a
negative going STB. This cycle is repeated for each of the 8
digits of time, followed by the 8 user bit digits. When the
output sequence is complete, the CTS line returns high. The
sequence of data is presented once per frame, during the last
half of field 2.
Flag bits are output along with the time bits as follows:
BIT POSITION NTSC PAL
10 x Frm Bit 2 Drop Frame Unassigned
10 x Frm Bit 3 Col'r Flag Col'r Flag
10 x Sec Bit 3 Field Flag Bin Grp Flg #1
10 x Min Bit 3 Bin Grp Flg #1 Bin Grp Flg #2
10 x Hrs Bit 2 Bin Grp Flg #2 Unassigned
10 x Hrs Bit 3 Unassigned Field Flag
MODEL 622 1-6

EV-BLOC
Figure 1-2: BCD Output Waveforms
1.4.2. Remote Control Switch Outputs
When the RCTL mode is formatted, the six parallel outputs are configured as
open collector transistor switch outputs. When source ID user bits are being
received, the 'hours' user bits, (binary groups 7 & 8), will be used to control the
remote control switch outputs. When a '1' is encoded in the corresponding
user bit position, the switch will be turned on, otherwise it will be off. These
switches can be used to remotely control devices using the user bits in the
VITC encoded in the video path, thus producing a low cost remote control
system.
1.5. TECHNICAL DESCRIPTION
The 622 reader is a microcontroller based module functionally divided into the
following hardware subsystems:
1. Microcontroller & I/O
2. Sync Separator
3. VITC reader logic
4. Video Character Generator
The microcontroller and VITC reader circuits are contained on the main circuit
card (6220). The video character inserter circuitry is optional and is contained
on a separate sub-module (6221) which plugs into the main module. Video
input buffers and all input/output connectors are contained on a separate I/O
module, (603) which plugs into the rear of the backplane. The relevant
schematic drawings are shown in brackets for each section of the circuit.
MODEL 622 1-7

EV-BLOC
1.5.1. Microcontroller (6220-30)
At the heart of the 622 reader module is an 8749 microcontroller, (MCU) U21.
Its two 8 bit bi-directional ports and 8 bit bus provide peripheral interfacing to
the rest of the circuits. Program memory and scratch pad and data RAM are
provided internally by the MCU.
An onboard oscillator, also part of the MCU, is crystal controlled. Its' 10.0699
MHz (10.08 MHz for PAL) is internally divided by 15 resulting in a processor
operating frequency of approximately 672 KHz. The time code output for the
LTC translator is generated internally in the MCU, and is brought out on port
line P24. The code edges are registered with the MCU clock at U22a, and
shaped to the correct rise and fall times by U23.
1.5.2. Sync Separator (6220-31)
Reader composite video with VITC, buffered on the separate I/O module, and
on the main PCB by Q5 and Q4, is AC coupled into U20b. Immediately
following each horizontal sync pulse, a sample pulse is generated at U20c
which allows U20a to compare the actual DC level of the video to ground
potential. If they are not equal, U20a generates an error signal which adjusts
the bias point of Q5 thus ensuring proper operation of the video keyer with
varying video and sync levels. DC restored video is fed to the VCG sub
module header J1 & J2.
The output of U20b is buffered by U7b producing composite SYNC. Composite
SYNC is integrated by U16a to derive vertical sync (VSYNC) which interrupts
the MCU at U21 pin 6. A field 2 pulse is generated by U14a and U15 and is
provided to the MCU to correctly frame the LTC code output.
1.5.3. VITC Reader (6220-31)
Composite video is fed to comparator U2, which recovers VITC data from the
DC restored video. U1 and associated components provide a reference level
to U2, of approximately one half the peak VITC level, to ensure proper
extraction of the VITC data regardless of the video level.
At VSYNC, the MCU releases the reset to U6a, enabling the VITC reader
circuitry. Switch U4d is closed, clocking the VITC line enable bit pattern from
U13, enabling flip flop U6b only for the selected lines. The first VITC data bit
turns on U6b which releases the reset to CRC detector U11 and U9.
A crystal controlled oscillator consisting of U7c and associated components
operates at a frequency of 14.31818 MHz for NTSC, or 14.5 MHz for PAL. The
oscillator output is buffered by U7a, measured at the OSC FREQ test point,
provides an 8 times bit rate clock to divider U3, which generates a series of
timing pulses at the VITC bit rate (1.78977 MHz for NTSC, 1.8125 MHz for
PAL). Each positive going transition of the VITC data re-synchronizes the
divider so that the VITC recovery clock at U3 pin 13 occurs in the middle of
each bit.
MODEL 622 1-8

EV-BLOC
Inverted VITC data is shifted into U11 which calculates the cyclic redundancy
check (CRC) word for the recovered data. Valid CRC and 90 bits of code,
detected by U9, clocks U6a on, disabling the VITC clock and generating a
VITC RDY signal to the MCU. The MCU unloads the VITC data through switch
U4.
1.5.4. Video Character Generator (6221-30)
The character inserter logic and keyer are contained on a separate circuit sub-
module which connects to the main circuit card via header J1 & J2. DC
restored video, HSYNC, VSYNC, and the MCU address and data bus are fed
up the header from the main board.
The character display is formatted to display 14 (16 for PAL) rows of 32
characters each in the small size, and 7 (8 for PAL) rows in the large size.
Each of the character positions corresponds to one of 512 locations in RAM
U9. The MCU writes characters into specified locations in the RAM
corresponding to the position of the characters on the screen. RAM locations
are scanned during each television field. Valid characters address
corresponding sections of the character PROM U15 and character data is
shifted out from U8 and keyed into the video by U23. Characters with bit 7=1
are written into all positions of the RAM where no characters are to be
displayed. These characters disable keyer control flip flop U6a, allowing
program video to pass through the keyer. Jumper J3 selects the background
signal for the keyer. Installing the jumper in the 'B' position selects the keyer
control signal from U6a as the background. Installing the jumper in the 'NB'
position selects the character dots themselves. Leaving the jumper off selects
the auto mode, where the MCU controls the background, however this mode is
not supported when the VCG sub-module is used with the 6220 base module,
and hence the jumper should be installed in one of the two positions.
Horizontal size of the characters is adjusted by the HOR SIZE trimpot (VR1).
The starting position of the characters at the left of the screen is preset but may
be altered by varying the value of R2.
The VCG keyer control signal from U22a and U22b switch U23a on and U23d
off for program video, and vice versa for characters. When U23d is on,
character dots are added to the black level of the video.
To calibrate the VCG keyer, connect colour bars from your sync generator to
the Video input loop, of the 622, and to channel A of your oscilloscope, and
terminate it. Connect the VCG output to channel B of your scope and
terminate it. Adjust the GAIN trimpot (VR 2) so that the output amplitude
matches the input. Adjust the LEVEL trimpot (VR 3) so that the inserted
characters are slightly above peak white luminance level. The frequency
response is adjusted using trimmer VC 1 so that the chrominance amplitude of
the inputs and outputs is the same.
MODEL 622 1-9

EV-BLOC
This page left intentionally blank
MODEL 622 1-10

EV-BLOC
2. 4600T INSTALLATION
2.1. REAR PANEL
The following connectors are provided on the rear panel for
connection into your system. Each slot has the same
configuration for its respective module.
Timecode Connectors
LTC OUT:A ¼"stereo phone jack for output of SMPTE/EBU longitudinal
time code from generator.
LTC IN: A ¼" stereo phone jack for input of SMPTE/EBU longitudinal
time code.
Video Connections
VIDEO IN: A BNC loop for input of program video with vertical interval time
code. This input is also used to insert characters onto.
OUT: A BNC output of program video with characters inserted.
Serial/Parallel I/O
SER_PAR I/O A 9 pin female "D"connector for either parallel or serial
remote control depending on the module inside the 4600T.
Power Connections
LINE: The unit may be set for either 115v/60 Hz or 230v/50 Hz AC
operation. The voltage selector switch is accessible on the top panel. The
line voltage connector contains an integral slow blow fuse (and a spare
one).
2.2. INSIDE THE 4600T:REMOVING THE FRONT PANEL
During the installation procedure it may be necessary to remove the front
panel to gain access to the programming switches located inside the unit.
This can be accomplished in a few seconds by turning the quick release
fasteners, located at the left and right hand sides of the front panel, several
turns counter clockwise. The front panel assembly pulls off showing the
three circuit modules that comprise the unit.
4600T INSTALLATION 2-1

EV-BLOC
4600T INSTALLATION 2-2
The module in the center is the LTC/VITC reader/character inserter for time
code, and the one on the right is the LTC/VITC reader/character inserter for
Keykode.
To replace the front panel assembly, slide it into place, and turn the quick
release fasteners clockwise until they are firmly secured.
2.3. MOUNTING
The 4600T rackframe is equipped with rack mounting angles and fits into a
standard 19 inch by 1 3/4 inch (483mm x 45mm) rack space. The
mounting angles may be removed if rack mounting is not desired.
2.3.1. Selecting the Correct Mains Voltage
Power requirements are 115 or 230 volts AC at 50 or 60 Hz, switch
selectable on the top cover. Before connecting the line power, be sure to
select the proper line voltage. Also, check that the line fuse is rated for the
correct value marked on the rear panel.
Never replace with a fuse of greater value.
"
