Filtration System
Installation & Cleaning Manual
For PURE POND 5,000 Filter
& PURE POND 10,000 Filter
USA
MANUAL
WARNING:
Ensure that the unit is switched off at the mains
before you attempt to conduct any type
of maintenance on the Pure Pond Filter.

SAFETY RULES
- Make sure the voltage on the product’s label matches mains voltage.
- The product must be plugged into an earthed socket.
- It is essential the product be protected upstream by a residual current circuit breaker (mains trip switch) with a
tripping current < 30 mA.
- Before connecting the unit to the mains, make sure the cables are not damaged in any way.
- Cables and plugs cannot be replaced or repaired. If either is damaged, the whole unit must be replaced.
- WARNING disconnect the unit from the mains before carrying out any kind of maintenance in or out of the water. If
the plugs or power socket are wet, switch off power with the master switch before unplugging the power cords.
- To stop accidental dripping from wetting the plug or power socket, use the cable to create a drip loop below the level
of the plug.
- When installing and maintaining the unit, do not lift it by the power cord.
- Keep out of reach of children.
- Do not operate the product with corrosive or abrasive liquids.
- Protect from freezing conditions. Remove the pump from the water if there is any danger of the water freezing.
- The product should not be used in water hotter than 35°C.
- The PURE POND filter has been designed for use outdoors, but must never be immersed in water.
- DANGER: avoid direct contact with UV-C light, which is dangerous for eyes and skin.
- To prevent the lamp overheating, switch it off when no water is running.
- WARNING: You may need to switch off the UV-C temporarily when treating the water with some fish
care products.
TECHNICAL SPECIFICATION
TECHNICAL DATA PURE POND 5,000
UV ONLY - NO PUMP
PURE POND 5,000
UV AND PUMP
PURE POND 10,000
UV ONLY - NO PUMP
PURE POND 10,000
UV AND PUMP
Mains voltage / frequency 230-240 V / 50 Hz 230-240 V / 50 Hz 230-240 V / 50 Hz 230-240 V / 50 Hz
Pump absorbed power -- 55 W (UL E177567) -- 75 W (UL E177567)
UV-C lamp absorbed power 11 W 11 W (UL E140004) 18 W (UL E140004) 18 W (UL E140004)
UV-C IP Rating IP54 IP54 IP54 IP54
UV-C lamp life hours 5,000 hours 5,000 hours 5,000 hours 5,000 hours
Maximum flow rate -- 634 US Gallons / hr -- 1057 US Gallons / hr
Maximum head (feet) -- 6.56 feet -- 8.53 feet
Power cable pump -- 24.5” (UL SJTW) -- 24.5” (UL SJTW)
Weight 7.3 kg 9.25 kg 11.8 kg 14.3 kg
Maximum dimensions of solid particles 4 mm (0.16”) 4 mm (0.16”) 4 mm (0.16”) 4 mm (0.16”)
Maximum temp. of the pumped fluid 35°C 35°C 35°C 35°C
For ponds up to (US Gallons) 2,642 US Gallons 2,642 US Gallons 1320 US Gallons 37,854 US Gallons
For ponds up to (Litres) 5,000 Litres 5,000 Litres 10,000 Litres 10,000 Litres
Ballast cable 17” (UL SJTW) 17” (UL SJTW) 17” (UL SJTW) 17” (UL SJTW)
Ballast -- -- C UV-118 C UV-118
Filter dimension (inches) 17.7” x 11” x
H 11.8”
17.7” x 11” x
H 11.8”
22.8” x 14.6” x
H 17.3”
22.8” x 14.6” x
H 17.3”
Hose connection Inlet 25 mm / 1” 25 mm / 1” 25 mm / 1” 25 mm / 1”
Hose connection Outlet 32 mm / 1¼” 32 mm / 1¼” 50 mm / 2” 50 mm / 2”
Hose connection Waste 25 mm / 1” 25 mm / 1” 25 mm / 1” 25 mm / 1”
Recommended minimum amount
of PURE POND 500ml 500ml 1000ml 1000ml
Filtration System
PUREPond
Filtration System
2 3USA MANUAL

Filtration System
PUREPond
Filtration System
WARRANTY
This product is guaranteed against defects in material and workmanship for 2 years from the date of purchase, under
normal usage. The guarantee DOES NOT APPLY in case of improper use, negligence, lack of maintenance or accidental
damage to the Pure Pond Filter. If the Pure Pond Filter fails due to a manufacturing fault within this period it will be
either repaired or replaced free of charge. Liability is limited to replacement of the faulty product only; no other costs
will be reimbursed. This guarantee is not transferable and does not affect your statutory rights. This guarantee does not
confer any rights other than those expressly set out above. This guarantee does not cover any parts that may wear,
such as UV Bulbs and quartz sleeves, Pump Rotors.
The manufacturer or supplier shall not be responsible, or held liable for any damages caused by defective components
or materials of this product; or for loss incurred by interruption of service; or any consequential/incidental damages and
expenses arising from the production, sale use or misuse of this product.
Evolution Aqua and its dealers shall not be held liable for any loss of fish, plants or any other livestock as a result of any
failure or defect of this product.
DISPOSAL OF YOUR OLD PRODUCT
Your product is designed and manufactured with high quality material and components,
which can be recycled and reused. When this crossed-out wheeled bin symbol is
attached to a product, it means the product is covered by the European Directive
2002/96/EC. Please contact your local authority about correct disposal for electrical
and electronic equipment. Our WEE Registration Number is WEE/FE1471RR.
Please act according to your local rules and do not dispose of your old products with
your normal household waste. The correct disposal of your old product will help prevent
potential negative consequences for the environment and human health.
HOSE CONNECTIONS
This unit is not supplied with hoses.
PURE POND 5,000 MODEL:
- You will need 25mm / 1” size hose for connecting the pump to the filter.
- You will need 32mm / 1¼” size hose for returning the water to the pond.
- You will need 25mm / 1” size hose to take the waste away during cleaning.
PURE POND 10,000 MODEL:
- You will need 25mm / 1” size hose for connecting the pump to the filter.
- You will need 50mm / 2” size hose for returning the water to the pond.
- You will need 25mm / 1” size hose to take the waste away during cleaning.
We recommend securing hoses with stainless steel hose clips.
2 3USA MANUAL

PURE POND FILTRATION SYSTEM
Evolution Aqua’s PURE POND Filtration System is a complete, compact filter system developed specifically to clean
garden ponds. As pond water is pumped through the filtration system, it passes through four successive filtration stages:
1. UV-C filter, (11 Watt on the PURE POND 5,000 model and 18 Watt on the PURE POND 10,000 model).
This stage will clear green water, which is caused by single cell algae, and prevent it from returning.
2. Mechanical stage, where pond water passes through Kaldnes K1 Media, removing solid waste from the water.
See information on page 13.
3. Aeration stage, where pond water passes through a trickle filter screen, which replenishes the water’s oxygen levels
and encourages gaseous exchange with the atmosphere.
4. Biological stage, where pond water interacts with the award winning, PURE POND bio balls (not included)
promoting beneficial bacteria colonies. This will help the filter keep the pond water healthy and safe for your fish.
Included inside the compact unit is a UV-C filter, a basket of Kaldnes K1 Filter Media and a basket to hold Evolution
Aqua’s award winning PURE POND bio balls (not included). This winning combination ensures that your water is as
clear and healthy as can be, meaning your fish are in the perfect environment.
The PURE POND Filtration System works with an Evolution Aqua pump (supplied with some models). There is a
2,400 litre per hour pump (634 US Gallons per hour) supplied with some PURE POND 5000 models and a
4,000 litre an hour pump (1057 US Gallons per hour) supplied with some PURE POND 10,000 models, all suitable
for continuous duty. See information on Pure Pond on page 12.
The PURE POND Filtration System is easy to maintain and compact enough to fit at the side of any garden pond.
NEW PONDS
In a new pond set up, you should dechlorinate the water as you fill the pond. Your dealer should advise as to the best
way to do this. Once you have set your filter going, we would recommend you introduce 1 or 2 small fish straight away.
This will give the Pure Pond bacteria some waste to work on, and so start the ammonia and nitrite reduction process
which is critical for the health and wellbeing of your fish.
You can slowly increase the amount of fish in your pond as the filter matures over the next few weeks, whilst checking
the ammonia / nitrite levels (using a test kit available from your aquatics dealer).
EXISTING PONDS
When replacing an existing filter, we would recommend that you test your water weekly, for ammonia and nitrite,
and add more Pure Pond if these levels rise. You should consult your dealer for more details.
Filtration System
PUREPond
Filtration System
4 5USA MANUAL

Filtration System
PUREPond
Filtration System
Trickle Filter
Screen
Assembly Parts & Fittings
Blue Pure Pond Basket
To hold Pure Pond Balls
K1 Media Cartridge
UV-C
11 Watt UV-C with 5,000 Model
18 Watt UV-C with 10,000 Model
Please take time to familiarise yourself with the fittings below:
Inside your Pure Pond Filter box you will find:
4 5
Inlet / Waste Valve x 2
For 25mm / 1” hose
Adaptor
To Connect Inlet Valve
to UV-C
Large O-Ring x 1
To fit between adaptor
and inlet valve
Pump Hosetail
For 25mm / 1” hose
Outlet Nut
1½” - 10,000
32mm / 1¼” - 5,000
Outlet Hosetail
50mm / 2” - 10,000
32mm / 1¼” - 5,000
Large Rubber Gasket
To fit the Outlet
assembly
Securing Nut
For inlet and waste
valves
Securing Nut
For UV-C
Small O-Ring x 5
In both models.
To ensure water tight
connections.
Securing Pipes
5,000 Model = Qty. 2
10,000 Model = Qty. 4
Items not required
634 US Gallons / hr with 5,000 Model
1057 US Gallons / hr with the 10,000 Model
NOT SUPPLIED
WITH ALL MODELS
Pump
USA MANUAL

Filtration System
PUREPond
Filtration System
UV-C lamp
UV Housing
O-Ring
Inlet Valve
Threaded
Collar
Inlet
Valve
Adaptor
Ballast
Inspection
Glass
O-Ring
O-Ring
Quartz
Sleeve
Lamp Holder
Ring connector 1½”
Outlet Pipe 1½”
(Return to Pond)
O-Ring
only external side
Inlet Valve
connected to
pump
Inlet Valve
connected to
pump
UV Inspection
Glass
Outlet Pipe
(Return to Pond)
Drainage / Waste
Valve
Drainage / Waste
Valve
O-Ring
UV Power
Cable
O-Ring
only external side
Drainage / Waste
Valve Connector 1”
Wet and Dry Screen
“Pure Pond Tray”
K1 Media Basket
Pure Pond
Basket
Bac
Case
Raccord
3/4” x 25
Hose connector
3 m / ø 25 mm
1 m / ø 50 mm
Pompe
Pump
Matérial de filtration biologique
Biologic filtering materia l
Mousse Noire
Black sponge
Mousse bleue
Blue sponge
Grille Wet & dry
Wet & dry screen
Grille
Grid
Tuyau
Pipes
Couvercle
Lid
Outlet back
to pond
Pump in pond
Drainage / Waste
Valve
UV Inspection
Glass
UV Power
Cable
Inlet Valve
connected to
pump
Outlet Pipe
(Return to Pond)
Drainage / Waste
Valve
O-Ring
only external
side
UV Power
Cable
PURE POND FILTRATION SYSTEM - UV-C ASSEMBLY
UV-C FITTING
Underside view of Pure Pond 5,000 Underside view of Pure Pond 10,000
6 7
UV-C lamp
UV Housing
O-Ring
Inlet Valve
Threaded
Collar
Inlet
Valve
Adaptor
Ballast
Inspection
Glass
O-Ring
O-Ring
Quartz
Sleeve
Lamp Holder
Ring connector 1½”
Outlet Pipe 1½”
(Return to Pond)
O-Ring
only external side
Inlet Valve
connected to
pump
Inlet Valve
connected to
pump
UV Inspection
Glass
Outlet Pipe
(Return to Pond)
Drainage / Waste
Valve
Drainage / Waste
Valve
O-Ring
UV Power
Cable
O-Ring
only external side
Drainage / Waste
Valve Connector 1”
Wet and Dry Screen
“Pure Pond Tray”
K1 Media Basket
Pure Pond
Basket
Bac
Case
Raccord
3/4” x 25
Hose connector
3 m / ø 25 mm
1 m / ø 50 mm
Pompe
Pump
Matérial de filtration biologique
Biologic filtering materia l
Mousse Noire
Black sponge
Mousse bleue
Blue sponge
Grille Wet & dry
Wet & dry screen
Grille
Grid
Tuyau
Pipes
Couvercle
Lid
Outlet back
to pond
Pump in pond
Drainage / Waste
Valve
UV Inspection
Glass
UV Power
Cable
USA MANUAL

Filtration System
PUREPond
Filtration System
Wet and Dry Screen
“Pure Pond Tray”
UV Inspection
Glass
Inlet Valve
connected to
pump
Outlet Pipe 1¼”
(Return to Pond)
Ring Connector
On Inside
Drainage / Waste
Valve Connector 1”
Drainage / Waste
Valve
O-Ring
K1 Media Basket
PURE POND 5,000 ASSEMBLY
PURE POND 10,000 ASSEMBLY
Pump
in pond
Outlet back
to pond
Inlet Valve
UV Inspection
Glass
UV Power
Cable
Drainage / Waste
Valve
6 7
UV-C lamp
UV Housing
O-Ring
Inlet Valve
Threaded
Collar
Inlet
Valve
Adaptor
Ballast
Inspection
Glass
O-Ring
O-Ring
Quartz
Sleeve
Lamp Holder
Ring connector 1½”
Outlet Pipe 1½”
(Return to Pond)
O-Ring
only external side
Inlet Valve
connected to
pump
Inlet Valve
connected to
pump
UV Inspection
Glass
Outlet Pipe
(Return to Pond)
Drainage / Waste
Valve
Drainage / Waste
Valve
O-Ring
UV Power
Cable
O-Ring
only external side
Drainage / Waste
Valve Connector 1”
Wet and Dry Screen
“Pure Pond Tray”
K1 Media Basket
Pure Pond
Basket
Bac
Case
Raccord
3/4” x 25
Hose connector
3 m / ø 25 mm
1 m / ø 50 mm
Pompe
Pump
Matérial de filtration biologique
Biologic filtering materia l
Mousse Noire
Black sponge
Mousse bleue
Blue sponge
Grille Wet & dry
Wet & dry screen
Grille
Grid
Tuyau
Pipes
Couvercle
Lid
Outlet back
to pond
Pump in pond
Drainage / Waste
Valve
UV Inspection
Glass
UV Power
Cable
UV-C lamp
UV Housing
O-Ring
Inlet Valve
Threaded
Collar
Inlet
Valve
Adaptor
Ballast
Inspection
Glass
O-Ring
O-Ring
Quartz
Sleeve
Lamp Holder
Ring connector 1½”
Outlet Pipe 1½”
(Return to Pond)
O-Ring
only external side
Inlet Valve
connected to
pump
Inlet Valve
connected to
pump
UV Inspection
Glass
Outlet Pipe
(Return to Pond)
Drainage / Waste
Valve
Drainage / Waste
Valve
O-Ring
UV Power
Cable
O-Ring
only external side
Drainage / Waste
Valve Connector 1”
Wet and Dry Screen
“Pure Pond Tray”
K1 Media Basket
Pure Pond
Basket
Bac
Case
Raccord
3/4” x 25
Hose connector
3 m / ø 25 mm
1 m / ø 50 mm
Pompe
Pump
Matérial de filtration biologique
Biologic filtering materia l
Mousse Noire
Black sponge
Mousse bleue
Blue sponge
Grille Wet & dry
Wet & dry screen
Grille
Grid
Tuyau
Pipes
Couvercle
Lid
Outlet back
to pond
Pump in pond
Drainage / Waste
Valve
UV Inspection
Glass
UV Power
Cable
UV-C lamp
UV Housing
O-Ring
Inlet Valve
Threaded
Collar
Inlet
Valve
Adaptor
Ballast
Inspection
Glass
O-Ring
O-Ring
Quartz
Sleeve
Lamp Holder
Ring connector 1½”
Outlet Pipe 1½”
(Return to Pond)
O-Ring
only external side
Inlet Valve
connected to
pump
Inlet Valve
connected to
pump
UV Inspection
Glass
Outlet Pipe
(Return to Pond)
Drainage / Waste
Valve
Drainage / Waste
Valve
O-Ring
UV Power
Cable
O-Ring
only external side
Drainage / Waste
Valve Connector 1”
Wet and Dry Screen
“Pure Pond Tray”
K1 Media Basket
Pure Pond
Basket
Bac
Case
Raccord
3/4” x 25
Hose connector
3 m / ø 25 mm
1 m / ø 50 mm
Pompe
Pump
Matérial de filtration biologique
Biologic filtering materia l
Mousse Noire
Black sponge
Mousse bleue
Blue sponge
Grille Wet & dry
Wet & dry screen
Grille
Grid
Tuyau
Pipes
Couvercle
Lid
Outlet back
to pond
Pump in pond
Drainage / Waste
Valve
UV Inspection
Glass
UV Power
Cable
Trickle Filter
Screen
Trickle Filter
Screen
USA MANUAL

1. Assemble the UV-C as shown.
Hand tighten only.
4. Whilst holding the UV-C in place,
carefully turn the filter box upright
and screw the nut onto the UV-C
inside the filter to secure the UV-C.
7. Drop the K1 Media Cartridge into
the larger chamber.
2. Turn the entire filter unit
upside down.
5. Screw the outlet valve into
position with the O-Ring on the
outside. You should connect pipe
here to return water to the pond.
8. Now place the Pure Pond basket
into the smaller chamber.
3. Insert the UV-C into position.
O-Ring should be on the outside.
6. Do exactly the same with the
waste valve, and connect the hose.
9. Fill the Pure Pond Basket with
Pure Pond bio balls. Add the Pure
Pond after you have successfully
commissioned the filter. PLEASE
NOTE: You cannot overdose with
Pure Pond balls.
Filtration System
PUREPond
Filtration System
INSTALLATION GUIDE - Please refer to diagrams on pages 6 and 7
8 9
10,000 MODEL5,000 MODEL
- The filter must always be positioned above the pond’s water level.
- Place the filter horizontally on a flat, level surface (to prevent water overflowing).
- Return water must have an appropriate fall to the pond.
- If there is any overflowing, make sure that the trickle filter screen and the smaller chamber are clean.
USA MANUAL

13. Place the pump in your pond and connect the cable to the electricity supply.
14. Connect the UV cable to the electricity supply. PLEASE NOTE: We advise that you consult a qualified
electrician before connecting to any electrical connection.
DO NOT SWITCH PUMP OR UV ON YET
STARTING UP YOUR FILTER
15. Close the waste valve and open the inlet valve.
16. Now switch on the pump - the filter will start to fill.
17. After a few minutes the water will overflow from the large chamber into the Pure Pond Basket
and will return into your pond.
18. At this stage, ensure there are no leaks anywhere in the filter.
19. Now switch on the UV-C. The inspection cover should glow which indicates the UV-C is working.
YOUR FILTER IS NOW WORKING
10. Fit the tray over the top of the Pure
Pond basket with the cut out corners
facing away from main chambers.
11. Fit the securing pipes onto the
inside of the filter unit’s lid, so that
they are over the K1 Media Cartridge.
Now close the lid.
12. Screw the hosetail into the top
of the pump, and connect the hose
between here and the inlet on
the filter.
Filtration System
PUREPond
Filtration System
8 9USA MANUAL

Filtration System
PUREPond
Filtration System
MAINTENANCE
Cleaning the pump:
- Always disconnect the power supply before performing any maintenance work
- Make sure the pump’s protective housing is not entirely clogged by leaves or other debris. If it is, clean the housing.
- Remove the pump from the protective housing; turn the impeller cover anticlockwise; remove the rotor, being careful
not to lose the shock absorbers or O-ring; rinse under running water and check for wear - turn the rotor while holding
the shaft still and make sure rotation is smooth. Fit everything back together in the reverse order, being extra careful to
position the components correctly.
Cleaning the UV-C:
Always disconnect the power supply before performing any maintenance work.
If you notice an increase in algae formation and/or see that limescale is increasing, you will need to check that the
UV-C unit is working properly. To assure peak efficiency, the UV-C lamp must be replaced ever 5000 hours of operation.
Unscrew the cover of the case with the lamp inside and replace the lamp where necessary.
Carefully remove the protective quartz container. To do this, use a wide screwdriver, a coin or similar object, insert the
tool in one of the notches that you can see at the end of the case’s threading and lever up the case gently.
Clean the case and protective quartz container carefully using water and a soft rag. Remove any limescale from the
quartz tube with descaling solutions. Check the quartz tube for damage.
Reassemble in the reverse order, making sure you position the O-rings correctly.
Where necessary, grease O-rings with Vaseline.
Replacing the UV-C lamp:
Always disconnect the power supply before performing any maintenance work.
- Close the inlet valve
- Switch off the pump
- Open the waste valve and drain the filter
- Remove the K1 Media Cartridge
- Unscrew the nut holding in the UV-C
- Remove the UV-C from the filter box
- Unscrew the lamp holder on the UV-C
- Carefully pull the bulb out from its sleeve
- Remove the spacer from the end of the bulb
- Fit the spacer onto the new bulb
- Replace the bulb into the holder, ensuring all O-Rings are still in place
- Reverse the procedure for re-installation of the UV.
Should you notice the quality of the water deteriorating, a considerable reduction in water flow or the filter is
over flowing, your filter will need cleaning. We would suggest that to stop this happening you clean your filter on
a regular basis.
Cleaning your Pure Pond filter is a very simple procedure and carried out in five steps, which are outlined on the box.
A more detailed procedure is shown on page 11. We would recommend that a weekly clean would be best practice.
10 11USA MANUAL

Filtration System
PUREPond
Filtration System
7. Remove and rinse the tray above the
PURE POND Basket.
8. Check the PURE POND basket.
Rinse with pond water atleast once a
month. Replenish with PURE POND balls
when needed for maximum clarity and
health.
9. Once happy that the PURE POND
Basket is clean and the balls have been
replenished you can relocate the
trickle filter screen.
10. Close the waste valve. 11. Open the inlet valve. Now switch
the UV-C and water pump back on.
12. Once happy that the unit is clean,
and water is flowing back to the pond,
close the lid of the filter unit.
1. Open the lid of the PURE POND
Filtration System.
2. Close the inlet valve at the front of
the filter unit. You can now turn off the
power to the UV-C and the water pump.
3. Open the waste valve to lower the
water level in the large chamber by about
an inch. Then close the waste valve.
4. Hold the handles of K1 Media
Cartridge and lift the cartridge up and
down in the water to clean the filter
media.
5. Preferably remove the K1 Media
Cartridge completely out of the filter unit.
Then drain all the water to waste by
opening the waste valve.
6. With the waste valve still open,
put the K1 Media Cartridge back in the
chamber and then rinse with pond water
or dechlorinated tap water until the waste
water runs clear.
Follow these instructions to clean the PURE POND Filtration System
CLEANING GUIDE
10 11USA MANUAL

Filtration System
PUREPond
Filtration System
This innovative filter uses the revolutionary PURE POND*
bio-balls. Every PURE POND ball contains millions of live
bacteria and enzymes, which will break down organic waste in
your pond, leaving the water crystal clear. Other bacteria in the
PURE POND Ball will start to work breaking down the Ammonia
and Nitrite which is naturally produced when keeping fish, so
smoothing out the peaks and troughs in the ammonia / nitrite
cycle. The results are clearly seen, as your pond is left with
crystal clear and healthy water that sparkles.
• Millions of live bacteria in every ball
• PURE POND is biodegradable
• Available in 250ml,500ml, 1Litre, and 2Litre containers.
AWARD WINNING PRODUCT
PURE POND was launched by Evolution Aqua in spring 2010
and became an instant hit in the water gardening world. Its
success for delivering crystal clear and healthy water was
recognised at the Aqua 2010 Show as PURE POND won the
inaugural award for “Best Water Gardening Product of the Year”.
BUY FROM ALL EVOLUTION AQUA STOCKISTS.
*PURE POND contains live bacteria therefore must be purchased separately
For crystal clear water that sparkles
PURE Pond 1 Litre
For ponds up to 20,000 litres
(5,284 US Gallons)
PURE Pond 500ml
For ponds up to 10,000 litres
(2,642 US Gallons)
PURE Pond 2 Litre
For ponds up to 40,000 litres
(10,567 US Gallons)
12 13USA MANUAL

Filtration System
PUREPond
Filtration System
K1Media
Kaldnes K1 Filter Media has been scientifically tried and tested
in fish farming and waste water treatment for over 10 years, and
is extensively used by fish keepers worldwide to ensure that their
ponds are kept clean and healthy. K1 Media is exclusively distributed
worldwide to fishkeepers and aquaculturists by Evolution Aqua.
The K1 Media is engineered in a wheel shape and is slightly buoyant.
This near neutral buoyancy allows the media to circulate throughout
the vessel with only a minimal water flow. As the water passes
through your Pure Pond filtration system, the debris from your pond
which is the cause of poor clarity is held by the K1 Media. Regular
cleaning will help to maintain a crystal clear, healthy pond.
AVAILABLE FROM EVOLUTION AQUA STOCKISTS
IN 1 LITRE, 3 LITRE, 25 LITRE AND 50 LITRE.
K1 Media
12 13USA MANUAL

Filtration System
PUREPond
Filtration System
are the award winning pond filtration manufacturer
who put innovation, research and development at the top of their agenda.
With a proven track record for delivering the latest technology to the aquatics
and fish farming markets - we are the first choice for everyone from the general
hobbyist to the serious fishkeeper. Find out more about the evoUV and all of our
other innovative products at www.evolutionaqua.com. The difference is clear.
Evolution Aqua Ltd
Evolution House
Kellet Close
Wigan
Lancashire
United Kingdom
WN5 0LP
t: [phone]
f: [phone]
e: [email protected]
w: www.evolutionaqua.com USA MANUAL
