exemys MCV1-FO-ETH User manual

MCV1-FO-ETH User’s Manual
www.exemys.com Rev. 2 – March 2015 2
The Exemys products are in permanent evolution to satisfy the needs of our clients. For this
reason, the specifications and capabilities are subject to change without previous notice.
Please find updated information at www.exemys.com
Copyright © Exemys, 2009. All Rights Reserved.
Rev. 2 – March 2015

MCV1-FO-ETH User’s Manual
www.exemys.com Rev. 2 – March 2015 3
Contents
1Introduction 4
1.1 Purpose of this manual 4
1.2 General Description of the Product 4
2 Wiring 5
1.3 General Wiring 5
3Configuration 6
4Technical Specifications 7
5Ordering codes 7

MCV1-FO-ETH User’s Manual
www.exemys.com Rev. 2 – March 2015 4
1 Introduction
1.1 Purpose of this manual
The purpose of this manual is to provide the instructions to quickly and simple install and operate the Ethernet to Optic
Fiber Converters, MCV1-FO-ETH family
The manual begins with a general description of the product followed by the instructions for the correct hardware
installation. Its configuration and operation are described later in detail.
1.2 General Description of the Product
The MCV1-FO-ETH are multi mode and single mode Ethernet to Optic Fiber Converter that allows the extension of
communications up to 2 Km (10 Km in single mode) without electric noise interference.
The main features of the device are:
•Power Input: +10 a +30 Vdc / 200mA max
•Industrial DIN rail mountable case
•Multi mode or single mode fiber support
•ST or SC connectors (model depending)
•100 Base FX / 100 Base LX10 Optic Fiber Port (multi mode / single mode)
•10/100 Base TX Ethernet Port with auto negotiation

MCV1-FO-ETH User’s Manual
www.exemys.com Rev. 2 – March 2015 5
2 Wiring
1.3 General Wiring
MCV1 -FO-ETH wiring is very simple and intuitive. There are three different connectors.
-Ethernet port connector in RJ45 connector
-Optic fiber port connector in ST or SC connector according to device model.
-Power supply terminal block (+10 to +30 Vdc)
First connect your power supply to device, then the Ethernet port and lastly the two Optic Fiber connectors (TX
Transmitter and RX Receiver)

MCV1-FO-ETH User’s Manual
www.exemys.com Rev. 2 – March 2015 6
3 Configuration
The configuration of the converter is very simple and is made by means of jumper switches located in the top side of the
device as shown in the following figure.
There are two configuration jumper switches, both to configure the converter’s operation, from the optic fiber side:
Flow Control: This can be activated or deactivated.
Communications mode: Full duplex or Half-Duplex
LEDS
A– Activity Ethernet
B– Ethernet Link
C– Fiber Activity
D– Fiber Link

MCV1-FO-ETH User’s Manual
www.exemys.com Rev. 2 – March 2015 7
4 Technical Specifications
5 Ordering codes
