EXFO XTM-50 Series User manual

www.EXFO.com
XTM-50
Optical Tunable Filter
User Guide
XTM-50_UM_2.0v1.1

XTM-50 User Guide 3
About This Manual
Subject This document explains how to operate the XTM-50 optical tunable filter. It also explains
how to perform basic maintenance operations.
Intended Readers Users of this manual must be familiar with fiber optic technology.
Date 28 June 2018
Manual Reference XTM-50_UM_2.0v1.1
Typographical
Conventions
Symbols
Abbreviations
Used
Copyright Copyright © 2013–2018 by EXFO. Published by EXFO. All rights reserved.
This documentation is provided as a user guide to EXFO customers and potential
customers only. The contents of this document may not be reproduced in any part or as
a whole, transcribed, stored in a retrieval system, translated into any language, or
transmitted in any form or by any means (electronic, mechanical, magnetic, optical,
chemical, photocopying, manual, or otherwise) without the prior written permission of
EXFO.
bold Identifies graphical interface objects such as menu names, labels,
buttons and icons.
italic Identifies references to other sections or other guides.
monospace Identifies portions of program codes, command lines, or messages
displayed in command windows.
IMPORTANT Identifies important information to which you must pay particular
attention.
Warning
Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury. Do not proceed unless you understand and meet the
required conditions.
Caution
Indicates a potentially hazardous situation which, if not avoided, may result in
component damage. Do not proceed unless you understand and meet the
required conditions.
Abbreviation Meaning
FWHM Full Width Half Maximum

About This Manual
4XTM-50 User Guide
Product Warranty
and Limitation of
Warranty
For detailed information about the sales terms and conditions, visit the EXFO web site at
www.exfo.com/how-to-buy/sales-terms-conditions
Contact
Information
To obtain after-sales service or technical support for this product, contact EXFO at one of
the following numbers.
For detailed information about technical support and for a list of other worldwide
locations, visit the EXFO web site at
www.EXFO.com/support
To accelerate the process, please have information such as the name and the serial
number (see the product identification label), as well as a description of your problem,
close at hand.
Technical Support Group
400 Godin Avenue
Quebec (Quebec) G1M 2K2
CANADA
Tel. USA and Canada: 1 866 683-0155
Fax: [phone]
E-mail: [e-mail]

XTM-50 User Guide 5
Table of Contents
About This Manual..................................................................................................................................... 3
Table of Contents ...................................................................................................................................... 5
1. Product Presentation .......................................................................................................................... 7
1.1 Technical Specifications ....................................................................................................................... 7
1.2 Product Overview................................................................................................................................... 8
2. Installing and Connecting the XTM-50............................................................................................... 11
2.1 Unpacking and Installing the XTM-50................................................................................................. 11
2.2 Connecting an Optical Source to the XTM-50.................................................................................... 12
3. Setting the Wavelength/Frequency and FWHM Values....................................................................... 13
3.1 Adjusting the Central Wavelength....................................................................................................... 13
3.2 Adjusting the FWHM............................................................................................................................ 15
3.3 Reaching a Position on the Bandwidth or Wavelength Tuning Actuator ......................................... 17
4. Performing Basic Maintenance Operations........................................................................................ 19
4.1 Cleaning Optical Connectors............................................................................................................... 19
4.2 Cleaning the Cover of the XTM-50...................................................................................................... 20
4.3 Packaging for Shipment ...................................................................................................................... 21
List of Figures .......................................................................................................................................... 23

Table of Contents
6XTM-50 User Guide

XTM-50 User Guide 7
1. Product Presentation
The XTM-50 is a reliable optical tunable filter that features wavelength and bandwidth
tuning. The large wavelength range, the narrow FWHM and the flat-top shape ensure a
clean extraction of the optical signal. It is designed for closely-spaced channel selection
and extraction in DWDM applications.
The XTM-50 is based on the use of a reflection diffraction grating mounted in a Littman-
Metcalf configuration.
When an optical signal is detected at the XTM-50 input port, the input wave is directed
towards the output port after passing through the XTM-50 monochromator.
1.1 Technical Specifications
The following table lists the technical specifications of all the XTM-50 models.
Standard Ultrafine O-band*1 Wide
Optical Characteristics
Wavelength range 1450–1650 nm 1480–1620 nm 1260–1360 nm 1525–1610 nm
Wavelength resolution 5 pm*2 5 pm*2 5 pm*2 5 pm*2
Minimum bandwidth
(FWHM) 50 pm (6.25 GHz) 32 pm (4 GHz) 50 pm (8 GHz) 50 pm (6.25 GHz)
Maximum bandwidth
(FWHM) 950 pm (120 GHz) 650 pm (80 GHz) 900 pm (160 GHz) 5000 pm (625 GHz)
Bandwidth resolution 1 pm 1 pm 1 pm 0.3 % of FWHM typ.
Filter edge gradient 500 dB/nm
typical*3 800 dB/nm typical 500 dB/nm
typical*3
500 dB/nm
typical*4
Insertion loss 5 dB (4.5 dB
typical)*5*6
5 dB (4.0 dB
typical)*6*7
5 dB (4.5 dB
typical)*6*8
5 dB (4.5 dB
typical)*9*10
Flatness 0.2 dB*11 0.2 dB*12 0.3 dB*11*13 0.2 dB*14
Polarization dependent
loss ±0.2 dB*5 ±0.2 dB*7 ±0.2 dB*8 ±0.2 dB*9
Out-of-band suppression
(crosstalk)
40 dB (60 dB
typical)*15
40 dB (50 dB
typical)*15
40 dB (60 dB
typical)*15
40 dB (45 dB
typical)*15
Interface
Optical fiber type SMF or PMF SMF
Connector type FC/PC or FC/APC
Operating Conditions
Maximum optical input
Power 30 dBm 27 dBm
Temperature range 15° to 35°C, indoor use only
Storage Temperature -20°C to 60°C
Maximum Relative
Humidity
80 % for temperatures up to 31°C decreasing
linearly to 50 % relative humidity at 40°C
Altitude 2000 m (maximum operating)

Product Presentation
8XTM-50 User Guide
1.2 Product Overview
Figure 1: Front Panel
Handle
The handle bar enables you to:
•Carry the XTM-50, if positioned in front of the actuators.
•Tilt the XTM-50 for convenient purpose, if positioned below the unit: see section
Unpacking and Installing the XTM-50, p. 11.
The two buttons located at both ends of the handle enable you to rotate it forward or
backward.
Size & Weight
Dimensions (W x D x H) 230 x 173 x 136 mm
Weight 2.2 kg
All optical specifications apply at constant temperature.
*1: Specifications apply for wavelengths not equal to any water absorption line.
*2: Typical, related to user dexterity.
*3: From -3 and -40 dB for FWHM <800 pm.
*4: Between -3 and -40 dB. Typically 550 dB/nm @ FWHM = 50 pm,
450 dB/nm @ FWHM = 1 nm, 225 dB/nm @ FWHM = 5 nm.
*5: From 1500 to 1600 nm & FWHM >100 pm.
*6: At lowest FWHM the insertion loss is 7 dB typical.
*7: From 1500 to 1600 nm & FWHM >60 pm.
*8: From 1280 to 1340 nm & FWHM >100 pm.
*9: For FWHM >100 pm.
*10: At lowest FWHM the insertion loss is < 7.0 dB.
*11: Centered width of FWHM - 150 pm. For 150 pm < FWHM < 650 pm.
*12: Centered width of FWHM - 100 pm. For 100 pm < FWHM < 500 pm.
*13: From 1280 to 1340 nm.
*14: Centered width of FWHM - 150 pm. For 150 pm < FWHM < 2000 pm.
*15: Measured 1 nm away from the -3 dB points.
Optical
Connectors
Connector’s
drawer
Handle
Bandwidth
Actuator
Wavelength Actuator:
Coarse Adjustment
Fine Adjustment
Drawer screw
Handle
Button
Lock

Product Presentation
XTM-50 User Guide 9
Micrometer Actuators
Two high resolution micrometer actuators enable you to perform wavelength and
bandwidth tuning.
The screw located on top of the actuators enable you to lock the actuator at the wanted
setting.
•The bandwidth actuator is composed of two graduated scales:
•On the sleeve: 13 mm stroke with 0.5 mm graduation interval.
•On the thimble (rotary part): 250 μm by turn, with 5 μm graduation interval.
•The wavelength actuator includes coarse and fine position adjustments, with four
graduated scales:
•Coarse adjustment:
•On the sleeve: 13 mm stroke with 0.5 mm graduation interval.
•On the thimble (rotary part): 0.5 mm by turn, with 0.01 mm graduation
interval.
•Fine adjustment:
•On the sleeve: 200 μm stroke with 25 μm graduation interval.
•On the thimble: 25 μm by turn, with 0.5 μm graduation interval.
For more details on how to adjust wavelength and FWHM, see section Setting the
Wavelength/Frequency and FWHM Values, p. 13.
Optical Connectors
The two following optical connectors, protected by a dust cap, are located on the front
panel:
•Input: channel filter input port.
•Output: channel filter output port.
The two optical connectors are mounted on a drawer, which enables you to access the
internal optical connectors for cleaning (see section Cleaning Optical Connectors, p. 19).
Retractable Legs
The retractable legs located underneath the unit enable you to tilt the XTM-50 upward for
convenient purpose, so that it stands on both front legs and the rear feet (see section
Unpacking and Installing the XTM-50, p. 11).
Labels
Label Description
Identification of the Product
Indicates serial number, model, options (if any), CE
marking (see section Certification and Compliance, p. 27)
and date of manufacture.
Warranty Seal
The XTM-50 cover must not be open, otherwise the
warranty is not valid anymore.
MANUFACTURED
OPTIONS
MODEL
SERIAL NUMBER
Made in Franc e
xxxxxxxx xxxx
XTM-50
xxxxxxxxxxxx
xxxxxxxxxxxx
Warranty void
if seal broken.

Product Presentation
10 XTM-50 User Guide

XTM-50 User Guide 11
2. Installing and Connecting the XTM-50
2.1 Unpacking and Installing the XTM-50
Subject The XTM-50 is a bench-top instrument designed for indoor use only, and is not dedicated
to wet locations. It is designed for use either in the horizontal or tilted position.
You can also place the handle in front of the two actuators to carry the unit.
Before Starting
Procedure 1. Open the package with care and remove the protective foam.
2. Pull out the XTM-50 vertically from its packaging.
3. Set the XTM-50 on a flat stable surface free of excessive vibration.
4. Place the XTM-50 in the wanted operating position as illustrated in Figure 2, p. 11.
To tilt the XTM-50 upward, do one of the following:
•Deploy the two retractable legs located underneath it.
•Rotate the handle bar to place it below the unit by pressing simultaneously the
two handle buttons located at both sides of the handle.
Figure 2: Possible Operating Positions
To ensure proper environment conditions:
•Do not expose the XTM-50 to rain or excessive moisture.
•Do not install the XTM-50 near flammable gases or fumes.
IMPORTANT When unpacking, handle the device with care and do not damage the
original shipping container in case the XTM-50 needs to be returned
to EXFO.

Installing and Connecting the XTM-50
12 XTM-50 User Guide
2.2 Connecting an Optical Source to the XTM-50
Subject
Procedure •Remove the protective cap from the IN and OUT connectors and connect the
appropriate jumper corresponding to the connector type mounted on your product,
as indicated next to the connectors (see Figure 1, p. 8).
•Make sure you use the appropriate connector type, corresponding to the
one mounted on your XTM-50 (see section Technical Specifications, p. 7
for available models).
•Make sure optical connectors are perfectly clean. It is essential to
achieve optimum system performance (see section Cleaning Optical
Connectors, p. 19).
•To prevent premature failure of the XTM-50 optical connectors due to
frequent connections, always keep a fiber-optic jumper cable connected
to the XTM-50 optical port while you use the jumper's free end to connect
to other devices.
IMPORTANT Keep protective caps on optical connectors when not in use.

XTM-50 User Guide 13
3. Setting the Wavelength/Frequency and FWHM
Values
3.1 Adjusting the Central Wavelength
Subject The wavelength actuator enables you to adjust the wavelength with coarse and fine
adjustment positions.
•On the coarse adjustment screw, the scale on the thimble is graduated from 0 to 500.
One complete revolution of the thimble reaches one graduated marking on the
sleeve.
•On the sleeve: 13 mm stroke with 0.5 mm graduation interval.
•On the thimble (rotary part): 0.5 mm by turn, with 0.01 mm graduation interval.
•On the fine adjustment screw, the scale on the thimble is graduated from 0 to 30.
One complete revolution of the thimble reaches one graduated marking on the
sleeve.
•On the sleeve: 200 μm stroke with 25 μm graduation interval.
•On the thimble: 25 μm by turn, with 0.5 μm graduation interval.
Figure 3: Wavelength-tuning Actuator – Scale values
IMPORTANT When using thimbles, account for any backlash in the system: always
use the thimble in the same rotating direction.
Coarse adjustment, thimble scale
1 scale graduation corresponds to:
•XTM-50 Standard: 220 pm (typ.)
•XTM-50 Ultrafine: 130 pm (typ.)
•XTM-50 O-band: 240 pm (typ.)
•XTM-50 Wide: 220 pm (typ.)
Coarse adjustment, sleeve scale
1 scale graduation corresponds to:
•XTM-50 Standard: 11 nm (typ.)
•XTM-50 Ultrafine: 6.5 nm (typ.)
•XTM-50 O-band: 12 nm (typ.)
•XTM-50 Wide: 11 nm (typ.)
Fine adjustment, sleeve scale
1 scale graduation corresponds to:
•XTM-50 Standard: 550 pm (typ.)
•XTM-50 Ultrafine: 325 pm (typ.)
•XTM-50 O-band: 600 pm (typ.)
•XTM-50 Wide: 550 pm (typ.)
Fine adjustment, thimble scale
1 scale graduation corresponds to:
•XTM-50 Standard: 11 pm (typ.)
•XTM-50 Ultrafine: 6.5 pm (typ.)
•XTM-50 O-band: 12 pm (typ.)
•XTM-50 Wide: 11 pm (typ.)

Setting the Wavelength/Frequency and FWHM Values
14 XTM-50 User Guide
Procedure 1. Move the Wavelength tuning coarse thimble as follows:
•To increase the central wavelength from lower wavelength to higher
wavelengths, turn the thimble clockwise (from high to low values).
•To decrease the central wavelength from higher wavelength to lower
wavelengths, turn the thimble counterclockwise (from low to high values).
2. To finely adjust the central wavelength value, move the Wavelength tuning fine
thimble as follows:
•To increase the central wavelength from lower wavelength to higher
wavelengths, turn the thimble clockwise (from high to low values).
•To decrease the central wavelength from higher wavelength to lower
wavelengths, turn the thimble counterclockwise (from low to high values).
Figure 4: Central Wavelength Tuning
3. Tighten the lock screw (see Figure 1, p. 8) to lock the central wavelength setting.
4. If you had previously adjusted the FWHM, re-adjust it as it may have been slightly
altered by the central wavelength change.
IMPORTANT Modifying the FWHM can slightly alter the central wavelength setting.
So you may need to re-adjust the central wavelength after FWHM
change.

Setting the Wavelength/Frequency and FWHM Values
XTM-50 User Guide 15
3.2 Adjusting the FWHM
Subject The bandwidth actuator is graduated from 0 to 250. Two complete revolution of the
thimble reach one graduated marking on the sleeve.
•On the sleeve: 13 mm stroke with 0.5 mm graduation interval.
•On the thimble (rotary part): 250 μm by turn, with 5 μm graduation interval.
Figure 5: Bandwidth-tuning Actuator – Scale values
Figure 6: Bandwidth vs Actuator Graduations (Typical values) – XTM-50 Wide only
Caution
To avoid damaging your XTM-50, do not turn the bandwidth actuator beyond
the 0 graduation marked on the sleeve.
Sleeve scale
1 scale graduation corresponds to:
•XTM-50 Standard: 105 pm (typ.)
•XTM-50 Ultrafine: 68 pm (typ.)
•XTM-50 O-band: 96 pm (typ.)
•XTM-50 Wide: not linear, see Figure 6, p. 15
Thimble scale
1 scale graduation corresponds to:
•XTM-50 Standard: 0.21 pm (typ.)
•XTM-50 Ultrafine: 0.14 pm (typ.)
•XTM-50 O-band: 0.19 pm (typ.)
•XTM-50 Wide: not linear, see Figure 6, p. 15
IMPORTANT Modifying the central wavelength can slightly alter the FWHM. So you
may need to re-adjust the FWHM after central wavelength change.
FWHM (pm)
Actuator Graduation (sleeve scale)

Setting the Wavelength/Frequency and FWHM Values
16 XTM-50 User Guide
Procedure 1. Move the Bandwidth tuning actuator as follows:
•To increase the FWHM, turn the actuator clockwise (from high to low values)
•To decrease the FWHM, turn the actuator counterclockwise (from low to high
values)
Figure 7: FWHM Tuning
2. Tighten the lock screw (see Figure 1, p. 8) to lock the FWHM setting.
3. If you had previously adjusted the central wavelength, re-adjust it as it may have been
slightly altered by the FWHM change.
Caution
To avoid damaging your XTM-50, do not turn the bandwidth actuator
beyond the 0 graduation marked on the sleeve.

Setting the Wavelength/Frequency and FWHM Values
XTM-50 User Guide 17
3.3 Reaching a Position on the Bandwidth or Wavelength
Tuning Actuator
Subject The Acceptance Test Report delivered with your instrument indicates the actuator
position (in mm) of the central wavelength and FWHM on your XTM-50.
This section explains how to adjust the actuators to reach the wanted position.
Procedures Reaching a Position on the Bandwidth Tuning Actuator
The bandwidth actuator is composed of two graduated scales:
•On the sleeve: 13 mm stroke with 0.5 mm graduation interval.
•On the thimble (rotary part): 250 μm by turn, with 5 μm graduation interval.
To reach a graduated position on the actuator, you must add both scale values.
Example
To reach the value of 7.275 mm, proceed as follows:
1. Align value 0 of the thimble to value 7 of the scale on the sleeve.
2. Make a full counterclockwise revolution of the thimble to add 0.250 mm.
3. Turn the thimble counterclockwise to add 0.005 mm.
Reaching a Position on the Wavelength Tuning Actuator
The wavelength actuator enables coarse and fine adjustments.
•Coarse adjustment:
•On the sleeve: 13 mm stroke with 0.5 mm graduation interval.
•On the thimble (rotary part): 0.5 mm by turn, with 0.01 mm graduation interval.
•Fine adjustment:
•On the sleeve: 200 μm stroke with 25 μm graduation interval.
•On the thimble: 25 μm by turn, with 0.5 μm graduation interval.
To reach a graduated position on the actuator, you must add all four scale values.
Example
To reach the value of 8.852 mm you can use different combinations; the following
procedure explains the "8.7+0.152" combination:
1. On the fine adjustment screw, align value 0 of the rotary thimble to value 100 of the
sleeve scale.
2. On the coarse screw:
a. Align value 0 of the thimble to value 8.5 of the sleeve scale.
b. Turn the thimble counterclockwise to reach value 200, which adds 0.200 mm.
3. On the fine screw:
a. Align value 0 of the thimble to value 150 of the of the sleeve scale.
b. Turn the thimble counterclockwise to add 4 graduations on the thimble scale
(which is 0.002 mm).

Setting the Wavelength/Frequency and FWHM Values
18 XTM-50 User Guide

XTM-50 User Guide 19
4. Performing Basic Maintenance Operations
User maintenance of the XTM-50 system is limited to basic maintenance tasks that do
not require removing the instrument case-cover or accessing any internal component of
the instrument.
4.1 Cleaning Optical Connectors
Subject To optimize the performance of the instrument and prevent loss of optical power, you
must verify that optical connectors are clean every time you connect a fiber.
The XTM-50 optical connectors are mounted on a drawer to ease the cleaning of internal
connectors.
Before Starting Make sure you have the following material:
•Optical grade cleaning cotton swabs
•Canned air
•Isopropyl alcohol
•Fiberscope or similar if available
•Lint-free tissue or cleaning cartridges
Use only high quality cleaning supplies that are non-abrasive and leave no residue.
Procedure 1. On the front panel, make sure the protective caps of the connectors are in place.
2. On the front panel, use your fingers to unscrew the two screws of the connector
drawer.
Once unscrewed from the front panel, the two screws stay attached to the drawer.
3. Gently pull the drawer out of the front panel (no more than 70 mm) so that fiber ends
are made visible, as illustrated in the following figure.
Figure 8: Optical Connectors – Cleaning
Never remove the protective cover of the chassis to perform servicing or
maintenance operations to the XTM-50 internal parts and optical
components.
You must refer to EXFO service representative (see section Contact
Information, p. 4).
IMPORTANT To reduce the need for cleaning, immediately replace protective caps
on the optical connectors when not in use.

Performing Basic Maintenance Operations
20 XTM-50 User Guide
4. At the rear of the drawer plate, remove one connector end from the plate:
5. Gently clean the connector end, with the following instructions:
a. Hold the can of compressed air upright and spray the can into the air to purge
any propellant.
b. Spray the clean compressed air on the connector to remove any loose particles
or moisture.
c. Moisten a clean optical swab with isopropyl alcohol and lightly wipe the surfaces
of the connector with gentle circular motion.
d. Spray the clean compressed air on the connector again to remove any loose
particles or isopropyl alcohol.
e. Check that the connector is clean with a fiberscope (or similar).
6. Replace the connector end at the rear of the drawer plate: make sure the key of the
connector is mated with that of the adapter and screw it back.
7. Perform steps 5 to 7 on the second connector.
8. Push the connector drawer back on the front panel and screw the drawer back in its
location, making sure no fiber is trapped between the front panel and the drawer
plate.
4.2 Cleaning the Cover of the XTM-50
Subject If the external cover of the XTM-50 becomes dirty or dusty, clean it by following the
instruction below.
Before Starting Material needed: lint free cleaning cloth
Procedure •Gently swipe dirt and dust on the external cover of the XTM-50, without applying
excessive force onto it.
Do not use chemically active or abrasive materials to clean the XTM-50.
