Exmark ULTRAVAC 126-6122 Manual

ULTRAVAC®BAGGER
126-6122
SetupInstructions
ForUltraVacSerialNos.400,000,000&Higher
(TotRadiusModelsSerialNos.400,000,000&Higher)
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.Partnumbersnotshownareavailableonthedealer
extranet.
DealerPack
PartNo.DescriptionQty.Use
—Fillouttheonlinewarrantyregistration
form.
LiteraturePack
Manual-Operator's
©2017—ExmarkMfg.Co.,Inc.
P .O.Box808
Beatrice,NE68310
PartNo.4503-418Rev.C
PrintedintheUSA.
AllRightsReserved*4503-418*C

ModelsandRequiredCompletingKits
CompletingKits
Note:UsethefollowingchartstoverifythekitsrequiredfortheunityouareinstallingtheUltraVacon.
E-andS-Series
DeckCompletingKit
48inch126-6196
52inch126-6197
60inch126-6198
X-Series
DeckCompletingKit
48inch126-6209
52inch126-6210
60inch126-6211
2

InstallingtheHopperMount
Brackets
1.Raisethedecktothetransportposition.Raisethe
backofthemachineupandsupportthemachine
withjackstands.
CAUTION
Raisingthemowerdeckforserviceor
maintenancerelyingsolelyonmechanical
orhydraulicjackscouldbedangerous.The
mechanicalorhydraulicjacksmaynotbe
enoughsupportormaymalfunctionallowing
theunittofall,whichcouldcauseinjury.
DoNotrelysolelyonmechanicalorhydraulic
jacksforsupport.Useadequatejackstandsor
equivalentsupport.
2.Removethereartiresfromthemachine.
3.Removeandretaintherearweightanditsmounting
hardware(ifapplicable).
4.Removeandretainthenutsfromtheboltsonthe
bottomofeachhydroasshowninFigure1.Install
thetransmissionsupportbracketandsecurewith
nuts.
g189992
Figure1
1.Retainnuts3.Rearweight
2.Transmissionsupport
bracket
4.Torxbolts
5.Removeanddiscardthetorxboltsandnutsonthe
leftandrightsidesoftherearguardthatattaches
ittotheframe.
6.InstallthelegsoftheLHandRHbaggersupport
bracketontothetransmissionstudsandsecurewith
thenutsretainedinstep4(seeFigure2).
g037961
Figure2
1.LHsupportbracket4.5/16atwasher
2.RHsupportbracket5.5/16inchangednylocnut
3.5/16-18x31/4inchhex
screw
7.Securethesidesofthebaggersupportbracketsto
therearframeusing5/16-18x31/4inchhexscrews
and5/16inchangednylocnuts(seeFigure2).
8.Ifthemowerhasleftandrightrearguardupper
supportbracketsinstalled,asshowninFigure3,
removeanddiscardthehardwarethatsecuresthe
supportbracketstotherearguard.
g211861
Figure3
1.Rightrearguarduppersupportbracket
2.Leftrearguarduppersupportbracket
3.Discardhardware
9.InstalltheupperrearmountbrackettotheLHand
RHbaggersupportbracketsandrearguard(see
Figure4).
3

g189991
Figure4
1.Upperrearmountbracket4.Hitchcover
2.5/16-18x31/4inch
carriagescrew
5.Uppersupportbracket(if
equipped)
3.5/16inchangednylocnut
10.Placethehitchcoverontotherearguard.
Note:Itmaybenecessarytotapitintoplacewith
amallet.
InstallingtheWeightAssembly
WARNING
Casterortoeboardweightsinstalledwithoutthe
collectionsystemmaycauselossoftractionand
steeringcontrol.Lossofcontrolcanresultinan
accidentwhichmaycausedeath,injury,orproperty
damage.
InstallcasterortoeboardweightsONLYwhenthe
collectionsystemisinstalled.
Note:Theremovableweightsareheavy.Usecarewhen
liftingthem.Makesurethatyoucanholdthemsecurely
beforeliftingthem.Usecautionwhenpositioningyour
handssothatyouDoNotsetthemdownonyourhands
orngers.
1.Assembletheweightsbyplacingtheweightbracket
plateinsidethemountchannel.Installthetabbed
weightbracketplateinsidethemountchanneland
againsttheweightbracketplateasshowninFigure5.
Securethemountchannelassemblytotheweight
usingtwo3/8-16x21/2inchboltsandtwo3/8
inchwhizlocknuts.
g185955
Figure5
1.Weight4.Tabbedweightbracket
plate
2.Mountchannel5.3/8-16x21/2inchsquare
headbolt
3.Weightbracketplate6.3/8inchwhizlocknut
For48InchDeckOnly:
Removeandretainthetwomountingnutsonthe
topsideofthecasterweight.Installtheextraat
weightontopofthecasterweightandsecurewith
thetwonuts(seeFigure6).
g037628
Figure6
1.Nut3.Casterweight
2.Flatweight
2.Installoneremovablecasterweightoneachcaster
armasshowninFigure7.
4

g037183
Figure7
1.Bolt3.Washer
2.Knob4.Casterweight
3.Inserttheboltthroughthebracketholeandinstall
thewasherandknob.
4.Tightentheknobonweightassemblyuntilthe
weightisclampedsecurelytothecasterarm.
Note:TheportionsoftheUltraVaccollection
systemthatarenotboltedtothemoweraredesigned
tobeinstalledorremovedintheirentirety.Do
Notoperatethemowerwithonlyaportionofthe
UltraVacinstalled.
InstallingtheBeltCoverBracket
1.Removeandretainthedischargedeectorandits
mountinghardware.
2.Lowerthedeckfully.Removeandretainthe
standardrightsidebeltcover,wireformbracketand
itshardware.
3.Installthebeltcoverbracket.
•48and52InchDecks:Usetwo3/8-16x1
1/4inchcarriageboltsandtwo3/8inchanged
nylocnutsasshowninFigure8.
g037341
Figure8
48and52InchDecks
1.3/8-16x11/4inchcarriagebolt
2.Beltcoverbracket
3.3/8inchangednylocnut
•60InchDeck:Usetwo3/8-16x11/4inch
carriageboltsandtwo3/8inchangednyloc
nutstoinstallcoverbracketasshowninFigure9.
g213087
Figure9
1.3/8-16x11/4inchcarriagebolt
2.Beltcoverbracket
3.3/8inchnylocnut
InstallingtheBlowerDriveSheave
1.Removethedeckdrivebeltfromaroundtheright
handspindlesheave.
2.Supporttherightmowerbladeandshaftsothatit
willnotfalloutofthedeckwhentherightsheave
nutisremoved.
5

3.Removetherightsheavenutandsheavefromthe
spindleshaft.
4.Installthedoublesheaveontotherightspindleshaft.
•X-Series:Reinstallthespringdiscwasherand
nut;torqueto130-160ft-lb(176–217N-m).
g007021
Figure10
1.Torquesheavenutto130-160ft-lb(176–217N-m).
2.Installwithconetowardsnut.
•S-andE-Series:Reinstallthenutandtorqueto
75-85ft-lb(102-115N-m).
Blockthebladerotationwithablockofwood
betweenthebladeandbafesasindicatedinthe
bladeservicesectionoftheOperator’smanual.
DoNotusethebladebolttopreventrotation.
Checkbladebolttorqueaftercompletingthis
installation.
Torquebladeboltto50-60ft-lb(75-81N-m).
5.Re-installthedeckdrivebeltinthelowergrooveof
thedoublesheave.Installtheplugintotheboreof
thedoublesheave.
g190023
Figure11
1.Beltcoverbracket4.Belt
2.Beltcover5.Decksheaveandnyloc
plug
3.Knob
InstallingtheBlowerAssembly
1.Mountthebloweronthedeckbyinsertingthe
mountingpinintothetubeweldedtotherearcorner
ofthedeck.UseFigure12todeterminethepin
locationintheblowerframe.
g037990
Figure12
1.Mountingpin4.48inchdecklocation
2.Rollpin5.60inchdecklocation
3.52inchdecklocation
2.Pivottheblowertowardsthedeckandpulloutward
onthelatchpin.Releasethelatchpinwhenitaligns
withtheholeonthetabofthedecktolockthe
blowerinthisposition.
6

3.Pullthespringloadedidlerbackandslipthebelt
overthetopdecksheave.Thebeltshouldberouted
asshowninFigure13.
g190065
Figure13
ViewfromT opofBlower
4.Positionthebeltcoveratanangleandslideitunder
themowerframe(seeFigure14).
g038057
Figure14
1.Blower3.Mowerframe
2.Beltcover
5.Pushdownonthebackofthecoverandslideit
backwardsundertheblower.
6.Withthebeltcoverrestingonthedeck,slideit
forwarduntilitisseatedunderbothlipsonthedeck.
g038066
Figure15
1.Blower3.Decklip
2.Beltcover
7.Installtheknobanditshardware.
InstallingtheHopperFrame
1.Removethehairpinfromthepostonthehopper
frame.InsertthehopperframeintotheLHhopper
mountbracket(seeFigure16).Resttheotherend
ofthehopperframebetweenthetabsontheRH
hoppermountbracket.Slidethehopperframeinthe
LHhopperbracketuntilthepostgoesthroughthe
RHhoppermountbracket.Reinstallthehairpinto
thepostsecurethehopperframe.
Note:Ifthehopperframedoesnotseatproperlyin
themountbrackets,carefullyusethehopperframe
toslightlyadjustthealignmentofthebrackets.The
frameisdesignedtoinitiallyttightinthemounting
brackets.Itmaybenecessarytouseamalletto
install.
7

g211079
Figure16
1.LHhoppermountbracket
2.Hopperframe
3.Hairpin
4.RHhoppermountbracket
5.Post
2.Removethehairpinfromtheholddownrod.Insert
theholddownrodintothehopperframeand
reinsertthehairpin(seeFigure17).
g211078
Figure17
1.Holddownrod
2.Hairpin
InstallingtheHopper
1.Ifnotinstalled,removeandretainthehairpinsfrom
theairvent.
2.Pressthetabsontheairventintothenotchesonthe
insideofthehopperandsecurewithhairpins.
g188636
Figure18
1.Airvent3.Hairpin
2.Hopper
3.Slidethehopperhingesontothehopperframepins.
g037999
Figure19
1.Hopperframepin3.Hopperhinge
2.Seal(partiallyremovedfor
clarity)
4.Airvent
4.Makesurethesealispositionedaroundthebrackets
wherethebagsmount.
AssemblingtheTubes
1.Sliptheupperandthelowertubestogether.
8

2.Inserttheuppertubeintothehopperseal–pushin
thenpulloutsothatthesealisextendedoutward.
3.Alignthedimpleontheuppertubewiththeendof
hoppersealandorientbetweenthetwoscrewsas
showninFigure20.
g211170
Figure20
1.Dimple
4.Setthedeckinthelowestcuttingposition.
5.Slidethelowertubeontotheblowerandattachthe
latches.(Makesurethattheuppertubedoesnot
moveoutofalignment).
Usethechartbelowasaguidefortheapproximate
overlapbetweentheupperandlowertubes.
DeckSizeTubeOverlap
48inch7–9inches(18–23cm)
52inch4–7inches(10–18cm)
60inch4–7inches(10–18cm)
6.Drillthree7/32inchholesinthelowertubeusing
theuppertubeholesasreference(seeFigure21).
g037981
Figure21
1.Baggerhood4.Blowerassembly
2.Uppertube5.Drill
3.Lowertube
7.Removetubesfromtheunitandassembletheupper
andthelowertubesusingthree#10-24x3/4inch
hexwasherheadscrews,three#10washers,and
three#10-24nylocnuts.Thescrewheadshould
beinstalledtotheinsideofthetubetoprovide
minimumobstructiontoow.Makesurethatthe
upperandthelowerendsareorientedproperlyas
thetubesareassembled(seeFigure22).
9

g003392
Figure22
1.Lowertube4.#10-24nylocnuts
2.Uppertube5.#10-24x3/4inchhex
washerheadscrews
3.Flatwasher(7/32inch)
8.Reinserttheuppertubeinthehopperseal—push
in,thenpulloutsothatthesealisextendedoutward.
9.Installthelowertubeontotheblowerhousingand
secureitwiththelatches.
AdjustingtheBlowerDriveBelt
Position
1.Readtheoperator’smanualfortheUltraVacand
mowerbeforeperformingthisadjustment.Make
surethatyouunderstandthecontrols,theirlocations
theirfunctionsandsafetyrequirements.
2.Ensuretheblower,beltcover,bags,tubeandhood
areingoodcondition,properlyattachedandlatched.
3.RuntheunitwiththePTOandtheblowerengaged
fortwominutes.
4.DisengagethePTO,stoptheengineandremove
thekey.
5.Removethebeltcoverandchecktomakesurethat
thebeltisridingnearthecenteroftheatidleron
theidlerarm.Ifthebeltisnotridingnearthecenter
oftheidler,removetheblower,andbendtheidler
armslightly.
6.Reinstalltheblowerandbeltcoverandperform
steps3-5againtoverifybeltposition.
InstallingtheBags
1.Raisethehoodandinstallthebagassembliesonto
thereceiversofthehopperframe.
2.Inorderforthehoodtosealproperlyagainstthe
bagswhenlatched,checkiftherearofthebagis
1/2–11/2inches(12.7–38.1mm)higherthanthe
front(seeFigure23).
g211189
Figure23
1.Frontdimension
2.Reardimensionis1/2–11/2inches(12.7–38.1mm)higher
thanfront
3.Bag
3.Ifthebagsaretoohigh,adjustthembypressing
downontherearofthebagframeuntilthe
dimensionisachieved.
InstallingtheROPSPin
TopreventtheROPSbarfromdamagingthehopper,
installtheROPSpinassembly.
1.Using11/64or#19drillbit,drilltheinnerRHROPS
hole3/4inch(19mm)deepasshowninFigure24.
10

g038069
Figure24
1.Drill3.#10-24x3/4inchhex
screw
2.#10washer4.ROPSpinwithlanyard
2.Placethe#10washerandlanyardcableendonto
the#10-24x3/4inchhexscrewandinstallintothe
RHROPShole.
3.InstalltheROPSpin.
4.Repeatsteps1through3fortheLHROPS.
FillOutWarrantyRegistration
Form
Fillouttheonlinewarrantyregistrationform.
11
