FormNo.4502-012RevA
InstallationInstructions
ReplacementCableKit
KitNo.126-3925
ForSerialNo.313,000,000–313,999,999
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ItemPartNo.DescriptionQty
1126-1664Cable1
2614249Tie-Wire3
33290-55Rivet2
Figure1
©2014—ExmarkMfg.Co.,Inc.
IndustrialParkBox808
Beatrice,NE68310
www.Exmark.comOriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*4502-012*A

SafetyAlertSymbol
ThisSafetyAlertSymbol(Figure2)isusedbothinthis
instructionsheetandonthemachinetoidentifyimportant
safetymessageswhichmustbefollowedtoavoidaccidents
Thissymbolmeans:ATTENTION!BECOMEALERT!
YOURSAFETYISINVOLVED!
Figure2
SafetyAlertSymbol
Thesafetyalertsymbolappearsaboveinformationwhich
alertsyoutounsafeactionsorsituationsandwillbefollowed
bythewordDANGER,WARNING,orCAUTION.
DANGER:Whitelettering/Redbackground.Indicatesan
imminentlyhazardoussituationwhich,ifnotavoided,Will
resultindeathorseriousinjury.
WARNING:Blacklettering/Orangebackground.Indicates
apotentiallyhazardoussituationwhich,ifnotavoided,Could
resultindeathorseriousinjury.
CAUTION:Blacklettering/Yellowbackground.Indicates
apotentiallyhazardoussituationwhich,ifnotavoided,May
resultinminorormoderateinjury.
Thismanualusestwootherwordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
WARNING
Ifyouleavethewireonthesparkplug,someone
couldaccidentallystarttheengine.Accidental
startingoftheenginecouldseriouslyinjureyouor
otherbystanders.
Disconnectthewirefromthesparkplugbeforeyou
doanymaintenance.Setthewireasidesothatit
doesnotaccidentallycontactthesparkplug.
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
Note:Parktheunitonalevelsurface.Makesureall
movingpartshavestoppedandthesparkplugwirehas
beendisconnected.Allowunittocoolbeforestartingthese
instructions.
RemovingtheCable
1.Makesureallmovingpartshavestopped,thespark
plugwirehasbeendisconnected,andtheunitiscool.
2.RemovethefueltankasstatedintheOperator’s
manual.
3.Removetheself-propeldrivecablefromthehandle;
retainthemountinghardware.
Figure3
4.Tipthemowerontoitsrightside.
5.Removeandretainthestopbracket,itsmounting
hardwareandbelttensionspring(seeFigure4).
Figure4
1.Stopbracket3.Belt
2.Spring4.Transmission
6.Rotatethetransmissiondowntowardsthefrontofthe
unitandremovethedrivebelt.
2

7.Removethecableanchorfromthebracketonthe
transmissioncase.
Figure5
1.Squeezeend3.Transmissioncase
2.Cableanchor4.Remove
8.Unhookthecablespringendfromthetransmission
activationlever.
Figure6
1.Transmission3.Transmissionactivation
lever
2.Cablespringend
9.Removeanddiscardtheself-propeldrivecable.
10.Tipthemowerbackontoitswheelstooperating
position.
InstallingtheCable
1.Removeandretaintheserialplatefromthetopside
oftheframe.
2.Usingtherearserialtagmountinghole,asshownin
Figure7,carefullydrilla5/8inch(16mm)diameter
holethroughthemowerhousing(holecanbedrilledat
anangle).Deburrthehole.
Figure7
1.Serialplate-newlocation2.Drillhole
3.Placetheserialtagontheleftsideoftheframeinthe
locationshowninFigure7andmarkthemounting
holelocations.Removetheplateanddrilltwo.143inch
(3.63mm)diameterholes.Installtheserialtagusing
thetworivetsfromthekit.
4.Insertthespringendofthenewcableintothehole
drilledinstep2.
5.Tipthemowerontoitsrightside.
6.Reattachthecablespringendonthetransmission
activationlever(referenceFigure6).Insertthecable
anchorintotheholeinthebracketonthetransmission
case(seeFigure5).
7.Reinstallthebeltontothetransmissionandrotatethe
transmissionupward.
8.Reinstallthetransmissiondownstopandbelttension
spring.
9.Tipthemowerbackontoitswheelstooperating
position.
10.Reinstallthefueltank.
11.Routethecableupwardalongtheleftsideofthe
handle.
12.Securetheupperendofthecableuptothetraction
lever.
3

13.Loosenthecablesupportnut.
14.Pullthecablejacketdown(towardthemachine)until
thereisnoslackinthecable.
Figure8
15.Tightenthenutonthecablesupport.
16.Ziptiethecabletothebracetotheleftofthefueltank
anddownthehandleasshowninFigure1.
Note:Makesuretheself-propelcabledoesnotkink
atthetransmission.
Note:MakesuretheBBC(BladeBrakeClutch)arm
doesnotinterferewiththecablerouting.
17.Reconnectthesparkplugwire.
18.UsingtheAdjustmentssectionintheOperator’s
manual,checkandadjusttheself-propeldriveand
BBC.
