Extreme USB ADI Icron USB 2.0 Ranger 2304PoE User manual

Quick Start Guide
USB 2.0 Ranger® 2304PoE
4-Port USB 2.0 Power over Ethernet
LAN Extender System
Package Contents:
USB 2.0 Ranger 2304PoE LEX
USB 2.0 Ranger 2304PoE REX
USB 2.0 Cable
Quick Start Guide
The Ranger 2304PoE requires an IEEE 802.3at - PoE+ (25.5W) capable network switch to provide power to the units.
The POWER status LED illuminates BLUE when sucient power is present and RED when the power level is insucient.
An optional 24V 1A AC power adapter can be connected to either the LEX or REX and is sold separately (order part number 21-00110).
If power is present at both the RJ45 Link and DC power ports, the DC power adapter serves as the primary source with PoE as the backup.
Notes:
LEX = Local Extender
REX = Remote Extender
For more information about conguring and operating this product,
refer to the complete online user guide at icron.com/2304PoE.
For technical support, visit icron.com/support.
For sales/general inquiries, visit icron.com/contact.
Before starting, install any required drivers for your USB device(s).
LEX
REX REXLEX
LEX
Max 100m
(CAT cable not included)
USB Devices
Host Computer
LAN
Max 100m
LAN
Connect a CAT 5e/6/7 patch cable from the RJ45 Link port on the
LEX to an IEEE 802.3at - PoE+ (25.5W) capable LAN port.
Connect the LEX to the USB port on your host computer using the
included USB cable.
Connect the USB device(s) to the REX as desired. The LEX also acts
as a 3-port hub to accommodate additional USB devices.
Place the REX where desired. Connect a CAT 5e/6/7 patch cable to
the RJ45 Link port on the REX and to an IEEE 802.3at - PoE+ (25.5W)
capable LAN port.
12
34
