Eyedro EHWEM1 User manual

Eyedro
GREEN SOLUTIONS INC.
®
Quick Start Guide
Wireless Electricity Monitoring System (EHWEM1)
For applications not exceeding
200A up to 300VAC
Limited One Year Warranty
Eyedro Green Solutions Inc. warrants this
product for a period of one year from date
of purchase for all defects in material and
workmanship. Defective parts may be
repaired or replaced, at the discretion of the
manufacturer, during this period.
Full warranty policy details are available
at eyedro.com
Eyedro
GREEN SOLUTIONS INC.
®
Eyedro
GREEN SOLUTIONS INC.
®
Visit eyedro.com for any questions
or comments. We value your feedback.
Before Getting Started
This insert provides very high level installation
instructions. Complete installation instructions
and video can be found in the Product Manual
located at eyedro.com/support
Installation may require the cover of the main
electrical panel to be removed while some wires
are still electrified. Even when the main breaker
has been turned ‘OFF’ certain areas of the
panel may still be dangerous and carry the risk
of shock, burn, and electrocution. Installation
should be performed by a qualified electrician.
DO NOT attempt installation unless you know
where electrified areas within the panel are.
FOLD

3. Install Hardware1. Verify Package Contents
Template for mounting the
Eyedro Modules (optional)
Cut out the below template and use it as a guide to
mark screw locations for a wall mounted module.
3.1 Install Current Sensor(s)
on the line1 conductor
of the circuit(s) to
be monitored.
1Line/Live/Hot conductor(s) only
3.2 Securely mount the Eyedro modules,
using the template provided below (optional).
3.3 Connect Sensor(s) and
power adapter to the
Sensor module.
Copyright © 2016, Eyedro Green Solutions Inc.
A
B
C
D
Eyedro Gateway Module
Eyedro Sensor Module
200A Current Sensors (max 300VAC applications)
Low-voltage Power Adapter
Ethernet Cable
1
1
2
2
3ft (0.9m)
QTY/LENGTH DESCRIPTION
A B C D
(2) (2) (2) (1)
2.36in (60mm)
Ethernet
Power
3.4 Connect Ethernet and
power adapter to the
Gateway module.
Sensor(s)
Power
A
B
C
4. Create a MyEyedro User Account
4.2 Add the devices to your user account by entering the
serial numbers recorded earlier.
4.3 ENJOY! Login to MyEyedro as often as you like to
view your electricity consumption.
4.1 GO ONLINE TO:
my.eyedro.com
to create your
online account
(or login if you
have an existing
account).
4.4 For more details regarding the MyEyedro service, review
the MyEyedro User Guide located at eyedro.com/support.
2. Record Serial Numbers
Sensor SN: -
Gateway SN: -
