FAAC B680 User manual

B680H

1
ENGLISH
INDEX
B680HAUTOMATED SYSTEM
1. TECHNICAL SPECIFICATIONS ............................................................................................................................................................3
1.1 Summary table...............................................................................................................................................................................3
1.2 Key Fig.5.........................................................................................................................................................................................3
1.3 Key Fig.6.........................................................................................................................................................................................3
2. ELECTRICAL PREPARATIONS (standard system) ............................................................................................................................3
3. BARRIER DIMENSIONS........................................................................................................................................................................3
4. INSTALLING THE AUTOMATED SYSTEM ...........................................................................................................................................3
4.1 Preliminary checks .......................................................................................................................................................................3
4.2 Walling in the foundation plate ...................................................................................................................................................3
4.3 Electrical preparations.................................................................................................................................................................3
4.4 Mechanical installation ................................................................................................................................................................3
4.5 Balancing the barrier....................................................................................................................................................................4
5. START-UP...............................................................................................................................................................................................4
5.1 Connecting the control equipment.............................................................................................................................................4
5.2 Testing the automated system....................................................................................................................................................4
6. MANUAL OPERATION ..........................................................................................................................................................................4
7. RESTORING NORMAL OPERATION....................................................................................................................................................4
8. MAINTENANCE .....................................................................................................................................................................................4
8.1 Topping up the oil .........................................................................................................................................................................4
8.2 Air bleeding ...................................................................................................................................................................................4
9. REVERSING THE OPENING DIRECTION ............................................................................................................................................5
10. ACCESSORIES....................................................................................................................................................................................5
10.1 Installing a photocell .................................................................................................................................................................5
10.2 Installing the bar light kit ...........................................................................................................................................................5
10.3 Installation of a receiver antenna .............................................................................................................................................5
11. REPAIRS...............................................................................................................................................................................................5
E680 CONTROL BOARD
1. WARNINGS ............................................................................................................................................................................................6
2. DESCRIPTION OF THE COMPONENTS ..............................................................................................................................................6
3. TECHNICAL SPECIFICATIONS ............................................................................................................................................................6
4. ELECTRICAL CONNECTIONS..............................................................................................................................................................7
4.1 Terminal board J1 (inputs)...........................................................................................................................................................7
4.2 Terminal board J2 (outputs).........................................................................................................................................................8
4.3 Terminal board J3 (external flashing lamp)...............................................................................................................................8
4.4 Terminal board J4 (loop detector) ..............................................................................................................................................8
4.5 Connector J5 (Motor)....................................................................................................................................................................8
4.6 Connector J7 (Encoder)...............................................................................................................................................................8
4.7 Connector J10 (Radio)..................................................................................................................................................................8
4.8 Connector J11 (Beam break-out sensor)...................................................................................................................................8
4.9 Connector J12 (Emergency battery)...........................................................................................................................................8
4.10 Connector J13 (36VDC Power Supply) .....................................................................................................................................8
4.11 Connector J15 (flashing traffic light)........................................................................................................................................8
4.12 Connector J16 (beam lights)......................................................................................................................................................8
5. PROGRAMMING....................................................................................................................................................................................9
5.1 Basic configuration.......................................................................................................................................................................9
5.2 Changing the predefined parameters set................................................................................................................................10
5.3 BUS accessories menu..............................................................................................................................................................11
6. Advanced Configuration ....................................................................................................................................................................12
6.1 Configuring the loop detector ...................................................................................................................................................13
6.2 Expert Configuration..................................................................................................................................................................14
6.3 Pre-Defined Parameter Sets......................................................................................................................................................17
6.4 “Expert” default parameters.....................................................................................................................................................18
7. START-UP.............................................................................................................................................................................................18
7.1 Verifying the diagnostic LEDs...................................................................................................................................................18
7.2 Setup.............................................................................................................................................................................................18
8. TESTING THE AUTOMATED SYSTEM...............................................................................................................................................18
9. MASTER/SLAVE CONFIGURATION...................................................................................................................................................19
10. INTERLOCK.......................................................................................................................................................................................20
11. OPERATING LOGICS TABLE............................................................................................................................................................21
12. BALANCING TABLES .......................................................................................................................................................................24
13. DEFAULT SELECTION TABLES (cF parameter)............................................................................................................................25
Raccoltaimmagini-Picturescollection-Collectiond’images-PhotoKollection-Conjuntodeimagenes-Afbeeldingen

ENGLISH
WARNINGS FOR THE INSTALLER
GENERAL SAFETY OBLIGATIONS
1) ATTENTION! To ensure the safety of people, it is important that you
read all the following instructions. Incorrect installation or incorrect
use of the product could cause serious harm to people.
2) Carefully read the instructions before beginning to install the product..
3) Do not leave packing materials (plastic, polystyrene, etc.) within reach of
children as such materials are potential sources of danger.
4) Store these instructions for future reference.
5) This product was designed and built strictly for the use indicated in this do-
cumentation.Anyotheruse,notexpresslyindicated here, couldcompromise
the good condition/operation of the product and/or be a source of danger.
6) FAAC declines all liability caused by improper use or use other than that for
which the automated system was intended.
7) Do not install the equipment in an explosive atmosphere: the presence of
inflammable gas or fumes is a serious danger to safety.
8) ThemechanicalpartsmustconformtotheprovisionsofStandardsEN12604
and EN 12605. For non-EU countries, to obtain an adequate level of safety,
the Standards mentioned above must be observed, in addition to national
legal regulations..
9) FAAC is not responsible for failure to observe Good Technique in the con-
struction of the closing elements to be motorised, or for any deformation that
may occur during use.
10) The installation must conform to Standards EN 12453 and EN 12445. For
non-EU countries, to obtain an adequate level of safety, the Standards men-
tioned above must be observed, in addition to national legal regulations..
11) Before attempting any work on the system, cut out electrical power.
12) The mains power supply of the automated system must be fitted with an
all-pole switch with contact opening distance of 3mm or greater. Use of a
6A thermal breaker with all-pole circuit break is recommended.
13) Make sure that a differential switch withthreshold of 0.03Aisfitted upstream
of the system.
14) Make sure that the earthing system is perfectly constructed, and connect
metal parts of the closing elements to it.
15) Theautomatedsystemfeaturesabuilt-inanti-crushingsafetydeviceconsisting
of a torque control. It is however necessary to check its tripping threshold,
as provided for in the Standards described in point 10.
16) The safety devices (EN 12978 standard) protect any danger areas against
mechanical movement Risks, such as crushing, dragging, and shearing.
17) For each system, we recommend using at least one signal light (e.g.: FAA-
CLED or integrated flashing traffic light) as well as a warning sign securely
fixed to the structure, together with the devices described in point “16”.
18) FAAC declines all liability as concerns safety and efficient operation of the
automated system, if system components not produced by FAAC are used.
19) For maintenance, strictly use original parts by FAAC.
20) Do not in any way modify the components of the automated system
21) The installer shall supply all information concerning manual operation of the
system in case of an emergency, and shall hand over to the User the leaflet
supplied with the product.
22) Do not allow children or adults to stay near the product while it is operating.
23) Keep radio controls or other pulse generators away from children, to prevent
the automated system from being activated involuntarily.
24) Transiting is permitted only when the automated system is stationary.
25) The User must not attempt any kind of repair or direct action whatever and
contact qualified personnel only.
26) Maintenance: check at least every 6 months the efficiency of the system,
particularly the efficiency of the safety devices (including, where foreseen,
the operator thrust force) and of the release devices.
27) Anything not expressly specifiedinthese instructions is not permitted.
EC DECLARATION OF CONFORMITY
The Manufacturer
Company name: FAAC S.p.A. Soc. Unipersonale
Address: ViaCalari,10-40069ZolaPredosaBOLOGNA
- ITALY
hereby declares that the following products:
Description: Vehicular barrier
Model: B680H
comply with the following applicable EU legislations:
EMC Directive 2014/30/EU
Directive ROHS 2 2011/65/EU
Furthermore, the following harmonised standards have been ap-
plied: EN 61000-6-2:2005
EN 61000-6-3:2007 + A1:2011
Bologna,01-01-2016 CEO
DECLARATION OF INCORPORATION OF PARTLY COMPLETED
MACHINERY
(2006/42/EC ANN.II P.1, LETT. B)
Manufacturer and person authorised to prepare the relevant tech-
nical documentation
Company name: FAAC S.p.A. Soc. Unipersonale
Address: ViaCalari,10-40069ZolaPredosaBOLOGNA
- ITALY
hereby declares that for the partly completed machinery:
Description: Vehicular barrier
Model: B680H
the following essential requirements of the Machinery Directive
2006/42/EC (including all applicable amendments) have been
applied and met:
EHSR 1.1.2, 1.1.3, 1.1.4, 1.1.5, 1.1.6, 1.1.7, 1.2.1,
1.2.2, 1.2.3, 1.2.3.4, 1.2.4, 1.2.5, 1.3.1, 1.3.10,
1.3.12, 1.3.2,1.3.3, 1.3.4,1.3.6, 1.3.7,1.3.8, 1.3.9,
1.4.1, 1.4.11, 1.4.13, 1.4.15, 1.4.5, 1.4.6, 1.4.7,
1.4.8, 1.4.9, 1.5.3, 1.6.1, 1.6.1.1
and that the relevant technical documentation has been compiled
in compliance with part B of Annex VII.
Furthermore,the followingharmonisedstandardshavebeen applied:
EN 12100:2010
EN 60335-1:2012 + A11:2014
EN 13849-1:2008
EN 13849-2:2008
Other technical standards applied:
EN 12453:2000
It is also declared that the partly completed machinery identified above
may not be commissioned until the final machine - into which it will be
incorporated - has been declared complaint with the provisions of the
above mentioned Machine Directive 2006/42/EC.
Bologna,01-01-2016 CEO

3
ENGLISH
B680H AUTOMATED SYSTEM
The automated system consists of a white aluminium beam with
reflectors,optionalsignalling lights, acovering compartment andsteel
uprightprofile. Inside thecompartment there isan operatorconsisting
of the upright profile with a hydraulic unit and two plunging pistons
fixed to it, which, by means of a rocker arm, rotate the beam. The
latterremains balanced thanksto abalance spring fittedon one of the
twoplunging pistons.The electronic controlequipment is alsohoused
on the upright, inside a compartment, and the whole is protected by
the external covering compartment.
The system features an adjustable electronic anti-crushing safety,
a device that guarantees stopping and locking of the beam in
any position, and a convenient manual release for use in case of
black-out or inefficiency.
1. TECHNICAL SPECIFICATIONS
1.1 Summary table
Power supply (V ~/ Hz) 100-240 V ~ / 50-60Hz
Electric Motor 36Vdc Brushless
Absorbed power (W) 240
Absorbed current (A) 1,1A at 230 V ~
Motor rotation speed (RPM) 1000-6000
Pump capacity 3,2 l/min (max)
Yielded torque (Nm) 0-370
Oil type FAAC HP OIL
Oil quantity (L) ~ 1,2
Anti-crushing System Electronic with absolute encoder
Deceleration type Electronic with absolute encoder
Operating ambient temperature (°C) -20 / +55
Rated Operating Time (ROT) Continuous Duty at +55°C
Compartment protection treatment EP SL LF PRIMER
Beam type Rounded with lights and rubber bumper
Protection Class IP56
Compartment Dimensions
(LxHxP) (mm) See illustration Fig. 8
Weight (body + compartment) (kg) 65 + 20 / 85 (total)
Opening and closing time (s),
including deceleration 1.5 - 2 m beam 6 opening / 9 closing - 8 m beam
 Built-in flashing lamp
 Electronic control equipment
 Oil filling cap
 Right piston bleeder screw
 Hydraulic unit
 Right plunging piston
 Unit cooling fan
 Right feed tube
 Left feed tube
 Release lock
 Left plunging piston
 Left piston bleeder screw
 Covering compartment
 Encoder
 Box connecting the main power supply
 Switching power supply
 Bearing structure
 Mechanical stops
 Rocker arm
 Drive shaft
 Securing plate
 Spring guide
 Balance spring
 Preload adjustment ring nut
1.2 Key Fig.5
1.3 Key Fig.6
2. ELECTRICAL PREPARATIONS (standard system)
See details in the illustration Fig. 7.
3. BARRIER DIMENSIONS
All the dimensions contained in this manual are
expressed in mm
For barrier dimensions, refer to Fig. 8. The covering compartment is
the same for both models, while the bar dimensions differ as shown
in detail at (bar S) and (bar L) - Fig. 8
4. INSTALLING THE AUTOMATED SYSTEM
4.1 Preliminary checks
Forthe safety and correct operationof theautomated system, ensure
that the following conditions are met:
• Wheninmotion,thebeammustnotencounterobstaclesorflying
power cables.
• Thecharacteristicsofthegroundmustguaranteesufficientsolidity
of the foundation plinth.
• No tubes or electrical cables should be present in the plinth
digging area.
• If the barrier body is exposed to vehicle transit, provide for
adequate protection against accidental impact, when possible.
• Ensure that there is an efficient earth plate for connecting the
upright profile.
Wallinthefoundationplatesoastoalloweasyaccessto
thebarrier door.The foundationplinthmust beinstalled
keeping in mind the characteristics of the ground to
ensure perfect stability of the automated system.
4.2 Walling in the foundation plate
• Assemble the foundation plate as shown in Fig. 9 ref. 
• Set the foundation plinth as shown in Fig. 9 ref. 
• Wall in the foundation plate as shown in Fig. 9 ref. providing
for one or more sheaths for the passage of the electrical cables.
For dimensional reasons, the cable passage sheaths
must be placed on one side of the space provided at
the base of the barrier (see Fig. 9).
• Use a level to ensure that the plate is perfectly horizontal.
Wait for the cement to set.
4.3 Electrical preparations
Following the instructions shown in Fig. 7, prepare the ducts to
make all the control board electrical connections with the chosen
accessories.
Always separate the power cables from the control and safety cables
(button, receiver, photocells, etc.).
Use the cable diameters shown in Fig. 7 and referred to in the
following key:
 Barrier mod. B680H
 Photocells
 Key button
 Flashing lamp
 Radio receiver
 Magnetic Loops
4.4 Mechanical installation
• Fix the upright profile onto the foundation plate using the four
provided nuts (Fig. 11). Remember that the hydraulic unit must
usually face the inside of the property.
• Prepare the operator for manual operation, as shown in
paragraph 6 / Fig. 18 (Manual Operation).
• Remove and set aside the venting screw, as shown in Fig. 12
ref. .
• Set the rocker arm horizontally, then remove, as shown in Fig.
13 ref. , the upper fixing pin of the piston on the bar side and
insert on it the spring guide and balance spring, as shown in Fig.
14,followed bythe preloadadjustment ringnut, payingattention
to the direction it must be inserted in (see Fig. 14 ref. ).

4
ENGLISH
• Identify,as described in section12,Table 2 /Table3, the correct
fastening hole for the piston, then reinsert the pin and tighten
the nut.
• Fasten the piston on the opposite side in the same manner
With the barrier open, the spring must NOT be
compressed.
• Installthe beam and its fixingpocket usingthe provided screws,
as shown in Fig. 17, ref. from to (the rubber profile of the
beam must face the closing direction)
Do not grease the fixing screw of the bar.
• If the application requires a segmented bar, once the first
segment and fixing pocket have been assembled, close
the automatic system, lock it and follow the instructions for
additional segment assembly, as shown in Fig. 20, ref. from
to 
• Adjust the opening and closing mechanical stops as shown in
Fig. 15, and tighten the lock nut.
• Check that the beam is balanced according to the instructions
in section 4.5 .
The compartment should be fixed, as shown in the
sequence in Fig. 21, when all mechanical installations,
wiring and start-up have been completed.
4.5 Balancing the barrier
WARNING: This procedure must be carried out as the barrier is
not internally balanced. The beam is balanced when, operating
manually (ref. paragraph 6) the beam remains stationary in the
45° position.
To balance the barrier, proceed as follows:
• Installthebarand all related accessoriesonthebarrier structure,
as required by the final configuration of the system.
• Ensure that the operator is released: see paragraph 6.
• Manually move the bar to the 45° position and verify it remains
stationary. If the bar tends to open, turn the spring preload ring
nut anti-clockwise (Fig. 16 ref. ); if it tends to close, turn the
ring nut clockwise (Fig. 16 ref. ).
5. START-UP
5.1 Connecting the control equipment
WARNING: Before carrying out any work on the control board
(connections, maintenance, etc.) always cut off the electrical
power.
Forallautomaticsystemconnectionsandtesting,refer
to the section dedicated to the electronic equipment,
paragraph 1 on page 6 and following.
5.2 Testing the automated system
Onceinstallationhas been completed,applythe "danger" signsticker
(ref.Fig.29) to the topofthe upright profile. Proceedtoensure correct
operation of the automated system and all the accessories
connected to it.
Give the Customer the “User’s Manual”, the
documentation required by current law and show how
to correctly operate the barrier, pointing out the areas
of potential danger.
6. MANUAL OPERATION
Should manual operation of the barrier be required due to electrical
power cut-offs or automated system inefficiency, use the release
device with the provided key.
The provided unlocking key is either triangular (Fig. 18 ref. ) or
customised (Fig. 18 ref. optional).
• Insert the unlocking key in the lock and turn the key
anticlockwise until it clicks into place, as shown in Fig. 18
• Open or close the beam manually.
With the bar released, the motor may start for
approximately3seconds. Thisisnormalanddetermined
by the parameter Hold Close / Hold Open
7. RESTORING NORMAL OPERATION
Toavoidanaccidental pulse opening thebarrierduring this operation,
before activating the locking system, cut off all power to the system.
triangular unlocking key (standard):
- turn the key clockwise until it stops and then remove it (Fig. 18
ref. ).
customised unlocking key (optional):
- turn the key clockwise until it stops and then remove it(Fig. 18 ref.
).
8. MAINTENANCE
When performing six-month maintenance, always check the correct
balancing of the system and the correct operation of the safety
devices.
8.1 Topping up the oil
Check the amount of oil in the tank every 6 months.
Thelevelmustbeincludedbetween the two notches ontheinspection
rod.
To top up, unscrew the filler cap (Fig. 12 ref. ) and pour oil up to
the indicated level.
Use only FAAC HP OIL.
8.2 Air bleeding
FAAC products are delivered already bled of any air in the hydraulic
circuit. Maintenance operations, replacing spare parts (e.g.
connection pipes) or careless transport can cause entry of air in the
hydraulic circuit,whichinturncancause operator irregular movement
or reduce its torque. Should beam movement be irregular, release
the air from the hydraulic system following the instructions below:
• Electrically operate the beam:
• When opening is completed, slightly loosen and tighten the
bleeder screw of the piston with the balance spring (Fig. 5
ref. ).
• When closing is completed, slightly loosen and tighten the
bleeder screw of the piston without the balance spring (Fig. 5
ref. ).
If necessary, repeat the operation until regular movement of the
beam is obtained.
Care needs to be taken at this stage as the pistons
contain oil under pressure which could leak out if the
screws are loosened too much.
Ifthe parameters FO and FC inAdvancedConfiguration
have been changed and set to a value lower than
default, during bleeding we recommend setting them
to an equal or greater value, to facilitate air bleeding

5
ENGLISH
9. REVERSING THE OPENING DIRECTION
The opening direction of the barrier is usually determined at the time
of installation with the installation of the spring guide, the spring and
the preload adjustment ring nut on the piston located on the beam
downward travel side.
Should it be necessary to change the opening direction, proceed as
follows:
• Release the operator, as shown in paragraph 6, and place the
beam in vertical position, then lock the operator again.
• Remove the beam as shown in Fig. 17.
• Remove the device securing the plunging piston to the rocker
arm, as shown in Fig. 13.
• Loosen the pre-load ring nut completely, remove it and then
remove the balancing spring and spring guide, reversing the
order described in paragraph 4.4 and in Fig. 14 regarding the
mechanical installation of the automated system.
• Refit the plunging piston in the correct fixing hole.
• Proceedto remove thefixing screw onthe pistonon the opposite
side.
• Release the automated system, turn the rocker arm 90° and re-
insert, in order, the spring guide, the balancing spring and the
the ring nut in the plunging piston installed on the new closing
side, according to the order described in Fig. 14. Once this is
done, refit the plunging piston on the rocker arm.
• Reinstall the bar following the instructions in Fig. 17.
• Balancethesystemonceagainfollowingtheproceduredescribed
in paragraphs 4.5 and 4.6.
• Lock the operator once again following the instructions in
paragraph 7
• Reverse the motor cable connection as shown in point 
of Fig. 14
10. ACCESSORIES
10.1 Installing a photocell
The barrier is equipped with a lateral covering profile (fitted in the
compartment opening) under which there are holes for containing
Safebeam, BUS or wireless photocells.
To install the photocells, proceed as follows:
1. Remove the barrier compartment.
2. Match the holes on the barrier compartment with the holes on
the corresponding aluminium covering profile on the photocell
installation side; ref.  is used to fix the device, ref. is used
for the passage of the its power cable. Determine the hole size
accordingto thesize ofthe cables and of the fixing screws used.
3. Connect the photocell following the provided diagram.
4. Fix the photocell to the lateral profile, as shown in Fig. 22.
10.2 Installing the bar light kit
Installation of an LED bar light kit increases visibility of the bar.
Proceed to install following the instructions contained in Fig. 31 and
securingthe connection cable according to the pathshown, usingthe
openings for inserting the tie straps, located on the upright.
Connect the kit to output Out 4 on the electronic board and configure
it according to the available switching on modes (refer to the section
regarding the electronic board, paragraph 6 on page 12).
Ensure that the two connector jacks are actually in
contact with the conductors inside the cord. Should
the bar lights still not turn on, reverse the connection
polarity.
10.3 Installation of a receiver antenna
In case a receiver antenna should need to be attached to the barrier,
it can be secured to the flashing integrated traffic light connector (or
to the plastic bracket, if the optional flashing traffic light connector
shouldnothavebeeninstalled), as indicated in thediagramsinFig.32.
11. REPAIRS
For repairs, contact an authorised FAAC Service Centre.

6
J6
J12
J5
J11 J14
J7
+
-
F
SW1 SW2 SW3 J15
J1 J2 J3 J4
M2 M1A
M1
DL1 DL2
DL10
DL11
DL12
DL13 DL14
DL18 DL17
DL5
DL6
DL9
DL3
DL4
DL15
2Easy BUS
OPEN
CLOSE
FSW
STOP
EMR
GND
+24
345678 9 10 11 12 13 14 1516 17 18 19 20 21 22 23 2 2
+24
+24 +24 +24
OUT1
OUT2
OUT3
Relay NO
GND
LAMP
LOOP 1
LOOP 2
MOTOR
POWER
BATTERY
ENCODER DISP1
DL7
DL8
DL16
M
SW4
12 224567
Relay NO
Relay COM
J13
J16
SW5
J10
OUT5
OUT6
Fig. 1
Fig. 1

ENGLISH
E680 CONTROL BOARD
DISP1 Signalling/Programming display
DL1 BUS Device status
DL2 BUS status (see paragraph 5.3)
DL3 LOOP 1 status
DL4 LOOP 2 status
DL5 Board failure signal
DL6 Not used
DL7 Encoder status
DL8 Not used
DL9 Board power supply present
DL10 OPEN input status LED
DL11 CLOSE input status LED
DL12 FSW input status LED
DL13 STOP input status LED
DL14 EMR input status LED
DL15 Released bar signal
DL16 Battery power signal
DL17 Radio channel 1 activity
DL18 Radio channel 2 activity
J1 Input signal connector
J2 Digital output connector
J3 Signalling lamp connector
J4 Detection loop connector
J5 Motor connector
J6 BUS 2Easy connector
J7 Beam movement encoder connector
J10 Connector for Minidec / RP / Decoder radio board
J11 Released bar detection connector
J12 Emergency battery connector
J13 Continuous power voltage connector
J14 USB connector for firmware upgrade
J15 Integrated flashing
traffic light connector
SW1 Programming key “F”
SW2 Programming key “+”
SW3 Programming key “-”
SW4 /SW5 LOOP 1 / LOOP 2 calibration button
M1/M1A/M2 Optional module connector (Connectivity):
1. WARNINGS
Warning - Before carrying out any work on the control board
(connections, maintenance, etc.) always:
• cut off the electrical power;
• install a differential magnetothermic switch with a suitable
activation threshold upstream from the system;
• always separate the power cables from the control and safety
cables (button, receiver, photocells, etc.);
• avoid any electrical disturbance using separate sheaths or a
shielded cable (with the shield connected to the earth).
2. DESCRIPTION OF THE COMPONENTS
Mains power
voltage 100-240 V~ +6% -10% connected to switching power supply
Continuous
power voltage 36 V "
Absorbed power 240W
Accessories
power supply 24 V "
Max accessories
current 800 mA
Operating ambient
temperature from -20°C to +55°C
Protection fuses 4 self-restoring
Pause time Programmable (from 0 seconds to 4.1
minutes)
3. TECHNICAL SPECIFICATIONS
Work time Programmable (from 0 to 4 minutes)
Motor power Programmable on 50 levels
Motor speed Programmable on 10 levels
Programmability 3 configuration levels for greater flexibility
of use
Rapid connector 1 5-pin connector for Minidec radio board,
Decoder, RP/RP2
Programmable
outputs 4 programmable outputs in 19 different functions
Specifications Deceleration management, encoder,
multi-function display, BUS technology
and BUILT-IN METAL MASS DETECTOR

7
2Easy
OPEN
CLOSE
FSW
STOP
ALARM
GND +24
12 345678910 11 12 13 14 1516 17 18 19 20 21 22 23 24 25 26 27
+24
+24
+24
+24
OUT1
OUT2
OUT3
GND
LAMP
LOOP
BUS
LOOP 1 LOOP 2
Encoder
Relais
NO
COM
12
OUT4
OUT5
OUT6
GND
Fig. 2
Fig. 2
ENGLISH
4. ELECTRICAL CONNECTIONS
To connect the
photocells and safety
devices, refer
to paragraph 4.1.1
Released beam
Integrated
flashing
traffic light
4.1 Terminal board J1 (inputs)
OPEN - Open” command (N.O. - terminal 3): means any pulse
generator (e.g. button) which, by closing a contact, commands
opening and/or closing of the barrier.
CLOSE - Close” command (N.O. - terminal 4): means any pulse
generator(e.g.button) which, byclosinga contact, commandsclosing
of the barrier.
FSW - Safety contact when closing (N.C. - terminal 5): thepurpose
ofthe closing safeties is to protect thearea affectedby the movement
of the barrier during the closing phase, reversing its motion. They
never trip during the opening cycle.
Theclosing Safeties, ifengaged when theautomated systemis open,
prevent the closing movement.
If CLOSE safety devices are not connected, jumper
terminalsFSWandGND(Fig.26)andleavetheFAILSAFE
function (parameter o1 in Advanced Configuration) set
on the default value (disabled)
STP - STOP contact (N.C. - terminal 6): means any device (e.g.
button) which, by opening a contact, can stop movement of the
automated system.
If STOP safety devices are not connected, jumper
terminals STOP and GND (Fig. 26)
EMR - Emergency contact (N.C. - terminal 7): means any device
(e.g. switch) which, if activated in a situation of emergency, will open
thebarrier until the contact is restored. When activated, this input has
priority over any other command.
If emergency safety devices are not connected, jumper
terminals ALM and GND (Fig. 26)
GND (terminals 8-9) - Accessories power supply minus
+24 (terminals 10-11) - Accessories power supply plus
The maximum load of the accessories is 800mA. To
calculate absorption, refer to the instructions included
with the individual accessories.
4.1.1 Connecting the safety devices
TheE680 control boardfeatures an input for closing safety devices,
whichtrip during closing of theautomated system, provided to protect
the gate area from the risk of impact.
These devices must use a signal with “N.C.” contact, and must be
connected in series to the relay photocells that may be installed on
the system, as shown in Fig. 23 to Fig. 26.
Fig. 23: connection of one pair of closing photocells, with FAILSAFE
safety enabled: in addition to making the connection as
shown in the diagram, it is necessary to set in Advanced
Configuration
o1 = 00
Fig.24:connection of one pairofclosing photocells withoutFAILSAFE
safety
Fig.25: connection of two pairs of closing photocells without
FAILSAFE safety
Fig. 26: connection of no relay safety device
4.1.2 Connecting BUS photocells
Upto8 pairs ofphotocellscan be connectedto the E680 controlboard
using BUS technology. The connection must be made in parallel,
on terminal board J6, using a single power/communication line, as
shown in Fig. 27.

8
ENGLISH
Dip 1 Dip 2 Dip 3 Dip 4 Pair
no. Type
ON OFF OFF OFF 1° Pair
CLOSE
photocells
ON OFF OFF ON 2° Pair
ON OFF ON OFF 3° Pair
ON OFF ON ON 4° Pair
ON ON OFF OFF 5° Pair
ON ON OFF ON 6° Pair
ON ON ON OFF 7° Pair
ON ON ON ON Single OPEN
PULSE
DIP-SWITCH
TX DIP-SWITCH
RX
SAME
ADDRESS
BUS photocells do not require a matching polarity
connection.
The 8 pairs of photocells feature the following functions:
Pairs of closing photocells: max 7
Pairs of OPEN pulse photocells: max 1
After positioning the BUS technology photocells, it is necessary
to proceed with selecting the address for each pair using various
combinations of the DIP-SWITCHES located on each photocell.
Set the SAME DIP-SWITCH ADDRESS chosen both on
the transmitter and receiver of the same pair.
Ensure that two or more pairs of photocells do not have
thesameaddress.IfnoBUSaccessoriesareused,leave
terminals 1 and 2 free.
The following table describes how to set the dip-switches located
inside the transmitter and receiver of the BUS photocells.
Addressing BUS photocell PAIRS
To allow operation of the installed BUS accessories,
store them on the board as described in paragraph 5.3.
4.2 Terminal board J2 (outputs)
OUT 1 - Output 1 open-collector GND (terminal 13): The output
can be set in one of the functions described in the Advanced
Configuration (par. 6). The default value is 04
- Beam OPEN or in
PAUSE. Maximum load: 24 VDC with 100 mA.
OUT 2 - Output 2 open-collector GND (terminal 15): Theoutput can
beset in one ofthe functions describedin theAdvancedConfiguration
(par. 6). The default value is 03
- CLOSED BEAM. Maximum load:
24 VDC with 100 mA.
OUT 3 - Output 3 open-collector GND (terminal 17): Theoutputcan
beset in one ofthe functions describedin theAdvancedConfiguration
(par. 6). The default value is 19
- WARNING LAMP. Maximum load:
24 VDC with 100 mA.
OUT 4 - Relay output 4 (terminals 19, 20, 21): The output can be
set in one of the functions described inAdvanced Configuration (par.
6). The default value is 01
- BEAM ILLUMINATION. Maximum load:
24 VDC with 800 mA.
4.3 Terminal board J3 (external flashing lamp)
LAMP: to these terminals you can connect a 24VDC FAACLED
external flashing lamp. The integrated flashing traffic light must be
connected independently to connector J15.
The 24V FAACLIGHT with incandescent lamp cannot be
connected to the J3 connector
4.4 Terminal board J4 (loop detector)
LOOP 1: magnetic loop LOOP 1 (OPEN, terminals 24-25): for
OPENING.
LOOP2: magnetic loopLOOP2 (SAFETY/CLOSE,terminals 26-27):
for SAFETY/CLOSING.
4.5 Connector J5 (Motor)
Rapid connector for connecting the motor.
4.6 Connector J7 (Encoder)
TheB680H barrier isequipped with adevice for detectingthe opening
angle/bar position to ensure greater anti-crushing safety thanks to
the possibility of reversing the direction of movement the moment in
which an obstacle is detected. This device interfaces with the board
through connector J7.
4.7 Connector J10 (Radio)
Used for the rapid connection of the Minidec, Decoder and RP / RP2
Receivers (see Fig. 28). If a 2-channel receiver is used, like the RP2,
it will be possible to directly command automated system OPEN and
CLOSEfroma 2-channel radiocontrol.If a 1-channelreceiveris used,
like the RP, it will only be possible to command OPEN.
Boards should be inserted and removed ONLY after
having cut off electrical power
4.8 Connector J11 (Beam break-out sensor)
Designed for connecting the break-out sensor for the pivoting beam
(if present). The sensor is optional. If it is not present, do not remove
the installed jumper.
4.9 Connector J12 (Emergency battery)
This connector is for connecting a battery (optional) for ensuring
automated system operation in case of temporary cut off of the main
power supply.
4.10 Connector J13 (36VDC Power Supply)
This factory-wired connector powers the E680 board.
The terminal shown in Fig. 1 ref. a must be connected
to the system earth by the installer during the electrical
connection operations.
4.11 Connector J15 (flashing traffic light)
This connector is for connecting the flashing traffic light built into
the barrier head. The flashing traffic light visually signals barrier
movement and, if needed, regulate access to the property using
traffic light signals.
4.12 Connector J16 (beam lights)
Connector which allows the rope light for the rod to be connected,
providing visual warning of barrier movement. The connector has a
common GND connection and two +36V (BLR / BRG) outputs. The
defaultvalueis02- “BEAM LIGHTINGTYPE2” for OUT5, 04 - “BEAM
OPEN OR PAUSED” for OUT 6.
5. PROGRAMMING
The E680 board features 3 programming levels that make it entirely
configurable and allow it to adapt the logics to any use.
Each of the three levels can be accessed through a specific key
combination.
Changes to the configuration parameters become
effective immediately, while final storage occurs
only upon exiting configuration and returning to the
automated system status display. If the equipment is
powereddownbeforereturningtotheautomatedsystem
status display, all changes made will be lost.

9
ENGLISH
5.1 Basic configuration
To perform BASIC programming:
1. Press and hold button F; the name of the first function is
displayed.
2. Release the button; the function value is displayed and can be
modified using the + and - buttons.
3. Press and hold Fagain; the name of the following function is
displayed, and so on.
Thelast function St lets youchoose whether to save theconfiguration
made (Y) or exit without saving (no). Later, the display will resume
showing the automated system status
You can go to St at any time. To exit programming,
simultaneously press F and -.
BASIC CONFIGURATION
Display Function Default
cF Barrier configuration
01 Minimum mass
06 Maximum mass
Before automated system start-up, you must
set the correct value, directly correlated to
the length of the beam and the number and
type of accessories installed. To determine
saidvalue, refer to Tables 4 and 5 on page 25
WARNING: Setting a mass default
lower than the one actually
installed could cause irreversible
damage to the bar and barrier
structure.
Loading a different configuration
will reset the parameters to the
default values
06
dF Default
Yindicates that all values set correspond
to the defaults
no indicates that one or more set values
are different from the defaults. Select
Yto restore the default configuration.
Y
Ct Master / slave configuration
MA Configures the board in master mode
SL Configures the board in slave mode
For details on MASTER / SLAVE
configuration, refer to section 9.
MA
bu BUS accessories menu
For functions associated with this parameter
see paragraph 5.3
no
Display Function Default
LO Operating logics
A Automatic
A1 Automatic 1
E Semi-automatic
P Parking
PA Automatic parking
Cn Condo
CA Automatic condo
C Dead-man
CU Custom
E
PA Pause time
Iseffectiveonly if an automatic logicischosen;
the value can be set from Oto 59 sec. in
one second steps. Next, the display changes
tominutes and tenths of a second (separated
by a decimal point) and time is adjusted in
10-second steps up to the maximum value
of 4.1 minutes.
e.g. if the display shows 2.5, the pause time
will be 2 minutes and 50 seconds.
20
So Opening speed
Adjusts the barrier opening speed.
00 Minimum speed
10 Maximum speed
WARNING: Setting an excessive speed
could cause irreversible damage to the
beam and barrier structure.
10
Sc Closing speed
Adjusts the barrier closing speed.
00 Minimum speed
10 Maximum speed
WARNING: Setting an excessive speed
could cause irreversible damage to the
bar and barrier structure.
02
L1 Loop 1
Activating this parameter, any loop that is
connected to the Loop 1 input will serve as
an OPEN function.
Y Loop 1 enabled
no Loop 1 disabled
Note: Should this function be disabled, the
detection status of the loop will in any case
remain available on one of the two outputs,
if configured (see parameters o1... o4 in
Advanced Configuration)
no
L2 Loop 2
Activating this parameter, any loop that is
connected to the Loop 2 input will serve as a
SAFETY/CLOSE function.
Y Loop 2 enabled
no Loop 2 disabled
(see note regarding Loop 1)
no

10
ENGLISH
Display Function Default
S1 Loop 1 sensitivity
Adjuststhe sensitivity of the vehicle detection
loop
00 Minimum sensitivity
10 Maximum sensitivity
05
S2 Loop 2 sensitivity
Adjuststhe sensitivity of the vehicle detection
loop
00 Minimum sensitivity
10 Maximum sensitivity
05
Mt Motor movement
Using the function provided by this para-
meter makes it possible to manually move
the barrier bar, operating as dead-man.
Pressing + will open the automated system,
pressing - causes the automated system to
close.
oP pressing +, open
cL pressing -, close
--
tL Learning
Working time and limit switch learning (see
section 7.2)
--
St AUTOMATED SYSTEM STATUS:
Thisallows you tochoose whether toquit the programme
and save the data.
Y= quit and save the data
no = quit without saving the data
On quitting the programme, press the Fkey to display
the status of the automated system
00 Beam closed
01 Beam open
02 Stationary ready to open
03 Stationary ready to close
04 Automated system paused
05 Opening
06 Closing
07 Failsafe in progress
08 2-EASY device verification in progress
09 Pre-flashing then OPENS
10 Pre-flashing then CLOSES
11 EMERGENCY Open
You can go to St at any time by simultaneously
pressing F and -.
Displayingof the automated system statusSt is extremely
important for the installing/maintenance technician in order
to distinguish the logical processes that the board carries
out during movement.
If, for example, the automated system status is CLOSED,
the display MUST read 00. When the OPEN command is
received, the display will change to 09, if pre-flashing is
enabled, or directly to 05 (the OPENING movement) to
then display 01 once the position of gate OPEN is reached).
Exampleof a statussequence displayed startingfroma closed barrier
The sequence does not include statuses 09 and 10 which
correspond to pre-flashing when opening and closing,
respectively.
5.2 Changing the predefined parameters set
The E680 board features six sets of pre-defined configurations that
allow rapid adapting to the size of the beam installed, making it the
startingpoint fora fine adjustment of the parameters. To selectone of
the available configurations, it is necessary to change the parameter
cF from the default value of 06 to that corresponding to the barrier
configuration(beamlength, type andquantityof accessories installed)
giveninTable 4orTable 5 onpage25 (for example,choosethe default
04 for a beam L of 5 metres with lights and foot).
To complete configuration, it is necessary to exit the Basic
Configuration menu by pressing “F” until parameter St is reached
or by pressing “F” and “-”
This operation changes the value of the parameters
So and SC in Basic configuration and FO, FC, oc
in Advanced configuration, setting them on the default
values as shown in the tables in paragraph 6.3.
Unliketheotherparameters,thevalueofstepdF isnotstored,
thusallowingaccesstothemenuthroughaneutralcondition,
which is the one displayed every time the configuration
menu is opened..
If you do not wish to load any set of pre-defined parameters, leave
parameter St on 00 and press “F” to go on to the next parameter
Setting a set of pre-defined parameters that does not
correspondtotheactualconfigurationofthebarriercould
cause irreversible damage to the automated system, in
particular if the default corresponds to a beam length
shorter than the actual one.
00 Beam closed 05 Opening
01 Beam open /
04 Pause 06 Closing

11
FSW-CL FSW-OPEN
Fig. 3
Fig. 3
ENGLISH
5.3 BUS accessories menu
The E680 board is designed to connect up to 8 pairs of BUS
photocells. For the bus devices connected to the E680 board to be
detected and managed by it, they must be stored on the board. To
do this, proceed as follows:
• cut off power from the board.
• install and program the accessories using the desired address,
depending on the function you wish to use (as described in
paragraph 4.1.2)
• power up the board.
• access Basic Configuration, as described in paragraph 5.1
• once programming step
bu is reached, no, will be displayed,
indicating that here are no stored bus devices.
• to perform entry, simultaneously press and hold the + and -
buttons for at least 5 seconds (during this time, the writing no
will flash)
• oncethe procedure iscompleted, Y will appear as confirmation.
• when + and - are released, the display will show the current
statusof the BUSdevices, or no again, ifthere are noconnected
BUS devices.
Thefollowing image (Fig.3) shows thecorrespondence of thevarious
display segments to the different types of BUS devices that can be
connected to the system:
FSW CL: BUS photocells placed to protect the gate
closing area
OPEN: BUS photocells used as OPEN pulse generators
From the display of the status of the BUS devices, pressing the + key
enables the types of BUS devices present to be verified.
For example, the following photograph shows safety devices present
during closing and a pair of photocells functioning as open pulse:
Fortheautomatedsystem to operatecorrectly,the status
of the segments of the left-hand digit must correspond
to the automated system at rest and without pulse
generators or or safeties engaged.
When the CLOSE photocells are engaged, the bottom
segments will go on, as shown in the image to the side.
If the pair of OPEN pulse generator photocells is
engaged, the display will show the configuration of
segments shown in the image on the side of the page,
in which the corresponding vertical segment is on, and
will remain like this until the photocells are disengaged.
If involved, the pair of OPEN pulse generator photocells
commands opening of the automated system and
prevents it from closing until it is disengaged, like a
normal OPEN pulse received through terminal board
J1 (terminal 3).
The BUS communication system uses a self-diagnostic function able
to provide connection error signals or BUS accessories configuration
error signal.
The display will show a flashing cc if there is a
short circuit along the BUS line, as shown in the
figure. To solve the problem it is necessary to
carefully verify all the connections made.
The display will show a flashing Er as shown
in the image on the side of the page, should
more than one pair of photocells have the
same adress and in case of a calling or failsafe
error. Ensure that the settings are correct, with
reference to the indications given in paragraph
4.1.2
The status of the BUS and related input signals can also be seen by
analysing the two LEDs DL1 (red) and DL2 (green), which make it
possible to immediately verify if BUS communication is active or if
there is an error, and if there are any active inputs or not. The status
The LED states refer to the tables on the following page.
J6
DL1 DL2
2Easy BUS
21
Bus status (always on)

12
ENGLISH
DL1 LED description (Red)
On At least one of the inputs (safeties, OPEN pulse) is
engaged or active
Off No OPEN input is active and no safety device is
engaged
DL2 LED description (Green)
On
fixed Normallyactive(LED on evenifthere are nodevices connected)
Off BUS-2EASY line short-circuited (flash every 2.5
sec.)
Rapid
flashing An error has been detected in the BUS-2EASY connection; repeat the acquisition procedure. If the
error persists, check that:
• the system does not have more than one
accessory with the same address (see also
instructions regarding the accessories)
• make sure there is no calling error (number of
devices connected is greater or less than that
stored during setup)
6. Advanced Configuration
To access Advanced Configuration, press Fand, while holding it,
also press +:
• when
+is released, the number of the first available function
will appear
• when Fis also released, the value is displayed, and can be
changed using +and -
• pressing Fagain, and holding it, the name of the next parameter
will be displayed; when released, the value can be changed
using +and -
• once the last function has been reached, pressing Fmakes it
possibletoeither save thepreviouslychanged parameters or exit
without saving the changes; the display will go back to showing
the status of the inputs.
ADVANCED CONFIGURATION
Display Function Default
FO Opening motor power
Adjusts the thrust of the motor during the ope-
ning phase.
00 Minimum power
50 Maximum power
40
FC Closing motor power
Adjuststhethrust of themotor during theclosing
phase.
00 Minimum power
50 Maximum power
40
PF Pre-flashing
This parameter is used to activate the flashing
lamp for 5 seconds before the selected
movement.
no disabled
OC before each movement
CL before each closing movement
OP before each opening movement
PA only at the end of the pause
no
Display
Function Default
tP Pre-flashing time
Pre-flashing time expressed in seconds.
00 minimum pre-flashing
10 maximum pre-flashing
00
oc
Sensitivity of obstacle during closing
This determines the sensitivity to an obstacle
before reversing takes place.
01 Minimum sensitivity
50 Maximum sensitivity
30
o1 Output 1
Setting this function makes it possible to modify
the signal type of output 1, allowing high
connection flexibility with external devices.
00 Failsafe
01 TYPE 1 BEAM ILLUMINATION (output
active when beam closed, disabled
with bar open or paused, intermittent
when moving). Use only with output
4!
02 BAR LIGHTING TYPE 2 (flashing
output during opening, closing and with
rod closed or stopped. inactive with rod
open or paused).
03 Beam CLOSED
04 Beam OPEN or in PAUSE, it goes off
during closing pre-flashing.
05 Beam in OPENING MOVEMENT,
including pre-flashing.
06 Beam in CLOSING MOVEMENT,
including pre-flashing.
07 Beam STATIONARY
08 Beam in EMERGENCY mode
09 LOOP1 engaged
10 LOOP2 engaged
11 OPEN for E680 slave
12 CLOSE for E680 slave
13 Beam RELEASED
14 Not used
15 Not used
16 FCA engaged
17 FCC engaged
18 Interlock
19 WARNING LAMP (on during opening
and pause, flashing when closing, off
when the automated system is closed)
20 Battery operation
04

13
ENGLISH
Display
Function Default
P1 Output 1 Polarity
Allows setting of the output polarity:
Y output NC
no output NO
NOTE: if the output setting is 00 (Failsafe),
keep the value set to no
no
o2 Output 2
Output 2 signal type, see “Output 1”03
P2 Output 2 Polarity
Output 2 polarity, see parameter regarding
“Output 1 Polarity”no
o3 Output 3
Output 3 signal type, see “Output 1”19
P3 Output 3 Polarity
Output 3 polarity, see parameter regarding
“Output 1 Polarity”no
o4 Output 4
Output 4 signal type, see “Output 1”01
P4 Output 4 Polarity
Output 4 polarity, see parameter regarding
“Output 1 Polarity”no
o5 Output 5
Output 5 signal type, see “Output 1” 02
P5 Output 5 polarity
Output 5 polarity, see parameter for “Output
1 polarity” no
o6 Output 6
Output 6 signal type, see “Output 1” 04
P6 Output 6 polarity
Output 6 polarity, see parameter for “Output
1 polarity” no
o7 Integrated flashing lamp operating mode
Lets you choose between two operating modes
for the integrated flashing lamp (if present)
connected to output J15.
01 “Traffic light” mode (steady green
when paused/open, flashing red when
moving, steady red when closed)
02 ”Flashing lamp” mode (flashing red
when bar is moving, off in all other
cases)
01
AS Service request (linked to the following
two functions):
If activated, at the end of the countdown
(which can be set with the two following “Cycle
Programming” functions) it activates the LAMP
output for 4 sec every 30 sec (service request).
It can be useful for setting programmed
maintenance work.
YActive
no Disabled
no
Display
Function Default
nc Cycle programming in thousands:
Is used to set a countdown of the system
operation cycles; the value can be set from
0 to 99 (thousands of cycles). The value
displayed is updated with the succession of
the cycles, interacting with the value of nC (99
decrements of nc correspond to 1 decrement
of nC).
The function can be used, together with nC,
to verify the use of the system and for use of
“Service Request”.
00
nC Cycle programming in hundreds of
thousands:
Is used to set a countdown of the system
operation cycles; the value can be set from 0
to 99 (hundreds of thousands of cycles). The
value displayed is updated with the succession
of the cycles, interacting with the value of
nc. (1 decrement of nC corresponds to 99
decrements of nc).
The function can be used, together with nc,
to verify the use of the system and for use of
“Service Request”.
01
St AUTOMATED SYSTEM STATUS:
Thisallows you tochoose whether toquit theprogramme
and save the data.
Y= quit and save the data
no = quit without saving the data
On quitting the programme, press the Fkey to display
again the status of the automated system.
You can go to St at any time by simultaneously
pressing F and -
6.1 Configuring the loop detector
The E680 board features an integrated metal mass detector for the
induction detection of vehicles.
6.1.1 Specifications:
• Galvanic separation between the detector electronics and the
loop electronics
• Automatic alignment of the system immediately following
activation
• Continuous resetting of the frequency drifts
• Sensitivity independent of loop inductivity
• Adjustment of the loop work frequency with automatic selection
• Occupied loop message with LED display
• Loop status addressable on outputs
6.1.2 Connection:
Connect the loops according to the layout on page 7, Fig. 2
- Terminals 24 - 25 for LOOP 1 = loop with gate opening function;
- Terminals 26 - 27 for LOOP 2 = loop with closing and/or safety
when closing function.
Formoreinformationontheeffectoftheloopsignalsontheautomated
system, refer to the logics tables in paragraph 10 “OPERATING
LOGICS TABLE”.
To enable the functionality of the connected loops, enter Basic
configuration mode and set parameters L1 and L2 on Yconsistently
with the number and type of connected loops. If only one loop is
installed, enable only the corresponding programming step.
The loop detector operating status is indicated by the DL3 and DL4
status LEDs.

14
8 mm
30-50 mm
~ 1 m
ENGLISH
6.1.3 Calibration
Each time the E680 board is powered, the integrated loop detector
performs a calibration of the connected loops. Therefore, you can
perform calibration by cutting off power to the board for at least 10
seconds and then reconnecting it.
Fromthebarrier status display,you can press,atany time, SW4/CAL1
to calibrate the loop connected to the LOOP 1 input or SW5/CAL2 to
calibrate the loop connected to the LOOP2 input.
Calibration is highlighted by the board diagnostics by flashing LEDs
DL3 and DL4, and when calibration is completed, they will indicate
the loop detection status, if connected.
The other signals provided by the board diagnostics are described
in the following table:
DL3
DL4
LOOP 1
LOOP 2
22 224567
If one or both magnetic loops are not installed, the loop
detector, following a first attempt to calibrate, will keep
the status LEDs flashing every 5 seconds (as shown in
the above table)
LED Status LOOP Status
Off Loop clear
On Loop engaged
Flashing (0.5 s) Loop calibration
in progress
Rapid flashing Loop short circuit
Slow flashing
(5 s) No loop or loop interrupted
Two flashes (every 5 s) Non-conforming loop
(heater or inductance
out of range)
6.1.4 Adjusting sensitivity
By adjusting the sensitivity of the loop detector, you determine the
variation of inductivity, for each channel, that a vehicle must cause in
order to activate the corresponding detector output.
Sensitivity is adjusted separately for each channel using the two
parameters S1 and S2 in Basic configuration
6.1.5 Making the loops
The loop must be laid at least 15 cm from fixed metal objects, at least
50 cm from moving metal objects and no more than 5 cm from the
surface of the final paving.
Use a standard unipolar cable measuring 1.5 mm² in diameter (if
the cable is laid below ground level directly, it must have double
insulation).Makea preferably squareor rectangular loopby preparing
a PVC cable duct or by tracing the paving, as shown in figure 16 (the
corners must be cut at a 45° angle to avoid cable breaks). Lay the
cable using the number of windings shown in the table. The two ends
of the cable must be twisted together (at least 20 times per metre)
from the loop to the E680 board.Avoid splicing a cable (if necessary,
weldtheconductors and seal thespliceusing a heat-shrinkingsheath)
and keep it separate from the mains power lines.
Loop
Perimeter Nr. of Windings
less than 3 m 6
from 3 to 4 m 5
from 4 to 6 m 4
from 6 to 12 m 3
more than 12 m 2
6.2 Expert Configuration
EXPERT configuration is used only in the event that operation logics customisation is already stored.
Before making changes at this level, be certain that the steps you wish to change and their effect on the automated
system are fully understood.
Changing the third-level parameters involves indicating the CU value on the LO parameter of the first-level programming
To access EXPERT configuration, press F and, holding it, press + for approximately 10 seconds.
The use of F, +and -in this menu is the same as in the other two programming levels
“EXPERT” CONFIGURATION 10 sec
Display.Function Setting
01 If this function is activated, automatic closing occurs after the pause time. Y= automatic closing
no = disabled
02 If this function is activated, two distinct input operation mode is obtained: OPEN for
opening and CLOSED for closing. Y= 2-input operation
no = disabled
03
Activation of recognition of the OPEN and CLOSE input levels (maintained command).
That is to say, the board recognises the level (if, for example, with OPEN held, you press
STOP, when the latter is released, the automated system will continue to open). If 03 is
disabled the board commands a manoeuvre only if there is an input variation.
Y= level recognition
no = status variation
recognition
04
Activation of DEAD-MAN opening (command always pressed). Releasing the OPEN
command will stop operation
Y= active
no = disabled

15
ENGLISH
05
When this function is activated, the OPEN command during opening will stop movement.
If parameter 06 is no the system is ready for opening.
If parameter 06 is Ythe system is ready for closing.
Y= when opening it stops
no = disabled
06 When this function is activated, the OPEN command during opening reverses movement.
If parameters 05 and 06 are no OPEN will have no effect during opening. Y= when opening it reverses
no = disabled
07 When this function is activated, the OPEN command during pause stops operation.
If parameters 07 and 08 are no OPEN resets the pause time Y= when in pause it stops
no = disabled
08 When this function is activated, the OPEN command during pause causes closing.
If parameters 07 and 08 are no OPEN resets the pause time. Y= when in pause it closes
no = disabled
09 When this function is activated, the OPEN command during closing stops operation,
otherwise it reverses movement. Y= stops
no = reverses
10 Activation of DEAD-MAN closing (command always pressed). Releasing the CLOSE
command will stop operation Y= active
no = disabled
11 When this function is activated, the CLOSE command has priority over OPEN, otherwise
OPEN has priority over CLOSE. Y= active
no = disabled
12 When this function is activated, the CLOSE command commands closing when released.
As long as CLOSE is activated, the unit stays in closing pre-flashing. Y= closes when released
no = closes immediately
13 When this function is activated, the CLOSE command during opening stops operation,
otherwise the CLOSE command commands reverse immediately or when opening is com-
pleted (see also parameter 14)
Y= CLOSE stops
no = CLOSE reverses
14 Whenthisfunctionisactivated,andifparameter13 isno,theCLOSEcommandcommands
immediate closing at the end of the opening cycle (stores CLOSE). If parameters 13 and 14
are no CLOSE commands immediate closing.
Y= closes at the end of
opening
no = immediate closing
15 When this function is activated, with the system blocked by a STOP, a next OPEN
moves in the opposite direction. If parameter 15 is no it always closes.
Y= moves in the opposite
direction
no = always closes
16 When this function is activated, during closing, the CLOSING SAFETIES stop and allow
motion to resume when they are disengaged, otherwise they immediately reverse opening. Y= closes when disengaged
no = immediate reverse
17 When this function is activated, the CLOSING SAFETIES command closing when they are
disengaged (see also parameter 18).
Y= closing when FSW
is disengaged
no = disabled
18 When this function is activated, and if parameter 17 is Y, the unit will wait for the
opening cycle to end before executing the closing command provided by the
CLOSING SAFETIES.
Y= closes at the end of
opening
no = disabled
19 When this function is activated, during closing, LOOP2 stops and allows motion to resume
when it is disengaged, otherwise it immediately reverses opening. Y= closes when disengaged
no = immediate reverse
20 When this function is activated, LOOP2 commands closing when it is disengaged (see also
parameter 21). Y= closes if LOOP2 is clear
no = disabled
21 When this function is activated, and if parameter 20 is Y, the unit will wait for the opening
cycle to end before executing the closing command provided by LOOP2.
Y= closes at the end of
opening
no = disabled
22 When this function is activated: in case of a blackout, once electrical power has been
restored, if an OPEN command is not active the automated system recloses immediately. Y= active
no = disabled
23 LOOP 1 commands opening and, once completed, it closes if disengaged (useful in case
of vehicle backing-up with consecutive loops). If disabled, when LOOP 1 is disengaged, it
does not close.
Y= closes if LOOP1 clear
no = disabled
24 When this function is activated, an open or close command is only carried out after
the safeties have been disengaged. Y= active
no = disabled
25
A.D.M.A.P. function
When this function is activated, the result is operation of safeties compliant with French
regulations.
Y= active
no = disabled
26
When this function is activated, the CLOSING SAFETIES during closing stop and reverse
movement when they are disengaged, otherwise they reverse immediately.
Y= stops and reverses when
disengaged.
no = reverses immediately.
27
DO NOT CHANGE no
28
DO NOT CHANGE no
29
DO NOT CHANGE no
30 When this function is activated, the LOOP1 commands are prioritised rather than the
LOOP2 commands. Y= active
no = disabled

16
ENGLISH
A0
HOLD CLOSE / HOLD OPEN function
When this function is activated, the automated system will monitor the position of the beam
at set intervals (see parameter
A1 ). If the beam is not completely closed or completely open
(depending on the logical condition of the board), the automated system will command a
CLOSE or OPEN movement to bring the beam back to the correct position, for a maximum
of 3 seconds. If, when the 3 seconds have elapsed, the bar does not go back to completely
closed/open position (e.g. because the bar is blocked), the function will be disabled until the
next OPEN command is received.
Y
A1
HOLD CLOSE / HOLD OPEN function activation time
This parameter indicates the time interval between two activations of the HOLD OPEN /
HOLD CLOSE function, expressed in minutes. (from 00 to 99)
60
r1 Loop 1 frequency reading
This menu item lets you verify the reading of the current oscillation frequency of the loop
connected to the Loop 1 input. The indication should be read as follows:
First digit: tens (kHz)
Second digit: units (kHz)
Decimal point: hundreds (kHz)
For example, the reading 05. refers to a reading of 105 kHz
Read-only parameter
r2 Loop 2 frequency reading
This menu item lets you verify the reading of the current oscillation frequency of the loop
connected to the Loop 2 input. (see parameter r1 for explanations on how to read the
indicated value)
Read-only parameter
F1 Loop 1 frequency selection
This parameter lets you set an oscillation frequency specific to the loop connected to the
Loop 1 input, or lets the system choose the most adequate setting among the 4 available.
AAutomatic selection
1-2-3-4 Frequency 1-2-3-4
Note: When you exit the Advanced configuration menu after having changed the loop
operation frequency setting, the system will be recalibrated. This will provide an updated
frequency reading once you re-enter the menu to consult the values of parameters r1 or
r2
A
F2 Loop 2 frequency selection
This parameter lets you set an oscillation frequency specific to the loop connected to the
Loop 2 input, or lets the system choose the most adequate setting among the 4 available.
AAutomatic selection
1-2-3-4 Frequency 1-2-3-4
Note: When you exit the Advanced configuration menu after having changed the loop
operation frequency setting, the system will be recalibrated. This will provide an updated
frequency reading once you re-enter the menu to consult the values of parameters r1 or
r2
A
h1 LOOP 1 holding time
Is used to set presence time on loop 1. When this time has elapsed, the board will self-
calibrate and signal “loop clear” (LED DL3 off). When the board is turned on, an automatic
reset is carried out.
Y5 minutes
no infinite
no
h2 LOOP 2 holding time
Is used to set presence time on loop 2. When this time has elapsed, the board will self-
calibrate and signal “loop clear” (LED DL4 off). When the board is turned on, an automatic
reset is carried out.
Y5 minutes
no infinite
no

17
ENGLISH
H1 Loop 1 articulated lorry function
This function lets you increase the level of sensitivity at the time of detection, to allow correct
detection even in case of very tall vehicles or during the transit of a tractor and trailer.
Yenabled
no disabled
Y
H2 Loop 2 articulated lorry function
This function lets you increase the level of sensitivity at the time of detection, to allow correct
detection even in case of very tall vehicles or during the transit of a tractor and trailer.
Yenabled
no disabled
Y
tWork time (time-out)
Maximum work time of the automated system before the motor stops, if the open or close
position is not reached. The value can be set from Oto 59 sec. in one second steps. Next,
the display changes to minutes and tenths of a second (separated by a decimal point) and
time is adjusted in 10-second steps up to the maximum value of 4.1 minutes.
30
dr Red light brightness (OUT 5)
Changing this value increases or decreases the output voltage for OUT 5, changing the
brightness of the rope light.
04
dG Green light brightness (OUT 6)
Changing this value increases or decreases the output voltage for OUT 5, changing the
brightness of the rope light.
04
St
STATUS OF THE AUTOMATED SYSTEM:
Exit from programming, storage of data and automated system status display.
6.3 Pre-Defined Parameter Sets
The table below shows, for each set of pre-defined parameters, the
values that they will load in the board memory.
Basic Configuration
cF 01 02 03 04 05 06
dF YYYYYY
Ct MA MA MA MA MA MA
bu no no no no no no
LO EEEEEE
PA 20 20 20 20 20 20
So 10 10 10 10 10 10
Sc 10 05 05 04 02 02
L1 no no no no no no
L2 no no no no no no
S1 05 05 05 05 05 05
S2 05 05 05 05 05 05
Advanced Configuration
The following table shows, for each set of pre-defined parameters,
the values that they will load in the board memory, in advanced
configuration.
cF 01 02 03 04 05 06
FO
25 25 30 28 30 40
FC
25 25 30 28 30 40
PF
no no no no no no
tP
00 00 00 00 00 00
oc
30 30 30 30 30 30
FS
no no no no no no
o1
04 04 04 04 04 04
P1
no no no no no no
o2
03 03 03 03 03 03
P2
no no no no no no
o3
19 19 19 19 19 19
P3
no no no no no no
o4
01 01 01 01 01 01
P4
no no no no no no
o5
02 02 02 02 02 02
P5
no no no no no no
o6
04 04 04 04 04 04
P6
no no no no no no
o7
01 01 01 01 01 01
AS
no no no no no no
nc
00 00 00 00 00 00
nC
00 00 00 00 00 00

18
J6
J12
J11 J14
J7
+
-
F
S
W
1
S
W
2
SW
3
J15
J1 J2 J3 J4
D
L
1
D
L
2
D
L1
0
D
L1
1
D
L1
2
D
L1
3
D
L14
DL18
DL17
D
L
5
D
L
6
DL9
D
L
3
DL4
D
L1
5
2
Eas
y
BU
S
O
PE
N
CL
O
S
E
FS
W
ST
OP
EMR
G
ND
+2
4
3
4
5
6
7
8
9
1
0
1
1
1
2
1
3
1
4
1
5
1
6
1
7
1
8
1
9
2
0
2
1
2
2
2
3
2
2
+2
4
+2
4
+2
4
+2
4
OU
T
1
OU
T
2
OU
T
3
Rel
G
ND
LAMP
LOO
P
1
LOO
P
2
BATTERY
E
NC
O
DE
R
D
I
S
P
1
DL7
DL8
D
L1
6
S
W4
1
2
2
2
4
5
6
7
Rel
Rel
Rel
ay
N
O
ay NO
Rel
ay
C
OM
J16
S
W
5
J10
OU
T
5
OU
T
6
Fig. 4
Fig. 4
ENGLISH
6.4 “Expert” default parameters
Thefollowing table containsthe pre-defined settingsthat characterize
the various operation logics.
Step AA1E PPACnCaC
01 YYNNYNYN
02 NNNYYYYY
03 NNNNNNNN
04 NNNNNNNY
05 NNYNNNNN
06 NNYNNNNN
07 NNNNNNNN
08 NNNNNNNN
09 NNNNNNNN
10 NNNNNNNY
11 NNNNNNNN
12 NNNYYNNN
13 NNNNNNNN
14 NNNYYYYN
15 NNNNNNNN
16 NNNYYNNN
17 NYNNNNNN
18 NYNNNNNN
19 NNNYYNNN
20 NYNYYYYN
21 NYNYYYYN
22 NNNNNNNN
23 NNNYYNNN
24 NNNNNNNN
25 NNNNNNNN
26 NNNNNNNN
27 NNNNNNNN
28 NNNNNNNN
29 NNNNNNNN
30 NNNNNYYN
7. START-UP
7.1 Verifying the diagnostic LEDs
Before starting up the board, it is necessary to verify that the status
of the diagnostic LEDs corresponds to the logic. Said status must
coincide with the indications in Fig. 4, situation which reflects that of
an automated system that is CLOSED and ready to open.
TheFSW,STOPandALARM LEDs aresafetyinputs with
NC contacts, therefore the related LEDs must be ON
when the automated system is at rest, and go off when
the device connected is engaged.
The OPEN and CLOSE inputs are NO contact inputs,
therefore the related LEDs must be OFF when the
automated system is at rest, and go on when the device
connected is active.
TheBUSstatusmustcorrespondtoDL2(green)onfixed
and DL1 (red) off. The BUS menu of the
Basic configuration must display the
indicationshowntothesideconfirming
the fact that there are no engaged
photocells or active pulse generators.
7.2 Setup
Before being put into operation, the E680 board requires a setup
procedureduringwhichthe automated systemdeterminestherotation
angle of the beam and consequently its travel. These measurements
allow correct management of motor decelerations and acceleration
ramps.
Atfirst start-up theboardwill signal theneedfor a setup
cycle, by displaying a flashing S0.
For setup, proceed as follows:
1. Usingthe parameter “Mt”inBasic configuration mode,check that
theopening /closing movementcorresponds tothe pressedkey
(+/-);ifnot,go to the motor wiringandreversethetwoconductors
L1 and L3, as shown in Fig. 14, Ref. 
2. Bring the automation system to the fully closed position with the
“Mt” parameter of the Base configuration level or by operating
the release device as indicated in sections 6 and 7 on page 4.
3. Access Base programming and repeatedly press the Fbutton
until you reach the parameter tL, then press the +and -buttons
at the same time until the automation system begins opening
slowly.
During setup, a flashing -- indication will appear on the
display.
4. On reaching the fully open position, the automation system will
stop automatically.
5. The automation system will then begin the beam closing
movement.
6. On reaching the closed position, the automation system will
stop automatically.
7. Press the Fbutton to exit the procedure, and confirm you wish
to save the data with the parameter St. Check that the status
of the automation system shown on the display is 00 (closed)
and that the rod is in the closed position. If the rod is open and
the display is showing 00, check / adjust the correct direction
of movement of the motor again as in step 1 of the procedure.
8. TESTING THE AUTOMATED SYSTEM
Onceprogramming is completed, ensure that the systemis operating
correctly.
Verifyespeciallythe correct regulationofthe automated system power
andcorrectoperation of thesafetydevices it isconnectedto and verify
that the automated system conforms to current safety standards.
