SEA SURF 350 Reversible User manual

ELECTROMECHANICAL SWING GATE OPERATOR
International registered trademark n. 2.777.971
REV 06 - 02/2020
SURF 350 - SURF 450
SURF K
67410720

International registered trademark n. 2.777.971
IMPORTANT SAFETY INFORMATION
All the above described operations must be made exclusively by an authorized installer
Clean and grease parts in movement (wheels,
counter-connecting rod, release, etc.)
Check for corroded parts and replace if
necessary
Check if the screws and all mounting
hardwares are properly tighten
Annual
Annual
Annual
Check the conditions of wear and tear of the
devices in movement
Check the correct drain of the rainwater
Check the integrity of the connection cables
Annual
Annual
Annual
Inspect the track for any signs of cracking or
separation
Ensure that the gate moves freely
Annual
Annual
Check and confirm the proper operation of all
safety devices (photocells, edge sensors etc)
Check and confirm the operation of all
installed accessories
Check and confirm the operation of the
manual release
Annual
Annual
Annual
TURNING ON THE POWER
Check the battery conditions and be sure that
connections are free of corrosion
Verify the functionally of the battery backup,
or power failure option
BY MAIN POWER SOURCE TURNED OFF
Annual
TURNING OFF THE POWER
CCCC
GENERAL SAFETY PRECAUTIONS
The following precautions are an integral and essential part of the product and must be supplied to the user Read
them carefully as they contain important indications for the safe installation, use and maintenance.
1. These instruction must be kept and forwarded to all possible future users of the system.
2. This product must be used only for that which it has been expressly designed.
3. Any other use is to be considered improper and therefore dangerous.
4. The manufacturer cannot be held responsible for possible damage caused by improper, erroneous or
unreasonable use.
5. Avoid operating in the proximity of the hinges or moving mechanical parts.
6. Do not enter the path of the moving gate while in motion.
7. Do not obstruct the motion of the gate as this may cause a situation of danger.
8. Do not allow children to play or stay within the path of the moving gate.
9. Keep remote control or any other control devices out of the reach of children, in order to avoid possible involuntary
activation of the gate operator.
10. In case of break down or malfunctioning of the product, disconnect from the main power source.
Do not attempt to repair or intervene directly, contact only qualified personnel for repair.
11. Failure to comply with the above may create a situation of danger.
12. All cleaning, maintenance or repair work must be carried out by qualified personnel.
13. In order to guarantee that the system works efficiently and correctly it is important to have the manufacturer's
instructions on maintenance of the gate and operator carried out by qualified personnel.
14. In particular, regular checks are recommended in order to verify that the safety devices are operating correctly.
All installation, maintenance and repair work must be documented and made available to the user.
IMPORTANT SAFETY INSTRUCTIONS
WARNING – To reduce the risk of injury or death:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Never let children operate or play with gate controls. Keep the remote control away from children.
3. Always keep people and objects away from the gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE.
4.Test the gate operator monthly. The gate MUST reverse on contact with a rigid object or stop when an object
activates the non-contact sensors. After adjusting the force or the limit of travel, retest the gate operator. Failure to
adjust and retest the gate operator properly can increase the risk of injury or death.
5. Use the emergency release only when the gate is not moving
6. KEEP GATES PROPERLY MAINTAINED. Read the owner’s manual. Have a qualified service person make
repairs to gate hardware.
7. The entrance is for vehicles only. Pedestrians must use separate entrance.
8. Every gate operator installation MUST have secondary protection devices agains entrapments, such as edge
sensors and photo beams more in particulary in places where the risk of entrapments is more likely to occur
9. SAVE THESE INSTRUCTIONS
!
PERIODICAL MAINTENANCE

GENERAL SAFETY INFORMATION
An appliance shall be provided with an instruction manual. The instruction manual shall give instructions for the
installation, operation, and user maintenance of the appliance.
The installation instructions shall specify the need for a grounding-type receptacle for connection to the supply and
shall stress the importance of proper grounding.
The installation instructions shall inform the installer that permanent wiring is to be employed as required by local
codes, and instructions for conversion to permanent wiring shall be supplied.
Information shall be supplied with a gate operator for:
a) The required installation and adjustment of all devices and systems to effect the primary and secondary protection
against entrapment (where included with the operator).
b) The intended connections for all devices and systems to effect the primary and secondary protection against
entrapment. The information shall be supplied in the instruction manual, wiring diagrams, separate instructions, or the
equivalent.
Vehicular gate operators (or systems)
A vehicular gate operator shall be provided with the information in the instruction manual that defines the different
vehicular gate operator Class categories and give examples of each usage. The manual shall also indicate the use for
which the particular unit is intended as defined in Glossary, Section 3. The installation instructions for vehicular gate
operators shall include information on the Types of gate for which the gate operator is intended.
A gate operator shall be provided with the specific instructions describing all user adjustments required for proper
operation of the gate. Detailed instructions shall be provided regarding user adjustment of any clutch or pressure relief
adjustments provided. The instructions shall also indicate the need for periodic checking and adjustment by a qualified
technician of the control mechanism for force, speed, and sensitivity.
Instructions for the installation, adjustment, and wiring of external controls and devices serving as required protection
against entrapment shall be provided with the operator when such controls are shipped with the operator.
Instructions regarding intended installation of the gate operator shall be supplied as part of the installation instructions
or as a separate document. The following instructions or the equivalent shall be supplied where applicable:
IMPORTANT INSTALLATION INSTRUCTIONS
a) Install the gate operator only when:
1) The operator is appropriate for the construction of the gate and the usage Class of the gate,
2) All openings of a horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 4 feet
(1.22 m) above the ground to prevent a 2-1/4 inch (57.2 mm) diameter sphere from passing through the openings
anywhere in the gate, and in that portion of the adjacent fence that the gate covers in the open position,
3) All exposed pinch points are eliminated or guarded, and
4) Guarding is supplied for exposed rollers.
b) The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a
separate access opening. The partial access opening shall be designed to promote pedestrian usage. Locate the gate
such that persons will not come in contact with the vehicular gate during the entire path of travel of the vehicular gate.
c) The gate must be installed in a location so that enough clearance is supplied between the gate and adjacent
structures when opening and closing to reduce the risk of entrapment. Swinging gates shall not open into public access
areas.
d) The gate must be properly installed and work freely in both directions prior to the installation of the gate operator. Do
not over-tighten the operator clutch or pressure relief valve to compensate for a damaged gate.
e) The gate operator controls must be placed so that the user has full view of the gate area when the gate is moving and
AWAY FROM THE GATE PATH PERIMETER.
f) Controls intended for user activation must be located at least six feet (6’) away from any moving part of the gate and
where the user is prevented from reaching over, under, around or through the gate to operate the controls. Outdoor or
easily accessible controls shall have a security feature to prevent unauthorized use.
g) The Stop and/or Reset button must be located in the line-of-sight of the gate. Activation of the reset control shall not
cause the operator to start.
h) A minimum of two (2) WARNING SIGNS shall be installed, one on each side of the gate where easily visible
International registered trademark n. 2.777.971

i) For gate operators utilizing a non-contact sensor:
1) See instructions on the placement of non-contact sensors for each Type of application
2) Care shall be exercised to reduce the risk of nuisance tripping, such as when a vehicle, trips the sensor while the
gate is still moving
3) One or more non-contact sensors shall be located where the risk of entrapment or obstruction exists, such as the
perimeter reachable by a moving gate or barrier
j) For a gate operator utilizing a contact sensor:
1) One or more contact sensors shall be located where the risk of entrapment or obstruction exists, such as at the
leading edge, trailing edge, and postmounted both inside and outside of a vehicular horizontal slide gate.
2) One or more contact sensors shall be located at the bottom edge of a vehicular vertical lift gate.
3) One or more contact sensors shall be located at the pinch point of a vehicular vertical pivot gate.
4) A hardwired contact sensor shall be located and its wiring arranged so that the communication between the
sensor and the gate operator is not subjected to mechanical damage.
5) A wireless contact sensor such as one that transmits radio frequency (RF) signals to the gate operator for
entrapment protection functions shall be located where the transmission of the signals are not obstructed or
impeded by building structures, natural landscaping or similar obstruction. A wireless contact sensor shall
function under the intended end-use conditions.
6) One or more contact sensors shall be located on the inside and outside leading edge of a swing gate. Additionally,
if the bottom edge of a swing gate is greater than 6 inches (152 mm) above the ground at any point in its arc of
travel, one or more contact sensors shall be located on the bottom edge.
7) One or more contact sensors shall be located at the bottom edge of a vertical barrier (arm).
Instruction regarding intended operation of the gate operator shall be provided as part of the user instructions or as a
separate document. The following instructions or the equivalent shall be provided
NOTICE
As for misunderstandings that may arise refer to your area distributor or call our help desk. These instructions are part
of the device and must be kept in a well known place. The installer shall follow the provided instructions thoroughly.
SEA products must only be used to automate doors, gates and wings. Any initiative taken without SEA USA Inc. explicit
authorization will preserve the manufacturer from whatsoever responsibility. The installer shall provide warning notices
on not assessable further risks. SEA USA Inc. in its relentless aim to improve the products, is allowed to make
whatsoever adjustment without giving notice. This doesn’t oblige SEA to up-grade the past production. SEA USA Inc.
can not be deemed responsible for any damage or accident caused by product breaking, being damages or accidents
due to a failure to comply with the instructions herein. The guarantee will be void and the manufacturer responsibility
will be nullified if SEA USA Inc. original spare parts are not being used. The electrical installation shall be carried out by
a professional technician who will release documentation as requested by the laws in force. Packaging materials such
as plastic bags, foam polystyrene, nails etc must be kept out of children’s reach as dangers may arise.
To respect the norms in force it is recommended to use the ENCODER SYSTEM together with the electronic
control units
International registered trademark n. 2.777.971
Starting on Jan. 12, 2016, new UL 325 changes take effect, bringing a series of new mandates for the gate operator
industry. Here’s a quick guide to the key modifications.
1. Entrapment-Protection Devices. Gate operators are required to have a minimum of two independent means of
entrapment protection where the risk of entrapment or obstruction exists. A manufacturer can use two inherent-type
systems, two external-type systems, or an inherent and an external system to meet the requirement. However, the
same type of device cannot be used for both means of protection.
2. Monitoring Required. An external non-contact sensor or contact sensor may be used as a means of entrapment
protection. However, the sensor must be monitored once every cycle for (1) the correct connection to the operator and
(2) the correct operation of the sensor.
If the device is not present, not functioning, or is shorted, then the gate operator can only be operated by constant
pressure on the control device. Portable wireless controls will not function in this case.
3. Entrapment Risk Identification. As in the past, it’s up to the installer to examine the installation and determine
where a risk of entrapment or obstruction exists. Manufacturers are required to provide instructions for the placement
of external devices, but they give only examples of suggested entrapment protection in their installation manuals. If the
installer identifies a risk of entrapment or obstruction, at least two independent means of entrapment protection are
required.
4.Terminology Change. The terms “primary” and “secondary” have been removed in the description of entrapment
protection devices. This was done to emphasize that all entrapment protection devices are equally important.
Changes to UL 325 ED. 6th for Gate Operators

5. The End of Type E. Type E (audible alarm) devices can no longer be used for entrapment protection. This change
was made because the Type E device is really a warning device, not an entrapment-protection device. Also, all gate
operator classes are now required to have an audio alarm that sounds when two successive obstructions are
encountered via a contact-type system.
6. Access Control Location for Emergency Use. An exception has been added in the manufacturer’s instructional
requirements for the location of controls that operate the gate.
The instructional requirements state that these controls must be at least 6' away from any moving part of the gate. In the
new exception, “Emergency access controls only accessible by authorized personnel (e.g., fire, police, EMS) may be
placed at any location in the line-of-sight of the gate.”
7. Barrier-Arm Operator Exception. An exception has changed for barrier-arm gate operators requiring entrapment
protection. The previous exception stated that a barrier-arm operator did not require entrapment protection if the arm
did not move toward a rigid object closer than 2'. The distance has been reduced to 16" so it more closely aligns with the
industry-defined entrapment protection provisions in ASTM F2200.
8. Gate Operator Class II and Class III Definitions. The definitions for installation classes for gate operators were
modified. Class II now includes commercial locations accessible to the general public. Class III was refined to specify
industrial locations not accessible to the general public. These changes, while seemingly minor, may affect which gate
operator is suitable for a particular installation location.
UL 325 ED. 6th ENTRAPMENT PROTECTION REQUIREMENTS
This vehicular gate operator must be installed with at least two independent entrapment protection
means as specified in the table below.
International registered trademark n. 2.777.971
VERITICAL BARRIER NOTE:
Barrier gate operators (arm) that is not intended to move toward a rigid objact closer than 16 inches (406mm)
are not required to be provided with a means of entrapment protection
* B1 and B2 means of entrapment protection MUST be MONITORED
HORIZONTAL SLIDE
VERTICAL LIFT - VERTICAL PIVOT
ENTRAPMENT
PROTECTION
TYPES
TYPE A
TYPE B1
TYPE B2
TYPE C
Inherent entrapment protection system
Non-contact sensors such as photoelectric sensors or equivalents
Contact sensors such as edge sensors or equivalent devices
Inherent force limiting, inherent adjustable clutch or inherent pressure relief device
The same type of device shall not be used for both entrapment protection means. Use of a single device to cover both
the opening and closing directions is in accordance with the requirement; however, a single device is not required to
cover both directions. Tice installer is required to install entrapment protection devices in each entrapment zone
TYPE D Actuating device requiring constant pressure to maintain opening or closing motion of the gate
SWING
VERTICAL BARRIER (ARM)
A , B1*, B2* or D A , B1*, B2*, C or D
GATE OPERATOR CATEGORY
Effective January, 12 2016
VEHICULAR GATE OPERATOR CLASSES
Residential Vehicular Gate Operator-Class I: A vehicular gate operator (or system) intended for use in garages or
parking areas associated with a residence of one-to-four single families
Commercial/General Access Vehicular Gate Operator-Class II: A vehicular gate operator (or system) intended for
use in a commercial location or building such as a multi-family housing unit (five or more single family units), hotel,
garages, retail store, or other buildings accessible by or servicing the general public
Industrial/Limited Access Vehicular Gate Operator–Class III: A vehicular gate operator (or system) intended for
use in an industrial location or building such as a factory or loading dock area or other locations not accessible by or
intended to service the general public
Restricted Access Vehicular Gate Operator–Class IV: A vehicular gate operator (or system) intended for use in an
industrial location or building such as a factory or loading dock area or other locations not accessible by or intended to
service the general public

GATE WARNINGS
The first thing to check is that the gate is in good running order as follows:
A. The gate is rigid and straight and runs smoothly throughout its travel.
B. The length of each leaf must comply with max. length indicated on technical specifications of the model
C. The weight of each leaf must comply with max. weight indicated on technical specifications of the model
D. The hinges are hardly anchored and are able to support the torque of the operator; they do not have
irregular movements and/or any friction during the whole movement of the leaf.
PRECAUTIONS
SEA motors have been created for the automation of gates used by vehicles only. Be aware to avoid the
crossing of the gate path because it is very dangerous for pedestrians (fig. 4).
Install the warning signs, on each side of the gate and in avisible zone which informs the pedestrians
about the danger they run when passing or resting in the environment of the gate (fig. 5).
Important:
For a higher security, SEA advices to install infrared photocells.
Fig. 4
Fig. 3
Fig. 5
Fig. 1 Fig. 2
GATE WARNINGS AND PRECAUTIONS
International registered trademark n. 2.777.971
Install the operator in the correct position
Do not Install the front bracket in a weak part of the gate
Not for pedestrian opening

7
1
2
4
36
5
7
8
10
11
9
13
12
1. Aluminium casing
2. Front fixing bracket
3. Back fixing bracket
4. Release system
5. Terminal board
6. Capacitor
7. Motor
9
8. Gear reducer
9. Bearings
10. Stop in opening
11. Stop in closing
12. Endless-screw
13. Lead screw barrel nut
Fig. 1
* with mechanical stop in
opening and closing inserted
SURF 350 - SURF 450 , is an irreversible electromechanical swing gate operator strong and safe, easy to
install, for leaf length up to is equipped with release system through key, which 14,76 feet SURF operator
allows the manual release of the leaf in case of emergency or black out
TECHNICAL SPECIFICATIONS
3,86
15,6 15,75*
31,3
4,13
34,56
DIMENSIONS (inches)
Fig. 4
International registered trademark n. 2.777.971
Fig. 2
7. Motor
8. Metallic bever gear
9. Bearings
10. Endless-screw
11. Lead screw barrel nut
1. Aluminium casing
2. Front fixing bracket
3. Back fixing bracket
4. Release system
5. Terminal board
6. Capacitor
SURF K is an irreversible electromechanical swing gate operator, strong and safe, easy to install, for leaf
length up to 16,40 feet. SURF K operator is equipped with release system through key, which allows the
manual release of the leaf in case of emergency or black out
1
2
3
4
5
7
9
9
10
11
6
8
Fig. 3
39,50
36,61
3,10
SURF 350 - 450 SURF K

8
TECHNICAL DATA
Note: The frequency of use is valid only for the first hour at 68°F room temperature
SURF 350 (24V)
120V (± 5%)50/60Hz ~
3 A
2,5 A
60 W 280 W
2350 rpm 1430 rpm
15,75 inches
- 4° F + 131° F
0,71 inches/sec.
Adjustable
50
40 20
266° F
2000 N
60 µF (not on board)
17,19 Lb 17,64 Lb 16,53 Lb
IP 44
12 ft 13 ft
15 ft
900 Lb 1000 Lb
1100 Lb
SURF 450 (24V) SURF 350 (120V)
24Vcc
- - - -
- - - -
TECHNICAL DATA
Power supply
Max. power
Max. absorbed current
Motor speed
Shaft stroke
Shaft speed
Cycle/hour
(operating at 20°C)
Operating temperature
Motor thermal protection
Max. thrust
Capacitor
Operator weight
Protection
Max. leaf length
Max. leaf weight
International registered trademark n. 2.777.971
SURF K (24V)
17,19 Lb
16 ft
1200 Lb
USING GRAPHICS
12 feet
15 feet
40
Fig. 5
20
50
SURF 350 (24V)
SURF 350 (24V)
SURF 350 (120V)
SURF
350
(120V)
SURF 450 (24V)
SURF 450 (24V)
OPERATOR
MAX LEAF LENGTH
CYCLES/HOUR
13 feet
16 feet
SURF K
SURF K
16 ft
1200 Lb
Weight
Leaf length
900 Lb
600 Lb
15 ft
9 ft 12 ft
1100 Lb
400 Lb
5 ft
SURF 350 (24V)
13 ft
1000 Lb
SURF 350 (120V)
SURF 450 (24V)
SURF K (24V)
Fig. 6

9
SURF 350 - SURF 450 MAIN PARTS
Back fixing bracket
Front fixing bracket
Covering lid for terminal board
Cable glands
Lock nut
Manual release
Fig. 7
International registered trademark n. 2.777.971

10
Fig. 8
SURF K MAIN PARTS
Back fixing bracket
Front fixing bracket
Covering lid for terminal board
Cable glands
Lock nut
Manual release
International registered trademark n. 2.777.971

11
STANDARD INSTALLATION
Note: The operator must be mounted with the release turned up (Fig. 10)
Release
Fig. 10
International registered trademark n. 2.777.971
Fig. 9
* For SURF K operator use 2x2,5 cables type to connect motors to the control unit
1
1
2
2
3
4
5
6
7
8
9
10
10
11
2x1
4x1
4x1,5 *
2x1
4x2,5
4x1
2x1,5
1xRG58
4x1
4x1,5 *
EXIT
ENTRY
1) Operator
2) Mechanical stop
3) Electronic control unit
4) Flashing lamp
5) Right Photocell (Dx)
6) Differential switch 16A - 0,03A
7) Left Photocell (Sx)
8) Start - stop push button with key
9) Antenna
10) Support for photocells with photocells
11) Warning notice

12
Fig. 12 Fig. 13
Fig. 11
GATE ARRANGEMENT
You must do some checks on the gate to see if fitting the operator is possible; Make sure that:
A. the fixed and moving parts of the gate are strong and non-deformable;
B. the length of each gate leaf must not exceed the propped-up measure by each model (see graphic in Fig. 6)
C. the weight of each gate leaf must not exceed the propped-up weight by each model (see graphic in Fig. 6)
D. the hinges and general structure must be in good conditions and able to support the operator thrust; the
gate must move smoothly throughout its whole travel;
Where possible, it is advisable to install mechanical stops on the ground for a good functioning of the operator
Mechanical stop
in opening
Mechanical stop
in closing
SURF 350 - 450 INSIDE INSTALLATION SURF 350 - 450 OUTSIDE INSTALLATION
outside
inside inside
outside
International registered trademark n. 2.777.971
SURF K INSIDE INSTALLATION SURF K OUTSIDE INSTALLATION
Fig. 14 Fig. 15
outside outside
inside inside

13
Fig. 16
a
(inches)
b
(inches)
d
max
(inches)
e
(inches)
Fig. 17
b
c
d
a
e
a
b
c
d
e
105°
105°
105°
100°
100°
100°
95°
95°
95°
90°
90°
90°
90°
90°
90°
90°
90°
90°
90°
95°
100°
100°
100°
100°
100°
100°
100°
SURF 350 - 450 INSIDE OPENING INSTALLATION
SURF 350 - 450 OUTSIDE OPENING INSTALLATION
Total stroke 15,75 in - max. recommended stroke 14,96 in
Max
Opening
Angle
Max
Stroke
(inches)
Piston
Stroke for
90° (inches)
inside
outside
outside
inside
Total stroke 15,75 in - max. recommended stroke 14,96 in
Max
Opening
Angle
Max
Stroke
(inches)
Piston
Stroke for
90° (inches)
a
(inches) b
(inches)
e
(inches)
8,26
7,87
7,48
8,66
8,26
7,87
9,05
8,66
8,26
9,44
9,05
8,66
9,84
9,44
9,05
10,23
9,84
9,44
6,30
6,30
6,30
5,90
5,90
5,90
5,51
5,51
5,51
5,11
5,11
5,11
4,72
4,72
4,72
4,33
4,33
4,33
5,90
5,51
5,11
6,30
5,90
5,51
6,70
6,30
5,90
7,08
6,70
6,30
7,48
7,08
6,70
7,87
7,48
7,08
14,96
15,35
15,74
14,56
14,96
15,35
14,37
14,76
15,15
14,17
14,56
14,96
14,17
14,56
14,96
14,17
14,56
14,96
13,97
14,37
14,76
13,97
14,37
14,76
13,97
14,37
14,76
14,17
14,56
14,96
14,17
14,56
14,96
14,17
14,56
14,96
24,80
24,80
24,80
25,19
25,19
25,19
25,59
25,59
25,59
25,98
25,98
25,98
26,37
26,37
26,37
26,77
26,77
26,77
7,87
7,48
7,08
6,70
6,30
5,90
5,51
5,11
4,72
3,14
3,56
3,93
4,33
4,72
5,11
5,51
5,90
6,30
10,82
11,41
11,61
11,81
11,81
11,81
11,81
12
12
10,82
10,82
11,02
11,02
11,02
11,02
11,02
11,02
11,02
20,86
21,25
21,65
22,04
22,44
22,83
23,22
23,62
24,01
International registered trademark n. 2.777.971
* For SURF K operator quotes, please contact SEA-USA technical support

14
Fig. 18
ad
b
42,05
2,36
6,10 Minimum
d
7,87
3,14 Minimum CAUTION:
During installation, make sure
that the cables do not
interfere with the niche
If you have to make a niche
observe the dimensions shown
DIMENSIONS IN INCHES
INSTALLATION ON MASONRY PILLARS BY MAKING A NICHE
2,36
6,10 Minimum
International registered trademark n. 2.777.971
Fig. 19
ad
b
d
CAUTION:
During installation, make sure
that the cables do not
interfere with the niche
If you have to make a niche
observe the dimensions shown
42,05
2,36
6,10 Minimum
7,87
3,14 Minimum
2,36
6,10 Minimum
DIMENSIONS IN INCHES

15
A
A
AA
A
2,65 in
Fig. 20
Fig. 21
(1)
Fig. 22
BACK FIXING BRACKET MOUNTING
If the back fixing bracket has to be screwed and the «A» holes are used, the fixing bracket must be cut at a
distance of 2,65 inches from its end; if instead you use the other holes it is not necessary to do the cutting.
The support must be positioned so that the operator is in a perfect horizontal position (see Fig. 26 or 31)
CAUTION: before assembling the back and front fixing brackets lubricate with water repellent grease
BACK FIXING BRACKET TO BE SCREWED
Nut (1)
NOTE:
T o a v o i d t h e
oscillation of the
o p e r a t o r d u r i n g
operating phase, it is
recommended to
adjust the nut (1)
being careful to not
block the rotation of
the operator on the
f i x i n g b r a c k e t
International registered trademark n. 2.777.971
Depending on the type of gate (wood, iron, aluminium) the front fixing bracket
can be welded or screwed
FRONT FIXING BRACKET MOUNTING
WARNING:
once the back bracket has been fixed,
immediately fix the front bracket,
always keeping the operator in a
horizontal position. Do not leave the
front of the operator detached
because it would fall down causing
damage
4,33 in
Fig. 23
Once the operator has been mounted on the back fixing
bracket, close the leaf of the gate and proceed as follows:
1) Release the operator keeping it always in a horizontal
position
2) Weld the front fixation bracket on the gate operating on
the the points indicated by the arrows (Fig. 23)
3) Place the operator on the front fixing bracket (SURF 350
- 450 as per Fig. 26 - 27) or insert the bracket into the
housing pin on the operator (SURF K as per Fig. 30 - 31)
and tighten the «A» screw to max 8.5 Nm (Fig. 27 or 30)
CAUTION: Lubricate the pin with grease before
installing the front fixing bracket on the operator
CAUTION: For the correct operation it is very important to position both the operator and its front
and back fixing brackets, in a perfectly horizontal way, using a level, as shown in Fig. 26 or 31
Furthermore the front fixing bracket MUST NOT TILT when it reaches the limit stop
(Fig. 28), otherwise serious damages can be caused to the electronic limit-switches
WELDED FRONT FIXING BRACKET
WELDED FRONT FIXING BRACKET

16
Fig. 24 Fig. 25
4,33 in
2,44 in
1,5 in
2,44 in
= =
1,5 in
Level
front
fixing
bracket
(A)
Fig.26
Fig. 27
CAUTION: For the correct operation it is very important to position both the operator and its
front and back fixing brackets, in a perfectly horizontal way, using a level, as shown in Fig. 26 or 31
SCREWED FRONT FIXING BRACKET
International registered trademark n. 2.777.971
Fig. 30
(A)
Once the operator has been mounted on the back fixing bracket, close the leaf and proceed as follows:
1) Release the operator keeping it always in a horizontal position
2) Screw the front fixing bracket onto the gate in correspondence of the holes made respecting the
dimensions as per Fig. 24 and Fig. 25
3) Place the operator on the front fixing bracket (for SURF 350 - 450 as per Fig. 26 - 27) or insert the bracket
into the housing pin on the operator (for SURF K as per Fig. 30 - 31) and tighten the «A» screw to max 8.5 Nm
CAUTION: Lubricate the pin with grease before installing the front fixing bracket on the operator
Livella
Level
Fig. 31
SURF K
SURF 350 - 450
SURF K
WARNING:
The front fixing bracket MUST
NOT TILT when it reaches the limit
stop (Fig. 28), otherwise serious
damages can be caused to
the electronic limit-switches
Fig. 28
Front fixing bracket
Fig. 29
0,90 in
2,40 in
NOTE: When positioning the front fixing bracket on the gate, consider the offset in respect to the
central axis of the operator (Fig. 29)

17
Max = 2,55 in
Fig. 32
Max = 2,95 in
Fig. 33
MECHANICAL STOP IN CLOSING
INSTALLATION OF MECHANICAL STOP
MECHANICAL STOP IN OPENING
International registered trademark n. 2.777.971
SURF K CONNECTIONS
24V MOTOR
24V MOTOR
Operator
Terminal
board
Fig. 34
SURF K 24V
Fig. 35

18
SURF 350 - SURF 450 CONNEXIONS
operator
terminal
MOTOR 24V
LIMIT-SWITCH
IN OPENING
COMMON (-)
LIMIT-SWITCH
MOTOR 24V
LIMIT-SWITCH
IN CLOSING
SURF 350
WITH MECHANICAL STOP AND LIMIT-SWITCH
ENCODER DATA
ENCODER + 24V
CAUTION: Limit-switches must be connected to the control unit (not to the operator directly)
!
MOTOR COMMON
MOTOR OPENING
MOTOR CLOSING
GROUND
LIMIT-SWITCH
IN OPENING
COMMON (-)
LIMIT-SWITCH
LIMIT-SWITCH
IN CLOSING
MOTOR COMMON
MOTOR OPENING
MOTOR CLOSING
GROUND
LIMIT-SWITCH
IN OPENING
COMMON (-)
LIMIT-SWITCH
LIMIT-SWITCH
IN CLOSING
Fig.36
SURF (350-450) 24V
WITH MECHANICAL STOP AND LIMIT-SWITCH
SURF 350
WITH MECHANICAL STOP, LIMIT-SWITCH AND ENCODER
SURF (350-450) 24V
WITH MECHANICAL STOP
WITHOUT LIMIT-SWITCH
MOTOR 24V
MOTOR 24V
International registered trademark n. 2.777.971

19
90°
Spingere e
ruotare
90°
Fig. 37 Fig. 38
Fig. 39 Fig. 40
To the attention of users and technicians
PLASTIC INTERNAL RELEASE SYSTEM
Handle
LOCK
RELEASE
Handle
Lock
protection
cover
To release the operator proceed as
follows:
1) Turn counter-clockwise the lock protection
cover (Fig. 37)
2) Insert the release key, push it and turn it of
about 90° clockwise (Fig. 38)
3) handleTurn the counter-clockwise to
release the operator (Fig. 39)
To lock the operator proceed as follows:
1) Turn the handle clockwise to revert it to
the initial position
2) Turn the key about 90° counter-clockwise
(Fig. 40)
3) After having relocked the operator, close
the lock protection cover to prevent
damages due to atmospheric agents
Note: for a greater safety of the release,
SEA recommends to install the SURF
release lock KIT (Code: 12715280)
METALLIC INTERNAL RELEASE SYSTEM
To release the operator proceed as
follows:
1) Turn counter-clockwise the lock
protection cover (Fig. 41)
2) Insert the key and turn of about 90°
clockwise (Fig. 42)
3) handleTurn the counter-clockwise to
release the operator (Fig. 43)
To lock the operator proceed as follows:
1) Turn the handle clockwise to revert it to
the initial position
2) Turn the key about 90° counter-
clockwise (Fig. 44)
3) After having relocked the operator, close
the lock protection cover to prevent
damages due to atmospheric agents
NOTE: for a proper operation of the
manual release it is recommended to
observe the current regulations
regarding the thrust force
90°
Fig. 44
Fig. 41
90°
Fig. 42
Fig. 43
Handle
LOCK
RELEASE
Handle
Lock
protection
cover
International registered trademark n. 2.777.971

20
To the attention of users and technicians
PERIODICAL MAINTENANCE
Check the solidity and the stability of the gate, especially
the points of support and/or rotation of the gate (pivots)
Check the release system function
Check and grease the fixing pivots and the endless screw
Check the integrity of the connection cables
Verify the functionality and the conditions of the
mechanical stops in opening and closing
Verify the good condition of all mechanism which are subject to stress
(as front and back fixing bracket, oscillating fork bracket etc.)
Check the functionality of all accessories, in particular of all safety devices
After having executed the periodical maintenance it is necessary
to repeat the test of the automation and its commissioning
All the above described operations MUST be made exclusively by an authorized installer
Annual
1
2
3
4
5
6
7
8
Annual
Annual
Annual
Annual
Annual
Annual
Annual
RISK EXAMINATION
The points pointed by arrows in Fig. 45 are potentially dangerous. The installer must
take a thorough risk examination to prevent crushing, conveying, cutting, grappling,
trapping so as to guarantee a safe installation for people, things and animals
(Re. Laws in force in the country where the installation has been made.
NOTICE
SEA USA Inc. can not be deemed responsible for any damage or accident caused by
product breaking, being damages or accidents due to a failure to comply with the
instructions herein. The guarantee will be void and the manufacturer responsibility
will be nullified if SEA USA Inc. original spare parts are not being used. The electrical
WARNINGS All electrical installation work should conform to current regulations. A 16A - 0,030A differential switch must be
incorporated into the source of the gate main electrical supply and the entire system must be properly earth bonded. Remember to
separate mains (230/120V) carrying cables from low voltage control cables. Separate conduits should be used to prevent noise
issues. Note: Use “cable-glands” and/or “pipes/sheatings” close to the control panel box so to protect the interconnection
cables against pulling efforts
INTENDED USE The operator has been designed exclusively for the automation of sliding gates
SPARE PARTS: SEA USA Inc. - Doral 33172 - Miami (FL) - USA Telephone: ++1-305.594.1151 Toll free: 800.689.4716
www.sea-usa.com
SAFETY AND RESPECT FOR THE ENVIRONMENT
We recommend not to spoil the environment with product and circuit packing material.
STORAGE
The product must be handled using suitable means.
MAINTENANCE AND DECOMMISSION
The decommission and maintenance of products must be carried out by specialised and authorised personnel only
GUARANTEE LIMITS For the guarantee see the sales conditions
NOTE: THE MANUFACTURER SHALL NOT SHOULDER ANY RESPONSIBILITIES IN CASE OF DAMAGE CAUSED BY
INAPPROPRIATE, WRONG OR CARELESS USE.
SEA reserves the right to make all the necessary changes and modifications of the products or manuals without giving prior notice
Tmin
-4°F
Tmax
+149°F
Humiditymin
5% without condensation
Humiditymax
90% without condensation
STORAGE TEMPERATURE
installation shall be carried out by a professional technician who will release documentation as requested by the laws in force.
Packaging materials such as plastic bags, foam polystyrene, nails etc must be kept out of children’s reach as dangers may arise
Fig. 45
International registered trademark n. 2.777.971
