FAAC DSL2000 User manual

DSL2000
Slide Gate Operator
Revision D
FAAC International Inc.
Headquarter & East Coast Operations
5151 Sunbeam Road #9-11
Jacksonville, FL 32257
[phone]
FAAC International Inc.
West Coast Operations
357 S Acacia Avenue #357
Fullerton, CA 92831
[phone]
American Built
www.FAACUSA.com

IMPORTANT SAFETY INFORMATION
Important User Instructions .................................... 3
Restrictions & Warnings ........................................ 3
Internal Entrapment Prevention ............................. 5
External Entrapment Prevention ............................ 5
UL325 Gate Operator Classification ...................... 6
Glossary Of Terms ................................................ 6
Warning Sign Installation ....................................... 7
Installation Precautions ......................................... 7
GATE OPERATOR INSTALLATION
PreInstallation Guidelines ...................................... 8
Gate Operator Location ......................................... 8
Concrete Pad Size & Location ............................... 9
Gate Operator Bolt Down .................................... 10
Chain Connection - Front Mount .......................... 10
Chain Connection - Rear Mount .......................... 11
Limit Switch Setup ............................................... 12
Gate Operator Direction ...................................... 12
ELECTRICAL INSTALLATION
Power Switch Location ........................................ 13
AC Power Guidelines .......................................... 13
AC Power Connection ......................................... 13
Battery Power Connection ................................... 14
Accessory Power ................................................. 14
Master/Slave Connection .................................... 15
GATE OPERATOR ADJUSTMENTS
Reverse Sensitivity Adjustment ........................... 16
Reverse Sensitivity Shutdown ............................. 16
Close Time Delay Adjustment ............................. 17
DIP Switch Settings ............................................. 17
ACCESSORY CONNECTIONS
Accessory Wire Overview .................................... 18
Edge Sensor Connections ................................... 19
Photo Sensor Connections .................................. 20
Standard Reverse Connections ........................... 21
Open, Close, Stop Connections .......................... 21
External Reset Connection .................................. 21
Access Control Connection ................................. 22
Fire Lock Connection ........................................... 22
Radio Receiver Connections ............................... 23
MagLock & Solenoid Lock Connections .............. 23
Alarm & Warning Light Connections .................... 24
Solar Panel Connections ..................................... 24
LOOP & LOOP DETECTORS
Basic Loop Layout ............................................... 25
Loop Installation Guidelines ................................ 25
Plug-In Loop Detector Connections ..................... 26
External Loop Detector Connections ................... 26
TROUBLESHOOTING TIPS
Fault Light Count ................................................. 26
Read and follow all U.L. and Safety Standards before installing any access device. Please refer to this manual and
qualified personnel for assistance. DO NOT install this device unless all entrapment and pinch points are eliminated.
!
T
TABLE
ABLE
O OF
F
C CONTENTS
ONTENTS
DSL2000 Slide Gate Operator 2

I
IMPORTANT
MPORTANT
S SAFETY
AFETY
I INFORMATION
NFORMATION
IMPORTANT USER INSTRUCTIONS:
Automatic gate systems provide user convenience and limit vehicular traffic. Because these systems can produce high levels
of force, it is important that you are aware of the potential hazards associated with the system. Potential hazards may include
pinch points, entrapment positions, lack of proper pedestrian access, blind spots for traffic visibility.
It is the joint responsibility of the designer, purchaser, installer and end user to verify the system is properly configured for its
intended use. Be sure that the installer has instructed you on the proper operation of the gate and gate system before use. Be
sure the installer trains you about the basic functions of the required reversing devices associated with the gate system and
how to properly test them. Reversing devices may include reverse loops, sensing edges, photoelectric cells, inherent reverse
detection, and/or other external devices.
All users should follow and understand the following points:
 Carefully read and follow all instructions in this manual and keep it in a safe place for future reference.
 Carefully read and follow the “Restrictions & Warnings” section of this manual.
 Carefully read and follow the “Entrapment Prevention” section of this manual.
 Carefully read and understand the “Glossary of Terms” section of this manual.
 Make sure that all residents and users are familiar with the proper use of the gate system and its potential hazards.
 Make sure proper reversing devices are installed on all gates to avoid all potential hazards and entrapment.
 Understand loops and loop detectors, photoelectric cells and other devices must be installed with this gate operator to prevent the
gate from closing on vehicles.
 Installation, service and maintenance must be carried out by qualified personnel.
 Understand the manufacturer can not be held responsible for damage or injury caused by improper, erroneous or unreasonable use.
Failure to comply with these guidelines may create a dangerous situation and will void any and all warranties.
 Always consult your qualified dealer if any concerns or questions arise.
RESTRICTIONS & WARNINGS:
WARNING - To reduce the risk of injury of death:
1. READ AND FOLLOW ALL INSTRUCTIONS.
2. Never let children operate or play with gate controls. Keep the remote control away from children. Never allow children to play in
the area of the gate system.
3. Always keep people and objects away from gate. NO ONE SHOULD CROSS THE PATH OF THE MOVING GATE!
4. Test the operator monthly. The gate MUST reverse on contact with a rigid object or stop or reverse when an object activates the
non-contact sensors. After adjusting the force or the limit of travel, retest the gate operator. Failure to adjust and retest the gate
operator properly can increase the risk of injury or death. If any reverse device functions improperly, remove the operator from
service immediately.
5. KEEP GATES PROPERLY MAINTAINED. Read the owner’s manual. Have a qualified service person make repairs to gate
hardware.
6. The entrance is for vehicles only. Pedestrians must use separate entrance. Keep all pedestrian traffic away from the gate.
7. Use the emergency release/shut off only when the gate is not moving. Make sure the power for the gate operator is off by using the
On/Off switch located inside the cover on the left side of the controller.
8. Every gate operator installation MUST have secondary protection devices against entrapment, such as edge sensors and
photoelectric cells more in particularly in places where the risk of entrapment is more likely to occur. Proper reversing devices
MUST be installed on all gates to avoid all potential hazards and entrapment.
9. SAVE THESE INSTRUCTIONS
WARNING: A moving gate can cause serious injury or death. Read and follow all
Installation Manual, Reference Manual, and Warning Label Instructions.
!
WARNING: DO NOT INSTALL this product unless all safety standards are followed and
all entrapment and pinch points have been eliminated.
!
DSL2000 Slide Gate Operator 3

I
IMPORTANT
MPORTANT
S SAFETY
AFETY
I INFORMATION
NFORMATION
RESTRICTIONS & WARNINGS:
Install the gate operator only if:
1. The gate operator is appropriate for the construction of the gate and the usage Class of the application. Make sure the gate is within
the weight and length limitations specified for the operator.
2. All openings of a horizontal slide gate are guarded or screened from the bottom of the gate to a minimum of 4 feet (1.2m) above the
ground to prevent a 2 1/4 inch (57.15mm) diameter sphere from passing through the openings anywhere in the gate, and in that
portion of the adjacent fence that the gate covers in the open position.
3. ALL EXPOSED PINCH POINTS ARE ELIMINATED OR GUARDED AND GUARDING IS SUPPLIED FOR EXPOSED ROLLERS.
DO NOT INSTALL THIS DEVICE UNLESS ALL ENTRAPMENT AND PINCH POINTS ARE ELIMINATED!
4. The operator is intended for installation only on slide gates used to control vehicles. Pedestrians must be provided with a separate
access opening.
5. The gate must be installed in a location so that enough clearance is provided between the gate and adjacent structures when
opening and closing to reduce the risk of entrapment. Gates should not open into public access areas.
6. The gate must be properly installed and work freely in both directions prior to the installation of the gate operator. DO NOT
REDUCE REVERSING SENSITIVITY TO COMPENSATE FOR A DAMAGED GATE.
7. Gate operator controls must be placed far enough from the gate to prevent the user from coming in contact with the gate while
operating the controls. All activating devices must be installed in a clear line-of-sight with the gate and its travel. Activating devices
must be installed a minimum of 10 feet away from the gate. Be sure to mount ALL operating devices clearly out of reach of through
gate. Controls intended to be used to reset an operator after two sequential activations of the entrapment protection device must be
located in the line-of-sight of the gate. Outdoor or easily accessible controls shall have a security feature to prevent unauthorized
use.
8. Warning signs must be permanently installed on both sides of the gate and must be fully visible to traffic and pedestrians.
9. Install the gate system and gate in accordance with ASTM F220-02: Standard Specification for Automated Vehicular Gate
Construction. For a copy of this standard, contact ASTM at [phone], se[email protected], or www.astm.org. Install the gate
system and gate in accordance with UL325 standards.
Space or
screen to
prevent a 2
1/4 inch
sphere from
passing
Vehicular Gate Only
Pedestrian
Access
Fence
FenceFence
All openings of a slide gate are guarded or screened
from the bottom of the gate to a minimum or 4 feet
(1.2m) above the ground to prevent a 2 1/4 inch
(57.15mm) diameter sphere from passing through the
openings anywhere in the gate, and the portion of the
adjacent fence that the gate covers in the open position.
The operator is intended for installation only on slide
gates used for vehicular traffic. Pedestrians must be
provided with a separate access opening.
NO ONE SHOULD CROSS THE PATH OF A MOVING
GATE!
Gate operator controls must be placed far enough from
the gate to prevent the user from coming in contact
with the gate while operating the controls. All
activating devices must be installed in a clear line-of-
sight with the gate and its travel. Be sure to mount all
devices clearly out of reach of through gate.
WARNING: DO NOT INSTALL this product unless all safety standards are followed and
all entrapment and pinch points have been eliminated.
!
DSL2000 Slide Gate Operator 4

I
IMPORTANT
MPORTANT
S SAFETY
AFETY
I INFORMATION
NFORMATION
INTERNAL ENTRAPMENT PREVENTION:
This vehicular gate operator is equipped with an inherent (Type A) entrapment sensing device. The system will sense an
obstruction in both the open and close cycles, and will reverse the direction of the gate travel upon encountering an
obstruction. If the system detects a second obstruction before reaching the full open or close limit after the initial reversal, a
warning alarm will activate and the operator will require a reset before resuming normal operation. This is called a “Hard
Shutdown”. Please read and follow the “Shutdown Conditions” section of this manual for more directions.
EXTERNAL ENTRAPMENT PREVENTION:
Non-contact and/or contact sensors must be installed to provide external entrapment prevention in accordance with UL325
section 3.1. Use only UL325 compliant devices and low voltage (24V) devices. Carefully follow the installation manual for the
UL325 device used for installation, usage, and maintenance.
Non-Contact Sensors (Photo Beams):
Non-contact sensors generally are photoelectric cells or like devices. For gate operators utilizing non-contact sensors:
1. Refer to the diagram below for placement of non-contact sensors.
2. Use care to reduce the risk of nuisance tripping, such as when a vehicle trips the sensor while the gate is still moving.
3. One or more non-contact sensors shall be located where a risk of entrapment or obstruction exists, such as the perimeter reachable
by a moving gate or barrier. Use caution when installing non-contact sensors since some devices only cover a select area. For
example, a photo beam will not cover the full height of a gate/fence area. Refer to the diagram below.
Contact Sensors (Edge Sensors):
Contact sensors generally are sensing edges or like devices. For gate operators utilizing contact sensors:
1. Refer to the diagram below for placement of contact sensors.
2. One or more contact sensors shall be located where the risk of entrapment or obstruction exists, such the leading edge, trailing
edge, and posts mounted inside and outside of the vehicular slide gate and motor.
3. Hardwired contact sensors shall be located and its wiring arranged so the communication between the sensor and the gate operator
is not subject to any mechanical damage.
4. Wireless contact sensors such as ones that transmit radio frequency (RF) signals to the gate operator for entrapment prevention
functions shall be located where the transmission of the signals are not obstructed or impeded by building structures, landscaping or
similar obstructions. All wireless contact sensors shall function under the intended end-use conditions.
Vehicular Gate Only
Pedestrian
Access
Fence
FenceFence
Protect against all entrapments areas that exist:
1. Between the gate and the adjacent fence when the
gate is in the open cycle
2. The gate operator and the slide gate when the gate
is in the open and close cycles
3. At the front end of the gate when the gate is in the
close cycle.
Open beams help protect areas
between the gate and the adjacent
fence. CAUTION: This beam
should be used in conjunction with
a contact sensor.
Close beams help prevent the
gate from hitting obstructions
during the close cycle.
Pedestrian
Access
Fence
FenceFence
Protect against all entrapments areas that exist:
1. Between the gate and the adjacent fence when the
gate is in the open cycle
2. The gate operator and the slide gate when the gate
is in the open and close cycles
3. At the front end of the gate when the gate is in the
close cycle.
Trailing edge sensor helps protect
areas between the gate and the
adjacent fence.
= Edge Sensor
Leading edge sensor helps
protect areas in front of the
gate.
Post edge sensors help protect
areas inside and outside of the
gate and around the operator
DSL2000 Slide Gate Operator 5

I
IMPORTANT
MPORTANT
S SAFETY
AFETY
I INFORMATION
NFORMATION
UL325 GATE OPERATOR CLASSIFICATION:
RESIDENITAL VEHICULAR GATE OPERATOR
CLASS I: A vehicular gate operator (or system) intended for use in a home of one
to four single family dwelling, or a garage or parking area associated therewith.
COMMERCIAL/GENERAL ACCESS VEHICULAR GATE OPERATOR
CLASS II: A vehicular gate operator (or system) intended for use in a commercial
location or building such as a multi-family housing unit (five or more single family
units), hotels, garages, retail store, or other building servicing the general public.
INDUSTRIAL/LIMITED ACCESS VEHICULAR GATE OPERATOR
CLASS III: A vehicular gate operator (or system) intended for use in an industrial
location or building such as a factory or lading dock area or other locations not
intended to service the general public.
RESTRICTED ACCESS VEHICULAR GATE OPERATOR
CLASS IV: A vehicular gate operator (or system) intended for use in a guarded
industrial location or building such as an airport security area or other restricted
access locations not servicing the general public, in which unauthorized access is
prevented via supervision by security personnel.
GLOSSARY OFTERMS:
GATE: A moving barrier such as a swinging, sliding, raising, lowering, or the like, barrier, that is a stand-alone passage barrier
or is that portion of a wall or fence system that controls entrance and/or egress by people or vehicles and completes the
perimeter of a defined area.
VEHICULAR HORIZONTAL SLIDE GATE OPERATOR (Or System): A vehicular gate operator (or system) that controls a
gate which slides in a horizontal direction that is intended for use for vehicular entrance or exit to a drive, parking lot, or the
like.
ENTRAPMENT: A condition when a object is caught or held in a position that increases the risk of injury or death.
INHERENT ENTRAPMENT SENSING DEVICE: An automatic sensor system, which senses entrapment of a solid object and
is incorporated as a permanent and integral part of the gate operator.
NON-CONTACT SENSOR: External device such as a photoelectric cell used to provide entrapment prevention and located
where a risk of entrapment or obstruction exists.
CONTACT SENSOR: External device such as a edge sensor used to provide entrapment prevention located where a risk of
entrapment or obstruction exists such as the leading edge, trailing edge, and posts mounted inside and outside of the vehicular
slide gate and motor.
IMPORTANT: Make sure the gate operator usage classification is correct for the site
and the type of gate.
!
ABC Apartments
ABC Manufacturing
Regional Airport
DSL2000 Slide Gate Operator 6

I
IMPORTANT
MPORTANT
S SAFETY
AFETY
I INFORMATION
NFORMATION
WARNING SIGN INSTALLATION:
This vehicular gate operator is supplied with two warning signs to alert people that a potential hazard may exist and that
appropriate action should be taken to reduce the risk of hazard, injury or death.
1. Warning signs must be permanently installed on both sides of the gate and must be fully visible to traffic and pedestrians.
2. Use appropriate hardware such as metal screws (not supplied) to permanently install each warning sign.
INSTALLATION PRECAUTIONS:
DO NOT allow children to play near, on or with the
gate, gate operator, or any of its controls.
! DO NOT allow pedestrian use of the vehicular gate.
No one should cross the path of a moving gate!
!
DO NOT mount operating devices accessible through
the gate or in between the gate and wall.
!
DO NOT mount the gate operator to a gate heavier
than 1000 pounds. Maximum gate weight = 1000 lbs.
!
DO NOT mount the gate operator to a gate longer than
40 feet. Maximum gate length = 40 feet.
!
40 Feet Maximum Length
1000 lb. Maximum
Gate Weight
DO NOT mount the gate operator on uphill or downhill
applications. Do not allow the gate to free roll.
!
Read and follow all U.L. and Safety Standards before installing any access device. Please refer to this manual and
qualified personnel for assistance. DO NOT install this device unless all entrapment and pinch points are eliminated.
!
DSL2000 Slide Gate Operator 7

G
GATE
ATE
O OPERATOR
PERATOR
I INSTALLATION
NSTALLATION
PREINSTALLATION GUIDELINES:
Before starting any installation, consider the following guidelines:
 Install the gate system and gate in accordance with ASTM F220-02: Standard Specification for Automated Vehicular Gate
Construction. Install the gate system and gate in accordance with UL325 standards.
 Be sure the gate is properly installed and moves freely. Repair or replace worn or damaged gate hardware before installing the gate
operator.
 Install over-travel stops at both ends of the gate rail or track for all types of installations to help prevent the gate from derailing.
 Add safety devices such as warning signs, photo eyes, and reverse edges to help prevent injuries or death. Reduce all pinch points
and protect all entrapment positions.
 If pedestrian traffic will be present, provide a separate pedestrian walk gate clear from the path of the automatic gate.
 Loops and loop detectors are required to help prevent the gate from closing on vehicles. Loops do not protect pedestrian traffic.
 Select the proper gate operator for the installation. Consider the usage, capacity, gate size, gate weight, and needed features and
safety accessories.
GATE OPERATOR LOCATION:
Select a location for the gate operator to be installed prior to pouring the concrete pad. There are two ways to mount a slide
gate operator: the traditional front mount, or the rear mount method. Both methods have their advantages and will reliably
open the gate.
WARNING: Install over-travel stops at both ends of the gate rail or track for all types
of installations to help prevent the gate from derailing.
!
REAR MOUNT METHOD:
A rear mount installation places the operator at the back of the
gate and uses a double chain with an additional idler sprocket.
The advantages and disadvantages include:
Advantages:
 The chain is attached to the rear of the gate and is not
visible when the gate is closed.
 The operator is in the back away from the flow of traffic for
added safety.
 The operator is in the back allowing more room for tight
parking conditions.
Disadvantages:
 Twice as much chain is required for this type of application
= added expense.
 The application requires the use of an additional idler
sprocket = added expense.
FRONT MOUNT METHOD:
The front mount method places the operator up front near
the flow of traffic and uses a single chain across the length
of the gate. The advantages and disadvantages include:
Advantages:
 Less chain is required for the application saving money
and time.
 Does not require the use of an additional idler sprocket
saving money and time.
 Less room is needed for the application and allowing the
operator to be more accessible for service.
Disadvantages:
 The operator is up front near the flow of traffic allowing
for a vehicle to damage the operator more easily.
 The chain runs across the length of the gate allowing
visitors to see and possible tamper with it.
DSL2000 Slide Gate Operator 8

G
GATE
ATE
O OPERATOR
PERATOR
I INSTALLATION
NSTALLATION
CONCRETE PAD SIZE & LOCATION:
The DSL2000 vehicular gate operator is designed to be mounted on a concrete pad. Select a location for the gate operator to
be installed. For pad location and size:
1. Determine the location for the operator to be installed. (Front Mount v. Rear Mount)
2. Follow all local building codes to determine the required depth of the concrete pad. The
average concrete pad should be 24” wide x 24” long x 24” deep.
3. Extend the pad 4” above ground and 24” below ground.
4. When the exact location of the operator can be predetermined, all conduits may be located in
the concrete pad terminating directly under the operator. Extend each conduit a minimum of
1” above the level of the concrete pad. See the Conduit Location diagram below. It is
suggested to install a minimum of four (4) conduits: (1) High Voltage Conduit, (1) Low
Voltage Conduit , (1) Loop Lead Wire Conduit, (1) Accessory Conduit.
5. When the exact location of the operator can not be predetermined, bring all conduits up to
one side and terminate in a Bell Box. Make connections to the operator using water-tight flex
conduit.
6. Form the concrete pad as shown and pour concrete. Allow the concrete to cure for 48 hours before removing the forms and
mounting the operator.
7. Do not place mounting bolts in the concrete while pouring. Bolts may drift in wet concrete making the operator location inaccurate.
8. NOTE: The path of the gate and gate track must be installed on concrete. The average gate track concrete should be a minimum of
10” wide x 12” deep the entire length of the gate track and travel. Failure to place the gate track on concrete can result in track
movement and cause gate failure or derailment.
24”
4”
24”
24”
Available
Conduit
Area
14” Wide x 12.5” Deep
GATE (2” x 2” Frame)
1.25” Distance From
Gate To Cover Gate
Bracket
3.5”
Distance From
Gate to Operator
Frame (3.5”)
12.5”
2.75” Distance From
Gate To Chain
14”
17”
WARNING: Install over-travel stops at both ends of the gate rail or track for all types
of installations to help prevent the gate from derailing.
!
DSL2000 Slide Gate Operator 9

G
GATE
ATE
O OPERATOR
PERATOR
I INSTALLATION
NSTALLATION
GATE OPERATOR BOLT DOWN
To align the operator to the gate and bolt it down:
1. Remove the gate operator cover and place the operator on the concrete pad. Position the operator with a distance of 3.5” from the
gate to the back frame of the operator. IMPORTANT: Make sure the gate and operator are parallel and level with each other.
2. Mark the mounting holes and remove the operator. Drill the mounting holes to the required depth and diameter for the sleeve
anchors being used. It is recommended to use 3/8” x 4” sleeve anchors. The use of sleeve anchors allows greater flexibility and
makes the installation and alignment much easier.
3. Clean the mounting holes and install the sleeves. Position the operator over the anchors. Recheck to make sure the gate and
operator are parallel and level with each other. Tighten the anchor bolts to securely hold the operator.
CHAIN CONNECTION - FRONT MOUNT
Once the gate operator is securely bolted down, the chain may be attached. To attach the chain for a front mounted system:
1. Make sure the chain will be in a straight line and same height as the lower idler sprockets.
2. Weld the chain brackets to the end of each side of the gate and level with the lower idler sprockets. (Approximately 11”)
3. Route the chain through the operator, over the first lower chain idler, under the chain sprocket, and over the second lower idler.
4. Connect the chain bolts to each end of the chain using the supplied master links. Connect the chain bolts to the chain brackets.
Adjustments to the chain length should be made now.
5. Tighten the chain using the chain bolts so the chain does not sag more than one (1) inch per 10 feet of travel. Do not over tighten!
GATE
GATE
OPERATOR
90o
3.5”
CORRECT ! WRONG !
GATE
GATE
OPERATOR
GATE
GATE
OPERATOR
CORRECT
GATE
GATE
OPERATOR
! WRONG !
CORRECT
Approx.
11”
! WRONG !
DSL2000 Slide Gate Operator 10

G
GATE
ATE
O OPERATOR
PERATOR
I INSTALLATION
NSTALLATION
CHAIN CONNECTION - REAR MOUNT
Rear mount operators require the use of an endless idler assembly and twice as much chain. Approximately 1 foot of added
opening space is needed. Once the gate operator is securely bolted down, the chain may be installed for a rear mount system.
1. Adjust the chain idler sprocket inside the gate operator for a rear mount application. Remove the lower idler on the unused side and
move it to the upper idler hole on the chain side of the operator. Both chain idlers should be above/below each other.
2. Increase the cover chain slot on the chain side of the operator. (Side toward the gate opening)
3. Close the gate and mount an endless idler assembly near the back of the gate. The chain must extend beyond the back of the gate.
IMPORTANT: Only use an endless idler assembly with a safety guard to prevent pinch and entrapment points.
4. Adjust the height of the endless idler sprocket so the chain from the lower chain idler is level with the bottom of the endless idler.
(Approximately 11”) Make sure the chain will be in a straight line and same height as the lower idler sprocket.
5. Weld the bottom chain bracket to the end of the gate and level with the top of the endless idler sprocket. (Height depends upon the
size of the endless idler sprocket)
6. Weld the top chain brackets to the end of the gate and level with the top of the upper idler sprocket. (Approximately 15”)
7. Route the chain through the operator, over the upper chain idler, around and under the chain sprocket, and over the lower idler.
8. Route the lower chain under and around the endless idler assembly.
9. Connect the chain bolts to each end of the chain using the supplied master links. Connect the chain bolts to the chain brackets.
Adjustments to the chain length should be made now.
10. Tighten the chain using the chain bolts so the chain does not sag more than one (1) inch per 10 feet of travel. Do not over tighten!
WARNING: DO NOT INSTALL this product unless all safety standards are followed and
all entrapment and pinch points have been eliminated.
!
DSL2000 Slide Gate Operator 11

G
GATE
ATE
O OPERATOR
PERATOR
I INSTALLATION
NSTALLATION
LIMIT SWITCH SETUP:
The gate operator uses a limit switch assembly to adjust the distance of travel. These adjustments should be made before
power is supplied to the operator. To adjust the distance of travel using the limits:
1. Turn power OFF! Use the power switch on the side to assure AC and Battery power are both OFF.
2. Manually move the gate fully to the right. Push the limit guide plate down and roll the top limit nut until it activates the top limit
switch. The switch will click when activated.
3. Manually move the gate to the left. Push the limit guide plate down and roll the bottom limit nut until it activates the bottom limit
switch. The switch will click when activated.
4. Release the limit guide plate and make sure it is engaged in the slots of each limit nut.
5. Readjust the limit nuts as necessary to fine tune the full-open and full-closed positions.
GATE OPERATOR DIRECTION:
The gate operator uses a DIP switch setting to determine the open and close direction. To set the Open/Close direction:
1. Turn power OFF! Use the power switch on the side to assure AC and Battery power are both OFF.
2. Standing inside the gate looking at the gate operator, determine if the gate opens to the LEFT or RIGHT.
3. If the gate opens to the LEFT, move DIP SWITCH 6 to the Left.
4. If the gate opens to the RIGHT, move DIP SWITCH 6 to the Right.
RIGHT
(Top)
LEFT
(Top)
Opens LEFT
Switch 6:
OFF
Opens RIGHT
Switch 6:
ON
DSL2000 Slide Gate Operator 12

E
ELECTRICAL
LECTRICAL
I INSTALLATION
NSTALLATION
POWER SWITCH LOCATION:
The gate operator uses a built-in power switch to control power to the operator and controller. This switch should be turned
OFF during installation and service. Failure to use this switch can result in unexpected gate movement. Please note:
1. The switch is located on the LEFT side of the control box.
2. DOWN position = OFF. UP position = ON.
3. This switch must be used to turn OFF AC and battery power. Only disconnecting AC power still allows battery power to the
operator, controller, and accessories.
4. Turn OFF until the installation is complete.
AC POWER GUIDELINES:
Under normal conditions, the gate operator will use a single phase AC power line to operate the gate, charge the batteries, and
power gate accessories. Use the following guidelines when installing the AC power:
1. Check the local wiring codes in all cases and follow all local building codes. Wiring and hookup should be performed by a qualified
electrician/installer only.
2. AC power should be supplied from a circuit breaker panel and must have its own dedicated circuit breaker. This supply must include
a green ground conductor.
3. Only use U.L. approved 14 AWG or larger 600 Volt Insulated Wire. Use the following chart to determine the AC wire size. This
information is for suggested use only - Check your local codes before installation.
4. Properly ground the gate operator to minimize or prevent damage from power surges and/or lightning. Use a grounding rod if
necessary. A surge suppresser is recommended for additional protection.
AC POWER CONNECTION:
To connect AC power to the gate operator:
1. Turn the circuit breaker for the AC gate operator power OFF before connecting the AC input wires.
2. Turn the Power Switch OFF located on the left side of the controller before connecting the AC input wires.
3. Connect the AC input wires to the AC terminal located on the bottom/center of the control box. See diagram below.
4. Batteries must be installed after the AC power is on. See Battery Power Connection.
Wire Size: 14 Gauge 12 Gauge 10 Gauge 8 Gauge 4 Gauge
Distance: 250 Feet 400 Feet 650 Feet 1000 Feet 2000 Feet
L1 L2
GREEN = Ground
WHITE = Neutral
BLACK = 120 VAC
DSL2000 Slide Gate Operator 13

E
ELECTRICAL
LECTRICAL
I INSTALLATION
NSTALLATION
BATTERY POWER CONNECTION:
If AC power is connected, the system does not need the batteries to function. However, the batteries must be connected for
the Power Fail Battery Backup features to operate. When AC power is active, the batteries will charge until fully charged.
Once the batteries have fully charged, the system will stop charging. Charging is automatic when AC power is available. The
system should be prewired with the batteries. If not, to connect batteries to the system:
1. Connect the RED wire from the Battery + Terminal to the positive terminal of the first battery.
2. Connect the BLACK wire from the Battery - Terminal to the negative terminal of the second battery.
3. Connect a jumper between the remaining terminals of each battery.
ACCESSORY POWER:
Two plug-in power plugs are located on the back of the controller. These plugs are for low voltage accessories and are
separately fused. Low voltage, low current draw transformers may be plugged into these outlets for accessory power. DO
NOT USE THESE POWER OUTLETS FOR INSTALLATION OR SERVICE TOOLS. Each plug supplies 110 VAC when AC
power is active to the gate operator. If AC is not available, the power plugs will not supply power. Accessories requiring power
during battery backup modes should use the 24 VDC located on the controller terminals.
Additional accessory power may be found on the controller terminals. The controller terminals supply 24 VDC for accessories.
This power is available during AC and battery power modes. When AC power is active, accessories will be supplied 24 VDC
without a power draw on the batteries. When the battery backup mode is active, accessories will be supplied 24 VDC from the
batteries. If the battery power mode is used frequently, consider the current draw of the accessories. The lower the current
draw, the longer the battery power supply will last. Additional 24 VDC for accessories may be found on the Radio Terminal,
Edge/Photo Terminal, and External Loop Terminal. A connection between 24V DC+ and Common will supply power.
Batteries should be tested regularly for proper battery backup operation.
Batteries should be replaced each year or as needed.
!
12VDC, 7 amp
Battery
12VDC, 7 amp
Battery
+
+
-
-
RED
BLACK
DSL2000 Slide Gate Operator 14

Master
Switch 3:
OFF
Master
Gate Operator
Slave
Switch 3:
ON
Slave
Gate Operator
E
ELECTRICAL
LECTRICAL
I INSTALLATION
NSTALLATION
MASTER/SLAVE CONNECTION:
The gate operator uses RS422 connectors to wire a Master and Slave operator together. The RS422 connectors allow for a
stronger more complete signal between the two operators. All external devices and inputs must be wired directly to the
Master operator. To connect two operators together:
1. Determine which operator is the Master and which operator is the slave. All external devices such as loop detectors and safety
devices must be wired directly to the Master unit.
2. Turn Slave Operator DIP Switch 3 to ON = SLAVE
3. Turn Master Operator DIP Switch 3 to OFF = MASTER
4. In a separate conduit, run a 6-conductor cable between the Master operator and the Slave operator. (Recommended Wire: Outdoor
Rated CAT 5 or CAT 7 Cable)
5. Using RS422 connectors, color connect each wire.
 MASTER ORANGE WHITE to SLAVE ORANGE WHITE (Pin 1 to Pin 6)
 MASTER ORANGE to SLAVE ORANGE (Pin 2 to Pin 3)
 MASTER GREEN WHTIE to SLAVE GREEN WHITE (Pin 3 to Pin 2)
 MASTER GREEN to SLAVE GREEN (Pin 6 to Pin 1)
 MASTER BROWN WHITE to SLAVE BROWN WHITE (Pin 5 to Pin 5)
Brown White (Pin 5 to Pin 5)
Green (Pin 6 to Pin 1)
Green White (Pin 3 to Pin 2)
Orange (Pin 2 to Pin 3)
Orange White (Pin 1 to Pin 6)
IMPORT NOTE:
All external safety and auxiliary
devices must be wired directly to
the Master operator.
Pin 8 Pin 7 - Pin 6 - OrangeWhite Pin 5 - Brown White Pin 4 Pin 3 - Orange Pin 2 - Green White Pin 1 - Green
Slave Plug
Pin 8 Pin 7 - Pin 6 - Green Pin 5 - Brown White Pin 4 Pin 3 - Green White Pin 2 - Orange Pin 1 - OrangeWhite
Master Plug
DSL2000 Slide Gate Operator 15

G
GATE
ATE
O OPERATOR
PERATOR
A ADJUSTMENTS
DJUSTMENTS
REVERSE SENSITIVITY ADJUSTMENT:
The gate operator is equipped with an inherent (Type A) entrapment sensing system. The sensor detects obstructions in both
the open and close path of the gate. There is an OPEN SENSITIVITY Adjustment and a CLOSE SENSITIVITY Adjustment.
To adjust the sensitivity:
1. Activate the gate to open.
2. While the gate is running open, slowly rotate the OPEN SENSITIVITY adjustment clockwise to INCREASE the sensitivity until the
gate stops in mid-travel.
3. Gently rotate the OPEN SENSITIVITY adjustment counter-clockwise 1/8 turn to DECREASE the sensitivity.
4. Activate the gate to close.
5. While the gate is running closed, slowly rotate the CLOSE SENSITIVITY adjustment clockwise to INCREASE the sensitivity until the
gate stops in mid-travel.
6. Gently rotate the CLOSE SENSITIVITY adjustment counter-clockwise 1/8 turn to DECREASE the sensitivity.
7. Operate the gate a few times to be sure it fully cycles without stopping.
8. Place an immobile object in the open path of the gate to stop the gate while in travel. The gate should stop and enter a Soft
Shutdown upon striking the object.
9. Place an immobile object in the closed path of the gate to stop the gate while in travel. The gate should stop and enter a Soft
Shutdown upon striking the object.
10. Repeat steps 2 - 6 until the correct sensitivity adjustment is found.
REVERSE SENSITIVITY SHUTDOWN:
Upon a first obstruction, the reverse sensor should:
1. Stop the gate and reverse it approximately two (2) inches.
2. Disable the Timer To Close Feature until the gate operator receives a new command = Soft Shutdown.
3. Any standard input can reactivate the gate and return it to normal operation.
Upon a second consecutive obstruction before the gate reaches either limit, the reverse sensor should:
1. Stop the gate.
2. Disable the gate operator = Hard Shut Down.
3. Sound the audio alarm for five (5) minutes or until the operator has been reset.
4. Only resetting the operator will reactivate the gate and return it to normal operation.
5. To reset the operator in a Hard Shut Down situation: Press the reset button on the left side of the controller or turn the power switch
OFF and back ON.
For the Reverse Sensor to function correctly, the gate must be properly installed and work freely in both directions.
Repair or replace worn hardware. DO NOT use sensitivity to compensate for a gate in need of service.
!
Clockwise Turn:
INCREASE Sensitivity
(Reverse the gate more easily)
Counter-Clockwise Turn:
DECREASE Sensitivity
(Reverse the gate less easily)
Gently rotate each
adjustment. Turning
the adjustment POT
too hard will break the
adjustment.
CAUTION:
WARNING: DO NOT INSTALL this product unless all safety standards are followed and
all entrapment and pinch points have been eliminated.
!
DSL2000 Slide Gate Operator 16

G
GATE
ATE
O OPERATOR
PERATOR
A ADJUSTMENTS
DJUSTMENTS
CLOSE TIME DELAY ADJUSTMENT:
The gate operator is equipped with a built-in automatic timer to close feature. This feature should be set to the OFF position
until proper safety and reverse devices have been installed. CAUTION: Turning on the Close Time Delay without proper
safety and reverse devices can cause serious injury, death, and property damage. The Close Time Delay can be set to from 1
to 90 seconds. When active, the Close Time Delay will hold the gate open until the internal timer has timed out and then
allows the gate to close. To turn OFF/ON and adjust the Close Time Delay:
1. To turn OFF the Close Time Delay, move DIP SWITCH 4 to the Left.
2. To turn ON the Close Time Delay, move DIP SWITCH 4 to the Right.
3. Turn power Off and back On to reset DIP Switch settings.
4. Rotate the TIME DELAY adjustment clockwise to INCREASE the delay.
5. Rotate the TIME DELAY adjustment counter-clockwise to DECREASE the delay.
DIP SWITCH SETTINGS
The DIP Switches located on the top right face of the controller are used to set several different functions. This list gives a
brief description. The factory setting is in bold print. Please review each individual section in this manual for more detail.
Switch Function Description
1 Alarm
OFF: Sounds the built-in alarm in shutdown applications only.
ON: Beeps while gate is moving. Sounds the alarm in shutdown applications.
2 Anti-Tailgate
OFF: Gate opens and closes normal.
ON: Uses loops to control vehicles individually.
3 Master/Slave
OFF: Operator is set as a Master (Primary).
ON: Operator is set as a Slave (Secondary).
4 Close Timer
OFF: Time Delay Close feature is inactive. Command to open, command to close.
ON: Time Delay Close feature is active. Gate opens, times out, closes.
5 Power Fail Cycle / Open OFF: During power failure, gate will cycle using BBU until batteries are too low to function.
ON: During power failure, gate will open and remain open until AC power is restored.
6 Open Left/Right
OFF: Opens the gate Left. (Standing inside looking out at operator)
ON: Opens the gate Right. (Standing inside looking out at operator)
7 Quick Close
OFF: Gate opens and closes normal.
ON: Gate opens until loops are cleared. Then close gate even if gate did not reach full open position.
8 Stop (NC / NO) OFF: Allows a NC Stop Switch to be used. This setting default is OFF until a Stop Switch is installed.
ON: Allows a NO Stop Switch to be used. Stop Switch must be installed for this setting to be ON.
9 Battery Cycle
OFF: Cycles gate until batteries are too low and stops. Switch 5 must be OFF.
ON: Cycles gate until batteries are too low and then opens gate. Switch 5 must be OFF.
10 Mag / Solenoid Delay OFF: No delay - activates gate immediately
ON: Delays 2 seconds before activating gate. Slave opens first followed by Master. Master closes first.
11 Tamper Detect
OFF: Gate opens and closes normal.
ON: When closed, if gate is forced off limit, alarm sounds, motor stops open movement and closes gate.
12 Hard Start
OFF: Gate opens and closes normal.
ON: Gate starts with 40% motor power for more starting torque. Normal start = 5% motor power.
Timer ON
Switch 4:
ON
Clockwise Turn:
INCREASE Time Delay
(Holds gate open longer time)
Counter-Clockwise Turn:
DECREASE Time Delay
(Holds gate open shorter time) Gently rotate each adjustment. Turning the
adjustment POT too hard will break the
adjustment.
CAUTION:
DSL2000 Slide Gate Operator 17

A
ACCESSORY
CCESSORY
C CONNECTIONS
ONNECTIONS
ACCESSORY WIRE OVERVIEW:
CLOSE
Photo Cell
OPEN
Photo Cell
O
P
E
N
E
D
G
E
C
L
O
S
E
E
D
G
E
Radio
Receiver OPEN
CLOSE
STOP
FIRE
LOCK
Card Access
1 2 3
4 5 6
7 8 9
* 0 #
Key Box
1 2 3
4 5 6
7 8 9
* 0 #
Phone Entry
WARNING: DO NOT INSTALL this product unless all safety standards are followed
and all entrapment and pinch points have been eliminated.
!
DSL2000 Slide Gate Operator 18

A
ACCESSORY
CCESSORY
C CONNECTIONS
ONNECTIONS
EDGE SENSOR CONNECTIONS:
The gate operator has a Close Edge Terminal and an Open Edge Terminal for added control of the Sensing Edge functions.
The following chart describes the functions for a Close Edge Sensor and an Open Edge Sensor:
To connect a Sensing Edge:
1. Refer to the “External Entrapment Prevention” section of this manual for guidelines and placement.
2. Connect Close Edge Sensors to EDGE CLOSE and COMMON.
3. Connect Open Edge Sensors to EDGE OPEN and COMMON.
Close Edge Input:
1. Input is only active during close cycle.
2. An input during the close cycle will stop and reverse the gate to
the full open position.
3. If an Open Edge Input is active before reaching the full open
position, the gate will stop and enter a soft shutdown.
4. If the gate reaches the full open position and the Time Delay
Close is ON, the gate will time out and close.
5. If the gate reaches the full open position and the time Delay
Close is OFF, the gate will remain open until a close input is
received.
6. If a second Close Edge Input is received while closing, the gate
will stop and enter a soft shutdown.
Open Edge Input:
1. Input is only active during open cycle.
2. An input during open cycle will stop and reverse the gate to the
full closed position and enter a soft shutdown.
3. NOTE: If the gate was initially activated by a time clock with a
contact closure across the Access Input, this input will be
ignored until another input (Open Loop, Reverse Loop, etc.) is
received.
4. If a Close Edge input is active before reaching the full closed
position, the gate will stop and enter a soft shutdown.
O
P
E
N
E
D
G
E
C
L
O
S
E
E
D
G
E
Edge Sensor Notes:
1. One or more contact sensors shall
be located where the risk of
entrapment or obstruction exists,
such the leading edge, trailing
edge, and posts mounted inside
and outside of the vehicular slide
gate and motor.
2. Hardwired contact sensors shall
be located and its wiring arranged
so the communication between
the sensor and the gate operator
is not subject to any mechanical
damage.
3. Wireless contact sensors such as
ones that transmit radio frequency
(RF) signals to the gate operator
for entrapment prevention
functions shall be located where
the transmission of the signals are
not obstructed or impeded by
building structures, landscaping or
similar obstructions. All wireless
contact sensors shall function
under the intended end-use
conditions.
4. Wireless contact sensors should
be checked on a regular basis.
Batteries should be replaced on a
WARNING: DO NOT INSTALL this product unless all safety standards are followed and
all entrapment and pinch points have been eliminated.
!
DSL2000 Slide Gate Operator 19

A
ACCESSORY
CCESSORY
C CONNECTIONS
ONNECTIONS
PHOTO SENSOR CONNECTIONS:
The gate operator has a Photo Close Terminal and an Photo Open Terminal for added control of the Photo Sensor functions.
The following chart describes the functions for a Photo Close Sensor and a Photo Open Sensor:
To connect a Photo Sensor:
1. Refer to the “External Entrapment Prevention” section of this manual for guidelines and placement.
2. Connect the Photo Close Sensor to PHOTO CLOSE and COMMON.
3. Connect the Photo Open Sensor to PHOTO OPEN and COMMON.
4. For Photo Sensors that use 24VDC power, connect power to +24VCD and COMMON.
OPEN
Photo Cell
CLOSE
Photo Cell
Photo Sensor Notes:
1. Use care to reduce the risk of
nuisance tripping, such as
when a vehicle trips the
sensor while the gate is still
moving.
2. One or more non-contact
sensors shall be located
where a risk of entrapment or
obstruction exists, such as the
perimeter reachable by a
moving gate or barrier. Use
caution when installing non-
contact sensors since some
devices only cover a select
area. For example, a photo
beam will not cover the full
height of a gate/fence area.
Refer to the diagram below.
3. Use only UL325 compliant
devices and follow all installation
guidelines set forth by the
manufacturer.
Photo Close Input:
1. Input is only active during close cycle.
2. An input during the close cycle will stop the gate.
3. The gate will remain stopped until the input is cleared.
4. When the Photo Close is cleared, the gate will continue to
close.
Photo Open Input:
1. Input is only active during open cycle.
2. An input during open cycle will stop the gate.
3. The gate will remain stopped until the input is cleared.
4. When the Photo Open is cleared, the gate will continue to open.
WARNING: DO NOT INSTALL this product unless all safety standards are followed and
all entrapment and pinch points have been eliminated.
!
DSL2000 Slide Gate Operator 20
