FabiaTech FX5201 User manual

FabiaTech Corporation
IPC Solution
Website: http://www.fabiatech.com
Email: [e-mail]
Small Cube System
Fanless Series
FX5201 User’ Manual
MAY 2013
Version: 1.3
Part Number: FX5201

Copyright
Copyright © 2006 FabiaTech Corporation, The content of this publication may not
be reproduced in any part or as a whole, transcribed, stored in a retrieval system,
translated into any language, or transcribed in any form or by any means,
electronic, mechanical, and magnetic… or otherwise without the prior written
permission of FabiaTech Corporation.
Disclaimer
FabiaTech makes no representation of warranties with respect to the contents of
this publication. In an effort to continuously improve the product and add features,
FabiaTech reserves the right to revise the publication or change specifications
contained in it from time to time without prior notice of any kind from time to time.
FabiaTech shall not be reliable for technical or editorial errors or omissions, which
may occur in this document. FabiaTech shall not be reliable for any indirect,
special, incidental or consequential damages resulting from the furnishing,
performance, or use of this document.
Trademarks
Trademarks, brand names and products names mentioned in this publication are
used for identification purpose only and are the properties of their respective
owners.
Technical Support
If you have problems or difficulties in using the system or setting up the relevant
devices, and software that are not explained in this manual, please contact our
service engineer for service, or send email to sup[email protected].
Returning Your Board for Service & Technical Support
If your board requires servicing, contact the dealer from whom you purchased the
product for service information. You can help assure efficient servicing of your
product by following these guidelines:
A list of your name, address, telephone, facsimile number, or email address
where you may be reached during the day
Description of you peripheral attachments
Description of your software (operating system, version, application
software, etc.) and BIOS configuration
Description of the symptoms (Extract wording any message)
For updated BIOS, drivers, manuals, or product information, please visit us
at www.fabiatech.com
ii

Table of Contents
FX5201 User’ Manual .............................................................................................................i
Chapter 1 Introducing the FX5201 System ............................................................................... 1
Overview..................................................................................................................................1
Series Comparison Table.......................................................................................................2
Layout.......................................................................................................................................3
Specifications..........................................................................................................................4
Packing List..............................................................................................................................5 
Chapter 2 Hardware Installation ............................................................................................... 7
Before Installation...................................................................................................................7
Removing Covers –Installing HDD, Compact Flash or Memory ..................8
Installing the universal fixers on FX5201..........................................................10
LED Indicators (On the Front Panel)...............................................................10
Connecting the Monitor, Keyboard, Mouse................................................11
Connecting the DC Power and Power Switch ............................................14
Jumper setting...................................................................................................15
Chapter 3 BIOS Setup............................................................................................................... 17
Overview................................................................................................................................17
BIOS Functions ...................................................................................................18
Keyboard Convention.....................................................................................19
Standard CMOS Setup........................................................................................................20
Date & Time Setup............................................................................................20
Hard Disk Setup.................................................................................................20
Video ..................................................................................................................21
Halt On................................................................................................................21
Memory ..............................................................................................................21
Base Memory.....................................................................................................21
Extended Memory............................................................................................21
Other Memory...................................................................................................22
Total Memory.....................................................................................................22
BIOS Features Setup.............................................................................................................23
Virus Warning.....................................................................................................23
iii

CPU Internal Cache .........................................................................................23
First /Second /Third/Boot Other Device/ Boot Device................................24
Boot Up Numlock status...................................................................................24
Gate A20 Option ..............................................................................................24
Typematic rate Setting.....................................................................................24
Security Option..................................................................................................25
Chipset Features Setup........................................................................................................26
CPU Frequency.................................................................................................26
CAS Latency......................................................................................................26
Video Memory Size...........................................................................................27
Onboard Audio.................................................................................................27
Peripheral Setup...................................................................................................................28
OnChip Primary IDE Channel 1.......................................................................28
Master /Slave Drive PIO mode........................................................................28
IDE Primary Master/Slave UDMA.....................................................................28
IDE HDD Block Mode........................................................................................29
OnBoard UART/IRQ Port 1/2............................................................................29
Serial Port 2 Mode Select.................................................................................29
LAN1 Controller .................................................................................................29
Onboard LAN Boot ROM.................................................................................29
Power Management ...........................................................................................................30
Power Management........................................................................................30
PCI/Plug and Play ................................................................................................................31
PNP O/S Installed...............................................................................................31
Reset Configuration Data: Enable, Disable..................................................31
Resources Controlled By: Auto, Manual .......................................................31
PCI/VGA Palette Snoop...................................................................................32
PC Health Status...................................................................................................................33
System Hardware Monitor...............................................................................33
Password Setup.....................................................................................................................34
Chapter 4 Software Installation ............................................................................................... 35
VGA Drivers ...........................................................................................................................35
iv

WINDOWS XP Driver..........................................................................................35
LAN Utility & Driver................................................................................................................35
Audio Drivers .........................................................................................................................36
WINDOWS XP Driver..........................................................................................36
AES Drivers .............................................................................................................................36
WINDOWS XP Driver..........................................................................................36
BIOS Flash Utility.....................................................................................................................36
Watchdog Timer...................................................................................................................37
Watchdog Timer Setting..................................................................................38
Watchdog Timer Enabled ...............................................................................39
Watchdog Timer Trigger ..................................................................................39
Watchdog Timer Disabled...............................................................................40
rogramming RS-485..............................................................................................................41
Chapter 5 Technical Reference .............................................................................................. 45
Trouble Shooting for Post Beep and Error Messages.......................................................45
POST BEEP...........................................................................................................45
Error Message....................................................................................................45
Technical Reference............................................................................................................48
Physical and Environmental............................................................................48
Real-Time Clock and Non-Volatile RAM .......................................................48
CMOS RAM Map...............................................................................................50
I/O Port Address Map.......................................................................................51
Interrupt Request Lines (IRQ)...........................................................................52
DMA Channel Map..........................................................................................53
DMA Controller 2........................................................................................................53
Serial Ports..........................................................................................................54
Appendix................................................................................................................................... 58
Dimension..............................................................................................................................58
v

vi

FabiaTech Corporation
Chapter1IntroducingtheFX5201System
Overview
The FX5201 is a 1U embedded system with AMD Geode™ LX-800 processor board
inside. This user’s manual provides information on the physical features, installation,
and BIOS setup of the FX5201.
Built to unleash the total potential of the AMD Geode™ Processor, Able to support
500 MHz CPU, this system support 10/100M interface network port, audio, 1 So-
DIMM socket with 256MB DDR RAM, Four USB2.0 ports, and a VGA controller.
Each FX5201 has two ports for I/O communications. Two RS-232C ports are
available.
The FX5201 is perfect for ATM machines, KIOSK, point-of-sales/point-of- information,
gaming and infotainment, measurement technology, lotteries, banking and Thin
Client and small Embedded Control. The unit is only 123.0mm(D) x 120.0mm(W) x
44.2mm(H), offering unparalleled performance in a very small footprint.
1

FabiaTech Corporation
SeriesComparisonTable
Model FX5201
Processor AMD Geode™ LX800 (500MHz)
Chipset AMD Geode™ CS5536
1 200 Pin-DIMM (Max.) 256MB/1GB
CRT VGA Yes
Watchdog Timer Yes
Multi I/O Two RS232C
Enhanced IDE One
CF (Compare Flash Socket) One
USB2.0 Four
Audio MIC-In/Out
RJ45 Ethernet
(10/100M Base-TX) One
Dimensions (Unit: mm) 123.0 (D) x 120.0 (W) x 44.2 (H)
2

FabiaTech Corporation
Layout
OFF
ON
+
-
DC12~24V 2/
1
LINK
ACT
VGA Comport
DC IN KB/MOUSE LAN SWITCH
MIC Ear-phone RESET
USB
HDDLINK
POWERACTIVE
3

FabiaTech Corporation
Specifications
Processor Board –
AMD Geode™ LX800 (500MHz) CPU with 256MB DDR RAM.
I/O Outlets –
One 10/ 100M Ethernet with RJ-45 ports.
Two RS-232 serial ports and four USB ports (V2.0).
One CRT and one PS/2 compatible keyboard and mouse interfaces.
Audio function supports MIC-In, Line -Out connector.
One DC-In plug connector with power switch.
One push button reset switch.
One power LED and hard disk/ Compact Flash access LED, and two LED’s
with access and link for LAN.
Storage Bay-
One Compact Flash slot for Compare Flash Module or Micro Drivers
One 2.5" hard disk space with HDD clamp holder.
Power requirement –
+12 ~ +24V DC with 15% tolerance, 10VA maximum with 2.5” HDD and 19V
input voltage.
Dimensions (1U height)-
123.0mm(D) x 120.0mm(W) x 44.2mm(H)
4

FabiaTech Corporation
PackingList
Upon receiving the package, verify the following things. Should any of the
mentioned happens, contact us for immediate service.
•Unpack and inspect the FX5201 package for possible damage that may
occur during the delivery process.
•Verify the accessories in the package according to the packing list and see
if there is anything missing or incorrect package is included.
•If the cable(s) you use to install the FX5201 is not supplied from us, please
make sure the specification of the cable(s) is compatible with the FX5201
system.
Note: after you install the FX5201, it is recommended that you keep the diskette or
CD that contains drivers and document files, and keep the document
copies, or unused cables in the carton for future use.
The following lists the accessories that may be included in your FX5201 package.
Some accessories are optional items that are only shipped upon order.
•One FX5201 embedded system.
•One AC to DC power adapter and one AC power code.
•One 44-pin flat cable and 4 screws for fixing and connecting a 2.5" HDD
driver.
•One Y-type (3-terminal) PS/2 keyboard plus mouse port adapter cable.
•Two L-type universal fixers and 4 screws.
•One FX5201k1 pack of Wall Mounting Kit with VESA 75/100 mm Standards.
(Optional)
•One 2-pin apartable terminal block.
•One compact disc includes software utility.
5

FabiaTech Corporation
6

FabiaTech Corporation
Chapter2HardwareInstallation
This chapter introduces the system connectors & jumper settings, and guides you to
apply them for field application.
BeforeInstallation
Before you install the system, make sure you follow the following descriptions.
1. Before removing the cover, shut down the operation System and disconnect
power switch to off and unplug AC-to DC Adapter cable.
2. Install or unplug any connector, Compact Flash, and hard disk be sure that the
power is disconnected or power switch to off from the system. If not, this may
damage the system.
3. The ESD (Electricity Static Discharge) may be created from human body that
touches the board. It may do damage to the board circuit.
7

FabiaTech Corporation
8
Removing Covers –Installing HDD, Compact Flash or Memory
If you are installing hardware option, you can remove the rear panel and bottom
cover. The following figure will guide you how to install 2.5" HDD inside the FX5201
and how to install the FX5201 fixers.
Note: Use caution when handling the hard disk to prevent damage to IDE
connector as you insert hard disk.
Be careful with the pin orientation when installing connectors and the cables. A
wrong connection can easily destroy your hard disk. CN7 is used to connect a
2.5" HDD with included 44-pin flat-cable.

FabiaTech Corporation
9
Installing Compact Flash
If you are installing Compact Flash modules you need to remove the real panel
and bottom cover. (Please see the spots circled.)
Installing Memory: SO-DIMM Socket for DDR Modules
You may extend additional memory to FX5201 by removing the bottom cover, See
as following figure and rear pictures.The SO-DIMM socket supports 128MB to 1GB of
DDR RAM modules.
Note: The Compact Flash socket supports 3.3V Compact Flash and Micro Drives.
The JP2 is used to select master/slave device of this socket and default is slave
(close). Be sure to avoid the same master/slave setting with which connects to
IDE connector, if you use CF and IDE hard disk simultaneous.

FabiaTech Corporation
10
Installing the universal fixers on FX5201
Please refer to the down side figure for installing the FX5201 with universal fixers.
a. FX5201 L-type universal fixers.
b. FX5201k1 universal fixers-Wall Mounting Kit with VESA 75/100 mm Standards.
LED Indicators (On the Front Panel)
The Power and HDD LED’s has two distinctive statuses: Off for inactive operation
and blinking light for activity. And the 2 LED’s for LAN ports. The up side LED’s
(Green) indicate on-line, and down side LED (Orange) access status of LAN.
LINK
ACT
USB
HDDLINK
POWERACTIVE

FabiaTech Corporation
Connecting the Monitor, Keyboard, Mouse
To connector the peripheral control devices and monitor to the FX5201, refer to the
following procedure.
OFF
ON
+
-
DC12~24V 2/
1
VGA Comport
DC IN KB/MOUSE LAN SWITCH
MIC Ear-phone RESET
1. A VGA connector is provided for CRT display
2. The connector uses the included adapter cable you can attach standard PS/2
type keyboard and mouse. Standard PS/2 keyboard can be plugged into this
connector without any adapter cable. If PS/2 keyboard and mouse will be used
simultaneously, a Y-type (3-terminal) adapter cable is needed.
DB15 Signal
1 Red
2 Green
3 Blue
13 Hsync
14 Vsync
12 DDC Data
15 DDC Clock
5 & 10 Digital Ground
6,7,8 Analog Ground
Others Not Used
Pin Description
1 Mouse Data
2 Keyboard Data
3 Ground
4 VCC
5 Mouse Clock
6 Keyboard Clock
11

FabiaTech Corporation
12
3. Connecting the COM ports
The DB9 (COM1/2) is standard serials port connector. The following tables show
the signal connections of these connectors.
4. Connecting the LAN ports and USB Ports
The RJ45 connector with 2 LED’s for LAN. The right side LED (orange) indicates data
is being accessed and the left side LED (green) indicates on-line status. (On
indicates on-line and off indicates off-line)
The FX5201 supports a four port USB connector. Any USB device can be attached
to USB ports with plug-and-play supported. The left side port is USB # 1/2 and the
right side port is USB # 3/4
DB-9 RS-232 Signal
1 -DCD2
6 -DSR2
2 RXD2
7 -RTS2
3 -TXD2
8 -CTS2
4 -DTR2
9 -RI2
5 Ground
Case Case Ground
LAN Signal LAN Signal
1 TPTX+ 5 FBG1
2 TPTX - 6 TPRX -
3 TPRX+ 7 FBG2
4 FBG1 8 FBG2
USB#1~4 Signal
1 USBV
2 USBD-
3 USBD+
4 USBG
RJ45 connector
(Front View)
1
8
The following lists the pin assignment of RJ45
The following lists the pin assignment of USB port

FabiaTech Corporation
5. System Reset button
The FX5201 has a push button switcher for system reset; Push and release the
button will cause hardware reset of FX5201 and restart system booting.
6. LED Indicators (On the Front Panel)
The Power, LAN and HDD LED have two distinctive statuses: Off for inactive
operation and blinking light for activity.
LED1: HDD LED (Red)
3
4
1
LED2: POWER LED (Green)
LED3: LAN LINK LED (Green)
2
LED4: LAN Access LED (Orange)
7. Connecting the Audio Microphone In/ Line Out
MIC - In (Left Side) Line – Out (Right Side)
13

FabiaTech Corporation
14
Connecting the DC Power and Power Switch
Power is supplied through an external AC/DC power adapter or power DC In.
Check the technical specification section for information about AC/DC power
input voltage. See following figure and a side pictures.
DC-Power Jack: Use External AC/DC power adapter
DC12~24V
-+
Since the switch does include a power switch, plugging its power adapter into a
power outlet then switch power to on, when you final installed system hardware
device.
DC Power Connector: Use external 2-pin apartable terminal block.
DC +12~+24V, 15% tolerance
25VA minimum
On: Power On
Off: Power Off
DC12~24V
-+
