FabiaTech Corporation
1
Chapter1IntroducingtheFX5634System
Overview
The FX5634 is an embedded system with low-power CPU module inside. This user’s
manual provides information on the physical features, installation, and BIOS setup
of the FX5634.
Built to unleash the total potential of the AMD - Sempron uPGA 638 pin S1
Processors with 800 MHz Front Side Bus ( FSB), Able to supports 1600Mhz ~ 2000Mhz
CPU, this system supports two 10/100/1000M Base –TX LAN ports, DDR2 667MHz-RAM,
mini PCI socket for wireless LAN, Four USB2.0 ports, and a VGA controller.
Each FX5634 has two ports for I/O communications. Two RS-232C ports are
available.
The FX5634 is perfect for ATM machines, KIOSK, point-of-sales/point-of- information,
gaming and infotainment, measurement technology, lotteries, and banking and
small Embedded Control. The unit is only 189.80.0mm (D) X280.0mm (W) X85mm (H).

FabiaTech Corporation
2
SeriesComparisonTable
Model FX5634
System Processor AMD Mobile
Sempron
N+S Chipset AMD RS690E +SB600
2 200 Pin-DIMM (Max.) DDR2 533/667MHz
1GB/2GB/4GB
VGA Yes
Watchdog Timer Yes
Multi I/O Two RS232
Storage One CF /One ATA/Two SATA2
COMBO Drive DVD/CD-RW(OPTION)
USB 2.0 Four
Audio Earphone-out/Line-In/Microphone-In
RJ45 Giga LAN port Two RTL8111B CHIPSET(PCI-e)
Mini-PCI Socket One
PCI Bus Expansion One
Operating Temperature 0~+ 40℃(32~104℉)
Storage Temperature -20~+60℃(4~140℉)
Dimensions (Unit: mm) 189.0(D) x280(W) X 85(H)

FabiaTech Corporation
3
Layout
POWER
SWITCH
RESET
HDD
LIGHT
POWER
LIGHT
MOUSE
KEYBOARD
COM2
COM1
VGA LAN2 LAN1
DC IN
8V~20V
USBUSB
OUT IN MIC
COM3COM4
ANTENNA
AC/110~240V

FabiaTech Corporation
4
Specifications
Processor Board –
AMD Mobile Sempron 638-pin Processor
2 SoDIMM slot support DDR II 533 /667 MHz SDRAM Up to 4GB
I/O Outlets –
One 10/100 and One 10/100/1000 base-TX Ethernet LAN ports.
Four USB ports (2.0) and two RS-232 serial ports.
One CRT and one PS/2 compatible keyboard and mouse interfaces.
Three audio connectors for Earphone/Line-out, Line-in and Microphone-In.
One Mini PCI Socket and One free PCI Expansion Slot.
One AC-In plug connector and one power push button.
One push button reset switch.
One power LED, One HDD/CF access LED.
Storage Bay-
One Compact Flash Socket for Compact Flash modules or MicroDrives
One 2.5" PATA or SATA hard disk space
One Combo DVD/CD-RW device (Option)
Power requirement –
AC100~AC264/47Hz~63Hz, VAC Input,45VA maximum with AMD Sempron
3700+ CPU,1G DDR2 and 160GB 2.5” SATA HD.
Dimensions -
190.0mm (D) x 280.0mm (W) x 85.0mm (H)
