FabiaTech FX5654 User manual

Version 1.0 FX5654 User’s Quick Reference Page 1/4
www.fabiatech.com ©2017 FabiaTech Corporation
1. Brief
The FX 6 4 is a fanless, compact size embedded system with Intel® Celeron™ J1900 processor board
inside. This user’s quick reference provides the I/O outlets description and their pin assignment.
2. Dimensions (in mm) and Front Rear Panel Information
180
60(REF)
2 0
RESET
ANTENNA ANTENNA
POWER BUTTONHDD
USB
DC IN VGA
DC12~24V
-+
1
2
3
10101
4 6
7
8
ANTENNA LAN
USB
COM1 / 3 / / 7
COM2 / 4 / 6 / 8 EAR-PHONE
3. Packing List
A. Standard Items
1 FX 6 4 embedded system.
1 apartable terminal block (2-pin, pitch .08mm).
1 pack of fixed screws for 2. ” SATA hard disk and mini-card+mSATA (2+4 screws).
1 compact disc includes software utilities and manuals.
B. Optional Items
 Wall mounting kit (FX 01K1, P/N: 0606010009G-20, 2 pieces of metal with 4 fixed screws)
 Panel back mounting kit #1 (FX 04K1, P/N: 0606010012G, 1 piece of metal with 2 fixed
screws)
 Panel back mounting kit #2 (FX 407K3, 2 pieces of metal with 12 screws, P/N: 0606010038R)
 Rack mounting kit (FX 622K1, P/N: 0606010024G, 2 pieces of metal with 4 fixed screws)
 Half size mPCIe module adapter kit (AK1006, 1 piece of metal with 2 screws, P/N:
0606010028G)
4. Features
* Processor Board
Intel® Celeron™ J1900 (2.0GHz to turbo 2.42GHz, 4C/4T, 2MB Cache, 1333MHz FSB, 10 Watts)
low power processor with 4GB DDR3L RAM. (8GB DDR3L is maximum)
* I O Outlets
1 GbE port, 6 USB ports (1 V3.0), 4 RS-232, and 4 RS-232/422/48 serial ports.
1 VGA (Analog) and Line-out (Earphone).
1 TB for DC input power and 1 power button.
1 HDD/mSATA access LED and 2 LAN LEDs.
* Storage Bay
One 2. " SATA hard disk space and 1 mSATA socket.
1 mini PCIe socket and 1 SIM socket.
* Power requirement
+12 ~ +24V DC, 2. 6A maximum (1.23A typical) with 19V input voltage.
* Dimensions
180.0mm (D) x 2 0.0mm (W) x 60.0mm (H) without rubber stands and mounting kits.
5. I O outlets and LED Indicators
A. Power Connectors (DC +12 to +24V, 0W minimum)
DC12~24V
B. LAN LED Indicators (RJ45)
The LAN port is a RJ4 connector with 2 LEDs. The orange LED indicates data is accessing and
the green LED indicates on-line status.

Version 1.0 FX5654 User’s Quick Reference Page 2/4
www.fabiatech.com ©2017 FabiaTech Corporation
6. Software Configuration and Driver Installation
Please refer to the driver installing documentaion in the included Compact Disc for installing what
device driver you need. If you need to change the system settings or configurations of I/O ports, Please
refer to User's Manual (also in the included Compact Disc) for details.
7. Open the Bottom Cover for installing HDD, DRAM, and mini cards (WLAN+Antenna)
M3*P0.
M3*P0.
M2*P0.4
Release
screws as
upper
shown
Install 2. ” SATA HDD with HDD kit (2+2 screws), DDR3L Modules, and mSATA modules (2 screws)
After all installations done, close bottom cover and fasten screws
M2*P0.4
Install SIM, mini PCIe Module, and Antenna. (2 screws)
Half size mini PCIe
adapter (Optional)
Installing half-size mini
PCIe module if necessary.

Version 1.0 FX5654 User’s Quick Reference Page 3/4
www.fabiatech.com ©2017 FabiaTech Corporation
8. Installing Mounting Kit (Optional)
M3*P0.
Wall mounting kit and its
installation dimensions
264(REF)
278(REF)
68(REF)
90(REF)
37
47
10
8
140
FX 01K1 (optional)
M3*P0.
Panel back mounting kit #1
and its installation dimensions
118
7
100
12
18
100
7 (REF)
12.
7
8
3.7(REF)
7
71.2(REF)
66(REF)
FX 04K1 (optional)
VESA 7 /100 Standard

Version 1.0 FX5654 User’s Quick Reference Page 4/4
www.fabiatech.com ©2017 FabiaTech Corporation
End of Document
60
469
4
OTHER CHOICE
44
31.7
480
M3*P0.
Rack mounting kit and its installation dimensions
M4*P0.7
M3*P0.
123.2
12.
100
7
100
7 (REF)
12.
12.
7
0
0
122
.(REF)
12.
12.2
74.9(REF)
64(REF)
Panel back mounting kit #2
and its installation dimensions
VESA 0/7 /100 Standard
Step 1: 4 screws for panel
Step 2: 2 screws for FX 6 4x
Step 3: Combination (4 screws)
FX 622K1 (optional)
