FALCON RIDGE CF-UFORCE-SDK01 Installation manual

2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of CF Moto U Force
Soft Door Kit
CF-UFORCE-SDK01
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is
best done when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at room temperature
prior to installation.
1. Carefully open the carton and remove the enclosure on a large flat surface that is clean and free of dirt.
2. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
Soft Doors
“ “ ““18 each------------3"
“ “ ““2 each------------36"
Snap Screw Studs 15 each (1 extra)
If any parts are damaged or missing please contact customer service at [phone].
3. Begin by holding the door up to the frame and attach it using the double-sided Velcro strips sewn
perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive
Velcro strips and adhere it to the inside of the frame. Then wrap the double-sided strip around it so that
the adhesive strip holds it firmly in place. The following diagrams on the next page show how it should
look.

4. Next take the 50" adhesive Velcro strip and run it down the back of the roll cage facing towards the rear
of the vehicle. You will see two double-sided Velcro tabs sewn along the back of the doors. The
adhesive strip must be aligned so that both tabs can attach to it. See photo below.

5. Once all the Velcro is in place the last thing to do is install the screw snap studs. NOTE: The best way
to install the snap studs is to put them in the sockets in the door first. Then push them into the
plastic to make an indention. Then pull the screw stud out and screw it into the plastic where the
mark was made. See the following photos.
6.

Cleaning and Storage Recommendations:
1. Before removing the Cab for storage, make sure it is very clean in order to prevent scratching of the
window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water
solution. Never rub the windows with a dry cloth or rag! Let the Cab dry thoroughly before attempting
to roll for storage.
2. It is important that the Cab be rolled up for storage rather than folding. Folding will cause damage to
the windows!!! Carefully roll up the Cab similar to the way it was when it was packed at the factory.
On a large, clean and flat surface, fold the doors over the rear panel first, then, interleave the top and
windshield on top of the doors. Begin rolling the Cab into a roll approximately 8 inches in diameter.
Put the rolled Cab back into the carton for storage at a normal room temperature. It is best not to expose
the Cab to either extreme hot or cold temperatures when storing.
3. A special cleaner conditioner is available from Falcon Ridge that will greatly increase the service life of
the Cab Enclosure. In addition, if additional hook and loop sets are needed, they can also be ordered.
Thank you for your purchase!

Return Policy
If for any reason you choose to return this product it must be returned within 30 days from date item is
received. You MUST package the product exactly as it was originally packaged from the factory to get a
full refund for the product!
The vinyl windows should never be folded when packaging in the box or for storage purposes. Lay all the
windows on top of each other with the canvas folded in between and the paper (if available) on both sides of the
windows.
All returned products will be inspected upon arrival at the production facility and must be in unused,
factory new condition to receive refund - a 25% restocking fee will apply.
If ordered from Falcon Ridge please call at 606-845-7439 to gain a return authorization number, use our
preferred shipping carrier (UPS) to return the item (unless the item is defective, you are responsible for paying
the shipping to return the item.) Any returns submitted to Falcon Ridge without a return authorization
number will be charged a 20% restocking fee. If ordered from one of Falcon Ridge’s many distributors, you
must first call them and see what their return policy is. Once your item reaches our production facility, our
customer satisfaction team will inspect your item to ensure unused, factory new condition. NOTE: All
windshields must be returned with the original protective film intact and not removed. Do NOT
REMOVE if you have any intentions of returning the item. Refund/ replacement of a windshield will only
be processed on items with original protective film or if the windshield is defective.
Items must be properly packaged in the original shipping carton to protect them during transit and ensure your
returned item arrives back factory fresh, and in new resalable condition (any returned items that have been
used, altered or damaged in any way will not be subject for a refund.) All contents including instruction
manuals, accessories, hardware, Velcro, etc. must be included in your return shipment. Only items in OEM
factory new condition will be approved. Once returned items are received, credit will be issued to the original
credit card/ payment method used for the purchase. Outbound shipping and return shipping cost will not be
refunded. Please allow 4 to 6 weeks for your refund to be processed.
Warranty
To The Owner of this Product:
Thank you for purchasing one of our Falcon Ridge Cab Enclosures, Tops &/or Windshields! Below are the
terms under which your product is covered under our manufacturer’s warranty.
30 Day Warranty which includes and is not limited to replacing the enclosure, tops and/or windshield due to
defect of the product. Please refer to the return policy in this case for more information.
1 Year Warranty includes any defect in material or workmanship within this time frame we will gladly correct
the problem or replace the enclosure, tops &/or windshield. Upon submitting for the correction or replacement
we will need to receive pictures of the defect in material or workmanship along with the receipt from the date of
purchase.
