Family Fun Companies Reactor User manual

+
Family Fun Companies, INC.
Parts, Service and Distribution
708-598-3720
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
1
Table of Contents
1. Brief Description ......................................................................................................................... 2
2. Caution ........................................................................................................................................ 2
2-1.Notice for Installation ....................................................................................................... 2
2-2. Notice for Operation ........................................................................................................ 2
3. Accessories ................................................................................................................................... 3
4. How to Play ................................................................................................................................. 4
5. Technical Parameter ................................................................................................................... 4
6. Appearance .................................................................................................................................. 5
7. All Parts Description and Location ........................................................................................... 6
8. Mechanical Parts Illustration .................................................................................................... 9
9. Game Features and Adjustments ............................................................................................ 15
9-1. Meter Board .................................................................................................................... 15
9-2. Power Supply Input Panel ............................................................................................. 16
9-3.Coin Selector .................................................................................................................... 16
9-4. Ticket Dispenser ............................................................................................................. 17
10. PIN Connection on Main board ............................................................................................ 18
11. Function Setting Instruction Ver:007 ................................................................................. 21
12. Lamp Control Board Connection Table............................................................................... 24
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
2
1. Brief Description
"Reactor” (TW.JQ03.36) is a ticket machine for 1 to 3 players. The play area has 3
symmetrical play stations surrounding a rotating center column target. Each play station
can be equally access the rotating targets which are slots in various positions seen
vertically on the column. These slots represent ticket score values. There are 3 Jackpot
target slots which award the Jackpot ticket scores values. There are 3 Jackpot award
shown as well as advancing the 3 Jackpot award value to a higher level. The3 Jackpot
levels advance each time a player at any station wins towards playing for the
"Mega-Jackpot” award which is shown on a block display in each play station.
We are confident "Reactor” will be a fun, reliable, and long term income generating
machine for your location!
2. Caution
2-1.Notice for Installation
 This machine is only intended for indoor use.
 After installation, we recommend always lowering the four stabilizing levelers
down.
 Do not take apart, assemble or remove the machine at random while under power.
 Before moving or making any internal adjustments, switch the power off, and
disconnect the power cord.
 Locate the machine on a flat floor. Do not place it on any uneven, unsteady or
easily obstructed place.
 Avoid placing the machine in locations having very high temperatures.
2-2. Notice for Operation
 Inspect whether the power plug and power cord are in good condition before
switching the power on. Make sure that the voltage is suitable for the machine.
 The power supply voltage must be consistent with the specifications on the back
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
3
of the machine.
 Switch the power off before any maintenance or repair.
 Only qualified persons can examine and repair the electric control units.
 Only use authentic, authorized components to replace the old ones.
 When you pull out the power cord, hold the plug. Do not hold the line.
 Do not plug or unplug the plug with wet hands. Do not pull or twist the line cord
heavily.
3. Accessories
Check that the following accessories are supplied.
Name
Qty
Remark
Manual
1
Power cord
1
Key
6
3172(2pcs) 3157(2pcs) 1866(2pcs)
Coin Switch
1
CNR-05L-03-Z 5A/250VAC
The Bounce Pad
3
Each machine with three small pieces
Test Launch Board
1
JL-Reactor -JF1.PCB (Every 6 machines with a piece)
Test Receive Board
1
JL-Reactor -JF2.PCB (Every 6 machines with a piece)
Coin Selector
1
TW-130W (Every 18 machines with one)
Main Board
1
JL-MainBoard-V2012.PCB
Every 18 machines with a piece
Power Supply Cage
1
EPT-S150D12+5R Every 18 machines with one
1
EST-H200S24 Every 18 machines with one
Stepper Motor Driver
1
Leadshine DM432C Every 18 machines with one
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
4
4. How to Play
 Players insert coin(s) into the coin selector at the target column which passes
through the coin mechanism, players need to correctly grasp the time of the
release of the coin, the coin is deflected off the bounce pad and passes through
the target slot, On the target column (there are “JACKPOT” station and two cent
value station). An award of that target amount is dispensed to the player. if it is
the“JACKPOT” station ,the “JACKPOT ”will rise to the next level of award .
 Players win the "Mega-Jackpot” (or “Surprise Value”); they can obtain
corresponding “Mega-Jackpot” (“Surprise Value”) scores.
 Coins which do not pass through the column are directed through the base of the
column and into the coin box below.
 All 3 play stations can win at any time .Following the win of the “Mega-Jackpot”,
the Jackpot award level then returns to the bottom of the target column to start
over.
5. Technical Parameter
Model Number………………: TW.JQ03.36
Environment Requirement: Temperature from–10+40, low radiation, low humidity
and no serious vibration.
Dimension..........................…: W 1200 × D 1110 × H 2180 (mm) (Single machine)
Weight………………………: 215KG
Power Supply…………….: The power supply voltage must be consistent with the
specifications on the back of the machine.
Maximum Power……………: 150W No. of Players ………………: 1 to 3 players
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
5
6. Appearance
LED display
REA-E-1
Clear alarm
for no ticket
Ticket Exit
Speaker
REA-E-9
Coin selector
REA-E-4
Bounce pad
REA-E-3
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
6
7. All Parts Description and Location
Main Board
REA-E-13
Ticket Box
REA-E-10
Coin Box
REA-E-11
Ticket Dispenser
C-1-7
Speaker
REA-E-8
Stepper Motor Drive
REA-E-18
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
7
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
8
Lamp Control Board
REA-E-14
Power Amplifier
(Note：DC12V)
REA-E-15
Power Supply
REA-E-16 (12V + 5V)
REA-E-17 (24V)
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
9
8. Mechanical Parts Illustration
Transmission Mechanism
See Reactor Mechanism
Exploded View-2
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
10
Console Mechanism
See Reactor Mechanism
Exploded View-1
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
11
No.
NAME
QTY
REA-1-1
M3*10 Hexagon head screws
4
REA-1-2
the reactor console
1
REA-1-3
M4*6 Hexagon socket
headless screws
3
REA-1-4
The reactor console cover
1
REA-1-5
Rubber
1
REA-1-6
the reactor console stand
1
REA-1-7
Countersunk head screws
M3*10
3
REA-1-8
Lamp board（white
1
REA-1-9
The reactor board
1
REA-1-10
Adjustable plate
4
REA-1-11
M4*16Cross recessed
countersunk head screws
4
REA-1-12
Lamp board（colorful
1
REA-1-13
Countersunk head screws
M3*10
3
REA-1-14
FRP
1
REA-1-15
Coin slot Components a
1
REA-1-16
Coin slot Components c
1
REA-1-17
Coin slot Components b
1
REA-1-18
M4*16 Cross recessed pan
head screw with plastic nuts
2
REA-1-19
M5*12 Cross screws with
meson
2
REA-1-20
The main frame of Coin
Selector
1
REA-1-21
ST4*12 Truss Head Screws
2
REA-1-22
The main frame of Console
1
REA-1-23
FRP
1
REA-1-24
Coin Selector cover board
1
REA-1-25
Coin Selector
1
REA-1-26
Lock
1
REA-1-27
Round head machine screw
M4*20
1
Console Mechanism Exploded View 1
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
12
Lower Core Exploded View 2
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
13
No.
NAME
QTY
REA-2-1
Motor
1
REA-2-2
Motor plate
1
REA-2-3
Round head screws with The bounce pad M4*12
2
REA-2-4
Hexagon socket head cap screw M4*12
1
REA-2-5
Motor stand
1
REA-2-6
Spring fixed column
2
REA-2-7
Spring
1
REA-2-8
Motor connection screws
4
*REA-2-9-NS
Hexagon socket head cap screw M4*8 (part of 2-9A)
1
*REA-2-10-NS
Rotating shaft (part of 2-9A)
1
*REA-2-11-NS
Friction wheel (part of 2-9A)
1
*REA-2-12-NS
Friction wheel locking pieces (part of 2-9A)
1
*REA-2-13-NS
M4*12 Countersunk head screws (part of 2-9A)
2
REA-2-9A
Drive wheel assembly (9,10,11,12,13)
REA-2-14
Snap head machine screw and nuts with plastic M4*12
2
REA-2-15
Block Level
1
REA-2-16
Sensor
2
REA-2-17
Round head screws and nuts with plastic M3*16
4
REA-2-18
The main frame of turntable
1
REA-2-19
Winning Coin slot
3
REA-2-20
Round head screws with The bounce pad M4*12
6
REA-2-21
Turntable inner cover
1
REA-2-22
Countersunk head screws M4*12
3
REA-2-23
Bearing seat A
1
REA-2-24
Bearing
1
REA-2-25
Funnel
1
REA-2-26
Round head machine screw M4*10
1
REA-x-x-NS
Item is part of a complete assembly and not sold
separately.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
14
No.
NAME
QTY
REA-3-1
Inner hexagon Screws M4*10
3
REA-3-2
Turntable
1
REA-3-3
Decoration strips
6
REA-3-4
Bayonet locks
6
REA-3-5
Inner hexagon Screws M4*8
3
REA-3-6
photoelectric coded disk
1
REA-3-7
Blocked currency
1
REA-3-8
M4*8 Grub screw
1
REA-3-9
Bracket
1
REA-3-10
Test board fixture screws
3
REA-3-11
Test board fixture
1
REA-3-12
Round head machine screws
M4*12
3
REA-3-13
Turntable inner cover
1
REA-3-14
Bearing B
1
REA-3-15
Lamp stand
1
REA-3-16
Bearing
1
REA-3-17
M8*12Inner hexagon Screw
1
Upper Core Exploded View 3
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
15
9. Game Features and Adjustments
9-1. Meter Board
Function Setting Display: This is a LED display which shows the game function settings.
Total Coins: Counts the total number of coins since the machine has been used.
Total Tickets: Counts the total number of tickets dispensed since the machine has been
used.
Power: This is a switch that controls the power supply to the whole game.
Clear Alarm for No Ticket: Install tickets and press this button to replenish the owed
tickets when the tickets run out.
JP Clear: Press this button to clear the coin memory and all data stored.
Menu: Press this button to enter or exit from the menu.
Option: Press this button to enter the various Option settings.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
16
9-2. Power Supply Input Panel
Power Supply Jack: Input AC power according to the specified power of the machine.
(At top and bottom of the machine have two Power Supply Jack!)
Fuse: There is an AC fuse in the fuse tube. Its specification is φ 6mm × 30mm.
9-3.Coin Selector
Coin selector is the CPU Comparison Type Coin selector, coin smooth, more
accurate identification.
Coin release bar Press this button to make the coin out if the there is any coin jam.
Coin exit If it is a non-standardized coin, the coin will be paid back to this exit.
VR If the standardized coin is paid back, please adjust VR.
Rated voltage DC+12V±20% Working current 30mA CONUTER connect to the coin
counter GND to ground COIN Signal of coin insertion output.
Acceptable coin size φ18mm φ30mm in diameter 1.2mm 3.0mm in thickness.
Power
Supply
Jack
Fuse
Coin
entrance
Coin
Release bar
Coin exit
Sample coin placement
VR
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
17
Coin inserting time adjustment FAST 25mS FAST MIDDLE 50mS MEDIUM
SLOW 100mS SLOW three section of pulse. It has been faulted to MEDIUM.
Output current level adjustment NO or NC it has been faulted to NO.
9-4. Ticket Dispenser
Ticket entrance: To load tickets.
Fixed plate: To fix the ticket dispenser.
Tickets exit button: Press this button and the machine dispenses tickets automatically.
MOTER: Connect motor of ticket dispenser.
LED: Ticket indicator light
Sensor: To test tickets.
Tickets installation:
A. Put tickets into the ticket pivot, under the pressing wheel.
B. Press the micro switch, until one paper of ticket comes out.
C. Caution
- Tickets cannot overlap each other in the tickets pivot;
- Tickets should be placed according to the exit direction;
- Do not let the wires and tickets be in contact;
- When tickets blocked in the ticket dispenser, please get off it and clear the jam
manually.
Fixed
panel
Main body
LED1
LED2
Ticket
release
button
Ticket entrance
Ticket dispenser
PCB board
Ticket entrance
Sensor
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
18
10. PIN Connection on Main Board
V2010
Port
Code
Port
No.
Program
Items
I/O No.
Specification
Of Wiring
Wiring
Color
Function
JP1
1
IN1.0
IN#0
0.3mm
1#Coin In
2
IN1.1
IN#1
0.3mm
1#Coin signal
3
+12v
0.3mm
4
IN1.2
IN#2
0.3mm
1# Ticket Dispenser Feedback
5
+12v
0.3mm
Meter Power Supply
6
IN1.3
IN#3
0.3mm
1# Test Signal for No Ticket
7
+5v
8
IN1.4
IN#4
0.3mm
Menu (Enter / Save )
9
+5v
10
IN1.5
IN#5
0.3mm
Test Switch (Adjustment)
11
GND
0.3mm
Black
Grounding for Coin Selector and
Ticket Dispenser
12
IN1.6
IN#6
0.3mm
Clear Alarm for No Ticket Switch
13
GND
0.3mm
Black
Button Grounding
14
IN1.7
IN#7
0.3mm
JP Clear Switch
JP2
1
+12v
2
IN2.0
IN#8
0.3mm
2# Coin In
3
+12v
4
IN2.1
IN#9
0.3mm
2# Coin signal
5
+5v
6
IN2.2
IN#10
0.3mm
2# Ticket Dispenser Feedback
7
+5v
8
IN2.3
IN#11
0.3mm
Initialize signal
9
+5v
10
IN2.4
IN#12
0.3mm
Keep-step signal
11
GND
12
IN2.5
IN#13
2# Test signal for No Ticket
13
GND
Button Switch Grounding
14
IN2.6
IN#14
15
GND
16
IN2.7
IN#15
JP3
1
IN3.0
IN#16
0.3mm
3# Coin In
2
IN3.1
IN#17
0.3mm
3# Coin signal
3
IN3.2
IN#18
0.3mm
3# Ticket Dispenser Feedback
4
IN3.3
IN#19
0.3mm
3# Test signal for No Ticket
5
IN3.4
IN#20
0.3mm
6
IN3.5
IN#21
7
IN3.6
IN#22
8
IN3.7
IN#23
9
IN4.0
IN#24
1#Coin selector signal
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Reactor
19
10
IN4.1
IN#25
2# Coin selector signal
11
IN4.2
IN#26
3# Coin selector signal
12
IN4.3
IN#27
1# Coin selector Feedback signal
13
IN4.4
IN#28
2# Coin selector Feedback signal
14
IN4.5
IN#29
3# Coin selector Feedback signal
15
+5v
16
IN4.6
IN#30
17
GND
18
IN4.7
IN#31
JP4
1
CLK
P1.0
0.5mm
Digital LED Board Output:
Connection Turns:
1.4-Digit LED (Adjusting Display );
2.4-Digit LED 1# Awards number
3.4-Digit LED 2# Awards number
4.4-Digit LED 3# Awards number
2
DO
P1.1
0.5mm
3
CTL
P1.2
0.5mm
4
+12v
O
0.3mm
5
GND
O
0.3mm
6
+5v
O
0.3mm
JP5
1
CLK
P1.3
0.5mm
2
DO
P1.4
0.5mm
3
CTL
P1.5
0.5mm
4
+12v
O
0.3mm
5
GND
O
0.3mm
6
+5v
O
0.3mm
JP8
1
OUT1.0
OUT#0
0.3mm
1#Ticket drive
2
OUT1.1
OUT#1
0.3mm
Ticket Meter
3
OUT1.2
OUT#2
0.3mm
Coin Meter
4
OUT1.3
OUT#3
0.3mm
1# Coin-In Lamp
5
OUT1.4
OUT#4
0.3mm
1# Alarm Lamp for No Ticket
6
OUT1.5
OUT#5
0.3mm
1# Red light of coin reactor
board
7
OUT1.6
OUT#6
0.3mm
1#Green light of coin reactor
board
8
OUT1.7
OUT#7
0.3mm
1#Blue light of coin reactor
board
JP9
1
OUT2.0
OUT#8
0.3mm
2# Ticket drive
2
GND
3
OUT2.1
OUT#9
0.3mm
2# Coin-In Lamp
4
GND
5
OUT2.2
OUT#10
0.3mm
2# Alarm Lamp for No Ticket
6
+5v
7
OUT2.3
OUT#11
0.3mm
3# Ticket drive
8
+5v
9
OUT2.4
OUT#12
0.3mm
3# Coin-In Lamp
10
+12v
11
OUT2.5
OUT#13
0.3mm
3# Alarm Lamp for No Ticket
12
+12v
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200
